engine Ram 2500 2011 (Gas and Diesel) User Guide

JOBNAME: 288987 2011 Maint-Wa PAGE: 3 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
26,000 km or 12 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
12 Months or
26,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 4 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
26,000 km or 12 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 5 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
39,000 km or 18 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
18 Months or
39,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 6 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
39,000 km or 18 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 7 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
52,000 km or 24 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏Replace the engine air filter.
❏Inspect the transfer case fluid. (4x4)
❏Replace the spark plugs on 3.7L and 5.7L engines.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
24 Months or
52,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 8 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Adjust the parking brake on vehicles equipped with four-
wheel disc brakes.
❏Replace the engine air filter.
❏Inspect the transfer case fluid. (4x4)
❏Replace the spark plugs on 3.7L and 5.7L engines.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
52,000 km or 24 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 9 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
65,000 km or 30 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
30 Months or
65,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 10 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
65,000 km or 30 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 11 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
78,000 km or 36 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 78,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 156,000 kilometres.
Perform Maintenance
At
36 Months or
78,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 12 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is
located on the side of the engine. The spark plugs located under the coils are a
standard plug and must be change every 78,000 kilometres. The spark plugs
located on the side of the engine are a premium plug and must be changed
every 156,000 kilometres.
Perform Maintenance At
78,000 km or 36 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
