AFTER REPAIR
NoneNOTES CC.1 - CC.0
DF029
present
CONT
Reconnect the computer and the driver’s pretensioner ignition module , switch the ignition
on again. Erase the computer memory, then switch off the ignition. Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer. Destroy the
pretensioners if there has
been a replacement (tool Elé. 1287).
Lock the computer using the command on the fault finding tool.
Disconnect the ignition module for the driver’s pretensioner and connect a dummy ignition module to
the ignition module connector.
Switch on the ignition and carry out a check using the fault finding tool.
If the fault is memorised (fault no longer declared present), check the condition of the seat wiring.
Replace the driver’s pretensioner if the wiring is not faulty.
Disconnect the computer connector and fit the 30 track B40 adaptor.
The XRBAG must be used for insulation measurements appropriate to the type of fault on adaptor cable
D . If the value obtained is not correct, check the connections on the 30 track connector (tracks 1 and 2)
and replace the wiring if necessary
If the checks carried out do not indicate the presence of a fault on the driver’s pretensioner circuit, check
on the air bag computer base for the 5 shunt opening pins for the 30 track adaptor.
Check the condition of the computer connections.
Check the condition of the 30 track connector (locking system, ...).
The XRBAG must be used for insulation measurements appropriate to the type of fault on point C1 (seat
connector) on the driver’s pretensioner line.
If the value is not correct, replace the wiring betweenpoints C1 and C3 (seat wiring).
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-39
Page 42 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Reconnect the computer and the pretensioner ignition module , switch the ignition on
again. Erase the computer memory, then switch off the ignition. Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer. Destroy the
pretensioners if there
has been a replacement (tool Elé. 1287).
Passenger’s pretensioner circuit
CC : Short circuit
CO : Open circuit
CC.1 : Short circuit to 12 volts
CC.0 : Short circuit to earthDF030
present
NOTESNever carry out measures on the triggering lines with equipment other than the
XRBAG.
NoneNOTES CO - CC
Lock the computer using the command on the fault finding tool.
Switch off the ignition and check that the passenger’s pretensioner ignition module is connected
correctly.
Disconnect the ignition module for the passenger’s pretensioner and connect a dummy ignition module
to the ignition module connector.
Switch on the ignition and carry out a check using the fault finding tool.
Replace the passenger’s pretensioner if the fault is memorised (no longer declared as present).
If the checks carried out do not indicate the presence of a fault, check on the air bag computer base for
the 5 shunt opening pins for the 30 track adaptor.
Check the condition of the computer connections.
Check the condition of the 30 track connector (locking system, ...).
The XRBAG must be used to measure resistance on point C1 (seat connector) of the passenger’s
pretensioner line.
If the value is not correct, replace the wiring betweenpoints C1 and C3 (seat wiring).
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
Disconnect the computer connector and fit the 30 track B40 adaptor.
The XRBAG must be used for resistance measurements onadaptor cable C . If the value is not correct,
check the connections on the 30 track connector (tracks 3 and 4) and replace the wiring if necessary
88-40
Page 43 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
NoneNOTES CC.1 - CC.0
DF030
present
CONT
Lock the computer using the command on the fault finding tool.
Disconnect the ignition module for the passenger’s pretensioner and connect a dummy ignition module
to the ignition module connector.
Switch on the ignition and carry out a check using the fault finding tool.
If the fault is memorised (no longer declared as present), check the condition of the seat wiring.
Replace the passenger’s pretensioner if the wiring is not faulty.
Disconnect the computer connector and fit the 30 track B40 adaptor.
The XRBAG must be used for insulation measurements appropriate to the type of fault on adaptor cable
C . If the value is not correct, check the connections on the 30 track connector (tracks 3 and 4) and replace
the wiring if necessary
If the checks carried out do not indicate the presence of a fault on the passenger’s pretensioner circuit,
check on the air bag computer base for the 5 shunt opening pins for the 30 track adaptor.
Check the condition of the computer connections.
Check the condition of the 30 track connector (locking system, ...).
The XRBAG must be used for insulation measurements appropriate to the type of fault on point C1 (seat
connector) on the passenger’s pretensioner line.
If the value is not correct, replace the wiring betweenpoints C1 and C3 (seat wiring).
Reconnect the computer and the pretensioner ignition module, switch the ignition on
again. Erase the computer memory, then switch off the ignition. Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer. Destroy the
pretensioner if there has been a replacement (tool Elé. 1287).
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-41
Page 44 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Computer locked
DF034
present
None.NOTES
This fault enables the locked condition of the computer to be seen.
When it is present, all trigger lines are inhibited, which prevents triggering of the air bags and seat belt
pretensioners.
This fault is normally present in two circumstances :
- The computer is new (it is sold locked).
- The computer locking command on the fault finding tool has been used during an operation on the
vehicle.
Erase the computer memory and switch off the ignition.
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-42
Page 45 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Erasing locked memorised faults
DF035
present
None.NOTES
This fault is normally present following an impact in the presence of memorised faults
This locking prevents accidental erasing of the registered contexts of impacts which lead to the systems
being triggered (the contexts are erased using the erasing command for the fault memory).
These contexts will be used later to simplify the repair of vehicles involved in accidents and also for
examination needs .
Erase the computer memory and switch off the ignition.
Carry out a check again using the fault finding tool.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-43
Page 46 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s front air bag configuration
DF045
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment.
The vehicle must be fitted with triggering lines which are not declared in the computer configuration,
especially the driver’s front air bag triggering line.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory and switch off the ignition.
Carry out a check again using the fault finding tool.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-44
Page 47 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Front passenger air bag configuration
DF046
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment.
The vehicle must be fitted with triggering lines which are not declared in the computer configuration,
especially the passenger’s front air bag triggering line.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory and switch off the ignition.
Carry out a check again using the fault finding tool.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-45
Page 48 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s pretensioner configuration
DF047
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment.
The vehicle must be fitted with triggering lines which are not declared in the computer configuration,
especially the driver’s pretensioner triggering line.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory and switch off the ignition.
Carry out a check again using the fault finding tool.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-46
Page 49 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s pretensioner configuration
DF048
present
None.NOTES
The presence of this fault corresponds to an incoherence detected by the computer between the
computer configuration and the vehicle equipment.The vehicle must be fitted with triggering lines which
are not declared in the computer configuration, especially the passenger’s pretensioner triggering line.
Change the computer configuration using the fault finding tool command "Configuration of the system’s
components"
Erase the computer memory and switch off the ignition.
Carry out a check again using the fault finding tool.
FAULT FINDING- INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensioners
88
FRONT
88-47
Page 50 of 90
Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
Only carry out this conformity check after a complete check using the fault finding
tool.NOTES
Order FunctionParameter / status checked or
actionDisplay/notes Diag
1 Computer conformity
PR002
VEHICLE TYPE
Clio II : 06
Replace computer if not
suitable None
2Computer
configurationDriver’s pretensioner
Passenger’s pretensioner
Driver’s front air bag
Passenger’s front air bagEnsure that the computer
configuration corresponds to
the vehicle equipment.None
3Operation of warning
light
Check computer
initialisationIgnition onIllumination of the warning
light for 3 seconds when the
ignition is switched on None
FAULT FINDING- CHECKING CONFORMITY
WIRING
Air bags and seat belt pretensioners
88
FRONT
