Ram 2500 2018 Quick Reference Guide

Manufacturer: RAM, Model Year: 2018, Model line: 2500, Model: Ram 2500 2018
Pages: 20, PDF Size: 0.98 MB

Load previous 10 pages

Page 11 of 20

Ram 2500 2018 Quick Reference Guide AUTOMATIC “SMART” EXHAUST BRAKE –
(DIESEL ONLY)
• Automatic Exhaust Brake technology deliv-ers smoother, less aggressive exhaust brak-
ing characteristics during downhill de-
scents. Although

AUTOMATIC “SMART” EXHAUST BRAKE –
(DIESEL ONLY)
• Automatic Exhaust Brake technology deliv-ers smoother, less aggressive exhaust brak-
ing characteristics during downhill de-
scents. Although it can apply full exhaust
braking force if needed, Automatic Exhaust
Brake may not apply obvious braking if the
vehicle speed is not increasing. Automatic
Exhaust Brake is intended to maintain ve-
hicle speed while Full Exhaust Brake is in-
tended to reduce vehicle speed.
•
Automatic Exhaust Brake can be enabled by
pushing the exhaust brake button again any
time after the normal Full Exhaust Brake has
been turned on. The “Exhaust Brake Indica-
tor” in the instrument cluster will change from
yellow to green when Automatic Exhaust
Brake is enabled. Pushing the exhaust brake
button again will toggle the exhaust brake
mode to off.
Adding Diesel Exhaust Fluid (DEF)
The DEF gauge (located in the instrument clus-
ter) will display the level of DEF remaining in the
tank.
Completely fill the DEF tank through the diesel
exhaust fluid fill location at every maintenance
interval, or before if prompted by the instru-
ment cluster display.
The DEF tank on these vehicles is designed with
a large amount of full reserve. So, the level sensor
will indicate a full reading even before the tank is
completely full. To put it another way, there’s
additional storage capacity in the tank above the
Full mark that’s not represented in the gauge. You
may not see any movement in the reading – even
after driving up to 2,000 miles in some cases.
NOTE:
• Driving conditions (altitude, vehicle speed, load, etc.) will effect the amount of DEF that
is used in your vehicle. •
Another factor is that outside temperature can
affect DEF consumption. In cold conditions,
12° F (-11° C) and below, the DEF gauge
needle can stay on a fixed position and may
not move for extended periods of time. This is
a normal function of the system.
• Since DEF will begin to freeze at 12°F
(-11°C), your vehicle is equipped with an
automatic DEF heating system. This allows
the DEF injection system to operate properly
at temperatures below 12°F (-11°C). If your
vehicle is not in operation for an extended
period of time with temperatures below 12°F
(-11°C), the DEF in the tank may freeze.
If the tank is overfilled and freezes, it could
be damaged. Therefore, do not overfill the
DEF tank. Extra care should be taken when
filling with portable containers to avoid over-
filling. Note the level of the DEF gauge in
your instrument cluster. On pickup applica-
tions, you may safely add a maximum of
2 gallons (7.5 liters) of DEF from portable
containers when your DEF gauge is reading
½ full. On Chassis Cab applications, a maxi-
mum of 2 gallons (7.5 liters) may be added
when the DEF gauge is reading ¾ full.

Page 12 of 20

Ram 2500 2018 Quick Reference Guide • There is an electric heater inside the DEFtank that automatically works when neces-
sary. And if the DEF supply does freeze, the
truck will operate normally until it thaws.
• Ensure the DEF cap

Page 13 of 20

Ram 2500 2018 Quick Reference Guide This feature allows an iPod or external USB
device to be plugged into the USB port. The
USB port supports certain iPod and iPhone
devices. The USB port also supports playing
music from external USB de

This feature allows an iPod or external USB
device to be plugged into the USB port. The
USB port supports certain iPod and iPhone
devices. The USB port also supports playing
music from external USB devices. Some iPod
software versions may not fully support the USB
port features. Please visit Apple’s website for
iPod software updates. Connect your iPod or
compatible device using a USB cable con-
nected to the USB port. USB memory sticks
with audio files can also be used. Then, audio
from the device can be played on the vehicle’s
sound system while providing the artist, track
title, and album information on the radio dis-
play (if available on device). When connected,
the iPod/USB device can be controlled using
the radio or steering wheel audio controls to
play, skip to the next or previous track, browse,
and list the contents.AUX/Audio Jack
The AUX/audio jack provides a means to con-
nect a portable audio device, such as an
MP3 player, to the vehicle’s sound system. This
requires the use of a 3.5 mm stereo audio patch
cable. AUX mode is entered by pushing the
Media button. Once in Media mode, select the
AUX button when the audio jack is connected.
Volume on the connected device may need to
be adjusted to optimize audio quality.
Access your Owner’s Information right through
your Uconnect 4C or 4C NAV touchscreen system
— If Equipped.
To access the Vehicle User Guide on your
Uconnect Touchscreen: Press the Uconnect
Appsbutton, then press the Vehicle User Guide
icon on your touchscreen. No Uconnect regis-
tration is required.
NOTE:
Vehicle User Guide features are not available
while the vehicle is moving. If you try to access
while the vehicle is in motion, the system will
display: Feature not available while the vehicle
is in motion.
Pre-Installed Features
Your User Guide —
Updated in real-time Available when and
where you need it
Touchscreen convenience Customizable interface
Maintenance schedules
and informationMultilingual
Comprehensive icon & symbol glossary
VEHICLE USER GUIDE

Page 14 of 20

Ram 2500 2018 Quick Reference Guide NOTE:
Uconnect screen images are for illustration
purposes only and may not reflect exact soft-
ware for your vehicle.
Activation
To use SiriusXM Guardian emergency, remote
and security services, you

Page 15 of 20

Ram 2500 2018 Quick Reference Guide • Press the “Location” button on the bottommenu bar of the app to bring up a map to
locate your vehicle or send a location to your
Uconnect Navigation, if equipped.
• Press the “Settings”

• Press the “Location” button on the bottommenu bar of the app to bring up a map to
locate your vehicle or send a location to your
Uconnect Navigation, if equipped.
• Press the “Settings” side menu in the upper left corner of the app to bring up app settings
and access the Assist Call Centers.
For further information:
• U.S. residents visit: siriusxm.com/guardian
• Canadian residents visit: siriusxm.com/ guardian/ca
Features
SiriusXM Guardian keeps you connected to your
vehicle. You have access to safety, remote and
security services. In-Vehicle Features
SiriusXM Guardian enhances your ownership
and driving experience by connecting your ve-
hicle to an operable network. When connected
to an operable network, you have access to:
• SOS Call: Connect to a live agent who con-
tact emergency services and stays on the
line with you until help arrives.
• Customer Care Assistance: Speak with a live agent when you press the ASSIST button on
your rearview mirror to get Roadside Assis-
tance or support.
Remote Services
SiriusXM Guardian helps you activate features
from a distance. The remote services are:
• Vehicle Finder helps you find where you parked your car.
• Send & Go allows you to send preset desti- nations to your navigation system for easy
access on the go. • Remote Door Lock/Unlock lets you unlock or
lock your doors from any distance.
• Remote Horn & Lights allows you to sounds your horn and flash your lights to easily find
your car.
• Receive monthly Vehicle Health Reports, and Alerts whenever a problem is detected
under the hood.
Security Services
The Uconnect Mobile App helps you activate
features from a distance. The remote services are:
• Receive text or email notifications if your vehicle's security alarm goes off.
• Receive stolen vehicle assistance, using GPS technology to help authorities locate
your vehicle if it is stolen.
SiriusXM Guardian remote services can be used
with the Uconnect app from virtually anywhere.
For further information on SiriusXM Guardian
or the Uconnect Mobile App, refer to your
Uconnect Owner’s Manual Supplement.
