78 Instruments and controlsInstrument lightingThe brightness of the instrument lighting
can be varied by means of the dimmer
switch adjacent to the headlight switch, the
ignition switch shall be in position ON. (See
also Night panel on page 73).
In daylight or other equally bright light, the
instrument and switch illumination is auto-
matically extinguished.
Wipers and washersWindshield wipersThe delay of the intermittent operation can
be adjusted to between 2 and 15 seconds.
Moving the control stalk to the
spring-loaded position between 0 and 2 will
produce a single sweep of the wipers. WashersWhen the washers are operated the wipers
will make 3, 4 or 5 sweeps depending on
how long the washers were in action. If the
speed of the car is less than 12 mph
(20 km/h) the wipers will make an additional
sweep after about 9 seconds.
The headlights are washed and wiped auto-
matically whenever you use the windshield
washers. They cannot be operated inde-
pendently of the windshield washers.
IB752
IB753
0OFF
1 Windshield wipers: intermittent operation.
The delay can be adjusted to between 2 and
15 seconds
2 Windshield wipers: low speed
3 Windshield wipers: high speed
4 Washing the windshield and cleaning the
headlights
ProCarManuals.com

79 Instruments and controls
Rear-window wiperRear-window washing and wiping are car-
ried out using the same stalk switch as for
washing and wiping the windshield and
headlights.
This stalk has two additional switches,
ON/OFF and .
The ON position gives intermittent wiping.
The position gives washing and wiping.
After a few sweeps the wiper stops, or
reverts to intermittent wiping if this has been
selected. When washing/wiping of the rear
window ends, the wiper makes a single
sweep after about 15 seconds to wipe away
any remaining washer fluid.
Moving the control stalk to the
spring-loaded position between OFF and
ON will produce a single sweep of the wip-
ers.
Intermittent wiping of the rear window is
done when reverse gear is selected, if the
wipers are in position 1, 2 or 3, see page 78.
IB754
Rear-window wiper 1 Intermittent wiping
2 Washing
Control for setting wiper delay 1 Long delay
2 Short delay
IB935
ProCarManuals.com

198 Car careWipers and washersWiper bladesCheck and clean all wiper blades regularly.
We recommend Saab washer fluid for
cleaning.
If poor wiper performance is experienced,
clean the windshield with Saab washer fluid.
This is particularly important if the car has
been through an automatic car wash, as this
sometimes leave a wax coating on the wind-
shield.
If wiper performance is still unsatisfactory,
fit new blades.
Windshield and rear window1 Push the catch in (1).
2 Pull the complete wiper blade down-
wards so that it comes away from the
wiper arm. Slide the entire blade out
from the arm.
Headlight wipers 1 Lift the wiper arm off the headlight.
2 Detach the wiper blade by pulling it
laterally from the wiper arm.
3 Fit the new blade by sliding it into the
retainer on the wiper arm and pressing it
firmly home.
WARNING
Take care not to spill washer fluid concen-
trate onto hot surfaces as this constitutes
a fire hazard.
IB901
IB902
ProCarManuals.com

209 Car care
Relay holderUnder the instrument panel next to the steering wheel No. Amp Function
21 10 Switch, manual A/C; soft top (Convertible)
22 15 Direction indicators; Cruise Control
23 20 Soft top (Convertible); telephone
24 7.5 Radio
25 30 Central locking; amplifier
26 30 Control module, engine management system
27 15 High beam flash; ACC
28 10 Control module, engine management system
29 10 Right parking light; license plate lighting
30 10 Left parking light
31 20 Reversing light; windshield wipers; headlight
beam-length adjustment
32 15 Fuel pump
33 15 Electric heating of rear seat
34 10 SID; control module; automatic transmission
35 15 DICE/TWICE; main instrument panel; interior light-
ing
36 10 Relay, starter
37 15 Limp-home
38 25 Oxygen sensor (lambda probe)
39 – –
S–SpareItem Function
A Electric heating of rear seat
B Reversing light, cars with automatic transmission
C1 –
C2 Lock motor, trunk lid
D1 Rear wiper
D2 Rear-window washing
E Ignition switch
F–
G1 Horn
G2 Windshield wipers (intermittent)
H Rear-window heating
IFuel pump
J–
KStart relay
L Main relay (injection system)
ProCarManuals.com

250 IndexStorage compartments
___________ 136
Sunroof
_______________________ 132
Switches _______________________ 75
TTachometer
_____________________ 66
Technical data __________________ 233
Telematics
_____________________ 111
Temperature gauge
______________ 67
Textile carpeting, cleaning
________ 219
Through-load hatch
______________ 141
Tie-down eyes
__________________ 142
Tipping the rear seat
_____________ 138
Tire markings
__________________ 212
Tire pressure ___________________ 178
Tire pressures __________________ 211
Tires and wheels, sizes
___________ 242
Tools
_________________________ 143
Top tether
______________________ 23
Touching up paintwork
___________ 221
Towing a caravan or trailer ________ 173
Towing the car
_________________ 179
Traction Control System
__________ 166
Trailer hitch attachment __________ 173
Trailer hitch load
________________ 176
Transmission, automatic
__________ 156
Transmission, manual
____________ 155
Transporting the car
_____________ 179
Traveling abroad
________________ 184
Trip computer, SID _______________ 69Trip meter
______________________66
Trunk
_________________________138
Trunk lid lock, Convertible
__________56
Trunk lighting
___________________133
Trunk, Convertible
________________56
Trunk, opening
__________________40
Turbo gauge
____________________67
Turn signal
_____________________76
UUpholstery and trim
______________219
Upholstery and trim, care of
_______219
Useful tips on starting
____________148
Useful tips, ACC
_________________92
VVanity mirror
___________________137
WWarning and indicator lights
________60
Warning labels
___________________7
Warning light, AIR BAG (SRS)
______32
Washer fluid
___________________199
Washer jets ____________________199
Washers
_______________________78
Washing ______________________220
Waxing and polishing
____________221Wear indicators, brake pads
______ 194
Wear indicators, tires
____________ 214
Wheel, change
________________ 215
Wheels
______________________ 211
Wheels and tires, sizes
__________ 242
Window glass sensor, car alarm
____ 42
Windshield washers
_____________ 78
Windshield wipers
_______________ 78
Winter driving
_________________ 171
Wiper blades
__________________ 198
Wipers
________________________ 78
