windshield wipers Ram 3500 2016 Owner's Manual

▫Lights-On Reminder ...................177
▫ Battery Saver ........................ .177
▫ Interior Lights ...................... .177
▫ Cargo Light With Bed Lights — If Equipped . .180
▫ Multifunction Lever ...................181
▫ Turn Signals ........................ .181
▫ Lane Change Assist ...................182
▫ Flash-To-Pass ....................... .182
▫ High/Low Beam Switch ................182
 WINDSHIELD WIPERS AND WASHERS ......182
▫ Windshield Wipers ....................182
▫ Windshield Wiper Operation .............183
▫ Intermittent Wiper System ...............183 ▫
Windshield Washers ...................183
▫ Mist Feature ........................ .184
▫ Rain Sensing Wipers — If Equipped ........185
 TILT STEERING COLUMN ...............186
 HEATED STEERING WHEEL — IF EQUIPPED .187
 DRIVER ADJUSTABLE PEDALS — IF
EQUIPPED .......................... .189
 ELECTRONIC SPEED CONTROL ...........190
▫ To Activate ......................... .191
▫ To Set A Desired Speed .................192
▫ To Deactivate ....................... .192
▫ To Resume Speed .....................192
▫ To Vary The Speed Setting ...............192
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125

Lane Change Assist
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash
three times then automatically turn off.
Flash-To-Pass
You can signal another vehicle with your headlights by
partially pulling the multifunction lever toward the steer-
ing wheel. This will cause the high beam headlights to
turn on until the lever is released.
High/Low Beam Switch
Push the multifunction lever toward the instrument
panel to switch the headlights to high beam. Pulling the
multifunction lever back toward the steering wheel will
turn the low beams back on, or shut the high beams off.WINDSHIELD WIPERS AND WASHERS
Windshield Wipers
The wipers and washers are operated by a switch in the
multifunction lever. Turn the end of the handle to select
the desired wiper speed.
High/Low Beam Switch
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

If the washer knob is depressed while in the delay range,
the wiper will operate for several seconds after the
washer knob is released. It will then resume the intermit-
tent interval previously selected. If the washer knob is
pushed while in the off position, the wiper will turn on
and cycle approximately three times after the wash knob
is released.
To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
WARNING!
Sudden loss of visibility through the windshield
could lead to a collision. You might not see other
vehicles or other obstacles. To avoid sudden icing of
(Continued)
WARNING!(Continued)
the windshield during freezing weather, warm the
windshield with the defroster before and during
windshield washer use.
Mist Feature
When a single wipe to clear off road mist or spray from
a passing vehicle is needed, push the washer knob,
located on the end of the multifunction lever, inward to
the first detent and release. The wipers will cycle one
time and automatically shut off.
NOTE:The mist feature does not activate the washer
pump; therefore, no washer fluid will be sprayed on the
windshield. The wash function must be used in order to
spray the windshield with washer fluid.
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rain Sensing Wipers — If Equipped
This feature senses moisture on the windshield and
automatically activates the wipers for the driver. The
feature is especially useful for road splash or overspray
from the windshield washers of the vehicle ahead. Rotate
the end of the multifunction lever to one of five settings
to activate this feature.
NOTE:If your vehicle is equipped with a touchscreen,
this feature can be programmed through the Uconnect
system. Refer to “Uconnect Settings” in “Understanding
Your Instrument Panel” for further information.
If your vehicle is not equipped with a touchscreen, this
feature can be programmed through the Electronic Ve-
hicle Information Center (EVIC) or Driver Information
Display (DID). Refer to “Electronic Vehicle Information
Center (EVIC)” or “Driver Information Display (DID)” in
“Understanding Your Instrument Panel” for further in-
formation. The sensitivity of the system can be adjusted with the
multifunction lever. Wiper delay position 1 is the least
sensitive, and wiper delay position 5 is the most sensi-
tive. Setting 3 should be used for normal rain conditions.
Settings 1 and 2 can be used if the driver desires less
wiper sensitivity. Setting 4 and 5 can be used if the driver
desires more sensitivity. Place the wiper switch in the
OFF position when not using the system.
NOTE:
•
The Rain Sensing feature will not operate when the
wiper switch is in the low or high-speed position.
• The Rain Sensing feature may not function properly
when ice, or dried salt water is present on the wind-
shield.
• Use of Rain-X or products containing wax or silicone
may reduce Rain Sensing performance.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185

or the ignition is switched to the OFF position. To set the
ParkView Backup Camera Delay push the SETTINGS
button on the faceplate, then the “Safety & Driving
Assistance” button on the touchscreen. Press the
“Parkview Backup camera Delay” button on the touch-
screen to turn the ParkView Delay ON or OFF.
•Rain Sensing Auto Wipers — If Equipped
When this feature is selected, the system will automati-
cally activate the windshield wipers if it senses moisture
on the windshield. To make your selection, press the
“Rain Sensing” button on the touchscreen and make your
selection.
• Hill Start Assist — If Equipped
When this feature is selected, the Hill Start Assist (HSA)
system is active. Refer to “Electronic Brake Control
System” in “Starting And Operating” for system function and operating information. To make your selection, press
the “Hill Start Assist” button on the touchscreen and
make your selection.
Lights
After pressing the “Lights” button on the touchscreen,
the following settings will be available:
•
Headlight Off Delay
When this feature is selected, it allows the adjustment of
the amount of time the headlights remain on after the
engine is shut off. To change the Headlight Off Delay
setting, press the “Headlight Off Delay” button on the
touchscreen and choose either “0,” “30,” “60,” or “90”
buttons on the touchscreen to select your desired time
interval.
• Headlight Illumination On Approach
When this feature is selected, it allows the adjustment of
the amount of time the headlights remain on when the4
UNDERSTANDING YOUR INSTRUMENT PANEL 385

•ParkView Backup Camera Delay
When this feature is enabled, it will allow the ParkView
Backup Camera display to remain on while in drive for
up to 10 seconds, or 8 mph. To make your selection, press
the “ParkView Backup Camera Delay” button on the
touchscreen to select from on or off.
• Rain Sensing Auto Wipers — If Equipped
When this feature is selected, the system will automati-
cally activate the windshield wipers if it senses moisture
on the windshield. To make your selection, press the
“Rain Sensing” button on the touchscreen to select from
on or off.
• Hill Start Assist — If Equipped
When this feature is selected, the Hill Start Assist (HSA)
system is active. Refer to “Electronic Brake Control
System” in “Starting And Operating” for system function and operating information. To make your selection, press
the “Hill Start Assist” button on the touchscreen to select
from on or off.
•
Two Or Four Corner Air Suspension Modes — If
Equipped
There are four air suspension modes designed to protect
the system in unique situations. Tire Jack Mode is se-
lected to assist in changing a spare tire. Transport Mode
is selected to assist when the vehicle is being flat bed
towed. Wheel Alignment Mode is selected before per-
forming a wheel alignment, refer to your authorized
dealer for information. Protection Mode will automati-
cally be selected to “protect” the air suspension system
when the payload has been exceeded or load leveling
cannot be achieved.
404 UNDERSTANDING YOUR INSTRUMENT PANEL

Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild nonabrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
NOTE:Life expectancy of wiper blades varies depend-
ing on geographical area and frequency of use. Poor
performance of blades may be present with chattering,
marks, water lines or wet spots. If any of these conditions
are present, clean the wiper blades or replace as neces-
sary. The wiper blades and wiper arms should be inspected
periodically, not just when wiper performance problems
are experienced. This inspection should include the fol-
lowing points:
•
Wear Or Uneven Edges
• Foreign Material
• Hardening Or Cracking
• Deformation Or Fatigue
If a wiper blade or wiper arm is damaged, replace the
affected wiper arm or blade with a new unit. Do not
attempt to repair a wiper arm or blade that is damaged.
812 MAINTAINING YOUR VEHICLE

4. Gently lower the wiper arm onto the glass.
Installing The Front Wipers
1. Lift the wiper arm off of the glass, until the wiper armis in the full up position.
2. Position the wiper blade near the hook on the tip of the wiper arm.
3. Insert the hook on the tip of the arm through the opening in the wiper blade.
4. Slide the wiper blade up into the hook on the wiper arm, latch engagement will be accompanied by an
audible click.
5. Gently lower the wiper blade onto the glass.
Adding Washer Fluid
The fluid reservoir is located under the hood and should
be checked for fluid level at regular intervals. Fill the reservoir with windshield washer solvent only (not ra-
diator antifreeze). When refilling the washer fluid reser-
voir, take some washer fluid and apply it to a cloth or
towel and wipe the wiper blades clean. This will help
blade performance.
To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
After the engine has warmed up, operate the defroster for
a few minutes to reduce the possibility of smearing or
7
MAINTAINING YOUR VEHICLE 815

CleaningWheels .............................. .836
Climate Control ...................... .420, 431
Automatic ........................... .431
Cold Weather Operation ....................480
Compact Disc (CD) Maintenance ..............418
Compact Spare Tire ....................... .655
Console, Overhead ....................... .215
Contract, Service ......................... .888
Coolant Pressure Cap (Radiator Cap) ...........821
Cooling System .......................... .818
Adding Coolant (Antifreeze) ...............820
Coolant Capacity ...................... .864
Coolant Level ...................818, 822, 824
Disposal Of Used Coolant .................822
Drain, Flush, And Refill ...................819
Inspection ........................ .822, 824
Points To Remember .....................824
Pressure Cap ......................... .821Radiator Cap
......................... .821
Selection Of Coolant (Antifreeze) ......819, 864, 866
Corrosion Protection ...................... .833
Cruise Light ......................... .327, 329
Cupholders ............................ .237
Customer Assistance ...................... .885
Customer Programmable Features .............396
Data Recorder, Event .......................84
Daytime Running Lights ....................173
Dealer Service ........................... .797
Defroster, Rear Window .....................248
Defroster, Windshield ...................120, 424
Delay (Intermittent) Wipers ..................183
Differential, Limited-Slip ....................589
Dipsticks Power Steering ........................ .615
Disabled Vehicle Towing ....................782
10
INDEX 899

Utility Rails, Rear Cargo Area................269
Vehicle Identification Number (VIN) .............6
Vehicle Loading ...................... .644, 687
Vehicle Modifications/Alterations ...............7
Vehicle Storage ....................... .441, 851
Viscosity, Engine Oil ....................800, 801
Voice Recognition System (VR) ................444
Warnings And Cautions ......................6
Warranty Information ..................... .889
Washers, Windshield ....................183, 815
Washing Vehicle ......................... .834
Water Driving Through ....................... .591
Wheel And Wheel Trim .....................836
Wheel And Wheel Trim Care .................836
Wheel Cover ........................... .769
Winch ................................ .594Accessories
........................... .598
Operation ............................ .599
Rigging Techniques ......................611
Usage .............................. .594
Wind Buffeting ....................... .51, 229
Window Fogging ........................ .442
Windows ................................48
Power ................................48
Rear Sliding .......................... .249
Reset Auto-Up ..........................50
Wind Buffeting ..........................51
Windshield Defroster ...................... .120
Windshield Washers .................182, 183, 815
Fluid ............................ .182, 815
Windshield Wiper Blades ....................812
Windshield Wipers ....................... .182
Wiper Blade Replacement ...................812
Wipers, Intermittent ...................... .183
Wipers, Rain Sensitive ..................... .185
10
INDEX 915
