RENAULT TWINGO 2009 2.G Air Conditioning Workshop Manual

62A-30
AIR CONDITIONING
Dehydrator reservoir - expansion valve connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
aRemove:
-the bolts (4) from the bulkhead heat-resistant pro-
tectors,
-the bulkhead heat-resistant protectors (5) .aRemove the bolt (6) from the « dehydrator reservoir
- expansion valve » connecting pipe on the dehydra-
tor reservoir.
aSeparate the « dehydrator reservoir - expansion
valve » connecting pipe from the dehydrator reser-
voir.
aInsert the blanking plugs.
aRemove all of the « dehydrator reservoir - expansion
valve » and « expansion valve - intermediate pipe »
connecting pipes.
REFITTING
I - REFITTING PREPARATION OPERATION
a D4F, and 780 – K4M
123903
123908
121174
WARNING
Do not remove the blanking plugs from each
component until the last moment.
Also, do not remove the components from their
packaging until they are to be fitted to the vehi-
cle.

62A-31
AIR CONDITIONING
Dehydrator reservoir - expansion valve connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
aClean the surface and seal of the pipe using EN-
GINE CLEANER (see Vehicle: Parts and con-
sumables for the repair) (04B, Consumables -
Products).
aUse a compressed air nozzle to blow on the sur-
face and the seal of the connecting pipe.
aLubricate the surface of the connecting pipe and the
seal with air conditioning oil (see 62A, Air condi-
tioning, Air conditioning: Parts and consum-
ables for the repair, page 62A-2) .
aRemove the blanking plugs.II - REFITTING OPERATION FOR PART
CONCERNED
aRefit the assembly of the « dehydrator reservoir - ex-
pansion valve » and « expansion valve - intermedi-
ate pipe » connecting pipes.
aFit:
-the « dehydrator reservoir - expansion valve » con-
necting pipe on the dehydrator reservoir,
-the connecting pipes on the expansion valve.
aCouple the « expansion valve - intermediate pipe »
connecting pipe to the « compressor - intermediate
pipe » connecting pipe.
aRefit:
-the bolts of the connecting pipes on the expansion
valve,
-the bolt of the « dehydrator reservoir - expansion
valve » connecting pipe on the dehydrator reser-
voir.
aFit the connecting pipes on the body.
aRefit the connecting pipe bracket nuts on the body.
III - FINAL OPERATION
aRefit the bulkhead heat-resistant protectors.
aRefit:
-the upstream oxygen sensor (see Oxygen sen-
sors: Removal - Refitting) (17B, Petrol injection),
-the air filter box (see Air filter unit: Removal - Re-
fitting) (12A, Fuel mixture).
aConnect the air temperature sensor.
aRefit:
-the scoop under the scuttle panel grille (see Scoop
under the scuttle panel grille: Removal - Refit-
ting) (56A, Exterior equipment),
143880
143882
D4F, and 780 – K4M
D4F, and 780
K4M

62A-32
AIR CONDITIONING
Dehydrator reservoir - expansion valve connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the wiper arms (see Windscreen wiper arm: Re-
moval - Refitting) (85A, Wiping - Washing).
aConnect the battery (see ) (80A, Battery).
aConsult the amount of refrigerant and oil required
before filling the air conditioning circuit (see 62A, Air
conditioning, Air conditioning: Parts and con-
sumables for the repair, page 62A-2) .
aFill the refrigerant circuit using a refrigerant charg-
ing station (see 62A, Air conditioning, Refriger-
ant circuit: Draining - Filling, page 62A-8) .
aCheck for leaks (see 62A, Air conditioning, Refrig-
erant circuit: Check, page 62A-7) .
aCheck that the air conditioning system is operating
correctly (see 62A, Air conditioning, Air condi-
tioning: Check, page 62A-4) .

62A-33
AIR CONDITIONING
Compressor - condenser connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
aDrain the refrigerant circuit using a refrigerant
charging station (see 62A, Air conditioning, Re-
frigerant circuit: Draining - Filling, page 62A-8) .
aDisconnect the battery (see ) (80A, Battery).
aRemove:
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
-the front wheel arch liners (see Front wheel arch
liner: Removal - Refitting) (55A, Exterior protec-
tion),
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection).II - OPERATION FOR REMOVAL OF PART
CONCERNED
aDisconnect the pressure sensor connector (1) . Equipment required
refrigerant charging station
compressed air nozzle
IMPORTANT
To avoid all risk of damage to the systems, apply
the safety and cleanliness instructions and opera-
tion recommendations before carrying out any
repair:
- (see 62A, Air conditioning, Air conditioning:
Precautions for the repair, page 62A-1) ,
- (see Vehicle: Precautions for the repair) (01D,
Mechanical introduction).
Note:
Use blanking plugs for the fuel circuits with part no.
77 01 208 229 or 77 01 476 857 to plug any open-
ings exposed to the open air. They must be clean.
Do not use any which have already been used to
plug a fuel circuit.
WARNING
Consult the device's operating manual to avoid
incorrect use.
121174

62A-34
AIR CONDITIONING
Compressor - condenser connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
aRemove the bolt (2) from the « compressor -
condenser » connecting pipe on the condenser.
aSeparate the « compressor - condenser » connect-
ing pipe from the condenser.
aFit plugs into the openings.aRemove the bolt (3) from the « compressor -
condenser » connecting pipe on the compressor.
aSeparate the « compressor - condenser » connect-
ing pipe from the compressor.
aFit plugs into the openings.
aRemove the « compressor - condenser » connect-
ing pipe.
aRemove the pressure sensor on the « compressor -
condenser » connecting pipe.
121312
WARNING
In order to avoid any refrigerant leaks, do not
damage (deform, twist, etc.) the pipe.
WARNING
To prevent moisture from entering the system,
place plugs on the cold loop components which
are open to the air.
121175
WARNING
In order to avoid any refrigerant leaks, do not
damage (deform, twist, etc.) the pipe.
WARNING
To prevent moisture from entering the system,
place plugs on the cold loop components which
are open to the air.

62A-35
AIR CONDITIONING
Compressor - condenser connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
REFITTING
I - REFITTING PREPARATION OPERATION
a
aClean the surface and seal of the pipe using EN-
GINE CLEANER (see Vehicle: Parts and con-
sumables for the repair) (04B, Consumables -
Products).aUse a compressed air nozzle to blow on the sur-
face and the seal of the connecting pipe.
aLubricate the surface of the connecting pipe and the
seal with air conditioning oil (see 62A, Air condi-
tioning, Air conditioning: Parts and consum-
ables for the repair, page 62A-2) .
aRemove the blanking plugs.
II - REFITTING OPERATION FOR PART
CONCERNED
aRefit the pressure sensor on the « compressor -
condenser » connecting pipe.
aFit:
-the « compressor - condenser » connecting pipe
on the compressor,
-the « compressor - condenser » connecting pipe
on the condenser.
aRefit:
-the bolt on the « compressor - condenser » con-
necting pipe on the compressor,
-the bolt on the « compressor - condenser » con-
necting pipe on the condenser.
aConnect the pressure sensor connector.
III - FINAL OPERATION
aRefit:
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection), WARNING
Do not remove the blanking plugs from each
component until the last moment.
Also, do not remove the components from their
packaging until they are to be fitted to the vehi-
cle.
143880
143882

62A-36
AIR CONDITIONING
Compressor - condenser connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
-the front wheel arch liners (see Front wheel arch
liner: Removal - Refitting) (55A, Exterior protec-
tion),
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres).
aConnect the battery (see ) (80A, Battery).
aConsult the refrigerant and oil quantity values before
filling the circuit (see 62A, Air conditioning, Air
conditioning: Parts and consumables for the re-
pair, page 62A-2) .
aFill the refrigerant circuit using a refrigerant charg-
ing station (see 62A, Air conditioning, Refriger-
ant circuit: Draining - Filling, page 62A-8) .
aCheck for leaks (see 62A, Air conditioning, Refrig-
erant circuit: Check, page 62A-7) .
aCheck that the air conditioning system is operating
correctly (see 62A, Air conditioning, Air condi-
tioning: Check, page 62A-4) .

62A-37
AIR CONDITIONING
Compressor - intermediate pipe connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
aDrain the refrigerant circuit using a refrigerant
charging station (see 62A, Air conditioning, Re-
frigerant circuit: Draining - Filling, page 62A-8) .
aDisconnect the battery (see ) (80A, Battery).
aRemove:
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),-the front wheel arch liners (see Front wheel arch
liner: Removal - Refitting) (55A, Exterior protec-
tion),
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection).
II - OPERATION FOR REMOVAL OF PART
CONCERNED
aDisconnect the « expansion valve - intermediate
pipe » (1) connecting pipe on the « compressor - in-
termediate pipe » connecting pipe using the (Mot.
1410). Special tooling required
Mot. 1410Set of refrigerant pipe union
disconnection sockets.
(dimensions in inches): 5/16,
3/8, 1/2, 5/8, 3/4, 7/8.
Equipment required
refrigerant charging station
compressed air nozzle
IMPORTANT
To avoid all risk of damage to the systems, apply
the safety and cleanliness instructions and opera-
tion recommendations before carrying out any
repair:
- (see 62A, Air conditioning, Air conditioning:
Precautions for the repair, page 62A-1) ,
- (see Vehicle: Precautions for the repair) (01D,
Mechanical introduction).
Note:
Use blanking plugs for the fuel circuits with part no.
77 01 208 229 or 77 01 476 857 to plug any open-
ings exposed to the open air. They must be clean.
Do not use any which have already been used to
plug a fuel circuit.
WARNING
Consult the device's operating manual to avoid
incorrect use.
121180

62A-38
AIR CONDITIONING
Compressor - intermediate pipe connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
aRemove the bolt (2) from the « compressor - inter-
mediate pipe » connecting pipe bracket on the com-
pressor.aRemove the bolt (3) from the « compressor-interme-
diate pipe » connecting pipe on the compressor.
aSeparate the « compressor - intermediate pipe »
connecting pipe from the compressor.
aFit plugs into the openings.
aRemove the « compressor - intermediate pipe »
connecting pipe.
REFITTING
I - REFITTING PREPARATION OPERATION
a
121174121175
WARNING
In order to avoid any refrigerant leaks, do not
damage (deform, twist, etc.) the pipe.
WARNING
To prevent moisture from entering the system,
place plugs on the cold loop components which
are open to the air.
WARNING
Do not remove the blanking plugs from each
component until the last moment.
Also, do not remove the components from their
packaging until they are to be fitted to the vehi-
cle.

62A-39
AIR CONDITIONING
Compressor - intermediate pipe connecting pipe: Removal - Refitting
AIR CONDITIONING or CLIMATE CONTROL
62A
aClean the surface and seal of the pipe using EN-
GINE CLEANER (see Vehicle: Parts and con-
sumables for the repair) (04B, Consumables -
Products).
aUse a compressed air nozzle to blow on the sur-
face and the seal of the connecting pipe.
aLubricate the surface of the connecting pipe and the
seal with air conditioning oil (see 62A, Air condi-
tioning, Air conditioning: Parts and consum-
ables for the repair, page 62A-2) .
aRemove the blanking plugs.II - REFITTING OPERATION FOR PART
CONCERNED
aRefit the « compressor - intermediate pipe » con-
necting pipe.
aFit the « compressor - intermediate pipe » connect-
ing pipe on the compressor.
aRefit:
-the bolt on the « compressor - intermediate pipe »
connecting pipe on the compressor,
-the bolt on the « compressor - intermediate pipe »
connecting pipe bracket on the compressor.
aCouple the « expansion valve - intermediate pipe »
connecting pipe to the « compressor - intermediate
pipe » connecting pipe.
III - FINAL OPERATION
aRefit:
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the front wheel arch liners (see Front wheel arch
liner: Removal - Refitting) (55A, Exterior protec-
tion),
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres).
aConnect the battery (see ) (80A, Battery).
aConsult the refrigerant and oil quantity values before
filling the circuit (see 62A, Air conditioning, Air
conditioning: Parts and consumables for the re-
pair, page 62A-2) .
aFill the refrigerant circuit using a refrigerant charg-
ing station (see 62A, Air conditioning, Refriger-
ant circuit: Draining - Filling, page 62A-8) .
aCheck for leaks (see 62A, Air conditioning, Refrig-
erant circuit: Check, page 62A-7) .
aCheck that the air conditioning system is operating
correctly (see 62A, Air conditioning, Air condi-
tioning: Check, page 62A-4) .
143880
143882
