Ram 2500 2014 Diesel Supplement

Air Suspension System
To aid in attaching/detaching the trailer from the vehicle,
the air suspension system can be used. Refer to “Air
Suspension System” in “Starting And Operating” for
further information.
NOTE:The vehicle must remain in the engine running
position while attaching a trailer for proper leveling of
the air suspension system.
DIESEL EXHAUST FLUID
Your vehicle is equipped with a Selective Catalytic Re-
duction system to meet the very stringent diesel emis-
sions standards required by the Environmental Protec-
tion Agency.
The purpose of the SCR system is to reduce levels of NOx
(oxides of nitrogen emitted from engines) that are harm-
ful to our health and the environment to a near-zero level.
Small quantities of Diesel Exhaust Fluid (DEF) is injectedinto the exhaust upstream of a catalyst where, when
vaporized, it converts smog-forming nitrogen oxides
(NOx) into harmless nitrogen (N2) and water vapor
(H2O), two natural components of the air we breathe.
You can operate with the comfort that your vehicle is
contributing to a cleaner, healthier world environment
for this and generations to come.
System Overview
This vehicle is equipped with a Diesel Exhaust Fluid
(DEF) injection system and a Selective Catalytic Reduc-
tion (SCR) catalyst to meet the emission requirements.
The DEF injection system consists of the following com-
ponents:
•DEF tank
•DEF pump
•DEF injector
4
STARTING AND OPERATING 279

•Electronically-heated DEF lines
•DEF control module
•NOx sensors
•NH3 sensor
•Temperature sensors
•SCR catalyst
The DEF injection system and SCR catalyst enable the
achievement of diesel emissions requirements; while
maintaining outstanding fuel economy, drivability,
torque and power ratings.
Refer to “Electronic Vehicle Information Center (EVIC)”
in “Understanding Your Instrument Panel” for system
messages and warnings.NOTE:
•Your vehicle is equipped with a DEF injection system.
You may occasionally hear an audible clicking noise.
This is normal operation.
•The DEF pump will run for a period of time after
engine shutdown to purge the DEF system. This is
normal operation.
280 STARTING AND OPERATING

WHAT TO DO IN EMERGENCIES
CONTENTS
JUMP STARTING......................282▫With Portable Starting Unit...............285
5

JUMP STARTING
WARNING!
•To prevent personal injury or damage to clothing,
do not allow battery fluid to contact eyes, skin or
fabrics. Do not lean over a battery when connecting
jumper cables or allow cable clamps to touch each
other. Keep open flames or sparks away from
battery vent holes. Always wear eye protection
when working with batteries.
•Do not use a booster battery or any other booster
source that has a greater than 12 Volt system, i.e., do
not use a 24 Volt power source.
NOTE:Replacement batteries should both be of equal
size to prevent damage to the vehicle’s charging system.
Your vehicle is equipped with two 12 Volt batteries. If it
becomes necessary to use a booster battery with jumpercables to start a vehicle’s engine because its batteries are
discharged, the following procedure should be used:
Set the parking brake and place an automatic transmis-
sion in PARK (or NEUTRAL for a manual transmission).
Turn off lights, heater and other electrical loads. Observe
charge indicator (if equipped) in both batteries. If the
indicator (if equipped) is light or yellow on either battery,
replace that battery.
CAUTION!
Use the jump start procedure only when the charge
indicator (if equipped) in both batteries is dark in the
center. Do not attempt jump starting when either
battery charge indicator (if equipped) is bright or
yellow. If the charge indicator (if equipped) has a
green dot in the center, failure to start is not due to a
discharged battery and cranking system should be
checked.
282 WHAT TO DO IN EMERGENCIES

1. Attach one jumper cable to the positive terminal of
booster battery and the other end of the same cable to
the positive terminal of the discharged battery.
WARNING!
Do not permit vehicles to touch each other as this
could establish a ground connection and personal
injury could result.
Jump Starting Location
1 — Discharged Battery
2 — Booster Battery
5
WHAT TO DO IN EMERGENCIES 283

2. Connect one end of the other jumper cable to negative
(-) post of booster battery. Connect the other end of the
jumper cable to a good ground on the engine block of
the vehicle with the discharged battery. Make sure a
good connection is made, free of dirt and grease.
WARNING!
•Do not connect the cable to the negative post of the
discharge battery. The resulting electrical spark
could cause the battery to explode.
•During cold weather when temperatures are below
freezing point, electrolyte in a discharged battery
may freeze. Do not attempt jump starting because
the battery could rupture or explode. The battery
temperature must be brought up above freezing
point before attempting to jump start.3. Take care that the clamps from one cable do not
inadvertently touch clamps from the other cable. Do
not lean over the battery when making connection.
The negative connection must provide good electrical
conductivity and current carrying capacity.
4. After the engine is started or if the engine fails to start,
cables must be disconnected in the following order:
•Disconnect the negative cable at the engine ground.
•Disconnect the negative cable at the negative post on
booster battery.
•Disconnect the cable from the positive post of both
batteries.
284 WHAT TO DO IN EMERGENCIES

WARNING!
Any procedure other than above could result in:
•Personal injury caused by electrolyte squirting out
the battery vent;
•Personal injury or property damage due to battery
explosion;
•Damage to charging system of booster vehicle or of
immobilized vehicle.
With Portable Starting Unit
There are many types of these units available. Follow the
manufacturer’s instructions for necessary precautions
and operation.
CAUTION!
It is very important that the starting unit operating
voltage does not exceed 12 Volts DC or damage to
battery, starter motor, alternator, or electrical system
may occur.
5
WHAT TO DO IN EMERGENCIES 285

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 6.7L DIESEL —
SIX-SPEED 68RFE (2500/3500 Models).......289
ENGINE COMPARTMENT — 6.7L DIESEL —
SIX-SPEED AS69RC HD (3500/CHASSIS CAB
MODELS)............................290
MAINTENANCE PROCEDURES...........291
▫Engine Oil..........................292
▫Engine Air Cleaner Filter................296
▫Draining Fuel/Water Separator Filter.......300
▫Engine Mounted Fuel Filter Replacement.....302
▫Underbody Mounted Fuel Filter Replacement. .304▫Priming If The Engine Has Run Out Of Fuel . .306
▫Intervention Regeneration Strategy — EVIC
Message Process Flow..................307
▫Diesel Exhaust Fluid...................308
▫Maintenance-Free Batteries..............309
▫Cooling System......................310
▫Charge Air Cooler — Inter-Cooler.........315
▫Brake System........................316
▫Clutch Hydraulic System................317
▫Transfer Case — If Equipped.............317
6

▫Manual Transmission — If Equipped........318
▫Automatic Transmission — If Equipped......318
▫Noise Control System Required Maintenance &
Warranty...........................322
FLUID CAPACITIES....................327FLUIDS, LUBRICANTS AND GENUINE
PARTS ..............................328
▫Engine.............................328
▫Chassis............................330
288 MAINTAINING YOUR VEHICLE
