STORAGE ........................... .239
▫ Glove Compartment ...................239
▫ Door Storage ........................ .241
▫ Center Storage Compartment — If Equipped . .242
▫ Second Row In-Floor Storage Bin — If
Equipped .......................... .245
▫ Seatback Storage ..................... .246
▫ Storage (Regular Cab) ..................246
▫ Storage and Seats (Crew Cab) .............247
▫ Plastic Grocery Bag Retainers (Regular Cab
Models) ........................... .247
 REAR WINDOW FEATURES ..............248
▫ Rear Window Defroster .................248
▫ Power Sliding Rear Window — If Equipped . .249 ▫
Manual Sliding Rear Window — If Equipped .249
 FOLD FLAT LOAD FLOOR — IF EQUIPPED . .249
 PICKUP BOX ........................ .254
▫ Cargo Camera — If Equipped ............256
▫ Turning Cargo Camera On Or Off — With
Uconnect 8.4A/8.4AN ..................257
 RAMBOX — IF EQUIPPED ...............257
▫ RamBox Integrated Box Side Storage Bins . . . .257
▫ Locking And Unlocking RamBox ...........260
▫ RamBox Safety Warning .................261
▫ Bed Extender — If Equipped .............262
▫ Bed Rail Tie-Down System ..............269
 SLIDE-IN CAMPERS ....................271
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Remove the connector bracket from the sill by pushinginward in the locking tab. 3. Disconnect the chassis wiring harness, ensuring the
connector bracket does not fall into the sill.
4. Connect the chassis plug and bracket (provided in the glove box) to the chassis wiring harness and insert the
bracket back into the sill.
Connector BracketLocking Tab
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

5. Connect the tailgate plug (provided in the glove box)to the tailgate wiring harness to ensure that the
terminals do not corrode.
6. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will pre-
vent damaging the connector and bracket when stor-
ing or reinstalling the tailgate.
Removing The Tailgate
1. Disconnect the wiring harness for the rear camera andor power locks (if equipped), refer to “Disconnecting
the Rear Camera — If Equipped” in this section.
2. Unlatch the tailgate and remove the support cables by releasing the lock tang from the pivot.
NOTE: Make sure tailgate is supported when removing
support cables. 3. Position the tailgate on a 45 degree angle.
4. Raise the right side of the tailgate until the right side
pivot clears the hanger bracket.
5. Slide the entire tailgate to the right to free the left side pivot.
Locking Tang
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273
