Page 251 of 260
251 Technical data
Suspension
SteeringBrake systemSpring type, front and rear ____________ Coil springs
Maximum deflection of springs:
front, Coupé/5-door/Convertible _______ 6.4" (163 mm)
front, Viggen ______________________ 6.5” (165 mm)
rear, Coupé/5-door/Convertible _______ 8.3" (212 mm)
rear, Viggen ______________________ 7.9” (200 mm)
Dampers, front and rear ______________ Gas-filled tele-
scopic shock
absorbers
Steering __________________________ Power-assisted
steering gear of
rack-and-pinion
type with tele-
scopic, universal
joint steering- col-
umn shaft
Number of turns, lock to lock __________ 3.0
Oil type ___________________________ Power Steering
Fluid CHF 11S Footbrake (ABS) ___________________ Hydraulic disc
brakes with vacuum
servo, diagonally
split circuits
Parking brake ______________________ Acts on rear wheels
Brake fluid ________________________ DOT 4
Do not use DOT 5
Disc diameter:
front, Coupé/5-door/Convertible _______ 11.4" (288 mm)
front, Viggen ______________________ 12.0” (306 mm)
rear ____________________________ 11.3" (286 mm)
Total friction area of brake pads:
front, Coupé/5-door/Convertible _______ 34.4 in² (224 cm²)
front, Viggen ______________________ 35.9 in² (234 cm²)
rear ____________________________ 14.2 in² (92 cm²)
ProCarManuals.com
Page 252 of 260
252 Technical dataRims and tires
Rim size:
Coupé/5-door/Convertible____________ 6.5 x 15 or 6.5 x 16
Viggen __________________________ 7.5 x 17
Viggen must use 6.5 x 16 or 7.5 x 17
Contact an authorized Saab dealer if you
wish to fit other wheels than those fitted
as standard.
Tire sizes (summer tires):
6.5 x 15 (not Viggen) _______________ 195/60 R15
6.5 x 16 __________________________ 205/50 R16 or
205/55 R16
7.5 x 17 Viggen only ________________ 215/45 R17
Tire sizes (winter tires):
6 x 15 (not Viggen) _________________ 185/65 R15 M+S or
195/60 R15 M+S
6.5 x 16 _________________________ 205/50 R16 M+S
Recommended rims for snow chains:
Coupé/5-door/Convertible____________ 6 x 15
Viggen __________________________ 6.5 x 16
Spare wheel:
Tire _____________________________ T115/70 R16
Rim _____________________________ 4.0 x 16
Maximum life _____________________ 2000 miles
(3500 km)
Maximum speed __________________ 50 mph (80 km/h)
NOTESnow chains
Snow chains must not be fitted to the rear wheels and must be
used on the following tire/wheel combinations:
Wheel Tire
6 x 15 _________ 185/65 R15 M+S (not Viggen),
195/60 R15 (not Viggen) or
195/60 R15 M+S (not Viggen)
6.5 x 15________ 195/60 R15 (not Viggen)
6.5 x 16________ 205/50 R16, 205/55 R16 or 205/50 R16 M+S
Max. speed is 30 mph (50 km/h).
Consult your authorized Saab dealer of approved snow chains.NOTECoupé/5-door/Convertible: Bigger rims than 17” must not be
used. The offset of the rims must not exceed 49 mm.
Viggen: Bigger rims than 17” must not be used.
The offset of the rims must not exceed 42 mm.
Front-wheel angles:
Toe-in, measured on the wheel rim ____ 1.5±0.5 mm
Viggen __________________________ 1.3±0.3 mm
ProCarManuals.com
Page 253 of 260
253 Technical data
Plates and labelsIn contacts with your Saab dealer it may
sometimes be necessary to quote the car’s
chassis, engine and gearbox numbers.
1 Modification identity plate (in the spare
wheel compartment).
2 V.I.N. number inside windshield.
3 Certification label.
4 Gearbox number.
5 Engine number.
6 Label for tire pressures and color codes
(trim and body).
7 Chassis number.
8 Chassis number (stamped on body).
9 Vehicle Emission Control Information.
10 Spark ignition system information
(Canada only)
4728473IB1523
CANADA US
ProCarManuals.com
Page 254 of 260
254 Technical data1 - Region
____________
Y = Northern Europe
2 - Country _______S = Sweden
3 - Manufacturer ___3 = Saab Automobile AB
4 - Product line ____D = 9-3
5 - Model series ___D = 9-3 S with driver’s and
passenger’s airbag
F = 9-3 SE with driver’s and
passenger’s airbag
P = 9-3 Viggen with driver’s and
passenger’s airbag6 - Body version ___3 = Coupé (3-door)
5 = 5-door
7 = Convertible
7 - Gearbox _______5 = Manual 5-speed
8 = Automatic 4-speed
8 - Engine variant __G = 2.3 Turbo Viggen
H = 2.0 Turbo (185 bhp)
K = 2.0 Turbo (205 bhp)
9 - Check digit ____0-9 or X
10 - Model year _____1 = 2001
11 - Factory ________2 = Trollhättan
7 = Nystad
12 - Serial number __000001-999999 position: 1234567891011 12
||||||||| | | |
VIN:YS3DF 5 8K7 1 2005543
||||||
123456= identification codes for certain chassis details
IB541
ProCarManuals.com
Page 255 of 260
255 Technical data
Several of the systems in your Saab
car may be adjusted to better fit your
individual needsSome functions are governed by legal
requirements and cannot therefore be
reprogrammed.
Consult an authorized Saab dealer for fur-
ther information.
Car alarm/central locking system:
The level of the siren when locking/
unlocking, HIGH or LOW.
The number of blinks when locking/
unlocking, 1 to 7.
Automatic locking of the trunk when the
car is driven, 1 to 8 mph (2-14 km/h), YES
or NO.
Preclude the unlocking of the trunk while
the car is driven, YES or NO.
Automatic locking of the trunk after
1 second-4 minutes if it has not been
opened, YES or NO.
Automatic locking of the trunk when it is
closed, YES or NO.Saab Information Display (SID):
Outdoor temperature display can be
adjusted.
Miscellaneous:
Select the on-time for heated rear seat.
Coolant temperature gauge adjustment
can be increased/decreased.
Fuel level gauge adjustment can be
increased/decreased.
Additional sweep of the wipers after wind-
shield washer function (ON or OFF).
Courtesy Headlight Feature (follow-me
home) on-time can vary from 20 to
50 seconds.
Night panel illumination deactivation
speed for the speedometer can be
adjusted.
Following adjustments can be done
by the driver:Automatic Climate Control (ACC):
To alter the preprogrammed “AUTO“ start
up mode with your own preferences you can
manually select the desired settings for:
Temperature.
Fan speed.
Air distribution.
See “Programming I” on page 90 and “Pro-
gramming II” on page 91.
ProCarManuals.com
Page 256 of 260
256 Technical dataSaab 9-3 Audio System:
The following functions can be adjusted by
the driver (see page 108):
Maximum starting volume (when the
radio is switched on).
Telephone volume (if the car is equipped
with a phone connected to the audio sys-
tem).
Speed dependent volume (volume
increases or decreases with vehicle
speed).
Loudness.Alarm System:
The glass breakage sensor can be tempo-
rarily disabled, see page 42.
Daytime Running Lights:
To disable, turn off the ignition and pull out
fuse 15, see page 214.
ProCarManuals.com
Page 257 of 260
257 Index
Index
AA/C system, fault diagnosis
________ 232
A/C system, maintenance _________ 232
ACC
__________________________ 84
ACC, useful tips
_________________ 92
Adjustment, steering wheel
________ 137
Air conditioning (A/C), fault diagnosis
and maintenance
______________ 232
Airbag
_________________________ 28
Alarm __________________________ 41
Alarm functions
__________________ 44
Alarm signals
___________________ 44
Anti-corrosion treatment
__________ 228
Anti-theft system
_________________ 41
Ashtray
_______________________ 141
Audio System
___________________ 93
Automatic climate control (ACC)
_____ 84
Automatic transmission
___________ 162
BBattery
________________________ 201
Boost starting from donor battery
___ 187
Brake fluid, check
_______________ 200
Brake fluid, grade _______________ 251
Brake pad wear indicators
____ 170
, 200Brakes
________________________ 170
Braking _______________________ 170
Bulb table _____________________ 211
CCD changer
____________________ 105
CD player
_____________________ 103
CHECK messages
_______________ 72
CHECKING
_____________________ 72
Cabin lighting __________________ 139
Calibration, ACC _________________ 90
Car alarm
______________________ 41
Car phone, installation
___________ 113
Care of safety belts
______________ 224
Cassette player
_________________ 100
Central locking __________________ 36
Change of address notification
_____ 238
Changing a wheel
_______________ 221
Changing bulbs
_________________ 206
Changing the coolant
____________ 199
Changing the engine oil __________ 196
Changing the key battery __________ 39
Changing the wheels round _______ 218
Changing wiper blades
___________ 204
Chassis number
________________ 253
Child car seats
__________________ 19
Child safety
_____________________ 19
Child safety locks, rear doors
_______ 39
Child seats
_____________________ 19
Cigar lighter ____________________ 141Cleaning the soft top, Convertible
____ 57
Climate-control system, manual
_____ 80
Compact spare wheel
____________ 220
Condensation water, A/C __________ 82
Condensation water, ACC __________ 85
Convertible
_____________________ 47
Coolant
_______________________ 198
Courtesy Headlight Feature
________ 76
Cruise Control
__________________ 169
Cup holder
_____________________ 140
DDICE/TWICE
___________________ 213
Date code, tires _________________ 220
Dim low beam
___________________ 75
Dimmer
________________________ 78
Direction indicators
_______________ 76
Direction-indicator stalk
____________ 76
Dome lighting
__________________ 139
Door mirrors
___________________ 143
Drive belt
______________________ 203
Driving in deep water
_____________ 185
Driving in hot weather ____________ 179
Driving technique
________________ 176
Driving with a compact spare wheel
_ 190
Driving with a load
_______________ 184
Driving with a roof load
___________ 182
Driving with the trunk lid open
______ 185
ProCarManuals.com
Page 258 of 260
258 IndexEEconomical motoring
____________ 176
Electrical system, technical data
____ 250
Electrical window
_______________ 136
Electrically adjustable seats
_______ 133
Electrically heated front seats ______ 135
Electrically heated rear seat
_______ 135
Electrically heated rear window _____ 83
Electronic starting interlock
_________ 37
Emergency opening, fuel filler door
_ 150
Emergency operation of the soft top,
Convertible
____________________ 52
Emergency operation of the sunroof
_ 138
Emission control systems
_________ 194
Engine bay
____________________ 193
Engine bay, cleaning
_____________ 226
Engine break-in period _______ 161
, 176
Engine number
_________________ 253
Engine oil, changing
_____________ 196
Engine oil, checking _____________ 196
Engine oil, grade
________________ 247
Engine oil, volume _______________ 247
Engine variants
_________________ 249
Engine, description ______________ 194
Engine, technical data ____________ 247
FFault codes, Audio System
________ 115
Flat spot
______________________ 224Folding the soft top, Convertible
_____ 49
For long trips
___________________ 190
Front fog lights __________________ 77
Fuel filler door, emergency opening
_150
Fuel gauge
_____________________ 68
Fuel grade _____________________ 249
Fueling
_______________________ 157
Fuel-tank capacity
_______________ 249
Fuse table
_____________________ 214
Fuses
________________________ 212
GGearbox number
________________ 253
Gearbox oil, checking
____________ 197
Gearbox oil, grade
_______________ 250
General particulars ______________ 244
General safety instructions, Convertible
48
Glove compartment
______________ 141
HHandbrake
_____________________ 174
Hazard warning lights
_____________ 76
Head restraint
___________________ 18
Headlight flasher _________________ 75
Hood
_________________________ 192
Horn signal
____________________ 137
IIf the car does not start
___________ 153
Ignition switch
__________________ 152
Immobilizer
_____________________ 37
Important considerations concerning
cars with catalytic converters
_____ 156
Important considerations for driving
_ 154
Indicator lights
___________________ 60
Instrument lighting
________________ 78
Integrated booster seat
____________ 26
Interior equipment
_______________ 129
Interior lighting
__________________ 139
Interior lighting, Convertible
_________ 58
Interior rearview mirror
___________ 143
JJump starting
___________________ 187
KKey
___________________________ 36
Key, removing
__________________ 152
LLATCH (child safety)
______________ 21
Labels and plates
_______________ 253
ProCarManuals.com
Page 259 of 260
259 Index
Leather upholstery, care of
________ 225
Load eyes
_____________________ 148
Locks
__________________________ 36
Lowering rear seat
______________ 144
Luggage compartment ___________ 144
Luggage compartment, Convertible
__ 56
Luggage-compartment lighting
_____ 148
MMain beam
_____________________ 75
Main instrument panel
_____________ 60
Maintenance schedule ___________ 236
Manual climate-control system
______ 80
Manual raising of the soft top,
Convertible
____________________ 52
Manual transmission
_____________ 161
Manually opening the fuel filler door,
Convertible
____________________ 58
Manually opening the fuel filler door,
Coupé and 5-door
______________ 150
Maxi fuses
_____________________ 213
Memory, driver’s seat
____________ 134
Motoring abroad
________________ 190
NNight Panel
_____________________ 73
OORVR
________________________ 195
Odometer ______________________ 66
Oil specification
_________________ 247
OnStar
________________________ 117
Opening handle
__________________ 36
Owner assistance _______________ 237
PPaint touch-up
__________________ 227
Parcel shelf
____________________ 147
Park Brake Shift Lock
____________ 164
Parking brake
__________________ 174
Parking lights ____________________ 75
Plates and labels
________________ 253
Power steering fluid, check
________ 201
Power steering oil, grade
_________ 251
Pressure gauge
__________________ 67
Programmable driver’s seat
_______ 134
Programming, ACC
_______________ 90
RRadio
__________________________ 98
Raising the soft top, Convertible
_____ 51
Rear fog light
____________________ 77
Rear seat
______________________ 144
Rear seat, tipping
_______________ 144Rearview mirrors
________________ 143
Rear-window wiper _______________ 79
Recirculation
____________________ 82
Recycling
______________________ 230
Refuelling _____________________ 157
Relay table ____________________ 215
Release handle, hood
____________ 192
Remote control
__________________ 36
Remote control battery, changing
____ 39
Removing the key
_______________ 152
Reporting safety defects
__________ 238
Rev counter
_____________________ 66
Reversing lights
__________________ 77
Roof rack
______________________ 182
Rotating the tires
________________ 218
Running-in
_____________________ 161
SSAHR, head restraint
_____________ 18
SID (Side Instrument Display)
_______ 69
SRS (airbag)
____________________ 28
Saab Audio System
_______________ 93
Saab Trionic engine
management system ____________ 195
Safety belts
_____________________ 12
Safety belts, care of
______________ 224
Seat belts
______________________ 12
Seat-belt pretensioners
____________ 13
Seats
_________________________ 130
Service costs
___________________ 237
ProCarManuals.com
Page 260 of 260
260 IndexService information
______________ 238
Service intervals
________________ 236
Service record retention
__________ 237
Side airbags
____________________ 30
Ski hatch
______________________ 147
Snow tires _____________________ 252
Soft top storage, Convertible
_______ 56
Spare wheel
___________________ 149
Speedometer ___________________ 66
Starting the engine
______________ 153
Steering-wheel adjustment
________ 137
Storage compartments
___________ 142
Sunroof
_______________________ 138
Switches _______________________ 75
TTachometer
_____________________ 66
Technical data __________________ 243
Telematics
_____________________ 117
Temperature gauge
______________ 67
Textile carpeting, cleaning
________ 225
Through-load hatch
______________ 147
Tie-down eyes
__________________ 148
Tipping the rear seat
_____________ 144
Tire markings
__________________ 218
Tire pressure ___________________ 184
Tire pressures __________________ 217
Tires and wheels, sizes
___________ 252
Tools
_________________________ 149
Top tether
______________________ 23Touching up paintwork
___________ 227
Towing a caravan or trailer ________ 179
Towing the car
__________________ 185
Traction Control System
__________ 172
Trailer hitch attachment ___________ 179
Trailer hitch load
________________ 182
Transmission, automatic
__________ 162
Transmission, manual
____________ 161
Transporting the car
_____________ 185
Traveling abroad
________________ 190
Trip computer, SID _______________ 69
Trip meter
______________________ 66
Trunk
_________________________ 144
Trunk lid lock, Convertible
__________ 56
Trunk lighting
___________________ 139
Trunk, Convertible
________________ 56
Trunk, opening
__________________ 40
Turbo gauge
____________________ 67
Turn signal
_____________________ 76
UUpholstery and trim
______________ 225
Upholstery and trim, care of
_______ 225
Useful tips on starting
____________ 154
Useful tips, ACC
_________________ 92
VVanity mirror
___________________ 143
WWarning and indicator lights
________ 60
Warning labels
____________________ 7
Warning light, AIR BAG (SRS)
______ 32
Washer fluid
___________________ 205
Washer jets
____________________ 205
Washers
_______________________ 78
Washing ______________________ 226
Waxing and polishing
____________ 227
Wear indicators, brake pads
_______ 200
Wear indicators, tires
_____________ 220
Wheels
_______________________ 217
Wheels and tires, sizes
___________ 252
Window glass sensor, car alarm
_____ 42
Windshield washers
______________ 78
Windshield wipers
________________ 78
Winter driving
__________________ 177
Wiper blades
___________________ 204
Wipers
_________________________ 78
ProCarManuals.com
