PETROL INJECTION
Fault finding - Conformity check
17B
17B-130
PETROL INJECTION
Fault finding - Conformity check
17B
17B-130V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB-FUNCTION: DRIVER PARAMETERS (continued 1):
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
10Accelerator
pedal and
motorised
throttleET075:Pedal released and
throttle closedYESIf NO, apply the
interpretation for
PR030 Accelerator
pedal position
followed by the
interpretation for fault
DF079 Motorised
throttle valve servo
control.
11
Motorised
throttlePR597:Motorised throttle in
safe mode15% < PR597 < 25%Run command
RZ005
Programming. If the
parameters or
statuses are still not
correct, contact the
Techline. 12 PR593:Motorised throttle in
safe mode gang 1PR593 ≈ 1 V
13 PR594:Motorised throttle in
safe mode gang 2PR594 ≈ 1 V
14Accelerator
pedalET081:Accelerator pedal
positionNo load
Full load
INTERMEDIATEIn the event of a fault
apply the
interpretation for
PR030 Accelerator
pedal position
15Accelerator
pedalPR030:Accelerator pedal
positionNo load = < 16%
PF ≥85%In the event of a fault,
apply interpretation of
DF196 and DF198
Pedal sensor circuit
gangs 1 and 2, then
DF011 and DF012
Sensor supply
voltage 1 and 2.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-154
PETROL INJECTION
Fault finding - Conformity check
17B
17B-154V9 MR-372-J84-17B050$517.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB-FUNCTION: DRIVER PARAMETERS (continued 1):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status Checked
or ActionDisplay and notes Fault finding
10Accelerator
pedal and
motorised
throttleET075:Pedal released and
throttle closedYESIf NO, apply the
interpretation of
PR030 Accelerator
pedal position
followed by the
interpretation of fault
ET082 Motorised
throttle valve servo
control.
11
Motorised
throttlePR597:Motorised throttle in
safe mode15% < PR597 < 25%Run command
RZ005
Programming. If the
parameters or
statuses are still not
correct, contact the
Techline. 12 PR593:Motorised throttle in
safe mode gang 1PR593≈ 1 V
13 PR594:Motorised throttle in
safe mode gang 2PR594≈ 1 V
14
Accelerator
pedalET081:Accelerator pedal
positionNo load
Full load
NOT DETECTEDIn the event of a fault
apply the
interpretation for
PR030 Accelerator
pedal position
15 PR030:Accelerator pedal
positionNo load = 0%
Full load = 100%In the event of a fault,
apply interpretation of
DF008 and DF009
Pedal potentiometer
circuit track 1 and
track 2, then DF011
and DF012 Sensor
supply voltage 1 and
2.
