audio Ram 3500 Chassis Cab 2019 Owner's Guide

MULTIMEDIA 529
Uconnect 4C NAV With 12–inch Display Settings
Uconnect 4C NAV With 12–inch Display Buttons On The Touchscreen And Buttons On The Faceplate
Press the “Settings” button on the touchscreen to display the
settings menu screen. In this mode the Uconnect system
allows you to access programmable features that may be
equipped such as Language, Display, Units, Voice, Clock &
Date, Camera, Safety & Driving Assistance, Mirrors and Wipers, Lights, Doors & Locks, Auto-On Comfort (if
equipped), Engine Off Options, Suspension, Trailer, Audio
Settings, Bluetooth, SiriusXM Setup (if equipped), Reset and
System Information.
NOTE:
Only one category may be selected at a time.
When making a selection, press the button on the touch
-
screen to enter the desired mode. Once in the desired mode,
press and release the preferred setting until a check-mark
appears next to the setting, showing that setting has been
selected. Once the setting is complete, press the back arrow
button on the touchscreen to return to the previous menu or
press the “X” button on the touchscreen to close out of the
settings screen. Pressing the Up or Down Arrow buttons on
the touchscreen on the right side of the screen will allow you
to toggle up or down through the list of available settings.
NOTE:
All settings should be changed with the ignition in the RUN
position.
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
9

MULTIMEDIA 545
Audio
After pressing the “Audio” button on the touchscreen, the following settings will be available:Setting Name Selectable Options
Balance/Fade FrontRightBackLeft
NOTE:
The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the speaker icon or use the
arrows to adjust, tap the “C” icon to readjust to the center.
Equalizer + –
NOTE:
When in the “Equalizer” display you may adjust the Bass, Mid and Treble settings.
Speed Adjusted
Volume Off
123
NOTE:
The “Speed Adjusted Volume” feature increases or decreases volume relative to vehicle speed.
Surround Sound — If
Equipped On
Off
NOTE:
The “Surround Sound” feature provides simulated surround sound mode.
9

546 MULTIMEDIA
Bluetooth
After pressing the “Bluetooth” button on the touchscreen, the following settings will be available:AUX Volume Offset
— If Equipped
On
Off
NOTE:
The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the
AUX input.
Auto Play On Off
Setting Name
Selectable Options
Setting NameSelectable Options
Phone Pop-Ups Displayed in Cluster On
Off
Do Not Disturb List of Settings
NOTE:
Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (both, text, call), Auto Reply
Message (custom, default) and Custom Auto Reply Message (create message). Paired Phones and Audio Devices List Of Paired Phones and Audio Sources
NOTE:
The “Paired Phones and Audio Sources” feature shows which phones and audio sources are paired to the Phone and Audio
Sources Settings system. For further information, refer to the Uconnect Owner’s Manual Supplement.

550 MULTIMEDIA
STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED
The remote sound system controls are located on the back
surface of the steering wheel. Reach behind the wheel to
access the switches.Steering Wheel Audio Controls (Rearview Of Steering Wheel)
The right hand control is a rocker type switch with a
push-button in the center. Pushing the top of the switch will
increase the volume, and pushing the bottom of the switch
will decrease the volume. Pushing the center button will make the radio switch
between the various modes available (AM/FM/SXM or
Media etc.).
The left hand control is a rocker type switch with a
push-button in the center. The function of the left hand
control is different depending on which mode you are in.
The following describes the left hand control operation in
each mode.
Radio Operation
Pushing the top of the switch will SEEK up for the next
listenable station and pushing the bottom of the switch will
SEEK down for the next listenable station.
The button located in the center of the left-hand control will
tune to the next preset station that you have programmed in
the radio preset button.

INDEX
A
Adaptive Cruise Control (ACC) (Cruise Control) ............. 288
Adding Engine Coolant (Antifreeze) ................................... 435
Adding Fuel ............................................................................. 336
Additives, Fuel ........................................................................ 480
Adjust Down....................................................................................... 42
Forward .................................................................................. 42
Rearward ................................................................................ 42
Up ............................................................................................ 42
Adjustable Pedals...................................................................... 55
Air Bag Air Bag Operation ............................................................... 205Air Bag Warning Light ....................................................... 203
Enhanced Accident Response ................................... 212, 409
Event Data Recorder (EDR) ............................................... 409
If Deployment Occurs ........................................................ 211
Knee Impact Bolsters .......................................................... 206Maintaining Your Air Bag System.................................... 213
Maintenance......................................................................... 213
Transporting Pets ................................................................ 240
Air Bag Light ........................................................... 146, 203, 241
Air Cleaner, Engine (Engine Air Cleaner Filter) ................ 420
Air Conditioner Maintenance ............................................... 421 Air Conditioner Refrigerant ..........................................421, 422
Air Conditioner System..........................................................421
Air Conditioning ................................................................. 77, 88
Air Conditioning Filter .....................................................91, 423
Air Conditioning System .........................................................89
Air Conditioning, Operating Tips ..........................................89
Air Filter ...................................................................................420
Air Pressure Tires .......................................................................................455
Alarm Panic ........................................................................................18
Security Alarm ...............................................................30, 148
Alterations/Modifications Vehicle.....................................................................................14
Android Auto ..........................................................................579
Antifreeze (Engine Coolant) ..................................................434 Capacites...............................................................................483
Disposal ................................................................................436
Anti-Lock Brake System (ABS) .............................................161
Anti-Lock Warning Light.......................................................154
Apple CarPlay .........................................................................581
Assist, Hill Start .......................................................................164
Audio Systems (Radio)........................................................... 487
Auto Down Power Windows ..................................................92

601
Spark Plugs .............................................................................. 484
Speed ControlAccel/Decel.......................................................................... 287
Cancel.................................................................................... 288Resume ................................................................................. 288
Speed Control (Cruise Control) .................................... 285, 288
Starting ............................................................................. 244, 246 Automatic Transmission .................................................... 245
Button...................................................................................... 23
Cold Weather ....................................................................... 250Engine Fails To Start ........................................................... 249
Starting And Operating ......................................................... 246
Starting Procedures ................................................................ 246
Starting Procedures (Gas Engines) ....................................... 244
Steering Power ............................................................................ 283, 284
Tilt Column ............................................................................ 53
Wheel, Heated ................................................................. 53, 54
Wheel, Tilt .............................................................................. 53
Steering Wheel Audio Controls ............................................ 550
Steering Wheel Mounted Sound System Controls............. 550
Storage ...................................................................................... 104
Storage Compartment, Center Seat ...................................... 106
Storage, Vehicle ................................................................. 90, 470
Storing Your Vehicle .............................................................. 470
Sunglasses Storage .................................................................. 122 Sway Control, Trailer .............................................................170
Synthetic Engine Oil ...............................................................419
T
Telescoping Steering Column .................................................53
Temperature Control, Automatic (ATC) ...............................89
Tilt Down .......................................................................................43
Up ............................................................................................43
Tilt Steering Column ................................................................53
Tip Start ....................................................................................245
Tire And Loading Information Placard ...............................450
Tire Markings ..........................................................................445
Tire Safety Information ..........................................................444
Tire Stowage ............................................................................396
Tires ...................................................................243, 454, 461, 468 Aging (Life Of Tires) ........................................................... 458Air Pressure..........................................................................454
Chains ...................................................................................465
Changing ..............................................................................390
Compact Spare.....................................................................462
Dual .......................................................................396, 467, 477
General Information....................................................454, 461
High Speed ...........................................................................456
Inflation Pressure ................................................................455
Jacking...................................................................................390
Life Of Tires..........................................................................458
11
