Ram 3500 2019 Owner's Manual

IN CASE OF EMERGENCY 459
F0640 Amp Green –ABS Pump Motor (DS 1500 Only)
F07 40 Amp Green –Starter Solenoid
F08 20 Amp Blue (DS 1500
LD/Cummins Diesel) 40 Amp Green –
–
NOX Sensor – If Equipped
Aux Relay Output- SSV Only
F09 40 Amp Green (SSV &
Cummins Diesel) –Aux Relay Output / Diesel Fuel Heater – If
Equipped
F09 30 Amp Pink –Brake Vacuum Pump – If Equipped (HD Only)
F10 40 Amp Green –Body Controller / Exterior Lighting #2
F11 30 Amp Pink –PWR - Trailer Tow Electric Brake Batt Feed – If
Equipped (DS 1500 Only)
F11 40 Amp Green –Brake System Module (ECU and Valves) (HD
Only)
F12 40 Amp Green –Body Controller #3
F13 40 Amp Green –Blower Motor
F14 40 Amp Green –Body Controller #4 / Exterior Lighting
F15 30 Amp Pink
40 Amp Green –
–Power Side Steps – If Equipped (HD Only)
Extra Fuse - SSV Only
F16 30 Amp Pink –Smart-Bar Module – If Equipped (HD Only)
F17 30 Amp Pink –Winch Control Module – If Equipped (HD Only)
Cavity
Cartridge Fuse Micro Fuse Description
6

460 IN CASE OF EMERGENCY
F1920 Amp Blue (DS 1500
LD Diesel)
30 Amp Pink
(Cummins Diesel) –
SCR – If Equipped
F20 30 Amp Pink –Passenger Door Module
F21 30 Amp Pink –Drive Train Control Module
F22 20 Amp Blue –Engine Control Module GPEC / Heavy Duty /
Other – If Equipped
F22 25 Amp White
(Cummins Diesel) –
PCM – If Equipped
F23 30 Amp Pink –CBC Feed # 1
F24 30 Amp Pink –Driver Door Module
F25 30 Amp Pink –Front Wiper

F26 30 Amp Pink –Antilock Brakes / Stability Control Module /
Valves – If Equipped (DS 1500 Only)
F28 20 Amp Blue –Trailer Tow Backup Lights – If Equipped
F29 20 Amp Blue –Trailer Tow Parking Lights – If Equipped
F30 30 Amp Pink –Trailer Tow Receptacle / Trailer Tow (Separate
E-Brake)/Trailer Tow (BUX)
Cavity
Cartridge Fuse Micro Fuse Description

IN CASE OF EMERGENCY 461
F3130 Amp Pink –Diesel Heater Control – If Equipped (DS 1500
LD Diesel)
F31 20 Amp Blue –Aux App SSV Only - If Equipped
F32 ––Aux Feed, Special Services Vehicle-If Equipped
(DS 1500 Only)
F33 20 Amp Blue –Trans Control Module – If Equipped (HD Only)
Aux Feed, SSV Only (DS 1500 Only)
F34 30 Amp Pink –Vehicle System Interface Module #2 – If
Equipped (HD Only)
SSV (DS 1500 Only)
F35 30 Amp Pink –Sunroof – If Equipped
F36 30 Amp Pink –
Electric Back Light – If Equipped
F37 30 Amp Pink –Fuel Heater #2, Aux Relay 2 – If Equipped (HD
Only)
SSV (DS 1500 Only)
F38 30 Amp Pink –Integrated Trailer Brake Module – If Equipped
(HD Only)
Power Inverter 115V AC – If Equipped (DS 1500
Only)
F39 20 Amp Blue –Power Outlet – SSV Only
F40 –10 Amp Red Ventilated Seats – If Equipped (HD Only)
Cavity
Cartridge Fuse Micro Fuse Description
6

462 IN CASE OF EMERGENCY
F41–10 Amp Red Active Grille Shutter / Active Air Dam – If
Equipped
F42 –20 Amp Yellow Horn
F43 –15 Amp Blue Heated Steering Wheel – If Equipped (HD Only)
F44 –10 Amp Red Diagnostic Port
F46 –10 Amp Red Upfitters Relay Coil – If Equipped (HD Only)
Spare (DS 1500 Only)
F49 –10 Amp Red Instrument Panel Cluster / HVAC (DS 1500
Only)
Instrument Cluster / MOD CSG (HD Only)
F50
– 20 Amp Yellow Air Suspension Control Module – If Equipped
F51 –10 Amp Red Ignition Node Module / Keyless Ignition Node
Module, Radio Frequency Hub Module /
Electric Steering Column Lock - If Equipped
F52 –5 Amp Tan Battery Sensor
F53 –20 Amp Yellow Trailer Tow – Left Turn/Stop Lights - If
Equipped
F54 –20 Amp Yellow Non Memory Adjustable Pedals - If Equipped
F56 –15 Amp Blue Additional Diesel Content - If Equipped (DS
1500 Only)
Cavity
Cartridge Fuse Micro Fuse Description

IN CASE OF EMERGENCY 463
F57–20 Amp Yellow TCM/PCM / Solenoid Trans Pressure SW (RFE
Trans Only) – If Equipped (HD Only)
Transmission (DS 1500 Only)
F58 –10 Amp Red Bed Lighting (LED) – If Equipped (HD Only)
F60 –15 Amp Blue Underhood Lamp / TCM – If Equipped (DS
1500 Only)
F61 –10 Amp Red UREA Sensor / PM Sensor – If Equipped (DS
1500 LD Diesel & Cummins Diesel)
F62 –10 Amp Red Air Conditioning Clutch
F63 –20 Amp Yellow Ignition Coils (Gas), Ignition Coils Capacitors
(Gas) / Short Runner Valve Actuator / Urea
Heater Control Unit (DS 1500 LD Diesel) / RLY
Coil Feed-SCR (DS 1500 LD Diesel)
F64 –25 Amp Clear Fuel Injectors / Powertrain Control Module /
SRV – If Equipped
F65 –10 Amp Red MOD Inverter (Wake Up) / Power Port / USB
IP / WCPM – If Equipped (HD Only)
Spare (DS 1500 Only)
F66 –10 Amp Red Sunroof / Light and Rain Sensor Module /
Inside Rearview Mirror / Passenger Window
SW / USB Port Rear / Feed for R/A RLY #2
Coil – If Equipped
Cavity
Cartridge Fuse Micro Fuse Description
6

464 IN CASE OF EMERGENCY
F67–10 Amp Red CD / DVD / UCI Port – If Equipped (HD Only)
Bluetooth Hands-Free Module / CD – If
Equipped (DS 1500 Only)
F68 –10 Amp Red AEB RACAM HTR – If Equipped (HD Only)
F69 –15 Amp Blue SCR Module – If Equipped (HD Only)
F70 –30 Amp Green Fuel Pump Motor / K09 RLY Coil Feed
(Cummins Diesel) – If Equipped
F71 –25 Amp Clear Amplifier / Active Noise Cancelation – If
Equipped (HD Only)
F72 –10 Amp Red PCM / DC/DC Converter Voltage– If Equipped
(DS 1500 Only)
F73 –20 Amp Yellow Fuel Transfer Pump (Rear Tank) – If Equipped
(HD Only)
F74 –20 Amp Yellow Brake Vacuum Pump Gas/Diesel – If Equipped
(DS 1500 Only)
F74 –10 Amp Red Backup Alarm – If Equipped (HD Only)
F75 –10 Amp Red ATMM / Coil-SCR Module RLY– If Equipped
(HD Only)
Coolant Temperature Valve – If Equipped (DS
1500 Only)
Cavity
Cartridge Fuse Micro Fuse Description

IN CASE OF EMERGENCY 465
F76–10 Amp Red Electronic Stability Control (HD Only)
Brake System Module / Stop Lamp Switch /
Electric Park Brake / Clutch Pedal Switch (DS
1500 Only)
F77 –10 Amp Red Drivetrain Control Module / Front Axle
Disconnect Module / TCM (HD Only)
Drivetrain Control Module / ELSD / Front Axle
Disconnect Module / Transmission Control
Relay / RDM / Power Take Off Unit – If
Equipped (DS 1500 Only)
F78 –10 Amp Red Engine Control Module / Powertrain Control
Module / Electric Power Steering (DS 1500
Only)
F78 –15 Amp Blue Engine Control Module / Powertrain Control
Module / AEB RACM MOD / Feed To AUX
PDC Relay Coils (HD Only)
F79 –15 Amp Blue ID / Clearance Lights
F80 –10 Amp Red Universal Garage Door Opener / Compass /
Anti-Intrusion Module (DS 1500 Only)
ASSY Overhead Console / SW Assist / SW 911
– If Equipped (HD Only)
F81 –20 Amp Yellow Trailer Tow Right Turn / Stop Lights - If
Equipped
Cavity
Cartridge Fuse Micro Fuse Description
6

466 IN CASE OF EMERGENCY
F82–10 Amp Red Steering Column Control Module / Cruise
Control
F83 ––No Connection
F84 –15 Amp Blue ASBM / HVAC / ICS / Rear Heated Seat
Switches
F85 –10 Amp Red Airbag Module
F86 –10 Amp Red Airbag Module
F87 –10 Amp Red Air Suspension / ITBM / Steering Column
Control Module / MOD Gateway CAN-C
Trailer TPM (HD Only)
Air Suspension / Trailer Tow / DC/DC
Converter (Voltage Stabilizer) / Steering
Column Control Module / Occupant
Classification Sensor (DS 1500 Only)
F88 –15 Amp Blue Instrument Panel Cluster
F90/F91 –20 Amp Yellow IGN or BATT Customer Selectable – If Equipped
(HD Only)
Power Outlet (Rear Seats) Customer Selectable
(DS 1500 Only)
F93 –20 Amp Yellow Cigar Lighter - If Equipped
Cavity
Cartridge Fuse Micro Fuse Description

IN CASE OF EMERGENCY 467
F94–10 Amp Red Shift-By-Wire / Transfer Case Switch (DS 1500
Only)
Shift-By-Wire / Transfer Case Switch / Module
TPM Trailer (HD Only) / Module Gateway
Can-C Trailer TPM (HD Only)
F95 –10 Amp Red Rearview Camera / Park Assist / CHMSL
Camera / Blind Spot Sensor / Surround View
Camera (HD Only)

Rear Camera / Park Assist / Blind Spot Sensor /
Compass (DS 1500 Only)

F96 –10 Amp Red Rear Seat Heater Switch / Trunk Lamp With
Flashlamp Charger / Truck Lamp - If Equipped
(DS 1500 Only)
Trailer Camera – If Equipped (HD Only)
F97 –25 Amp Clear Rear Heated Seats And Heated Steering Wheel –
If Equipped (DS 1500 Only)
F97 –20 Amp Yellow Front Heated Seat Passenger – If Equipped (HD
Only)
F98 –25 Amp Clear Front Heated Seats – If Equipped (DS 1500
Only)
F98 –20 Amp Yellow Front Heated Seat Driver – If Equipped (HD
Only)
Cavity
Cartridge Fuse Micro Fuse Description
6

468 IN CASE OF EMERGENCY
(Continued)
F99–10 Amp Red HVAC / DASM (DS 1500 Only)
HVAC / In-Car Temperature Sensor / CSG
MOD / Humidity Sensor (HD Only)
F100 –10 Amp Red Upfitters – If Equipped (HD Only)
F101 –15 Amp Blue SSV Only
F101 –20 Amp Yellow Rear Heated Seat Right (HD Only)
F102 –20 Amp Yellow Rear Heated Seat Left / Run RLY #3 Coil (HD
Only)
F103 –10 Amp Red HeadLamp AFLS (HD Only)
F104 –20 Amp Yellow Power Outlets (Instrument Panel / Center
Console) / Trunk – If Equipped (DS 1500 Only)
UCI Port / USB Rear (HD Only)
Cavity
Cartridge Fuse Micro Fuse Description
CAUTION!
• When installing the power distribution center cover, it is important to ensure the cover is properly positioned
and fully latched. Failure to do so may allow water to
get into the power distribution center and possibly
result in an electrical system failure.
• When replacing a blown fuse, it is important to useonly a fuse having the correct amperage rating. The use
of a fuse with a rating other than indicated may result
in a dangerous electrical system overload. If a properly
rated fuse continues to blow, it indicates a problem in
the circuit that must be corrected. CAUTION!
(Continued)
