oil filter Ram 3500 2011 Diesel Supplement

120,000 Miles (192,000 km) or 96 Months Maintenance Service Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be changed. If not prompted by the Engine Oil Indicator
System within 7,500 miles (12 000 km) or six months since the last oil and filter change, change the engine oil and engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Inspect drive belt, replace as required.
❏ Replace fuel filter element.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect the wheel bearings.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play;
replace if necessary.
❏ Inspect the front (4x4) and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
❏ Change automatic transmission fluid and sump filter (Chassis Cab Only).
❏ Change automatic transmission fluid and filter(s) (Ram Truck Only).
❏ Change the manual transmission fluid if using your vehicle for any of the following: police, fleet, or frequent trailer towing.
❏ Change the transfer case fluid (4x4).
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
154 MAINTENANCE SCHEDULES

127,500 Miles (204,000 km) or 102 Months Maintenance Service
Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be
changed. If not prompted by the Engine Oil Indicator System within 7,500 miles
(12 000 km) or six months since the last oil and filter change, change the engine oil and
engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
7
MAINTENANCE SCHEDULES 155

135,000 Miles (216,000 km) or 108 Months Maintenance Service Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be changed. If not prompted by the Engine Oil Indicator
System within 7,500 miles (12 000 km) or six months since the last oil and filter change, change the engine oil and engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Inspect drive belt, replace as required.
❏ Replace fuel filter element.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play;
replace if necessary.
❏ Inspect brake linings.
❏ Inspect and adjust parking brake if necessary.
❏ Inspect the front (4x4) and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
❏ Replace Crankcase Ventilation Filter (CCV).
❏ Clean EGR Valve (Ram Truck Only).
❏ Clean EGR Cooler (Ram Truck Only).
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
156 MAINTENANCE SCHEDULES

142,500 Miles (228,000 km) or 114 Months Maintenance Service
Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be
changed. If not prompted by the Engine Oil Indicator System within 7,500 miles
(12 000 km) or six months since the last oil and filter change, change the engine oil and
engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
7
MAINTENANCE SCHEDULES 157

150,000 Miles (240,000 km) or 120 Months Maintenance Service Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be changed. If not prompted by the Engine Oil Indicator
System within 7,500 miles (12 000 km) or six months since the last oil and filter change, change the engine oil and engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Replace fuel filter element.
❏ Inspect drive belt, replace as required.
❏ Adjust valve lash clearance.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect the wheel bearings.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play;
replace if necessary.
❏ Flush and replace engine coolant at 120 months, if not replaced at 97,500 miles (157 000 km).
❏ Inspect the front (4x4) and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
❏ Check the transfer case fluid (4x4).
❏ Change automatic transmission fluid (Chassis Cab Only).
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
158 MAINTENANCE SCHEDULES

Adding Fuel............................ 83
Air Cleaner, Engine (Engine Air Cleaner
Filter) ............................. 102,126
Air Filter .............................. 102
Airbag Light ............................ 19
Antifreeze (Engine Coolant) .............. 114,115
Capacities ........................... 130
Disposal ............................ 117
Anti-Lock Warning Light ................... 19
Automatic Transmission .................... 68
Adding Fluid ......................... 122
Fluid Level Check ..................... 122
Fluid Type ........................ 122,133
Shifting .............................. 62
Axle Fluid ............................. 133
Battery ............................... 112
Blanket ........................... 51,113
Emergency Starting ..................... 90 Brake Fluid
............................ 133
Brake System ........................... 119
Fluid Check .......................... 119
Master Cylinder ....................... 119
Warning Light ......................... 14
Brake/Transmission Interlock ................ 61
Calibration, Compass ...................... 33
Capacities, Antifreeze (Engine Coolant) ........ 130
Capacities, Fluid ........................ 130
Caps, Filler Oil (Engine) .......................... 100
Radiator (Coolant Pressure) ............... 116
Charge Air Cooler ....................... 119
Check Engine Light (Malfunction Indicator
Light) ................................. 18
Compass .............................. 32
Compass Calibration ...................... 33
Compass Variance ........................ 33
162 INDEX

Computer, Trip/Travel..................... 30
Conserving Fuel ......................... 30
Coolant Pressure Cap (Radiator Cap) .......... 116
Cooling System ......................... 113
Adding Coolant (Antifreeze) .............. 115
Coolant Capacity ...................... 130
Coolant Level ...................... 1 13,117
Disposal of Used Coolant ................ 117
Drain, Flush, and Refill .................. 114
Inspection ........................... 117
Points to Remember .................... 118
Pressure Cap ......................... 116
Radiator Cap ......................... 116
Selection of Coolant (Antifreeze) ......... 114,131
Diesel Exhaust Brake ...................... 58
Diesel Fuel ............................. 81
Diesel Fuel Requirements ................... 81
Bulk Storage of ........................ 84 Diesel Fuel System, Re-Priming
.............. 108
Dipsticks .............................. 98
Disposal .............................. 102
Antifreeze (Engine Coolant) ............... 117
Engine Oil ........................... 102
Draining Fuel/Water Separator Filter .......... 104
Electronic Range Select (ERS) ..............62,68
Electronic Vehicle Information Center (EVIC) ..... 21
Emergency, In Case of Jump Starting ......................... 90
Engine ................................ 97
Air Cleaner .......................... 102
Block Heater ........................ 44,57
Break-In Recommendations ................. 6
Compartment ......................... 97
Coolant (Antifreeze) .................... 131
Identification .......................... 97
Idling ............................... 52
8
INDEX 163

Jump Starting......................... 90
Oil .............................. 98,131
Oil Filler Cap ......................... 100
Oil Synthetic ......................... 102
Runaway ............................. 81
Temperature Gauge ..................... 11
Exhaust Brake ........................... 58
Exhaust System ......................... 126
Filters Engine Fuel .......................... 104
Engine Oil ...................... 98,102,131
Flashers Turn Signal ........................... 11
Fluid, Brake ........................... 133
Fluid Capacities ......................... 130
Fluid Level Checks Brake ............................... 119
Manual Transmission ................... 121 Transfer Case
......................... 121
Fluids, Lubricants and Genuine Parts .......... 131
Fog Lights ............................. 19
Fuel ................................ 81,83
Adding .............................. 83
Conserving ........................... 30
Diesel .......................... 81,83,131
Filter ............................... 104
Gauge ............................... 11
Requirements .......................... 81
Saver Mode ........................... 30
Specifications .......................... 82
Tank Capacity ........................ 130
Gasoline (Fuel) Conserving ........................... 30
Gauges Coolant Temperature .................... 11
Fuel ................................ 11
164 INDEX

ModeFuel Saver ............................ 30
New Vehicle Break-In Period ................. 6
Noise Control Maintenance ......................... 126
Tampering Prohibited ................... 126
Noise Emission Warranty ...............125,127
Odometer .............................. 13
Trip ................................ 13
Oil Change Indicator ................... 27,137
Oil Change Indicator, Reset ................. 27
Oil, Engine ............................ 131
Capacity ............................ 130
Change Interval ........................ 99
Dipstick ............................. 98
Disposal ............................ 102
Filter .......................... 98,102,131Identification Logo
..................... 100
Materials Added to ..................... 102
Pressure Gauge ........................ 13
Recommendation ...................... 100
Synthetic ............................ 102
Viscosity ............................ 100
Overdrive ............................ 65,71
Overdrive OFF Switch ................... 65,71
Perform Service Indicator, Reset ............. 138
Personal Settings ......................... 34
Power Take-Off Adapter ....................... 78
Take-Off Operation ...................... 78
Power Steering Fluid ..................... 133
Programmable Electronic Features ............. 34
PTO (Power Take-Off) ..................... 78
Radiator Cap (Coolant Pressure Cap) ....... 114,116
166 INDEX
