check engine Ram 2500 2011 (Gas and Diesel) Owner's Guide

JOBNAME: 288987 2011 Maint-Wa PAGE: 29 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
180,000 km or 90 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the brake linings; replace if necessary.
❏Inspect the parking brake; adjust if necessary.
❏Inspect the drive belt; replace as necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
90 Months or
180,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 30 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the brake linings; replace if necessary.
❏Inspect the parking brake; adjust if necessary.
❏Inspect the drive belt; replace as necessary.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
180,000 km or 90 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 31 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
192,000 km or 96 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Change the transfer case fluid.(4x4)
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the front wheel bearings.
❏Change the manual transmission fluid if using your vehicle for any of the following
police, fleet or frequent trailer towing.
❏Change the automatic transmission fluid and filter(s).
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
96 Months or
192,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 32 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Change the transfer case fluid.(4x4)
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the front wheel bearings.
❏Change the manual transmission fluid if using your vehicle
for any of the following police, fleet or frequent trailer
towing.
❏Change the automatic transmission fluid and filter(s).
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
192,000 km or 96 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 33 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
204,000 km or 102 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
102 Months or
204,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 34 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
204,000 km or 102 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 35 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
216,000 km or 108 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the brake linings; replace if necessary.
❏Inspect the parking brake; adjust if necessary.
❏Inspect the drive belt; replace as necessary.
❏Clean the EGR valve. (Ram Truck only)
❏Clean the EGR cooler. (Ram Truck only)
❏Replace the crankcase ventilation filter.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
108 Months or
216,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 36 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the brake linings; replace if necessary.
❏Inspect the parking brake; adjust if necessary.
❏Inspect the drive belt; replace as necessary.
❏Clean the EGR valve. (Ram Truck only)
❏Clean the EGR cooler. (Ram Truck only)
❏Replace the crankcase ventilation filter.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
216,000 km or 108 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 37 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
228,000 km or 114 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
114 Months or
228,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 38 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
228,000 km or 114 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
