2. REPLACING OR REMOVING THE TDC SENSOR
When replacing or removing the TDC sensor, program the flywheel target (see17B, Petrol injection,
Configuration and programming).
3. REPLACING THE MOTORISED THROTTLE VALVE
When replacing the throttle valve, the throttle stops are automatically programmed.
–PR058 Air temperature between 0°C and 105°C,
– wait for the end of power latch for the programming to be stored in the computer memory.
Check the programming using status ET051 Throttle stop programming is DONE.
When replacing the throttle valve, reinitialise the programming using command RZ005 Programming. IMPORTANT
– The injection computer retains the immobiliser code for life,
– the system has no security code,
– it is forbidden to perform tests with computers borrowed from the Parts Department or from another vehicle which
must then be returned. These computers are hard-coded.
IMPORTANT
Never drive the vehicle without having programmed the throttle stops.

PETROL INJECTION
Fault finding - Interpretation of faults
17B
17B-35
PETROL INJECTION
Fault finding - Interpretation of faults
17B
17B-35V9 MR-372-J84-17B050$329.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
DF002
PRESENT
AIR TEMPERATURE SENSOR CIRCUIT
1.DEF: Abnormal voltage
2.DEF: Non-compliance with emission control standards
NOTESPriority when dealing with a number of faults:
Deal with fault DF012 Sensor feed no. 2 voltage first, if it is present or stored.
Special note:
–OBD warning light illuminated.
– Refer to parameter PR058 Air temperature:
if PR058 = 120°C, short circuit to + 12 V,
if PR058 = - 40°C, short circuit to earth.
Check the cleanliness and condition of the air temperature sensor and its connections.
Disconnect the battery and the injection computer.
Check the cleanliness and condition of the connections.
Repair if necessary.
Use the "Universal bornier" to check the insulation and continuity of the following connections:
Injection computer, connectorB, track E3 track 2 of the air temperature sensor
Injection computer, connectorB, track E2 track 1 of the air temperature sensor
Repair if necessary.
Measure the resistance of the air temperature sensor between tracks 1 and 2.
Replace the air temperature sensor if the resistance is not:
9.6 kΩ ±1kΩ at an air temperature of -10°C
2000Ω ± 120Ω at an air temperature of 25°C
810Ω ±47Ω at an air temperature of 50°C
309Ω ±17Ω at an air temperature of 80°C
If the fault is still present, deal with the other faults then proceed with the conformity check.
AFTER REPAIRDeal with any faults declared by the diagnostic tool.
Clear the computer memory.
Carry out a road test followed by another check with the diagnostic tool.
S3000_V4C_DF002P/S3000_V54_DF002P

PETROL INJECTION
Fault finding - Conformity check
17B
17B-121
PETROL INJECTION
Fault finding - Conformity check
17B
17B-121V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB FUNCTION: SUB-FUNCTION (TURBOCHARGING/INLET):
NOTESOnly check the conformity after a complete check with the diagnostic tool. The values
shown in this conformity check are given as a guide.
Application conditions: Engine off, ignition on.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Air circuit
pressurePR035:Atmospheric
pressurePR035 = 1000 mb
± 100 mbIf not consistent, check
PR035 = PR312 = local
atmospheric pressure,
with the engine stopped
and ignition on.
2 PR312:Inlet manifold
vacuumPR312 = 1000 mb
± 100 mbIn the event of a fault
apply the interpretation for
PR312 Inlet manifold
vacuum.
3 Engine speed PR055:Engine speedIndicates the engine's
speed of rotation in
rpm.
PR055 = 0 rpmIn the event of a fault,
apply the interpretation for
DF154 Flywheel signal
sensor circuit.
4
Idle speedET054:Idle speed
regulationINACTIVE None
5 PR010:Idle speed
regulation
setting700 < X < 750 rpm
Indicates the speed of
rotation setpoint before
last engine stop in rpm.None
6Air
temperaturePR058:Air
temperature- 40°C < PR058 < 120°C
Default value: 120°CIn the event of a fault,
apply the interpretation of
DF002 Air temperature
sensor circuit.
7 Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064 < 120°C
Default value: - 39°CIn the event of a fault,
apply the interpretation of
DF001 Coolant
temperature sensor
circuit.

PETROL INJECTION
Fault finding - Conformity check
17B
17B-145
PETROL INJECTION
Fault finding - Conformity check
17B
17B-145V9 MR-372-J84-17B050$470.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
SUB FUNCTION: AIR CIRCUIT (TURBOCHARGING/INLET):
NOTESOnly perform this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application conditions: Engine warm, idling.
Order FunctionParameter or Status
Checked or ActionDisplay and notes Fault finding
1
Air circuit
pressurePR035:Atmospheric
pressure200 mb < PR035 < 1047 mbIf not consistent, check
PR035 = PR312 =
local atmospheric
pressure, with the
engine stopped and
ignition on.
In the event of a fault
apply the
interpretation for
PR312 Inlet manifold
vacuum. 2 PR312:Inlet manifold
vacuumFor K4M:
240 mb < PR312 < 410 mb
For K4J:
330 mb < PR312 < 400 mb
For > F4Rt:
270 mb < PR312 < 400 mb
For F4R:
270 mb < PR312 < 410 mb
3 Engine speed PR055:Engine speedShows the engine's speed
of rotation
in rpm.
PR055= 0rpmIn the event of a fault,
apply the
interpretation for
DF154 Flywheel
signal sensor circuit.
4
Idle speedET054:Idle speed
regulationINACTIVE None
5 PR010:Idle speed
regulation
setting700 < X < 750 rpm
Indicates the rotation
speed setpoint before last
engine stop
in rpm.None
6Air
temperaturePR058:Air
temperature- 40°C < PR058 < 120°C
Default value: 120°CIn the event of a fault,
apply the
interpretation of
DF002 Air
temperature sensor
circuit.
7 Coolant
temperaturePR064:Coolant
temperature- 40°C < PR064 < 120°C
Default value: 120°CIn the event of a fault,
apply the
interpretation of
DF001 Coolant
temperature sensor
circuit.

PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 174
PETROL INJECTION
Fault finding - Interpretation of statuses
17B
17B - 174V9 MR-372-J84-17B050$611.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54
ET054
IDLE SPEED REGULATION
ACTIVE
INACTIVE
NOTESThere must be no present or stored faults.
Check parameters: PR030 Accelerator pedal position,
PR035 Atmospheric pressure,
PR058 Air temperature,
PR064 Coolant temperature,
PR118 Measured throttle position gang 1,
PR119 Measured throttle position gang 2.
Check that all these parameters are completely correct.
IDLE SPEED TOO
HIGH
Check:
– the engine oil level (too high ⇒ oil combustion),
– that the restrictions are present in the oil vapour rebreathing circuit,
– the sealing between the throttle valve and inlet manifold,
– the manifold pressure sensor sealing,
– the fuel vapour absorber bleed, which must not be jammed open,
– the fuel vapour absorber bleed system sealing,
– the brake servo system sealing,
– the sealing between the inlet manifold and cylinder head,
– the oil vapour recovery circuit sealing between the inlet manifold and cylinder head,
– the fuel pressure and flow (see MR 364 or 370 Mechanics, 17B, Petrol injection),
– the condition and cleanliness of the injectors,
– the cylinder compressions,
– the timing adjustment,
– the hydraulic tappets if there is camshaft noise (see MR 364 or 370 Mechanics, 11A, Top and front of engine).
Repair the defective component if necessary.
AFTER REPAIRRepeat the conformity check from the start.
S3000_V4C_ET054/S3000_V54_ET054

PETROL INJECTION
17B
17B - 202
17B
17B - 202V9 MR-372-J84-17B050$658.mif
S3000 Injection
Program No.: AD
Vdiag No.: 4C / 54PETROL INJECTION
Fault finding - Parameter summary table
* OCR: Opening Cycle Ratio
* appli.: applicationTool parameter Diagnostic tool title
PR010Idling speed regulation setpoint
PR014Idling speed correction
PR018Estimated air flow
PR030Accelerator pedal position
PR035Atmospheric pressure
PR037Refrigerant pressure
PR055Engine speed
PR058Air temperature
PR064Coolant temperature
PR074Battery voltage
PR089Vehicle speed
PR090Idling speed regulation programming value
PR091OCR* Theoretical idle speed regulation
PR093Camshaft dephaser measured position
PR095Anti-pinking correction
PR096Motorised throttle upper stop programmed value
PR097Motorised throttle lower stop programmed value
PR098Upstream oxygen sensor voltage
PR099Downstream oxygen sensor voltage
PR101Duration of injection
PR102Canister bleed solenoid valve OCR*
PR103Instantaneous fuel consumption
PR105OBD fault warning light lit mileage counter
PR106Mileage counter fault warning light lit
PR111Motorised throttle position corrected value
PR113Throttle lower stop after offset appli.*
PR116Motorised throttle corrected position setpoint
