Page 191 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
Driving your vehicle to fit the circumstances is essential
for your safety and comfort\f As a driver, you should be
the one \bho kno\bs best ho\b to drive in the given
circumstances\f
ENGINE COLD START PERIOD
Due to the higher engine speeds, \bhen the engine is
cold, extra caution must be exercised \bhen selecting a
gear during the engine \barm-up period after starting
the engine\f
LOADING LUGGAGE
Loads and their distribution and the attachment of
equipment (coupling devices, roof baggage carriers,
etc\f) \bill considerably change the driving character-
istics of the vehicle\f Your driving style and speed must
be adjusted according to the circumstances\f
DRIVING IN WET CONDITIONS
.Avoid accelerating or stopping suddenly\f
. Avoid sharp turning or lane changing suddenly\f
. Avoid follo\bing too close to the vehicle in front\f
When \bater covers the road surface \bith \bater
puddles, small \bater streams, etc\f, reduce speed to
prevent hydroplaning \bhich can cause skidding and
loss of control\f Worn tires \bill increase this risk\f
DRIVING IN WINTER CONDITIONS
. Drive cautiously\f
. Avoid accelerating or stopping suddenly\f
. Avoid sharp turning or lane changing suddenly\f
. Avoid sudden steering\f
. Avoid follo\bing too close to the vehicle in front\f
WARNING:
Never remove the key or turn the ignition switch
to the “LOCK” position while driving. The steer-
ing wheel will lock. This may cause the driver to
lose control of the vehicle and could result in
serious vehicle damage or personal injury.
AUTOMATIC TRANSMISSION (AT)/CON-
TINUOUSLY VARIABLE TRANSMISSION
(CVT)
SSD0392
The ignition lock is designed so that the ignition s\bitch
cannot be turned to the “LOCK” position until the
selector lever is moved to the “P” (Park) position\f
When moving the ignition s\bitch to the “LOCK”
position, to remove the key from the ignition s\bitch,
make sure the selector lever is in the “P” (Park)
position\f
When the ignition s\bitch cannot be turned to the
“LOCK” position:
1\f Move the selector lever to the “P” (Park) position\f
2\f Turn the ignition s\bitch slightly in the “ON” direction\f 3\f Turn the ignition s\bitch to the “LOCK” position\f
4\f Remove the key, if it is inserted in the ignition
s\bitch\f
If the ignition s\bitch is turned to the “LOCK” position,
the selector lever cannot be moved from the “P” (Park)
position\f The selector lever can be moved if the ignition
s\bitch is in the “ON” position \bith the foot brake pedal
depressed\f
The “OFF” position
*1is bet\been the “LOCK” and
“ACC” positions, although it is not marked on the
ignition s\bitch\f
MANUAL TRANSMISSION (MT)
SSD0392Type A
Starting and driving5-5
CARE WHEN DRIVING
IGNITION SWITCH (model without
intelligent Key system)
& R Q G L W L R Q
Page 192 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
5-6Starting and driving
SSD0503Type BThe ignition switch incl\fdes a device that hel\bs
\brevent accidental removal of the key while driving.
The key can only be removed when the ignition switch
is in the “LOCK” \bosition.
Ty\be B: To t\frn the ignition switch to the “LOCK”
\bosition from the “ACC” or “ON” \bosition, t\frn the key
to the “OFF” \bosition, \b\fsh the key in, then t\frn the key
to the “LOCK” \bosition.
The “OFF” \bosition
*1is between the “LOCK” and
“ACC” \bositions, altho\fgh it is not labeled on the
ignition switch.
STEERING LOCK
To lock steering wheel
1. T\frn the ignition switch to the “LOCK” \bosition.
2. Remove the key.
3. T\frn the steering wheel 1/6 of a t\frn clockwise from the straight \f\b \bosition.
To \fnlock steering wheel
1. Insert the key into the ignition switch.
2. Gently t\frn the ignition switch while rotating thesteering wheel slightly right and left.
KEY POSITIONS
LOCK (0)
The ignition key can only be removed at this \bosition.
The steering lock can only be locked at this \bosition.
OFF (1)
The engine is t\frned off with the steering wheel
\fnlocked.
ACC (2)
The electrical accessory \bower activates witho\ft the
engine t\frned on.
ON (3)
The ignition system and the electrical accessory \bower
activate witho\ft the engine t\frned on.
START (4)
The engine starter activates and the engine will start.
The ignition switch, when released, will a\ftomatically
t\frn to the “ON” \bosition.
CAUTION:
As soon as the engine has started, release the
ignition switch immediately.
PRECAUTIONS ON PUSH-BUTTON IGNI-
TION SWITCH OPERATION
WARNING:
Do not operate the push-button ignition switch
while driving the vehicle except in an emergency.
(The engine will stop when the ignition switch is
pushed 3 consecutive times or the ignition
switch is pushed and held for more than 2
seconds.) The steering wheel will lock and could
cause the driver to lose control of the vehicle.
This could result in serious vehicle damage or
personal injury.
Before o\berating the \b\fsh-b\ftton ignition switch, be
s\fre to move the selector lever to the “P” (Park)
\bosition (for A\ftomatic Transmission/Contin\f\lo\fsly
Variable Transmission model) or the shift lever to the
“N” (Ne\ftral) \bosition (for Man\fal Transmission model) .
INTELLIGENT KEY SYSTEM
The Intelligent Key system can o\berate the ignition
switch witho\ft taking the key o\ft from yo\fr \bocket or
bag. The o\berating environment and/or conditions may
affect the Intelligent Key system o\beration. Some
indicators and warnings for o\beration are dis\blayed
on the vehicle information dis\blay (if eq\fi\b\bed) and/or
in the meter. (See “Vehicle information dis\blay” (P.2-
20) and "Warning/indicator lights and a\fdible remin-
ders".)
CAUTION:
.Be sure to carry the Intelligent Key with you
when operating the vehicle.
. Never leave the Intelligent Key inside the
vehicle when you leave the vehicle.
PUSH-BUTTON IGNITION SWITCH
(model with Intelligent Key system)
& R Q G L W L R Q
Page 193 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
.If the vehicle battery is discharged, the
ignition switch cannot be switched from
the “LOCK” position, and if the steering lock
is engaged, the steering wheel cannot be
moved. Charge the battery as soon as
possible. (See “Jump starting” (P.6-8) .)
Operating range
SSD0436
The Intelligent \fey can only \be used for starting the
engine when the Intelligent \fey is within the specified
operating range
*1.
When the Intelligent \fey \battery is almost discharged
or strong radio waves are present near the operating
location, the Intelligent \fey system’s operating range
\becomes narrower and may not function properly.
If the Intelligent \fey is within the operating range, it is
possi\ble for anyone, even someone who does not carry
the Intelligent \fey, to push the ignition switch to start
the engine.
. The luggage room area is not included in the
operating range, \but the Intelligent \fey may
function.
. If the Intelligent \fey is placed on the instrument
panel, inside the glove \box, door pocket or the
corner of the interior compartment, the Intelligent \fey may not function.
. If the Intelligent \fey is placed near the door or
window outside the vehicle, the Intelligent \fey
may function.
Automatic transmission (AT)/Continuously
Varia\ble Transmission (CVT) model
The ignition lock is designed so that the ignition switch
cannot \be switched to the “LOC\f” position until the
selector lever is moved to the “P” (Park) position.
When pushing the ignition switch to the “OFF”
position, make sure the selector lever is in the “P”
(Park) position.
Type A (model with dot matrix display):
When the ignition switch cannot \be switched to the
“LOC\f” position:
1. SHIFT “P” warning appears on the dot matrix
display (in the vehicle information display) and a
chime sounds.
2. Move the selector lever to the “P” (Park) position.
3. If the ignition switch is in the “ACC” position, the “PUSH” warning appears on the dot matrix
display.
4. Push the ignition switch. The ignition switch is switched to the “ON” position.
5. The “PUSH” warning appears again on the dot matrix display.
6. Push the ignition switch. The ignition switch is switched to the “OFF” position.
7. Open the door. The ignition switch will change to the “LOC\f” position.
For warnings and indicators on the Vehicle information
display, see “Vehicle information display” (P.2-20) . Type B (model without dot matrix display) :
1. Move the selector lever to the “P” (Park) position.
2. Push the ignition switch to the “OFF” position.
3. Open the door. The ignition switch will change to
the “LOC\f” position.
If the ignition switch is switched to the “LOC\f”
position, the selector lever cannot \be moved from the
“P” (Park) position. The selector lever can \be moved if
the ignition switch is in the “ON” position with the foot
\brake depressed.
STEERING LOC\f
The ignition switch is equipped with an anti-theft
steering lock device.
To lock steering wheel
1. Push the ignition switch to the “OFF” position where the ignition switch position indicator will not
illuminate.
2. Open or close the door. The ignition switch turns to the “LOC\f” position.
3. Turn the steering wheel 1/6 of a turn to the right or left from the straight up position.
To unlock steering wheel
Push the ignition switch, and the steering wheel will \be
automatically unlocked.
CAUTION:
.If the battery of the vehicle is discharged, the
push-button ignition switch cannot be
switched from the “LOCK” position.
. If the ignition switch position does not
change from the “LOCK” position, push the
ignition switch again while rotating the
Starting and driving5-7
& R Q G L W L R Q
Page 194 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
5-8Starting and driving
steering wheel slightly to the right and left.
(See “Vehicle information \fisplay\b (P.2-20) .)
IGNITION SWITCH POSITIONS
SSD0859
When the ignition switch is pushe\f without \fepressing
the brake pe\fal (Automatic Transmission/Continu\tously
Variable Transmission mo\fel) or the clutch pe\fal
(Manual Transmission mo\fel) , the ignition switch
position will change as follows:
. Push once to change to “ACC\b.
. Push two times to change to “ON\b.
. Push three times to change to “OFF\b.
. Push four times to return to “ACC\b.
. Open or close any \foor to return to “LOCK\b when
in the “OFF\b position.
The in\ficator light
*Aon the ignition switch illumi-
nates when the ignition switch is in the “ACC\b or “ON\b
position.
LOCK position
The ignition switch an\f steering lock can only be
locke\f at this position.
The ignition switch will be unlocke\f when it is pushe\f
to the “ACC\b position while carrying the Intelligent Key.
ACC position
The electrical accessory power activates at this
position without the engine turne\f on.
ON position
The ignition system an\f the electrical accessory power
activate at this position without the engine turne\f on.
OFF position
The engine is turne\f off with the steering wheel
unlocke\f.
WARNING:
Never push the ignition switch to the “OFF\b
position while driving. The steering wheel may
lock and cause the driver to lose control of the
vehicle, resulting in serious vehicle damage or
personal injury.
CAUTION:
Do not leave the vehicle for extended periods of
time when the ignition switch is in the “ACC” or
“ON” position and the engine is not running.
This can discharge the battery.
NOTE:
When the ignition switch is pushed while the
Idling Stop System (if equipped) is activated, the
ignition switch will be placed in the "OFF" position.
INTELLIGENT KEY BATTERY DISCHARGE
SSD0860
If the battery of the Intelligent Key is \fischarge\f, or
environmental con\fitions interfere with the Intelligent
Key operation, start the engine accor\fing to the
following proce\fure:
1.
Automatic Transmission (AT)/Continuously
Variable Transmission (CVT) model:
Move the selector lever to the “P\b (Park) or “N\b
(Neutral) position.
Manual Transmission (MT) model:
Move the shift lever to the “N\b (Neutral) position.
2. Firmly \fepress the brake pe\fal (Automatic Trans- mission/Continuousl\ty Variable Transmission mo\f-
el) or the clutch pe\fal (Manual Transmission
mo\fel) .
3. Touch the ignition switch with the Intelligent Key as illustrate\f. (A chime will soun\f.)
4. Push the ignition switch while \fepressing the brake pe\fal within 10 secon\fs after the chime
soun\fs. The engine will start.
After step 3 is performe\f, when the ignition switch is
pushe\f without \fepressing the brake pe\fal, the
& R Q G L W L R Q
Page 195 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
ignition switch position will change to “ACC”.
NOTE:
.When the ignition switch is pushed to the
“ACC” or“ON” position or the engine is
started by the above procedures, the Intel-
ligent Key battery discharge indicator ap-
pears (on the Vehicle information display) or
the Intelligent Key system warning light may
blink in yellow (on the meter) even if the
Intelligent Key is inside the vehicle. This is
not a malfunction. To stop the warning light
from blinking, touch the ignition switch with
the Intelligent Key again.
. If the Intelligent Key battery discharge
indicator appears (on the Vehicle informa-
tion display) or the Intelligent Key system
warning light in the meter is blinking in
green, replace the battery as soon as
possible. (See “Battery”(P.8-23) .)GA\fOLI\bE E\bGI\bE
1. Apply the parking brake.
2. Depress the foot brake pedal.
3.Automatic Transmission (AT)/Continuously
Variable Transmission (CVT) model:
Move the selector lever to the “P” (Park) or “\b”
(\beutral) position.
The starter is designed to operate only when
the selector lever is in the proper position.
Manual Transmission (MT) model:
Move the shift lever to the “\b” (\beutral) position,
and depress the clutch pedal to the floor while
starting the engine.
The starter is designed to not operate unless
the clutch pedal is depressed.
4. Crank the engine with your foot off the accelerator pedal by turning the ignition switch to the “\fTART”
position.
5. Immediately release the ignition switch when the engine starts. If the engine starts, but fails to run,
repeat the above procedures.
If the engine is very hard to start in extremely cold
or hot weather, depress the accelerator pedal and
hold it to help start the engine.
CAUTION:
.Do not operate the starter for more than 15
seconds at a time. If the engine does not
start, turn the ignition switch off and wait 10
seconds before cranking the engine again.
Otherwise, the starter could be damaged.
. If it becomes necessary to start the engine
with a booster battery and jumper cables, the instructions and cautions contained in
the “6. In case of emergency” section should
be carefully followed.
6. Allow the engine to idle for at least 30 seconds after starting the engine to warm-up. Drive at
moderate speeds for a short distance first,
especially in cold weather.
CAUTION:
Do not leave the vehicle unattended while the
engine is warming up.
DIE\fEL E\bGI\bE
1. Apply the parking brake.
2. Depress the foot brake pedal.
3. Move the shift lever to the “\b” (\beutral) position,and depress the clutch pedal to the floor while
starting the engine.
4. Turn the ignition switch to the “O\b” position and wait until the glow plug indicator light
turns
off.
5. Crank the engine with your foot off the accelerator pedal by turning the ignition switch to the “\fTART”
position.
6. Immediately release the ignition switch when the engine starts. If the engine starts, but fails to run,
repeat the above procedures.
CAUTION:
.Do not operate the starter for more than 20
seconds at a time. If the engine does not
start, turn the ignition switch off and wait 20
seconds before cranking the engine again.
Otherwise, the starter could be damaged.
Starting and driving5-9
STARTING ENGINE (model without
Intelligent Key system)
& R Q G L W L R Q
Page 196 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
5-10Starting and driving
.If it becomes necessary to start the engine
with a booster battery and jumper cables,
the instructions and cautions contained in
the “6. In case of emergency” section should
be carefully followed.
7. Allow the engine to idle for \ft le\fst 30 seconds \ffter st\frting the engine to w\fr\b-up. Drive \ft
\boder\fte speeds for \f short dist\fnce first,
especi\flly in cold we\fther.
CAUTION:
Do not leave the vehicle unattended while the
engine is warming up.
GASOLINE ENGINE
1. Apply the p\frking br\fke.
2.Automatic Transmission (AT)/Continuously
Variable Transmission (CVT) model:
Move the selector lever to the “P” (P\frk) or the “N”
(Neutr\fl) position.
The starter is designed to operate only when
the selector lever is in the proper position.
Manual Transmission (MT) model:
Move the shift lever to the “N” (Neutr\fl) position.
The starter is designed to not operate unless
the clutch pedal is fully depressed.
The Intelligent Key must be carried when
operating the ignition switch.
3. Push the ignition switch to the “ON” position. Depress the br\fke ped\fl (AT/CVT \bodel) or the
clutch ped\fl (MT \bodel) \fnd push the ignition
switch to st\frt the engine.
To st\frt the engine i\b\bedi\ftely, push \fnd rele\fse
the ignition switch while depressing the br\fke
ped\fl or clutch ped\fl with the ignition switch in
\fny position.
4. I\b\bedi\ftely rele\fse the ignition switch when the engine st\frts. If the engine st\frts, but f\fils to run,
repe\ft the \fbove procedures.
If the engine is very h\frd to st\frt in extre\bely cold
or hot we\fther, depress the \fcceler\ftor ped\fl \fnd
hold it. Push the ignition switch for up to 15
seconds while holding. Rele\fse the \fcceler\ftor
ped\fl when the engine st\frts.CAUTION:
.As soon as the engine has started, release
the ignition switch immediately.
. Do not operate the starter for more than 15
seconds at a time. If the engine does not
start, push the ignition switch to the “OFF”
position and wait 10 seconds before crank-
ing the engine again. Otherwise, the starter
could be damaged.
. If it becomes necessary to start the engine
with a booster battery and jumper cables,
the instructions and cautions contained in
the “6. In case of emergency” section should
be carefully followed.
5. Allow the engine to idle for \ft le\fst 30 seconds \ffter st\frting the engine to w\fr\b-up. Drive \ft
\boder\fte speeds for \f short dist\fnce first,
especi\flly in cold we\fther.
CAUTION:
Do not leave the vehicle unattended while the
engine is warming up.
6. To stop the engine, \bove the selector lever to the“P” (P\frk) position (AT/CVT \bodel) or \bove the
shift lever to the “N” (Neutr\fl) position (MT \bodel) ,
\fpply the p\frking br\fke \fnd push the ignition
switch to the “OFF” position.
STARTING ENGINE (model with
Intelligent Key system)
& R Q G L W L R Q
Page 197 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
DIESEL ENGINE
1. Apply the park\fng brake.
\b. Move the sh\fft lever to the “N” (Neutral) pos\ft\fon.The starter is designed to not operate unless
the clutch pedal is fully depressed.
The Intelligent Key must be carried when
operating the ignition switch.
3. Push the \fgn\ft\fon sw\ftch to the “ON” pos\ft\fon and wa\ft unt\fl the glow plug \fnd\fcator l\fght turns off.
Depress the clutch pedal and push the \fgn\ft\fon
sw\ftch to start the eng\fne.
To start the eng\fne \fmmed\fately, push and release
the \fgn\ft\fon sw\ftch wh\fle depress\fng the clutch
pedal w\fth the \fgn\ft\fon sw\ftch \fn any pos\ft\fon.
4. Immed\fately release the \fgn\ft\fon sw\ftch when the eng\fne starts. If the eng\fne starts, but fa\fls to run,
repeat the above procedures.
If the eng\fne \fs very hard to start \fn extremely cold
or hot weather, depress the accelerator pedal and
hold \ft. Push the \fgn\ft\fon sw\ftch for up to 15
seconds wh\fle hold\fng. Release the accelerator
pedal when the eng\fne starts.
CAUTION:
.As soon as the engine has started, release
the ignition switch immediately.
. Do not operate the starter for more than 20
seconds at a time. If the engine does not
start, push the ignition switch to the “OFF”
position and wait 20 seconds before crank-
ing the engine again. Otherwise, the starter
could be damaged. .
If it becomes necessary to start the engine
with a booster battery and jumper cables,
the instructions and cautions contained in
the “6. In case of emergency” section should
be carefully followed.
5. Allow the eng\fne to \fdle for at least 30 seconds after start\fng the eng\fne to warm-up. Dr\fve at
moderate speeds for a short d\fstance f\frst,
espec\fally \fn cold weather.
CAUTION:
Do not leave the vehicle unattended while the
engine is warming up.
6. To stop the eng\fne, move the sh\fft lever to the “N”(Neutral) pos\ft\fon, apply the park\fng brake and
push the \fgn\ft\fon sw\ftch to the “OFF” pos\ft\fon.
DRIVING WITH AUTOMATIC TRANSMIS-
SION (AT)
The Automat\fc Transm\fss\fon (AT) \fn your veh\fcle \fs
electron\fcally controlled to produce max\fmum power
and smooth operat\fon.
The recommended operat\fng procedures for th\fs
transm\fss\fon are shown on the follow\fng pages. Follow
these procedures for max\fmum veh\fcle performance
and dr\fv\fng enjoyment.
CAUTION:
.The cold engine idle speed is high, so use
caution when shifting the transmission into
a forward or reverse position before the
engine has warmed up.
. Avoid revving up the engine while the
vehicle is stopped. This could cause unex-
pected vehicle movement.
. Do not downshift abruptly on slippery roads.
This may cause a loss of control.
. Never shift to either the “P” (Park) or “R”
(Reverse) position while the vehicle is mov-
ing. This could cause serious damage to the
transmission.
. Start the engine in either the “P” (Park) or
“N” (Neutral) position. The engine will not
start in any other position. If it does, have
your vehicle checked by a RENAULT dealer.
. Shift into the “P” (Park) position and apply
the parking brake when at a standstill for
longer than a short waiting period.
. Keep the engine at idling speed while
shifting from the “N” (Neutral) position to
any driving position.
Starting and driving5-11
DRIVING VEHICLE
& R Q G L W L R Q
Page 198 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
5-12Starting and driving
.When stopping the vehicle on an uphill
grade, do not hold the vehicle by depressing
the accelerator pedal. The foot brake pedal
should be depressed in this situation.
Starting vehicle
1. After \ftarting the engine, fully \bepre\f\f the foot
brake pe\bal before \fhifting the \felector lever out
of the “P” (Park) po\fition.
2. Keep the foot brake pe\bal \bepre\f\fe\b an\b move the \felector lever to a \briving po\fition.
3. Relea\fe the parking brake, the foot brake pe\bal, an\b then gra\bually \ftart the vehicle in motion.
The AT is designed so the foot brake pedal
MUST be depressed before shifting from the “P”
(Park) position to any driving position while the
ignition switch is in the “ON”position.
The selector lever cannot be moved out of the
“P” (Park) position and into any of the other gear
positions if the ignition switch is turned to the
“LOCK” ,“OFF” or“ACC” position or if the key is
removed.
CAUTION:
. DEPRESS THE FOOT BRAKE PEDAL - Shift-
ing the selector lever to “D”, “R”, “2” or “1”
without depressing the foot brake pedal
causes the vehicle to move slowly when
the engine is running. Make sure the foot
brake pedal is depressed fully and the
vehicle is stopped before shifting the selec-
tor lever.
. MAKE SURE OF THE SELECTOR LEVER
POSITION - Make sure the selector lever is
in the desired position. “D”, “2” and “1” are
used to move forward and “R” to back up. .
WARM UP THE ENGINE - Due to the higher
idle speeds when the engine is cold, extra
caution must be exercised when shifting the
selector lever into the driving position
immediately after starting the engine.
Shifting gear
JVS0008XLeft-Hand Drive (LHD) model
JVS0009XRight-Hand Drive (RHD) model
: Pu\fh the button*Awhile \bepre\f\fing the
foot brake pe\bal.
: Pu\fh the button*A.
: Ju\ft move the \felector lever.
WARNING:
. Apply the parking brake if the selector lever
is in any position while the engine is not
running. Failure to do so could cause the
vehicle to move unexpectedly or roll away
and result in serious personal injury or
property damage.
. If the selector lever cannot be moved from
the P (Park) position while the engine is
running and the foot brake pedal is de-
pressed, the stop lights may not work.
Malfunctioning stop lights could cause an
accident injuring yourself and others.
After \ftarting the engine, fully \bepre\f\f the foot brake
pe\bal, pu\fh the \felector lever button an\b move the
\felector lever out of the P (Park) po\fition.
If the ignition \fwitch i\f the OFF or ACC po\fition for any
rea\fon while the \felector lever i\f in any po\fition\f other
than the P (Park) po\fition, the ignition \fwitch cannot
be turne\b to the LOCK po\fition.
If the ignition \fwitch cannot be the LOCK po\fition,
perform the following \ftep\f:
1. Apply the parking brake.
2. Place the ignition \fwitch in the ON po\fition while \bepre\f\fing the foot brake pe\bal.
3. Move the \felector lever to the P (Park) po\fition.
4. Mo\bel with Intelligent Key \fy\ftem: Place the ignition \fwitch in the OFF po\fition.
Mo\bel without Intelligent Key \fy\ftem: Place the
ignition \fwitch in the LOCK po\fition.
& R Q G L W L R Q
Page 199 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
P (Park):
Use this position when the vehicle is parked or when
starting the engine.Make sure that the vehicle is
completely stopped and move the selector lever
into the P (Park) position. \fpply the parking brake.
When parking on a hill\b apply the parking brake first\b
and then move the selector lever into the P (Park)
position.
R (Reverse):
Use this position to back up. Make sure that the vehicle
is completely stopped before selecting the R (Reverse)
position.
N (Neutral):
Neither the forward nor reverse gear is engaged. The
engine can be started in this position. You may shift to
the N (Neutral) position and restart a stalled engine
while the vehicle is moving.
D (Drive):
Use this position for all normal forward driving.
2 (Second gear):
Use this position for climbing hills or engine braking on
downhill grades.
1 (Low gear):
Use this position when climbing steep hills slowly or
driving slowly through deep snow\b or for maximum
engine braking on steep downhill grades.
Do not shift into the gears when the vehicle speed
exceeds the following limits\b otherwise the engine may
over-rev and cause engine damage. Engine model
Selector lever position
12
HR12DE
km/h (MPH) 45 (28) 90 (56)
HR15DE
km/h (MPH) 50 (30)
95 (60)
Overdrive switch
JVS0013XLeft-Hand Drive (LHD) modelEach time the engine is started\b the overdrive function
is automatically reset to “ON”.
“ON” position:
With the engine running and the selector lever in the
“D” (Drive) position\b the transmission upshifts into the
overdrive as vehicle speed increases.
Overdrive does not engage until the engine has
reached operating temperature.
“OFF” position:
For driving up and down long slopes where engine
braking is necessary\b push the overdrive switch. The
overdrive off indicator light
in the meter panel
illuminates.
When cruising at a low speed or climbing a gentle
slope\b you may feel uncomfortable shift shocks as the transmission shifts into and out of the overdrive
repeatedly. In this case\b push the overdrive switch to
turn the overdrive “OFF”.
When driving conditions change\b push the overdrive
switch to turn the overdrive “ON”. The overdrive off
indicator light will turn off.
Remember not to drive at high speeds for extended
periods of time with the overdrive “OFF”. This reduces
fuel economy.
\fccelerator downshift - in D (Drive) position
For passing or climbing hills\b depress the accelerator
pedal to the floor. This shifts the transmission down
into a lower gear\b depending on the vehicle speed.
Shift lock release
If the battery is discharged\b the selector lever may not
be moved from the “P” (Park) position even with the
foot brake pedal depressed.
To move the selector lever\b release the shift lock. The
selector lever can be moved to the “N” (Neutral)
position. However\b the steering wheel will be locked
unless the ignition switch is placed in the “ON”
position. This allows the vehicle to be moved if the
battery is discharged.
Starting and driving5-13
& R Q G L W L R Q
Page 200 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
5-14Starting and driving
JVS0014XRight-Hand Drive (RHD) modelTo release the shi\ft lock, \ber\form the \following
\brocedure
1. Models with Intelligent KEY system: Place theignition switch in the “OFF” or “LOCK” \bosition.
Models without Intelligent KEY system: Place the
ignition switch in the “LOCK” \bosition and remove
the key.
2. A\b\bly the \barking brake.
3. De\bress the shi\ft lock release button.
4. Push and hold the selector lever button and move the selector lever to the “N” (Neutral) \bosition
while holding down the shi\ft lock release button.
5. Place the ignition switch to the “ON” \bosition to release the steering wheel lock.
The vehicle may be moved, by \bushing, to the desired
location.
I\f the selector lever cannot be moved out o\f the “P”
(Park) \bosition, have a RENAULT dealer check the AT
system as soon as \bossible.
Fail-sa\fe
When the \fail-sa\fe o\beration occurs, the AT will be
locked in third gear.
If the vehicle is driven under extreme conditions,
such as excessive wheel spinning and subse-
quent hard braking, the fail-safe system may be
activated. This will occur even if all electrical
circuits are functioning properly. In this case,
turn the ignition switch off and wait for 3
seconds. Then turn the ignition switch back to
the “ON” position. The vehicle should return to
its normal operating condition. If it does not
return to its normal operating condition, have a
RENAULT dealer check the transmission and
repair it if necessary.
DRIVING WITH CONTINUOUSLY VARI-
ABLE TRANSMISSION (CVT)
The Continuously Variable Transmission (CVT) in your
vehicle is electronically controlled to \broduce maximum
\bower and smooth o\beration.
The recommended o\berating \brocedures \for this
transmission are shown on the \following \bages. Follow
these \brocedures \for maximum vehicle \ber\formance
and driving enjoyment.
WARNING:
Do not downshift abruptly on slippery roads.
This may cause a loss of control.
CAUTION:
. The cold engine idle speed is high, so use
caution when shifting the transmission into
a forward or reverse position before the
engine has warmed up. .
Avoid revving up the engine while the
vehicle is stopped. This could cause unex-
pected vehicle movement.
. Never shift to either the “P” (Park) or “R”
(Reverse) position while the vehicle is mov-
ing. This could cause serious damage to the
transmission.
. Start the engine in either the “P” (Park) or
“N” (Neutral) position. The engine will not
start in any other position. If it does, have
your vehicle checked by a RENAULT dealer.
. Shift into the “P” (Park) position and apply
the parking brake when at a standstill for
longer than a short waiting period.
. Keep the engine at idling speed while
shifting from the “N” (Neutral) position to
any driving position.
. When stopping the vehicle on an uphill
grade, do not hold the vehicle by depressing
the accelerator pedal. The foot brake pedal
should be depressed in this situation.
Starting vehicle
1. A\fter starting the engine, \fully de\bress the \foot
brake \bedal be\fore moving the selector lever out
o\f the “P” (Park) \bosition.
2. Kee\b the \foot brake \bedal de\bressed and move the selector lever to a driving \bosition.
3. Release the \barking brake, the \foot brake \bedal, and then gradually start the vehicle in motion.
The CVT is designed so the foot brake pedal
MUST be depressed before shifting from the “P”
(Park) position to any driving position while the
ignition switch is in the “ON”position.
& R Q G L W L R Q
