Ram 2500 2017 Owner's Manual

Storage (Regular Cab)
The storage bin is located behind the front seats and runs
the length of the cab.
Storage and Seats (Crew Cab/Quad Cab)
The Crew Cab and Quad Cab models provide additional
storage under the rear seats. Lift the seats to access the
storage compartment.
To open the storage compartments, unsnap the securing
snap located at either side of the load floor and lift upward
on the fold flat lid.
NOTE:For more information on storage and the fold flat
floor, refer to “Fold Flat Load Floor” in this section.
Storage Bin
Crew Cab Storage
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199

Plastic Grocery Bag Retainers
(Regular Cab Models)
Retainer hooks which will hold plastic grocery bag handles
are built into the back panel of the cab, behind the rear seat.
REAR WINDOW FEATURES
Rear Window Defroster
The rear window defroster button is located on the
climate control panel. Push this button to turn on
the rear window defroster and the heated outside mirrors
(if equipped). An indicator in the button will illuminate
when the rear window defroster is on. The rear window
defroster automatically turns off after approximately
10 minutes. For an additional five minutes of operation,
push the button a second time.
Grocery Bag Hooks
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:To prevent excessive battery drain, use the rear
window defroster only when the engine is operating.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
• Use care when washing the inside of the rear win-
dow. Do not use abrasive window cleaners on the
interior surface of the window. Use a soft cloth and a
mild washing solution, wiping parallel to the heat-
ing elements. Labels can be peeled off after soaking
with warm water.
•
Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the window.
• Keep all objects a safe distance from the window.
Power Sliding Rear Window — If Equipped
The switch for the power sliding rear window is located on
the overhead console.
Push the switch to the right to open the glass. Pull the
switch to the left to close the glass.
Rear Window Switch
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201

Manual Sliding Rear Window — If Equipped
A locking device in the center of the window helps to
prevent entry from the rear of the vehicle. Squeeze the lock
to release the window.
FOLD FLAT LOAD FLOOR — IF EQUIPPED
Quad Cab and Crew Cab models with a 60/40 rear seat
may be equipped with a folding load floor.
WARNING!
Do not operate the vehicle with loose items stored on
the load floor. While driving or in an accident you may
experience abrupt stopping, rapid acceleration, or
sharp turns. Loose objects stored on the load floor may
move around with force and strike occupants, resulting
in serious or fatal injury.Unfolding The Load Floor/Quad Cab
1. Lift the 60/40 seat cushion(s) to the upward position.
Unfolding The Load Floor
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Grasp the knob on the load floor and lift the knob untilthe load floor unfolds into position.
3. Reverse the procedure to store the load floor. Unfolding The Load Floor/Crew Cab
1. Lift the 60/40 seat cushion(s) to the upward position.
Load Floor In Open PositionLoad Floor Legs In Stowed Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203

2. Unfold both the legs using the straps.3. Lift the front panel until the load floor unfolds into
position.
4. Reverse the procedure to store the load floor.
Load Floor Legs In Opened Position
Load Floor In Open Position
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Positioning The Load Floor For Storage Access Under
The Seat
1. Lift the 60/40 seat cushion(s) to the upward position.
2. Unsnap the securing snap located at either side of theload floor.
3. Lift the load floor up to access storage under the load floor.
WARNING!
Do not drive with the load floor in the up position.
When stopping fast or in an accident, the load floor
could move to the down position causing serious
injury. Quad Cab — If Equipped
Load Floor Securing Straps/Quad Cab
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205

Crew Cab — If Equipped
4. Reverse the procedure to put the load floor back in thesecured down position before you operate the vehicle.PICKUP BOX
The pickup box has many features designed for utility and
convenience.
Load Floor Securing Straps/Crew Cab
Pick Up Box Features
1 — Upper Load Floor Indents
2 — Bulk Head Dividers
3 — Cleats
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:If you are installing a Toolbox, Ladder Rack or
Headache Rack at the front of the Pickup Box, you must
use Mopar Box Reinforcement Brackets that are available
from your authorized dealer.
You can carry wide building materials (sheets of plywood,
etc.) by building a raised load floor. Place lumber across the
box in the indentations provided above the wheel housings
and in the bulkhead dividers to form the floor.
WARNING!
• The pickup box is intended for load carrying pur-
poses only, not for passengers, who should sit in
seats and use seat belts.
• Care should always be exercised when operating a
vehicle with unrestrained cargo. Vehicle speeds may
need to be reduced. Severe turns or rough roads may
cause shifting or bouncing of the cargo that may
result in vehicle damage. If wide building materials
are to be frequently carried, the installation of a
support is recommended. This will restrain the cargo
and transfer the load to the pickup box floor.
(Continued)
WARNING! (Continued)
•If you wish to carry more than 600 lbs (272 kg) of
material suspended above the wheelhouse, supports
must be installed to transfer the weight of the load to
the pickup box floor or vehicle damage may result.
The use of proper supports will permit loading up to
the rated payload.
• Unrestrained cargo may be thrown forward in an
accident causing serious or fatal injury.
There are stampings in the sheet metal on the inner side
bulkheads of the box in front of and behind both wheel
housings. Place wooden boards across the box from side to
side to create separate load compartments in the pickup
box.
There are four tie-down cleats bolted to the lower sides of
the pickup box that can sustain loads up to 1000 lbs
(450 kg) total.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207

Cargo Camera — If Equipped
Your vehicle may be equipped with the Cargo Camera that
allows you to see an image of the inside of the pickup box.
The image will be displayed in the Uconnect screen.
The Cargo Camera is located in the bottom center area of
the center high-mounted stoplamp (CHMSL).
A touchscreen button
to indicate the current active
camera image being displayed is made available when-
ever the Cargo Camera image is displayed.
Also, a touchscreen buttonto switch the display to
rear view camera image is made available whenever the
Cargo Camera image is displayed.
A touchscreen button Xto disable display of the camera
image is made available when the vehicle is not in RE-
VERSE gear.
A display timer is initiated when the Cargo Camera image
is displayed. The image will continue to be displayed until
the display timer exceeds 10 seconds and the vehicle speed
is above 8 mph (13 km/h) or the touchscreen button Xto
disable display of the Cargo Camera image is pressed. NOTE:
•
If the vehicle speed remains below 8 mph (13 km/h), the
Cargo Camera image will be displayed continuously
until the touchscreen button Xto disable display of the
Cargo Camera image is pressed.
• If snow, ice, mud, or any foreign substance builds up on
the camera lens, clean the lens, rinse with water, and dry
with a soft cloth. Do not cover the lens.
Turning Cargo Camera On Or Off — With Uconnect
8.4/8.4 NAV
1. Press the “Controls” button located on the bottom of the Uconnect display.
2. Press the “Cargo Camera” button
to turn the Cargo
Camera system on.
NOTE: Once initiated by the Cargo Camerabutton, the
Cargo Camera image may be deactivated by pressing the
X soft button. On deactivation, the previous selected
screen will appear.
