relay Ram ProMaster 2016 Owner's Manual

The ID number of the electrical component correspond-
ing to each fuse can be found on the back of the cover.
CavityMaxi Fuse Mini Fuse Description
F01 40 Amp Orange –Electronic Stability Control (ESC) Pump
F02 20 Amp Yellow
(3.6 Gasoline Engine) –
Starter Relay 3.6L (3.6 Gasoline Engine)
F02 50 Amp Red
(3.0 Diesel Engine) –
Glow Plug Unit (3.0 Diesel Engine)
F04 50 Amp Red
(3.6 Gasoline Engine) –
Secondary Power Distribution Center
(PDC) (Trans Power Relay, Vacuum Pump,
KL30 for the Shifter Transmission Module
[STM]) (3.6 Gasoline Engine)
F04 40 Amp Orange (3.0 Diesel Engine) –
Fuel Filter Heater (3.0 Diesel Engine)
388 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F15 –7.5 Amp Brown USB Charger
F16 –7.5 Amp Brown KL15 Shifter Transmission Module (STM)
(3.6), KL15 Starter Relay Coil (3.6 Gasoline
Engine)
F16 –7.5 Amp Brown KL15 Manual Transmission Automated
(MTA), KL15 Shift Lever Unit, KL15 En-
gine Control Module (ECM), KL15 Starter
Relay Coil (3.0 Diesel Engine)
F17 –20 Amp Yellow Engine Control Module (ECM), Injectors
(3.6 Gasoline Engine)
F17 –20 Amp Yellow Secondary Loads, Engine Control Module
(ECM) (3.0 Diesel Engine)
F18 –7.5 Amp Brown KL30 Engine Control Module (ECM),
KL30 Main Relay Coil (3.6 Gasoline En-
gine)
390 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F18 –7.5 Amp Brown KL30 Manual Transmission Automated
(MTA), KL30 Engine Control Module
(ECM), KL30 Main Relay Coil (3.0 Diesel
Engine)
F19 –7.5 Amp Brown A/C Compressor (If Equipped)
F20 –30 Amp Green Windshield Wiper
F21 –15 Amp Blue Fuel Pump
F22 –20 Amp Yellow Engine Control Module (ECM), Ignition
Coils (3.6 Gasoline Engine)
F22 –20 Amp Yellow Engine Control Module (ECM), Primary
Loads (3.0 Diesel Engine)
F23 –20 Amp Yellow Electronic Stability Control (ESC) Valves
F24 –7.5 Amp Brown KL15 Vacuum pump relay coil (3.6 Gaso-
line Engine) — If Equipped
F30 –15 Amp Blue Heated Mirrors
