Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor identification
DF037
present
None.NOTES
This fault is normally present when the computer detects an inconsistency between the recognition signal
emitted by the side sensor and the programming which it has received.
Either the side sensor is not adapted to the vehicle, or the computer comes from another vehicle.
If the sensor has been replaced, fit another sensor adapted to the vehicle.
If the computer comes from another vehicle, use the "Side sensor programming" command on the fault
finding tool to change the computer’s programming.
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-71

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor
DF038
present
None.NOTES
Replace the driver’s side sensor
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-72

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor circuit
DF039
present
None.NOTES
Lock the computer using the fault finding tool command.
Check that the driver’s side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 20 and 21).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the driver’s side sensor then switch on the ignition.
Erase the computer memory then switch off the ignition Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-73

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor circuit
DF040
present
None.NOTES
Lock the computer using the command on the fault finding tool.
Check that the passenger side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 22 and 23).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the passenger side sensor then switch on the ignition
again. Erase the computer memory then switch off the ignition.
Carry out a check using the fault finding tool and, in the absence of a fault, unlock
the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-74

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Disrupted passenger’s side sensor signal(or in open circuit)DF041
present
None.NOTES
Lock the computer using the command on the fault finding tool.
Check that the passenger side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 22 and 23).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the passenger side sensor then switch on the ignition
again.Erase the computer memory then switch off the ignition. Carry out a check using the
fault finding tool and, in the absence of a fault, unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-75

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor identification
DF042
present
None.NOTES
This fault is normally present when the computer detects an inconsistency between the recognition signal
emitted by the side sensor and the programming which it has received.
Either the side sensor is not adapted to the vehicle, or the computer comes from another vehicle.
If the sensor has been replaced, fit another sensor adapted to the vehicle.
If the computer comes from another vehicle, use the "Side sensor programming" command on the fault
finding tool to change the computer’s programming.
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-76

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor
DF043
present
None.NOTES
Replace the passenger’s side sensor.
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-77

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor configuration
DF051
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment .
The vehicle must be fitted with side air bag sensors not declared in the computer configuration, especially
the driver’s side sensor.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory then switch off the ignition
Carry out a check again using the fault finding tool
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-84

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor configuration
DF052
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment .
The vehicle must be fitted with side air bag sensors not declared in the computer configuration, especially
the passenger’s side sensor.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory then switch off the ignition
Carry out a check again using the fault finding tool
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-85

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
Only carry out this conformity check after a complete check using the fault finding
tool.NOTES
Order FunctionParameter / status checked or
actionDisplay /notes Diag
1
Computer conformityPR002
VEHICLE TYPE
Clio II : 06
Replace computer if not
suitable None
2
Computer
configurationDriver’s pretensioner
Passenger’s pretensioner
Driver’s front air bag
Passenger’s front air bag
Driver’s side air bag
Passenger’s side air bag
Driver’s side sensor
Passenger’s side sensorEnsure that the computer
configuration corresponds to
the vehicle equipment.None
3Operation of warning
light
Check computer
initialisationIgnition onIllumination of the warning
light for 3 seconds when the
ignition is switched on None
FAULT FINDING - CHECKING CONFORMITY
WIRING
Air bags and seat belt pretensionersSIDE
88
88-86
