System Information
After pressing the “System Information” button on the
touchscreen, the following settings will be available:
Setting NameSelectable Options
System Information System Software Information Screen
NOTE: When the “System Information” feature is selected, a “System Software Information” screen will appear, dis-
playing the system software version.
Customer Programmable Features — Uconnect
8.4/8.4 NAV Personal Settings
Press the “Apps” button on the touchscreen then press the
“Settings” button on the touchscreen to display the settings
menu screen. In this mode the Uconnect system allows you
to access programmable features that may be equipped
such as Display, Voice, Clock, Safety & Driving Assistance,
Lights, Doors & Locks, Auto-On Comfort (if equipped),
Engine Off Options, Trailer Brake, Audio, Phone/
Bluetooth, SiriusXM Setup (if equipped), Restore Settings,
Clear Personal Data and System Information.
NOTE: Only one category may be selected at a time.
When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired mode, press and release the preferred setting until a
check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
either press the back arrow button on the touchscreen or
the Back button on the faceplate to return to the previous
menu or press the “X” button on the touchscreen to close
out of the settings screen. Pressing the Up or Down Arrow
buttons on the touchscreen on the right side of the screen
will allow you to toggle up or down through the list of
available settings.
NOTE:
All settings should be changed with the ignition in
the RUN position.
256 UNDERSTANDING YOUR INSTRUMENT PANEL

Towing Requirements — Trailer Lights And Wiring
Whenever you pull a trailer, regardless of the trailer size,
stop lights and turn signals on the trailer are required for
motoring safety.
NOTE:Do not cut or splice wiring into the vehicle’s wiring
harness.
WARNING!
Any work done to the vehicle’s electrical system or
wiring should be performed by a qualified automotive
technician. If done improperly it may cause damage to
the electrical system wiring and could result in serious
or fatal injury.
Towing Tips
Before setting out on a trip, practice turning, stopping and
backing the trailer up in an area away from heavy traffic.
Automatic Transmission — If Equipped
The DRIVE range can be selected when towing. The
transmission controls include a drive strategy to avoid frequent shifting when towing. However, if frequent shift-
ing does occur while in DRIVE, select TOW/HAUL mode
or select a lower gear range (using the Electronic Range
Select (ERS) shift control).
NOTE:
Using TOW/HAUL mode, or selecting a lower
gear range (using the ERS shift control) while operating the
vehicle under heavy loading conditions will improve per-
formance and extend transmission life by reducing exces-
sive shifting and heat build up. This action will also
provide better engine braking.
When towing a loaded trailer up steep grades at low
speeds (20 mph [32 km/h] or below), holding your vehicle
in first gear (using the ERS shift control) can help to avoid
transmission overheating.
If you regularly tow a trailer for more than 45 minutes of
continuous operation, then change the transmission fluid
and filter(s) as specified for police, taxi, fleet, or frequent
trailer towing. Refer to the “Maintenance Schedule” for
the proper maintenance intervals.
NOTE: Check the automatic transmission fluid level be-
fore towing.
414 STARTING AND OPERATING

the NEUTRAL (N) button or are no longer met during
the shift, the NEUTRAL (N) indicator light will flash
continuously until all requirements are met or until the
NEUTRAL (N) button is released.
• The ignition must be in the ON/RUN mode for a shift to
take place and for the position indicator lights to be
operable. If the ignition is not in the ON/RUN mode, the
shift will not take place and no position indicator lights
will be on or flashing.
• A flashing NEUTRAL (N) position indicator light indi-
cates that shift requirements have not been met.
Shifting Out Of NEUTRAL (N)
Use the following procedure to prepare your vehicle for
normal usage.
1. Bring the vehicle to a complete stop, leaving it con- nected to the tow vehicle.
2. Firmly apply the parking brake.
3. Turn the ignition to the ON/RUN mode, but do not start the engine.
4. Press and hold the brake pedal.
5. Shift the transmission into NEUTRAL. •
With manual shift transfer case, shift the transfer case
lever to the desired position.
• With electronic shift transfer case, push and hold the
transfer case NEUTRAL (N) button until the NEU-
TRAL (N) indicator light turns off. After the NEU-
TRAL (N) indicator light turns off, release the NEU-
TRAL (N) button. After the NEUTRAL (N) button has
been released, the transfer case will shift to the posi-
tion indicated by the selector switch.
NOTE: When shifting the transfer case out of NEUTRAL
(N), the engine should remain OFF to avoid gear clash.
6. Shift automatic transmission into PARK.
7. Release the brake pedal (and clutch pedal on a manual transmission).
8. Disconnect vehicle from the tow vehicle.
9. Start the engine.
10. Press and hold the brake pedal.
11. Release the parking brake.
12. Shift the transmission into gear, release the brake pedal (and clutch pedal on manual transmissions), and check
that the vehicle operates normally.
422 STARTING AND OPERATING

WARNING!(Continued)
vehicle control could occur that may result in an
accident involving serious injury or death.
• Access, or allow others to access, information
stored in your vehicle systems, including personal
information.
For further information, refer to “Privacy Practices — If
Equipped With Uconnect 8.4 Radio” and “Uconnect Cy-
berSecurity” in “All About Uconnect Access” in your
Owner ’s Manual Radio Supplement and “Cybersecurity”
in “Understanding Your Instrument Panel”.
Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines that
the fuel filler cap is loose, improperly installed,
or damaged, a loose gascap indicator will dis-
play in the instrument cluster telltale display
area. Refer to “Instrument Cluster Display” in “Under-
standing Your Instrument Panel” for further information.
Tighten the fuel filler cap properly and push the SELECT button to turn off the message. If the problem continues,
the message will appear the next time the vehicle is started.
A loose, improperly installed, or damaged fuel filler cap
may also turn on the Malfunction Indicator Light (MIL).
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass an
inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states that require an Inspection and Mainte-
nance (I/M), this check verifies the “Malfunction
Indicator Light (MIL)” is functioning and is not on
when the engine is running, and that the OBD II system is
ready for testing.
Normally, the OBD II system will be ready. The OBD II
system may notbe ready if your vehicle was recently
serviced, recently had a dead battery or a battery replace-
ment. If the OBD II system should be determined not ready
for the I/M test, your vehicle may fail the test.
7
MAINTAINING YOUR VEHICLE 449

Your vehicle has a simple ignition actuated test, which you
can use prior to going to the test station. To check if your
vehicle’s OBD II system is ready, you must do the follow-
ing:
1. Cycle the ignition switch to the ON position, but do notcrank or start the engine.
NOTE: If you crank or start the engine, you will have to
start this test over.
2. As soon as you cycle the ignition switch to the ON position, you will see the “Malfunction Indicator Light
(MIL)” symbol come on as part of a normal bulb check.
3. Approximately 15 seconds later, one of two things will happen:
• The MIL will flash for about 10 seconds and then return
to being fully illuminated until you turn OFF the igni-
tion or start the engine. This means that your vehicle’s
OBD II system is not readyand you should notproceed
to the I/M station. •
The MIL will not flash at all and will remain fully
illuminated until you place the ignition in the off posi-
tion or start the engine. This means that your vehicle’s
OBD II system is readyand you can proceed to the I/M
station.
If your OBD II system is not ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your vehicle
as you normally would in order for your OBD II system to
update. A recheck with the above test routine may then
indicate that the system is now ready.
Regardless of whether your vehicle’s OBD II system is
ready or not, if the MIL is illuminated during normal
vehicle operation you should have your vehicle serviced
before going to the I/M station. The I/M station can fail
your vehicle because the MIL is on with the engine
running.
REPLACEMENT PARTS
Use of genuine MOPAR parts for normal/scheduled main-
tenance and repairs is highly recommended to ensure the
designed performance. Damage or failures caused by the
450 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that service
is required for your vehicle. Operating conditions such as
frequent short-trips, trailer tow, extremely hot or cold
ambient temperatures, and E85 fuel usage will influence
when the “Oil Change Required” message is displayed.
Severe Operating Conditions can cause the change oil
message to illuminate as early as 3,500 miles (5,600 km)
since last reset. Have your vehicle serviced as soon as
possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other than
your authorized dealer, the message can be reset by
referring to the steps described under “Instrument Cluster
Display” in “Understanding Your Instrument Panel” for
further information.Gasoline Engines:
Under no circumstances should oil change intervals exceed
8,000 miles (13,000 km), twelve months or 350 hours of
engine run time, whichever comes first. The 350 hours of
engine run or idle time is generally only a concern for fleet
customers.
Severe Duty:
Change Engine Oil at 4,000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment or is
operated predominately at idle or very low engine RPM’s.
This type of vehicle use is considered Severe Duty
Once A Month Or Before A Long Trip:
•
Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
• Check the fluid levels of the coolant reservoir, brake
master cylinder, power steering and automatic transmis-
sion and fill as needed.
• Check function of all interior and exterior lights
504 MAINTENANCE SCHEDULES

Adding Engine Coolant (Antifreeze).............473
Adding Fuel ............................. .400
Additives, Fuel ........................... .398
Adjust Down .............................115,116
Forward ............................115,116
Rearward ...........................115,116
Up................................115,116
Adjustable Pedals ......................... .142
Air Bag Air Bag Operation .........................58
Air Bag Warning Light .....................55
Enhanced Accident Response ..............68, 444
Event Data Recorder (EDR) .................444
If A Deployment Occurs ....................67
Knee Impact Bolsters .......................58
Maintaining Your Air Bag System ..............69
Side Air Bags ......................... .58, 62
Transporting Pets .........................93
Air Bag Light ....................... .55, 96, 201
Air Bag Maintenance .........................69
Air Cleaner, Engine (Engine Air Cleaner Filter) ......454
Air Conditioner Maintenance ..................458
Air Conditioning .......................... .277
Air Conditioning Controls ....................277 Air Conditioning Filter
...................292, 459
Air Conditioning, Operating Tips ...............291
Air Conditioning Refrigerant ...............458, 459
Air Conditioning System ...............277, 291, 458
Air Pressure, Tires ......................... .377
Alarm, Panic ...............................24
Alarm (Security Alarm) ....................19, 203
Alarm System (Security Alarm) .................19
Alterations/Modifications, Vehicle ................7
Antifreeze (Engine Coolant) ...................472
Capacities ............................. .499
Disposal .............................. .474
Anti-Lock Brake System (ABS) .................353
Appearance Care .......................... .481
Ashtray ................................ .177
Assist, Hill Start .......................... .355
Auto
Down Power Windows ...................38
Automatic Door Locks ........................32
Automatic Headlights ...................... .130
Automatic High Beams ..................... .132
Automatic Temperature Control (ATC) ...........291
Automatic Transmission ..................... .478
Adding Fluid .......................... .480
Fluid And Filter Changes ...................481
Fluid Level Check ....................... .479
516 INDEX

Fluid Type......................... .478, 502
Shifting .............................. .327
Special Additives ........................ .479
Axle Fluid ........................ .477, 478, 502
Axle Lubrication ....................... .477, 478
Back-Up Camera .......................... .161
Battery .............................. .204, 457
Charging System Light ....................204
Keyless Key Fob Replacement ................24
Belts, Seat .................................96
Body Builders Guide ..........................6
Body Mechanism Lubrication ..................465
B-Pillar Location .......................... .371
Brake Assist System ........................ .355
Brake Control System, Electronic ................353
Brake Fluid .......................... .476, 502
Brake System ......................... .352, 475
Fluid Check ........................... .476
Master Cylinder ........................ .476
Parking .............................. .350
Warning Light .......................... .202
Brake/Transmission Interlock ..................327
Bulb Replacement ......................... .494Bulbs, Light
........................... .98, 493
Cab Top Clearance Lights .....................498
Camera, Rear ............................ .161
Capacities, Antifreeze (Engine Coolant) ...........499
Capacities, Fluid .......................... .499
Caps, Filler Oil (Engine) ........................... .453
Power Steering ......................... .350
Radiator (Coolant Pressure) .................474
Carbon Monoxide Warning .................95, 399
Cargo Light ............................. .137
Car Washes .............................. .481
Center High Mounted Stop Light ...............496
Center

Seat Storage Compartment ...............182
Certification Label ......................... .401
Chart, Tire Sizing .......................... .367
Check Engine Light (Malfunction Indicator Light). . . .449
Checking Your Vehicle For Safety ................95
Checks, Safety .............................95
Child Restraint .............................70
Child Restraints Booster Seats ............................74
Child Restraints ..........................70
Child Seat Installation .................83, 84, 85
10
INDEX 517

Exhaust Gas Caution.....................95, 399
Exhaust System ........................ .95, 469
Exterior Lighting .......................... .130
Exterior Lights .............................98
Filters Air Cleaner ............................ .454
Air Conditioning .....................292, 459
Engine Fuel ........................... .500
Engine Oil ......................... .454, 500
Engine Oil Disposal ...................... .453
Flashers Turn Signal ...................... .98, 137, 220
Flat Tire Stowage .......................... .435
Flooded Engine Starting ..................... .323
Fluid, Brake ............................. .502
Fluid Capacities ........................... .499
Fluid Leaks ...............................98
Fluid Level Checks Automatic Transmission ....................479
Brake ................................ .476
Power Steering ......................... .350
Fluids, Lubricants And Genuine Parts ............500
Fog Lights ........................ .133, 216, 496
Fold Flat Load Floor ....................... .187Four-Way Hazard Flasher
.....................426
Four Wheel Drive ......................... .338
Freeing A Stuck Vehicle ..................... .439
Front Axle (Differential) ..................... .477
Fuel ................................... .396
Adding .............................. .400
Additives ............................. .398
Clean Air ............................. .396
Ethanol .............................. .397
Filler Cap (Gas Cap) ..................... .400
Filter ................................ .500
Gasoline .............................. .396
Light ................................ .214
Materials
Added ........................ .398
Methanol ............................. .397
Octane Rating .......................... .396
Requirements .......................... .396
Tank Capacity .......................... .499
Fuses .................................. .486
Garage Door Opener (HomeLink) ............165, 170
Gas Cap (Fuel Filler Cap) .................400, 449
Gasoline, Clean Air ........................ .396
Gasoline (Fuel) ........................... .396
Gasoline, Reformulated ..................... .396
520 INDEX

Low Fuel............................. .214
Malfunction Indicator (Check Engine) ..........208
Park ................................. .219
Passing ............................... .138
Seat Belt Reminder ...................... .201
Security Alarm ......................... .203
Service ............................ .493, 494
Tire Pressure Monitoring (TPMS) ..........212, 389
Traction Control ........................ .360
Transfer Case .......................... .341
Turn Signal ....................98, 137, 220, 494
Warning (Instrument Cluster Description) . . . .204, 220
Limited-Slip Differential ..................346, 478
Loading Vehicle ........................... .401
Tires................................. .371
Load Shed Battery Saver Mode ...................... .236
Battery Saver On ........................ .236
Electrical Load Reduction ...................236
Intelligent Battery Sensor ...................236
Locks ....................................30
Automatic Door ..........................32
Child Protection ..........................33
Door ..................................30
Power Door .............................32 Low Tire Pressure System
.....................389
Lubrication, Body ......................... .465
Lug Nuts ......................... .427, 433, 434
Maintenance Free Battery .....................457
Maintenance Procedures ..................... .451
Maintenance Schedule ...................... .504
Malfunction Indicator Light (Check Engine) . . . .208, 449
Manual, Service ........................... .514
Manual Transmission Fluid Level Check ....................... .478
Memory Seat ............................. .124
Methanol ............................... .397
Mirrors ................................. .103
Electric

Powered .........................111
Heated ................................112
Memory .............................. .124
Outside ...............................110
Rearview ....................... .103, 104, 109
Trailer Towing ...........................113
Modifications/Alterations, Vehicle ................7
Monitor, Tire Pressure System ..................389
MOPAR Parts ......................... .450, 513
MTBE/ETBE ............................. .397
10
INDEX 523
