maintenance schedule RAM CHASSIS CAB 2007 User Guide

reference holes when the transmission reaches 180° F (21°
C). Remember it is best to check the level at the normal
operating temperature.
CAUTION!Be aware that if the fluid temperature is below 50° F
(10° C), it may not register on the dipstick. Do not
add fluid until the temperature is elevated enough to
produce an accurate reading.
7. Check for leaks. Release the Parking Brake.
NOTE: To prevent dirt and water from entering the
transmission after checking or replenishing fluid, make
certain that the dipstick cap is properly reseated. It is
normal for the dipstick cap to spring back slightly from
its fully seated positions, as long as its seal remains
engaged in the dipstick tube. Automatic Transmission Fluid and Filter Change
The fluid and filter(s) should be changed and the as
specified in the Maintenance Schedule (Section 8). Ve-
hicles having severe usage should follow Maintenance
Schedule “B” of the Maintenance Schedule (Section 8).
Severe usage consists of:
• Off-the-highway operation;
• Trailer towing;
• Snow plow operation;
• Prolonged operation with heavy loading, especially in
hot weather.
NOTE: If the transmission is disassembled for any
reason, the fluid and filter should be changed, and the
bands adjusted (if equipped).440 MAINTAINING YOUR VEHICLE

The fluid and filter(s) should be changed and the bands
adjusted (if equipped) as specified in the Maintenance
Schedule (Section 8). Vehicles equipped with gas engines
having severe usage should follow Maintenance Sched-
ule “B” of the Maintenance Schedule (Section 8).
Severe usage consists of:
• Off-the-highway operation;
• Trailer towing;
• Snow plow operation;
• Prolonged operation with heavy loading, especially in
hot weather.
NOTE: If the transmission is disassembled for any
reason, the fluid and filter should be changed, and the
bands adjusted (if equipped). Special Additives
The manufacturer recommends against the addition of
any additives to the transmission. Exception to this
policy is the use of special dyes to aid in detecting fluid
leaks. The use of transmission sealers should be avoided,
since they may adversely affect seals.
Front and rear Wheel Bearings
Front Wheel Bearings
Front wheel bearings for all Dodge Ram Trucks are
sealed-for-life. They do not require greasing or seal
replacement. In some instances, these bearings will
“purge” excess grease and the bearing will look slightly
wet. This is normal. Periodic inspection for excess play is
recommended.444 MAINTAINING YOUR VEHICLE

or suspected. Proper maintenance of the entire vehicle
will help the effectiveness of the noise control systems.
Exhaust System
Inspect the entire exhaust system for leaks and damaged
parts. Devices such as hangers, clamps, and U-bolts
should be tight and in good condition. Damaged compo-
nents, burned or blown out mufflers, burned or rusted
out exhaust pipes should be replaced according to the
procedures and specifications outlined in the appropriate
service manual.
Air Cleaner Assembly
Inspect air cleaner housing for proper assembly and fit.
Make certain that the air cleaner is properly positioned
and that the cover is tight. Check all hoses leading to the air cleaner for tightness. The air filter element must also
be clean and serviced according to the instructions out-
lined in the Maintenance Schedule Section of this
manual.
Tampering With Noise Control System Prohibited
Federal law prohibits the following acts or the causing
thereof: (1) the removal or rendering inoperative by any
person, other than for purposes of maintenance, repair, or
replacement, of any device or element of design incorpo-
rated into any new vehicle for the purpose of noise
control prior to its sale or delivery to the ultimate
purchaser or while it is in use, or (2) the use of the vehicle
after such device or element of design has been removed
or rendered inoperative by any person.446 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULESCONTENTS
Emission Control System Maintenance ........474

Maintenance Schedules — 6.7L Turbo Diesel ....474
▫ Maintenance Schedule ..................476
Maintenance Schedules – Gas Engines ........484
▫ Schedule “B” ........................487
▫ Schedule “A” ........................498
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed in bold
type in this section (Section 8) must be done at the times
or mileages specified to assure the continued proper
functioning of the emission control system. These, and all
other maintenance services included in this manual,
should be done to provide best vehicle performance and
reliability. More frequent maintenance may be needed for
vehicles in severe operating conditions such as dusty
areas and very short trip driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE: Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations. MAINTENANCE SCHEDULES — 6.7L TURBO
DIESEL
CAUTION!Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
• Check the engine oil level about 15 minutes after a
fully warmed engine is shut off. Checking the oil level
while the vehicle is on level ground will improve the
accuracy of the oil level reading. Add oil only when
the level is at or below the ADD or MIN mark.
• Check the windshield washer solvent and add if
required. When refilling the washer fluid reservoir,474 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

take some washer fluid and apply it to a cloth or towel
and wipe clean the wiper blades, this will help blade
performance.
Once a Month
• Check tire pressure and look for unusual wear or
damage.
• Inspect the batteries and clean and tighten the termi-
nals as required.
• Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer case (if
equipped), add as needed.
• Check Filter Minder™. Replace air cleaner filter
element if necessary.
• Check all lights and all other electrical items for correct
operation.
• Drain water from the fuel filter. At Each Oil Change
• Change the engine oil filter.
• Inspect the exhaust system.
• Inspect the brake hoses.
• Inspect the U-Joints ( if equipped) and front suspen-
sion components.
• Check the automatic transmission fluid level.
• Check the manual transmission fluid level.
• Check the coolant level, hoses, and clamps.
• Lubricate outer tie rod ends (4X4) models only.
• Lubricate Front Drive Shaft Fitting ( 4X4).
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. MAINTENANCE SCHEDULES 475
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Maintenance Schedule
Miles 7,500 15,000 22,500 30,000 37,500
(Kilometers) (12 000) (24 000) (36 000) (48 000) (60 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage. X X XXX
Lubricate outer tie rod ends. X X X X X
Check transfer case fluid level (4X4). X
Change front and rear axle fluid (4X4). X X
Change automatic transmission fluid. X
Replace fuel filter element. X X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Inspect fan hub. X476 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 7,500 15,000 22,500 30,000 37,500
(Kilometers) (12 000) (24 000) (36 000) (48 000) (60 000)
[Months] [6] [12] [18] [24] [30]
Inspect damper. X
Inspect front wheel bearings. X MAINTENANCE SCHEDULES 477
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (97 000) (109 000) (121 000)
[Months] [36] [42] [48] [54] [60]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage. X X XXX
Lubricate outer tie rod ends. X X X X X
Drain and refill transfer case fluid (4X4). X
Change front and rear axle fluid (4X4). X X X
Change automatic transmission fluid. X
Change manual transmission fluid. X
Flush and replace engine coolant at 60 months, if
not replaced at 100,000 miles (160 000 km). X
Inspect drive belt, replace as necessary. X X
Replace fuel filter element. X X X478 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (97 000) (109 000) (121 000)
[Months] [36] [42] [48] [54] [60]
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Inspect fan hub. X
Inspect damper. X
Inspect front wheel bearings. X
Replace fuel filter element. X
Replace Crankcase Ventilation Filter (CCV). XMAINTENANCE SCHEDULES 479
