Ram 3500 Chassis Cab 2019 User Guide
Manufacturer: RAM, Model Year: 2019, Model line: 3500 Chassis Cab, Model: Ram 3500 Chassis Cab 2019Pages: 607, PDF Size: 10.72 MB
Page 11 of 607
9
DEALER SERVICE ........................................................... 417
Engine Oil — Gas Engine .......................................... 418
Engine Oil Filter ......................................................... 419
Engine Air Cleaner Filter ......................................... 420
Air Conditioner Maintenance ................................. 421
Accessory Drive Belt Inspection ................................ 426
Body Lubrication ....................................................... 428
Windshield Wiper Blades ......................................... 428
Exhaust System ........................................................... 431
Cooling System ........................................................... 433
Brake System ............................................................... 438
Automatic Transmission ............................................ 439
Rear Axle And 4x4 Front Driving Axle Fluid
Level .......................................................................... 442
Transfer Case ............................................................... 444
HOISTING ......................................................................... 444
TIRES .................................................................................. 444
Tire Safety Information ............................................ 444
Tires — General Information ................................... 454
Tire Types ..................................................................... 460
Spare Tires — If Equipped ..................................... 461
Wheel And Wheel Trim Care ................................. 464
Tire Chains (Traction Devices) ................................. 465
Tire Rotation Recommendations ............................... 466
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES ...............................................468
Treadwear .....................................................................469
Traction Grades............................................................ 469
Temperature Grades ................................................... 469
STORING THE VEHICLE .............................................470
BODYWORK ......................................................................470
Protection From Atmospheric Agents ....................470
Body And Underbody Maintenance .........................471
Preserving The Bodywork .......................................... 471
INTERIORS .......................................................................472
Seats And Fabric Parts ................................................472
Plastic And Coated Parts ............................................473
Leather Parts.................................................................474
Glass Surfaces ..............................................................474
TECHNICAL SPECIFICATIONS
IDENTIFICATION DATA ...............................................475
Vehicle Identification Number ................................. 475
BRAKE SYSTEM ...............................................................476
Hydraulic Brake Assist ...............................................476
WHEEL AND TIRE TORQUE SPECIFICATIONS .....476
Torque Specifications ................................................477
Page 12 of 607
10
FUEL REQUIREMENTS .............................................. 479
6.4L Engine ................................................................... 479
Reformulated Gasoline .......................................... 479
Materials Added To Fuel .......................................... 480
Gasoline/Oxygenate Blends .................................... 480
Do Not Use E-85 In Non-Flex Fuel Vehicles............ 481
CNG And LP Fuel System Modifications ................ 481
MMT In Gasoline......................................................... 481
Fuel System Cautions.................................................. 481
Carbon Monoxide Warnings ................................... 482
FLUID CAPACITIES ..................................................... 483
FLUIDS AND LUBRICANTS ......................................... 484
Engine ........................................................................... 484
Chassis ......................................................................... 486
MULTIMEDIA
UCONNECT SYSTEMS ................................................... 487
DRAG & DROP MENU BAR ........................................ 487
CYBERSECURITY ............................................................ 488
UCONNECT SETTINGS ................................................. 490
Uconnect 3 Settings ..................................................... 490
Uconnect 4/4C/4C NAV Settings ............................ 509
Uconnect 4C NAV With 12–inch Display Settings ..... 529
STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED .......................................................................550
Radio Operation........................................................... 550
Media Mode..................................................................551
IPOD/USB/MP3 CONTROL — IF EQUIPPED ........551
RADIO OPERATION AND MOBILE PHONES .........555
Regulatory And Safety Information .........................556
VOICE COMMANDS .....................................................557
Introducing Uconnect .................................................557
Get Started .................................................................... 557
Basic Voice Commands...............................................559
Radio..............................................................................561
Media ............................................................................. 564
Phone ............................................................................. 566
Voice Text Reply — If Equipped ...............................569
Climate (4C/4C NAV) ................................................570
Navigation (4C NAV) .................................................572
SiriusXM Guardian (4C/4C NAV) —
If Equipped ...................................................................573
Register (4C/4C NAV)................................................574
Page 13 of 607
11
Mobile App (4C/4C NAV)......................................... 575
SiriusXM Travel Link (4C NAV) ............................... 576
Siri Eyes Free — If Equipped .................................... 577
Using Do Not Disturb ................................................ 579
Android Auto — If Equipped ................................... 579
Apple CarPlay — If Equipped .................................. 581
General Information .................................................... 583
Additional Information .............................................. 584
CD/DVD DISC MAINTENANCE ................................ 584
CUSTOMER ASSISTANCE
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR
VEHICLE ........................................................................... 585
Prepare For The Appointment .................................. 585
Prepare A List .............................................................. 585
Be Reasonable With Requests .................................... 585
IF YOU NEED ASSISTANCE .........................................585
FCA US LLC Customer Center..................................586
FCA Canada Inc. Customer Center...........................586
In Mexico Contact ........................................................586
Puerto Rico And U.S. Virgin Islands ........................ 586
Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY) .................................................587
Service Contract ..........................................................587
WARRANTY INFORMATION .......................................588
MOPAR PARTS .................................................................588
REPORTING SAFETY DEFECTS ...................................588
In The 50 United States And Washington, D.C. ...... 588
In Canada ......................................................................589
PUBLICATION ORDER FORMS ...................................589
Page 14 of 607
12
INTRODUCTION
INTRODUCTION
Dear Customer, congratulations on selecting your new
vehicle. Be assured that it represents precision workman-
ship, distinctive styling, and high quality.
This is a specialized utility vehicle. It can go places and
perform tasks that are not intended for conventional
passenger vehicles. It handles and maneuvers differently
from many passenger vehicles both on-road and off-road, so
take time to become familiar with your vehicle. If equipped,
the two-wheel drive version of this vehicle was designed for
on-road use only. It is not intended for off-road driving or
use in other severe conditions suited for a four-wheel drive
vehicle. Before you start to drive this vehicle, read the
Owner’s Manual. Be sure you are familiar with all vehicle
controls, particularly those used for braking, steering, trans -
mission, and transfer case shifting. Learn how your vehicle
handles on different road surfaces. Your driving skills will
improve with experience. When driving off-road, or
working the vehicle, don’t overload the vehicle or expect the
vehicle to overcome the natural laws of physics. Always
observe federal, state, provincial and local laws wherever
you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or
a collision. Refer to the “Driving Tips” in “Starting and Oper
-
ating” for further information.
This Owner’s Manual has been prepared with the assistance
of service and engineering specialists to acquaint you with
the operation and maintenance of your vehicle. It is supple -
mented by Warranty Information, and customer oriented
documents. In the attached Warranty Booklet you will find a
description of the services that FCA offers to its customers,
the Warranty Certificate and the details of the terms and
conditions for maintaining its validity. Please take the time
to read all of these publications carefully before driving your
vehicle for the first time. Following the instructions, recom -
mendations, tips, and important warnings in this manual
will help assure safe and enjoyable operation of your vehicle.
This Owner’s Manual describes all versions of this vehicle.
Options and equipment dedicated to specific markets or
versions are not expressly indicated in the text. Therefore,
you should only consider the information which is related to
the trim level, engine, and version that you have purchased.
Any content introduced throughout the Owner’s Informa -
tion, that may or may not be applicable to your vehicle, will
Page 15 of 607
INTRODUCTION 13
be identified with the wording “If Equipped”. All data
contained in this publication are intended to help you use
your vehicle in the best possible way. FCA aims at a constant
improvement of the vehicles produced. For this reason, it
reserves the right to make changes to the model described for
technical and/or commercial reasons. For further informa-
tion, contact an authorized dealer.
If applicable, refer to the Owner’s Manual Supplement for
related information.
NOTE:
After reviewing the Owner’s Information, it should be stored
in the vehicle for convenient referencing, and remain with
the vehicle when sold.
When it comes to service, remember that your authorized
dealer knows your vehicle best, has factory-trained techni -
cians and genuine MOPAR® parts, and cares about your
satisfaction.HOW TO USE THIS MANUAL
Essential Information
Consult the Table of Contents to determine which section
contains the information you desire.
Since the specification of your vehicle depends on the items
of equipment ordered, certain descriptions and illustrations
may differ from your vehicle's equipment.
The detailed index at the back of this Owner's Manual
contains a complete listing of all subjects.
Symbols
Some vehicle components have colored labels whose
symbols indicate precautions to be observed when using this
component. Refer to “Warning Lights and Messages” in
“Getting To Know Your Instrument Panel” for further infor -
mation on the symbols used in your vehicle.
1
Page 16 of 607
14 INTRODUCTION
WARNINGS AND CAUTIONS
This Owner’s Manual contains WARNINGS against oper-
ating procedures that could result in a collision, bodily injury
and/or death. It also contains CAUTIONS against proce -
dures that could result in damage to your vehicle. If you do
not read this entire Owner’s Manual, you may miss
important information. Observe all Warnings and Cautions.
VAN CONVERSIONS/CAMPERS
The New Vehicle Limited Warranty does not apply to body
modifications or special equipment installed by van conver -
sion/camper manufacturers/body builders. U.S. residents
refer to the Warranty Information book, Section 2.1.C. Cana -
dian residents refer to the “What Is Not Covered” section of
the Warranty Information book. Such equipment includes
video monitors, VCRs, heaters, stoves, refrigerators, etc. For
warranty coverage and service on these items, contact the
applicable manufacturer. Operating instructions for the special equipment installed by
the conversion/camper manufacturer should also be
supplied with your vehicle. If these instructions are missing,
please contact your authorized dealer for assistance in
obtaining replacement documents from the applicable
manufacturer.
For information on the Body Builder’s Guide refer to
www.rambodybuilder.com
. This website contains dimen -
sional and technical specifications for your vehicle. It is
intended for Second Stage Manufacturer's technical support.
For service issues, contact your authorized dealer.
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and may
lead to a collision resulting in serious injury or death.
Page 17 of 607
15
GETTING TO KNOW YOUR VEHICLE
VEHICLE USER GUIDE — IF EQUIPPED
Access your Owner’s Information right through your Ucon-
nect 4C or 4C NAV touchscreen system — If Equipped.
To access the Vehicle User Guide on your Uconnect Touch -
screen: Press the Uconnect Apps button. From there, press
the Vehicle User Guide icon on your touchscreen. No Ucon -
nect registration is required.
Uconnect 4C NAV With 8.4–inch Display Vehicle User Guide Touchscreen Icon2
Page 18 of 607
16 GETTING TO KNOW YOUR VEHICLE
NOTE:
Vehicle User Guide features are not available while the
vehicle is moving. If you try to access while the vehicle is in
motion, the system will display: Feature not available while
the vehicle is in motion.
Pre-Installed Features
Once you launch your Vehicle User Guide, you will be able
to explore your warranty information and radio manual
when and where you need them. Your Uconnect system
displays the Vehicle User Guide on your touchscreen radio
to assist in better understanding your vehicle. There’s no app
to download, no phone to connect and no external device
needed for playback. Plus, it’s updated throughout the year,
in real-time, so it never goes out of date.Features/Benefits
• Pre-installed on your Uconnect touchscreen radio
• Enhanced search and browsing capability
• Robust NAV application — If Equipped
• Add selected topics to a fast-access Favorites category
• Icon and symbol glossary
• Warranty information
• Crucial driver information and assistance:
Tip:
When viewing a topic, tap the star icon to add it to your
Favorites, for easy access in the future.
Your User Guide —
Updated in real-time
Available when and where
you need it
Touchscreen convenience Customizable interface
Maintenance schedules and
information Multilingual
Comprehensive icon &
symbol glossary
Operating Instructions Maintenance Schedules
Warranty Information Emergency Procedures
Fluid Level Standards 911 Contact and More
Page 19 of 607
GETTING TO KNOW YOUR VEHICLE 17
KEYS
Key Fob
Your vehicle uses a keyless ignition system. The ignition
system consists of a key fob with Remote Keyless Entry
(RKE) and a START/STOP push button ignition system. The
Remote Keyless Entry system consists of a key fob and
Keyless Enter-N-Go feature.
NOTE:
The key fob may not be found if it is located next to a mobile
phone, laptop or other electronic device; these devices may
block the key fob’s wireless signal.
The key fob allows you to lock or unlock all doors, as well as
activate the Panic Alarm from distances up to approximately
66 ft (20 m) using a handheld key fob. The key fob does not
need to be pointed at the vehicle to activate the system.
NOTE:
• In the ON/RUN position, all key fob buttons will workuntil the vehicle reaches 3 mph (5 km/h).
• The key fob should not be placed next to the wireless charging pad (if equipped). Key Fob
In case the ignition switch does not change with the push of
a button, the key fob may have a low or fully depleted
battery. A low key fob battery can be verified by referring to
the instrument cluster, which will display directions to
follow.
1 — Emergency Key
2 — Unlock
3 — Lock
4 — Remote Start
5 — PANIC
2
Page 20 of 607
18 GETTING TO KNOW YOUR VEHICLE
In a situation where the battery is low or fully depleted, a
back up method can be used to operate the ignition switch.
Put the nose side of the key fob (side opposite of the Emer-
gency Key) against the ENGINE START/STOP button and
push to operate the ignition switch.
To Unlock The Doors
Push and release the unlock button on the key fob once to
unlock the driver’s door. Push the unlock button twice
within five seconds to unlock all doors. The turn signal lights
will flash to acknowledge the unlock signal. The illuminated
entry system will also turn on.
NOTE:
The instrument cluster display or Uconnect Settings are
setup for driver door first, otherwise this will unlock all
doors.
To Lock The Doors
Push and release the lock button on the key fob to lock all
doors. The turn signal lights will flash and the horn will
chirp to acknowledge the signal. Sound Horn With Remote Key Lock
This feature will cause the horn to chirp when the doors are
locked with the key fob. This feature can be turned on or
turned off.
NOTE:
Pushing the lock button on the key fob while you are in the
vehicle will activate the vehicle security alarm system.
Opening a door with the vehicle security alarm system acti
-
vated will cause the alarm to sound. Push the unlock button
to deactivate the vehicle security alarm system.
Refer to “Instrument Cluster Display” in “Getting To Know
Your Instrument Panel” for further information.
Using The Panic Alarm
To turn the Panic Alarm feature on or off, push the Panic
button on the key fob. When the Panic Alarm is activated, the
turn signals will flash, the horn will pulse on and off, and the
interior lights will turn on.
