cruise control RENAULT SCENIC 2010 J95 / 3.G Petrol Injection S3000 Injection Owner's Guide

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 186
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 186V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
CRUISE CONTROL/SPEED LIMITER DEACTIVATION
NOTESSpecial notes:
Only perform the tests if the statuses do not correspond with the system programming
functions.
Note:
Cruise control can be activated when the vehicle speed exceeds 18 mph (30 km/h).
Status ET415 displays the various reasons for deactivation of the cruise control/speed limiter function, which are
due to driver demand or the exterior environment.
IMPORTANT
Clear the fault memory by running command RZ001 "Fault memory", to reset this status to "NONE".
NONEThis status is present on the diagnostic tool when:
The computer has been reinitialised.
The computer has been reprogrammed
STATUS 1Traction control request
If the vehicle is fitted with a traction control system, the cruise control function is
deactivated every time the ABS computer calls for traction control.
Status ET415 becomes STATUS 1 when driving with the cruise control active (ET042
Cruise control/Speed limiter: CRUISE CONTROL) and traction control is requested.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 1 with no traction control request (see 38C, Anti-lock
Braking System).
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool
S3000_V4C_ET415/S3000_V54_ET415

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 187
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 187V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
(CONTINUED 1)
STATUS 2Brake pedal depressed
The cruise control function is deactivated when the brake pedal is depressed.
Status ET415 becomes STATUS 2 when driving with cruise control active (ET042
Cruise control/Speed limiter: CRUISE CONTROL) and the brake pedal is depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 2 without depressing the brake pedal, consult the
interpretation of statuses ET704 Brake switch no. 1 and ET705 Brake switch no. 2.
STATUS 3Clutch pedal depressed
Manual gearbox ONLY
The cruise control function is deactivated when the gearbox is not coupled to the engine
(clutch pedal depressed).
Status ET415 becomes STATUS 3 when driving with cruise control active (ET042
Cruise control/speed limiter: CRUISE CONTROL) and the clutch pedal is depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 3 without the clutch pedal being depressed, consult
the interpretation of status ET405 Clutch pedal switch.
If the vehicle is fitted with automatic transmission:
Test the multiplex network: check the configuration of the multiplex network in relation to
the vehicle's technical specification, especially the configuration of the automatic
transmission computer (see 88B, Multiplexing)
STATUS 4Cancel button pressed
The cruise control/speed limiter function is deactivated whenever the suspend button is
pressed.
Status ET415 becomes STATUS 4 while driving when:
- Either the cruise control is active.
- Or the speed limiter is active,
- and the driver presses the 0 button.
This action deactivates the Cruise control/Speed limiter.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 4 without pressing the 0 button, consult the
interpretation of status ET703 Cruise control/speed limiter buttons and run fault
finding on the R/0 control button located on the right-hand side of the steering wheel.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 188
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 188V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
(CONTINUED 2)
STATUS 5Cruise control or speed limiter monitoring
This status appears when the vehicle brakes or decelerates sharply without the injection
computer receiving a signal indicating that the brake pedal switch has been pressed.
If status ET415 is STATUS 5, refer to the interpretation of:
- status ET042 Cruise control/Speed limiter,
- status ET703 Cruise control/speed limiter buttons,
- status ET704 Brake switch no. 1,
- and status ET705 Brake switch No 2,
to test the cruise control/speed limiter system components and find the defective
component.
In addition, check the operation of the accelerator pedal, and use the diagnostic tool to
check for a fault on it. Deal with them if necessary.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 changes to STATUS 5, deal with present faults or those stored in the
injection computer.
If the fault is still present, contact Techline.
STATUS 6Gear lever in neutral (manual gearbox) or the neutral position (automatic gearbox)
Status ET415 becomes STATUS 6, when driving with cruise control active (ET042:
Cruise control/speed limiter: CRUISE CONTROL) and:
- If the driver puts the gear lever in neutral position on a manual gearbox without
declutching or,
- if the gear lever is in neutral on an automatic gearbox.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 becomes STATUS 6 without shifting the gear lever into neutral on a
manual gearbox without declutching, or into neutral on an automatic transmission, test
the ABS computer and check the configuration of the tyre size stored in the computer.
If the configuration is correct, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 189
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 189V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
(CONTINUED 3)
STATUS 7Inconsistency between the request and the vehicle speed
Status ET415 becomes STATUS 7 if the computer detects too great a difference
between the speed requested by the driver and the vehicle speed.
STATUS 7 may occur when driving with the cruise control active (ET042 Cruise
control/speed limiter: CRUISE CONTROL) and when there is significant difference.
This inconsistency deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status ET415 changes to STATUS 7 where there is no significant difference in the
levels, contact the Techline.
STATUS 8Automatic transmission in defect mode.
Status ET415 becomes STATUS 8, when driving with cruise control active (ET042:
Cruise control/speed limiter: CRUISE CONTROL) and if the automatic transmission
is in defect mode.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the automatic transmission
computer.
Deal with any present or stored faults (see 23A, Automatic transmission,
interpretation of faults).
Clear the automatic transmission computer memory by running command RZ001 Fault
memory.
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status 8 continues, contact the Techline.
STATUS 9Vehicle speed monitoring
Status ET415 changes to STATUS 9 if the vehicle speed received by the computer is
invalid or absent.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the ABS computer.
Deal with present or stored faults (see 38C, Anti-lock braking system, Interpretation
of faults).
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If STATUS 9 is still present, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 190
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 190V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET415
(CONTINUED 4)
STATUS 10Monitoring by injection computer
Status ET415 becomes STATUS 10 when driving with cruise control active (ET042
Cruise control/speed limiter: CRUISE CONTROL) and if the injection computer
detects a fault anywhere in the engine management system, or an engine speed that is
too high or too low.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the injection computer.
Deal with any present or stored faults (see Interpretation of faults).
Reinitialise status ET415 on the injection computer by running command RZ001
"Fault memory".
If status 10 continues, contact the Techline.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 198
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 198V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET703
CRUISE CONTROL/SPEED LIMITER BUTTONS
NOTESSpecial notes:
Only perform the tests if the statuses do not correspond with the system programming
functions.
INACTIVEStatus ET703 becomes "INACTIVE" when none of the cruise control/speed limiter
buttons is pressed. These buttons are located on the steering wheel.
If status ET703 does not display "INACTIVE",
●check the condition of the cruise control/speed limiter +/- button and the condition of
its connector,
●check the condition of the cruise control/speed limiter R/0 button and the condition of
its connector.
INCREASEStatus ET703 becomes PLUS when the cruise control/speed limiter + button is pressed.
This button is on the steering wheel, on the left-hand side.
If status ET703 does not display PLUS, check the condition of the cruise control/speed
limiter +/- button, and the condition of its connector. Repair if necessary.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's front airbag (see MR 364 Mechanical, 88C,
Airbag and seat belt pretensioners, Driver's front airbag, Removal - Refitting)
Measure the resistance on the following connection with the "+" button pressed:
Injection computer,
connector A, black, 32-track track D2 "+/-" button track 2.
connector A, black, 32-track track D3 "+/-" button track 1.
If the resistance is not approximately 300 Ω, check the continuity of the connection when
the button is not pressed.
If there is continuity, replace the +/- control button.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
S3000_V4C_ET703/S3000_V54_ET703

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 199
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 199V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET703
CONTINUED 1
DECREASEStatus ET703 becomes MINUS when the cruise control/speed limiter - button is pressed.
This button is on the steering wheel, on the left-hand side.
If status ET703 does not change to MINUS, check the condition of the cruise control/
speed limiter "+/-" button, and the condition of its connector. Repair if necessary.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's front airbag (see MR 364 Mechanical, 88C,
Airbag and pretensioners, Driver's front airbag, Removal - Refitting).
Measure the resistance on the following connection with the "-" button pressed:
Injection computer,
connector A, black, 32-track track D2 "+/-" button track 2.
connector A, black, 32-track track D3 "+/-" button track 1.
If the resistance is not approximately 100Ω, check the continuity of the connection when
the button is not pressed.
If there is continuity, replace the "+/-" control button.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
RESUMEStatus ET703 becomes RESUME when the cruise control/speed limiter R button is
pressed. This button is located on the steering wheel, to the right.
If status ET703 does not change to RESUME, check the condition of the cruise control/
speed limiter R/0 button, and the condition of its connector. Repair if necessary.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's front airbag (see MR 364 Mechanical, 88C,
Airbag and pretensioners, Driver's front airbag, Removal - Refitting)
Measure the resistance of the following connection with the "R" button pressed:
Injection computer,
connector A, black, 32-track track D2 "+/-" button track 2.
connector A, black, 32-track track D3 "+/-" button track 1.
If the resistance is not approximately 900 Ω, check the continuity of the connection when
the button is not pressed.
If there is continuity, replace the "R/0" control button.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 200
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 200V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET703
CONTINUED 2
SUSPENDStatus ET703 becomes SUSPEND when the cruise control/speed limiter 0 button is
pressed. This button is located on the steering wheel, to the right.
If status ET703 does not change to SUSPEND, check the condition of the cruise control/
speed limiter R/0 button, and the condition of its connector.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's front airbag (see MR 364 Mechanical, 88C,
Airbag and pretensioners, Driver's front airbag, Removal - Refitting)
Measure the resistance of the following connection with the "0" button pressed:
Injection computer,
connector A, black, 32-track track D2 "+/-" button track 2.
connector A, black, 32-track track D3 "+/-" button track 1.
If the resistance is not approximately 0 Ω, replace the R/0 control button.
If there is continuity, replace the "R/0" control button.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition and carry out a road test followed by a test with the diagnostic
tool.
