SAAB 9-3 2001 Owners Manual

111 Saab 9-3 Audio System
AntennaThe antenna of the Audio System is motor-
ized.
Saab 9-3 Viggen Coupé and 5-door: The
antenna is located on the roof.
For the cleaning of the motorized antenna,
see the section headed "Washing", page
226.
The car has a factory-fitted roof antenna for
a car phone. Roof loads may negatively
affect telecommunication.
Multipath interference When the radio waves from an FM transmit-
ter collide with a large building, for example,
they will be reflected so that they reach the
car antenna slightly later than the direct
waves. This is referred to as multipath dis-
tortion. The effect is liable to be blamed
upon malfunctions in the radio.
Shadow effect Because FM radio waves travel in straight
lines from the transmitter, a shadow effect
can occur when tall buildings or hills
obstruct the interference path from the
transmitter to the car.
NOTERemove the antenna if you wash the car
in a car wash, to avoid it being damaged.
IB977
IB978
ProCarManuals.com

112 Saab 9-3 Audio SystemSources of FM interference Interference to FM reception can be caused
by the electrical systems in other vehicles,
particularly if the signal from the transmitter
is weak. Car phones can also produce inter-
ference.
To maintain good radio reception do not tint
the rear windshield, particularly with film
containing small metal flakes.
Cross-modulation When the radio is tuned to a weak transmit-
ter in the vicinity of a stronger one, the car’s
antennas will receive signals from both.
Such interference is apparent when the
unwanted broadcast can be heard faintly in
the background.
Radio waves, FM/AM FM radio waves radiate in straight lines from
the transmitter. Because such waves do not
follow the curvature of the Earth, their
strength becomes weaker the further they
travel. That is why a large number of trans-
mitters are needed to provide good recep-
tion.
AM waves, on the other hand, are reflected
off the ionosphere, thus greatly extending
their range.
IB980
IB388
AM
FM
IB979
ProCarManuals.com

113 Saab 9-3 Audio System
Sources of AM interference AM reception is prone to interference, e.g.
from electrical systems on other vehicles,
high-tension power lines and lightning.
Installation of car phone
(option) Roof loads can negatively affect tele-
communication.
Provision has been made for the installation
of a hands-free car phone.
Installation must be done by an authorized
Saab dealer.
A car-phone cradle is available as an acces-
sory.
Your Saab dealer has details of which
phones are suitable for the installation.
Provision for hands-free phone (only if
Saab 9-3 Audio System is fitted)
 Car phone connects to car’s circuitry.
 External antenna is fitted.
 Microphone for hands-free phone use
incorporated in overhead panel at front
(Convertible: microphone located in the
front windscreen pillar).
 Audio System mute functions when
phone activated.
 Phone conversation amplified through
Audio System speakers.
WARNING
To prevent crashes while using a cell
phone:
 Do not use the cell phone in distracting
traffic situations. Turn it off if traffic is
heavy.
 Dial sensibly, at a stoplight or safely off
the road.
 Consider installing hands-free or
speaker phone.
 Avoid stressful and intense phone
conversations.
 Acquaint yourself with the legal provi-
sions governing the use of car phones
while driving.
 Do not use the phone when refueling
with gasoline. Gasoline fuels are
highly explosive.
NOTETo reduce the risk of head injuries in the
event of a collision, the roof pillars and
side edges of the headlining incorporate
cushioning material (Convertible: wind-
screen pillars and upper part of wind-
screen rail). These areas must not be
modified in any way. Work on these areas
must only be carried out at an authorized
Saab dealer.
IB981
ProCarManuals.com

114 Saab 9-3 Audio System Requires accessory module for use with
OnStar system, standard on all Saab
models.
 "TELEPHONE" appears on the SID when
phone is in use.
 Volume level for ongoing conversation
can be adjusted by volume controls on
steering wheel or on audio-system mod-
ule. See also ”Volume-preset mode”,
page 108.
 If the sound is a bit fuzzy, adjust by means
of the volume control on the
phone set
.
 Phone battery is charging when ignition is
ON and phone in its cradle.
Please refer to the instructions supplied with
the phone for details of how to make and
receive calls.
OnStar System (US/Canada feature)
Your car may be equipped with OnStar, a
vehicle telematics system for communica-
tion and navigation. Please consult the sep-
arate chapter in this owner’s manual.
Mobile phones and
communications radios Mobile phones and communications radios
that do not have a separate external
antenna radiate an electromagnetic field
inside the car.Saab therefore recommends that a car
phone/radio transmitter should always be
connected to an external antenna.
An external antenna also provides
improved transmission/reception and a
greater range.
Mobile phones and communications radios
that are not supplied as standard equipment
by Saab can interfere with the car’s electri-
cal system and cause misleading fault
codes to be generated.
WARNING
The electromagnetic field produced, for
example, by a mobile telephone in the
passenger compartment may be detri-
mental to health. We therefore recom-
mend the use of an external antenna.
Do not use the phone when refueling with
gasoline. Gasoline fuels are highly explo-
sive.NOTEThe electromagnetic field can cause
interference with other electrical systems
in the car, such as the Audio System.
WARNING
Always consult an authorized Saab
dealer for installation guidance.
If you feel that any of the warnings or fault
indications are unclear, have the equip-
ment checked by an authorized Saab
dealer.
ProCarManuals.com

115 Saab 9-3 Audio System
Fault codesThe Audio System has a built-in diagnostics
function. If a fault is detected, a fault code is
generated to help dealer technicians to
diagnose the fault. Below is an example of
a fault code that you might be able to rectify
yourself.
Adjusting the frequency steps
North America/Europe If the car is taken from Europe to North
America, the radio’s frequency steps will
need to be adjusted.
 With the radio off, press and hold
(mid-segment) and switch the
radio on at the same time.
The station presets will be cancelled and
replaced by preset frequencies.
NOTEGreat care should be exercised in trying
to rectify a fault. If you are at all unsure,
contact an authorized Saab dealer.
Fault code Possible cause
CD/CDC
ERROR
12/17/19 CD is dirty, loaded
wrong side up or defec-
tive.
TAPE ERR 01 Tape broken or
mechanical fault in
deck.
TAPE ERR
02/03Tape snarled up or
mechanical fault in
deck.
TAPE ERR 11 Cassette jammed: can-
not be loaded/ejected.
WARNING
The CD player/CD changer is classified
as Class 1 laser equipment.
 Service and repair work must only be
carried out by authorized technicians.
 If the casing is damaged, hazardous
laser radiation can occur.
ProCarManuals.com

116 Saab 9-3 Audio System(This page has been left blank).
ProCarManuals.com

117 OnStar - Telematics
OnStar - Telematics
Using OnStar................... 118OnStar is Easy............................ 118
OnStar Services Button .............. 118
Emergency button ...................... 119
Call answer/end button ............... 119
System status light ..................... 119The OnStar Center .......... 120Connecting to the OnStar center 120
Your personal identification number
(PIN) ........................................... 120

The OnStar Safety and
Security Plan................. 120
Automatic notification of air bag
deployment ................................. 120
Emergency services ................... 120
Roadside assistance................... 121
Stolen vehicle tracking ................ 121
Accident Assist™ ........................ 121
OnStar Med-Net.......................... 121
Hands-free communication ......... 121The OnStar Premium Plan 121Route support ............................. 121
Ride Assist .................................. 121
Information and Convenience ser-
vices ........................................... 121
Concierge services ..................... 122
Additional Services......... 122Personal Calling: ........................ 122Virtual Advisor: ............... 126
OnStar Subscriber
Website .......................... 127
Limitations ....................... 127
Additional Information.... 128Warranty .................................... 128
A Note About Privacy ................. 128
Transferring OnStar .................... 128
OnStar Subscription Information 128
ProCarManuals.com

118 OnStar - TelematicsYour new vehicle comes equipped with
advanced telematics hardware and a full
year of Onstar premium service. Saab
Telematics is a sophisticated in-vehicle
system allowing convergence of wireless
communications, GPS (Global Positioning
System) satellites and advanced vehicle
electronics.
You must activate immediately to ensure
you receive your full year of service, as your
prepaid subscription begins at the time of
delivery.
Here’s how to activate your OnStar ser-
vice:
1 Push the blue OnStar button located in
your Saab. You will be greeted by a live
OnStar Advisor. The Advisor will acti-
vate your OnStar service.
2 Provide the information requested by
the Advisor to activate your account and
set up your personal profile. This will
take approximately 10-15 minutes.
Using OnStarWelcome to OnStar. This section gives you
all the information you need to get started
using OnStar, including descriptions of all
OnStar services. It also introduces the
added services of Personal Calling, Virtual
Advisor, and the Onstar Subscriber Web-
site. For a complete explanation of these
additional services, please see pages 122,
126 and 127.OnStar is EasyIt’s easy to start using your OnStar system.
In fact, pressing the OnStar button is usually
all you need to do. Once you are connected,
an OnStar Advisor will help you with the ser-
vices in your plan.Your onboard OnStar System consists of
three buttons:
OnStar Services Button
Press this button, and you are
connected to an OnStar Advi-
sor. You will hear a chime, fol-
lowed by the words
”Connecting to OnStar.” Allow
20-30 seconds for initial con-
nection to the OnStar Call Cen-
ter. The Advisor will then help
you with any of the services
included in your OnStar plan.
If cellular service is unavail-
able, OnStar will generate a
fast busy tone. The OnStar sys-
tem will retry calls a number of
times before returning to the
ready mode. To cancel the
automatic dialing, press the
Call Answer/End button.
ProCarManuals.com

119 OnStar - Telematics
System status lightSolid Green — Indicates the OnStar
system in the vehicle is powered ON and
ready to make calls or receive calls from the
OnStar Center.
Blinking Green — The light blinks green to
indicate a call is being connected or in
progress. If you notice this light blinking
while you are not on a call, press the Call
Answer/End button.
Red — This signals that your OnStar
system may not be functioning properly.
Press the OnStar button to attempt to con-
tact an OnStar Advisor. If the connection is
made, the Advisor will assist you in making
sure your OnStar system is operating prop-
erly. If you cannot contact the OnStar Cen-
ter, please take your car to the nearest Saab
dealer for diagnosis and service.The OnStar Center is the heart of your ser-
vice — staffed 24 hours a day, 7 days a
week with knowledgeable OnStar Advisors.
Even on weekends and holidays, there is
always someone ready to help.
OnStar uses sophisticated Global Position-
ing System (GPS) satellites to locate your
Saab, and wireless technology to provide
the communications link and seamless inte-
gration into your Saab. This system allows
our OnStar Advisors to pinpoint your Saab´s
location precisely. This way, Advisors can
provide you with a range of helpful services
to protect you and your Saab. Plus, with our
Premium Plan* included for 12 months with
your Saab, Advisors can also access an
extensive database to assist you with direc-
tions, making reservations and other conve-
nience services.
*) New retail deliveries only.
Emergency button
In an emergency, press this
button to connect with an
OnStar Advisor. Your call will
be given the highest priority,
and you will hear a tone fol-
lowed by the words ”Connect-
ing to OnStar Emergency.” The
Advisor will locate your Saab,
find out what kind of assistance
you require, and contact the
nearest emergency services
provider who can dispatch
ambulance, fire, police or other
emergency services. Please
use this button only for true
emergencies.
Call answer/end button
Press this button at the end of a
call. You’ll hear the words
”OnStar Request Ended.” Also,
press this button to answer a
call from the OnStar Center, or
cancel a call if one of the other
buttons is accidentally
pressed. This button is also
used to access OnStar Per-
sonal Calling services which
are described on page 122.
ProCarManuals.com

120 OnStar - TelematicsThe OnStar CenterConnecting to the OnStar centerIn addition to using the 3-button system
found in your Saab, there are two other
ways to connect to the OnStar Center.
Toll-Free Call
To take advantage of your OnStar Services
from outside your Saab, you can call OnStar
toll-free at 1-888-4-OnStar
(1-888-466-7827). Remember to have your
Personal Identification Number (PIN)
handy.
Automatic Notification
A priority signal will be sent to the OnStar
Center with your exact location if an airbag
deploy.(Vehicle electrical system and cellular service
must be operable.)
Your personal identification number
(PIN)When you signed up with OnStar, you were
asked to provide a Personal Identification
Number (PIN). You’ll need your PIN to
access many of OnStar’s services. If, for
example, your vehicle has been stolen, an
Advisor will ask for your PIN in order to pro-
vide assistance.
Changing your PIN is easy. Call the OnStar
Center and provide the Advisor with your
current number, and he or she will assist
you in setting up a new number. If you have
forgotten your PIN, just call the OnStar Cen-
ter. For security reasons, we will send your
PIN to you in the mail.
The OnStar Safety and
Security PlanThe OnStar Safety and Security Plan is part
of the Premium Plan that comes with your
vehicle.* With it, you have access to a com-
plete range of services providing you with
an unsurpassed level of safety and security
— 24 hours a day, 7 days a week. And you
have it all at the touch of a button.
So whether you’re on a lonesome country
road or stuck in highway traffic, you have at
your disposal a complete range of services
providing you with unsurpassed security.
And you have it all at the touch of a button.Automatic notification of air bag
deploymentShould your front air bags deploy, a priority
signal will be sent to the OnStar Center with
your Saab´s location (as long as cellular
service and the vehicle’s electrical system
are operable). An Advisor will attempt to
contact you to assess the nature of your
emergency, and then notify the necessary
emergency services provider.Emergency servicesShould you require emergency assistance,
press the red emergency button and we will
contact the nearest emergency services
provider with your exact location and your
request for help.* New retail deliveries only.
ProCarManuals.com
