wiper fluid Ram ProMaster 2015 Owner's Manual

NOTE:The mist feature does not activate the washer
pump; therefore, no washer fluid will be sprayed on the
windshield. The wash function must be used in order to
spray the windshield with washer fluid.
Windshield Washer Operation
To use the washer, pull the windshield wiper/washer
lever toward the steering wheel to activate the washers.
The wipers will activate automatically for three cycles
after the lever is released. and then resume the intermit-
tent interval previously selected.
If the lever is pulled while in the off position, the wipers
will operate for three cycles, then turn off.
WARNING!
Sudden loss of visibility through the windshield
could lead to a collision. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with the defroster before and during
windshield washer use.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99

3. Install the A/C air filter/filter retainer back into thefresh air inlet. When installing the filter retainer make
sure the retainer is fully engaged.
4. Install the two screws back into the assembly to secure the filter retainer to the fresh air inlet.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, decklid, sliding doors and hood hinges, should
be lubricated periodically with a lithium based grease,
such as MOPAR® Spray White Lube to assure quiet, easy
operation and to protect against rust and wear. Prior to
the application of any lubricant, the parts concerned
should be wiped clean to remove dust and grit; after
lubricating excess oil and grease should be removed.
Particular attention should also be given to hood latching
components to ensure proper function. When performing other underhood services, the hood latch, release mecha-
nism and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the Fall and Spring. Apply a small
amount of a high quality lubricant, such as MOPAR®
Lock Cylinder Lubricant directly into the lock cylinder.Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild nonabrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
344 MAINTAINING YOUR VEHICLE

Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
NOTE:Life expectancy of wiper blades varies depend-
ing on geographical area and frequency of use. Poor
performance of blades may be present with chattering,
marks, water lines or wet spots. If any of these conditions
are present, clean the wiper blades or replace as neces-
sary.
Adding Washer Fluid
The fluid reservoir is located in the engine compartment
and should be checked at regular intervals. Fill the
reservoir with windshield washer solvent (not radiator
antifreeze) and operate the system for a few seconds to
flush out any residual water.
The washer fluid reservoir will hold a full gallon of fluid
when the Low Washer Fluid Light illuminates.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
After the engine has warmed, operate the defroster for a
few minutes to reduce the possibility of smearing or
freezing the fluid on the cold windshield. MOPAR® All
Weather Windshield Washer Solution or equivalent, used
with water as directed on the container, aids cleaning
action, reduces the freezing point to avoid line clogging,
and is not harmful to paint or trim.
7
MAINTAINING YOUR VEHICLE 345

Ignition Key Removal.......................11
Illuminated Entry ..........................16
Immobilizer (Sentry Key) ....................13
Inside Rearview Mirror ......................72
Instrument Cluster .....................127, 128
Instrument Panel And Controls ...............126
Instrument Panel Cover .....................358
Instrument Panel Lens Cleaning ...............360
Interior Appearance Care ....................358
Intermittent Wipers (Delay Wipers) .............98
Introduction ..............................4
Jump Starting ............................317
Key-In Reminder ..........................13
Key, Replacement ..........................14
Keys ...................................11
Key, Sentry (Immobilizer) ....................13 Lane Change Assist
........................94
Lap/Shoulder Belts .........................27
Latches .................................68
Lead Free Gasoline ........................262
Leaks, Fluid ..............................68
Life Of Tires ............................ .252
Light Bulbs .......................... .67, 376
Lights ............................... .67, 91
AirBag .........................48, 65, 128
Anti-Lock ............................ .128
Brake Assist Warning ....................226
Brake Warning ........................ .128
Bulb Replacement .......................378
Check Engine (Malfunction Indicator) .........128
Cruise ...............................128
Daytime Running ........................92
Dimmer Switch, Headlight ...............91, 94
Electronic Stability Program (ESP) Indicator .....226
Engine Temperature Warning ...............128
10
INDEX 413

Driving Through........................215
Wind Buffeting ............................23
Windows ................................22
Power ................................22
Windshield Defroster ....................66, 186
Windshield Washers .....................97, 345
Fluid .................................97
Windshield Wiper Blades ....................344
Windshield Wipers .........................97
Wiper Blade Replacement ...................344
Wipers, Intermittent ........................98
Wrench (Service Indicator) ...................128
10
INDEX 421
