Owner’s Manual
Saab 9-3 M2007
© Saab Automobile AB 2006Service Readiness, Saab Automobile AB, Trollhättan, Sweden
Printed in Sweden
Safety 11
Security 47
9-3 Convertible 61
Instruments and controls 81
Interior equipment 117
Starting and driving 149
Car care 201
Customer Assistance and Information 273
Technical data 279
Index 299
93_U S _M 07.book Page 1 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 2 of 304
2IntroductionThis manual provides practical guidance on
driving and caring for your Saab.
Although this manual describes the most
important differences between model vari-
ants, it does not specify the equipment or
features included on individual models.
Importation and distribution of Saab auto-
mobiles, spare parts and accessories are
handled exclusively by Saab Cars USA, Inc.
in the United States and by General Motors
of Canada Limited in Canada.
We recommend that you read through the
manual before taking the car out for the first
time and keep it in the car for future refer-
ence.To find a specific item, use the overviews
given on page 3–6. A list of content is given
at the beginning of each section of the
manual, and there is also a comprehensive
index at the back of the book.
Supplied with the car is a Warranty and Ser-
vice Record booklet which contains impor-
tant warranty information and specifies the
regular maintenance to be carried out. Also
included is a Quick Reference Guide, an
Infotainment System manual, tire warran-
ties and (U.S. customers), a dealer directory
with Roadside Assistance Program infor-
mation.
Since the policy at Saab is one of continual
improvement, we retain the right to incorpo-
rate modifications and to alter specifications
during production without prior notice.3 Asterisk means: equipment not fitted in all
cars (can depend on model variant, engine
variant, market specification, options or
accessories).
If you have any questions concerning your
car, its equipment, the warranty conditions,
etc., your Saab dealer will be pleased to
help, or you may call the Saab Customer
Assistance Center in the U.S. at 1-800-955-
9007 or email them at saab-
[email protected]. In Canada, please
contact the Saab Customer Assistance
Center at 1-800-263-1999.
Enjoy the road ahead!
Saab Automobile AB
Saab Automobile AB does not accept liability for
any damage caused by the fitting of spare parts,
exchange parts or accessories that are not
approved by Saab Automobile AB.
WARNING
Failure to heed warnings may cause
personal injury.NOTICENOTICE texts warns of potential damage
to the car if the recommendations are not
followed.
93_U S _M 07.book Page 2 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 3 of 304
3
Instrument panelChanging bulbs __________ 219
Front fog lights___________ 99
Headlight levelling ________ 97
High/low beam __________ 98
Parking lights____________ 97
Rear fog light ____________ 99Cruise Control ___________ 169
Direction indicators _______ 100
High/low beam control stalk 98
Fuel gauge __________________ 89
Odometer and trip meter ________ 90
Speedometer ________________ 87
Tachometer __________________ 87
Temperature gauge ____________ 88
Turbo gauge _________________ 88
Warning and indicator lights _____ 82
Saab Information Display (SID) ___ 89Ashtray _____________________ 134
Cigarette lighter _______________ 134
Replacing wiper blades ___ 217
Washers and wipers ______ 101
Washer fluid ____________ 218Automatic climate control __ 106
Car care and maintenance _ 268
Hazard warning lights_____ 100
Seat heating, ACC _______ 113
93_U S _M 07.book Page 3 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 4 of 304
4ExteriorAnti-corrosion treatment ___ 265
Body __________________ 264
Service program _________ 274
Moonroof_______________ 128
Touching up paintwork ____ 264
Washing _______________ 261
Waxing and polishing _____ 264Brake lights _____________ 227
Changing bulbs __________ 219
Light switches ___________ 97
Taillights _______________ 227Towing _________________ 195
Towing hook eyes ________ 195
Towing a trailer __________ 188Folding down the rear seat _ 136
Lighting ________________ 227
Load-through hatch _______ 138
Spare wheel ____________ 140
Tools __________________ 140
Trunk __________________ 136
Maximum loads _______________ 280
Mounting holes for roof carriers ___ 192
Roof load ____________________ 192
Hood _______________________ 202
Washing the engine bay_________ 261
Central locking __________ 48
Child safety locks ________ 52
Lock buttons ____________ 48
Trunk lock ______________ 51Changing bulbs _________ 219
Dipswitch ______________ 97
Direction indicators_______ 100
Front lights _____________ 221
Headlight levelling (xenon) _ 97
Headlight switches _______ 97
Headlight washers _______ 218Economical motoring _____ 183
Fuel filler door __________ 157
Fuel gauge _____________ 89
Fuel grade _____________ 285
Refueling ______________ 157
Braking _____________________ 170
Changing wheels ______________ 257
Spare wheel _________________ 254
Tire pressure ________________ 292
Tires _______________________ 241
Wheels _____________________ 290
Winter driving ________________ 185
93_U S _M 07.book Page 4 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 5 of 304
5
InteriorAirbag _________________ 32
Steering wheel adjustment _ 118
Steering _______________ 288
Interior rearview mirror _________ 123
Vanity mirror _________________ 132
Door mirrors__________________ 122
Airbag_________________ 32
Child safety locks ________ 52
Child seats _____________ 24
Safety belt care _________ 260
Safety belts ____________ 12Glove box ______________ 134
Storage compartments____ 134Automatic transmission ___ 163
Changing gears _________ 162
Manual transmission _____ 162
Child seats ________________ 24
Folding down the rear seat ____ 136
Rear seat__________________ 136
Safety belts ________________ 12
Seat adjustment ____________ 18
Seat heating _______________ 113
Upholstery care _____________ 260
Interior lighting: changing bulbs ___ 232
Interior light switches ___________ 131
Moonroof ____________________ 128
Ashtray and cigarette lighter _____ 134
Break-In Period _______________ 161
Driving in hot/cold climates ______ 185
Ignition switch ________________ 150
Parking brake_________________ 177
Parking _____________________ 177
Starting the engine ____________ 152
Fuses _________________ 234Electric windows _________ 11993_U S _M 07.book Page 5 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 6 of 304
6Engine bay, 4-cylColor code______________ 293
Engine number __________ 293
Gearbox number _________ 293
Warning labels __________ 8
Vehicle identification number 293Alternator_______________ 216
Drive belt _______________ 216
Exhaust emission control __ 155
Ignition system __________ 286
Simple troubleshooting (ACC) 268
Spark plugs _____________ 286
Turbo gauge ____________ 88Engine oil: checking level __ 207Automatic transmission _________ 163
Transmission: technical data _____ 287
Manual transmission ___________ 162
Battery ______________________ 213
Battery charge ________________ 213
Jump starting _________________ 198
Engine: description ____________ 202
Engine: technical data __________ 283
Important considerations for driving 154
Oil grade and viscosity__________ 284
Topping-up fluid _________ 218
Wash/wipe stalk switch____ 101
Washer fluid ____________ 218
Washer jets ____________ 218
Power steering ________________ 212
Fluid: checking/topping up _______ 212
Coolant: checking/topping-up ____ 209
Driving in hot climates __________ 187
Radiator _____________________ 283
Temperature gauge ____________ 88
Changing a fuse _________ 234
Fuse table _____________ 239
Fuses _________________ 234
Relays ________________ 239ABS brakes_____________ 170
Brake pads _____________ 211
Brake system ___________ 289
Brake fluid______________ 211
93_U S _M 07.book Page 6 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 7 of 304
7
Engine bay, 2.8 V6Power steering___________ 212
Fluid: checking/topping up__ 212Vehicle identification
number ________________ 293
Colour code _____________ 293
Engine number __________ 293
Warning labels___________ 8
Gearbox number _________ 293Exhaust emission control __ 155
Drive belt _______________ 216
Simple troubleshooting (ACC) 268
Alternator_______________ 216
Turbo gauge ____________ 88
Spark plugs _____________ 286
Ignition system __________ 286Automatic transmission _________ 163
Manual gearbox_______________ 162
Gearbox: technical data_________ 287
Engine: description ____________ 202
Engine oil: topping up __________ 207
Oil grade and viscosity__________ 284
Engine: technical data __________ 283
Important considerations
for driving ___________________ 154Engine oil: checking level________ 207
Battery ______________________ 213
Battery charge ________________ 213
Jump starting _________________ 198
Wash/wipe stalk switch ____ 101
Topping-up fluid _________ 218
Washer jets_____________ 218
Washer fluid ____________ 218Changing a fuse _________ 236
Fuses _________________ 234
Relays ________________ 239
Fuse table ______________ 236ABS brakes_____________ 171
Brake pads _____________ 289
Brake system ___________ 170
Brake fluid______________ 211
Cooling system, coolant capacity__ 283
Coolant: checking/topping-up ____ 209
Driving in hot climates __________ 187
Temperature gauge ____________ 88
93_U S _M 07.book Page 7 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 8 of 304
8
Coolant:Never open when engine hot!
Radiator fan:Radiator fan may start at any
time.
Battery: No sparks, flames or smoking
Shield eyes, explosive gases can cause blindness or injury
Sulphuric acid can cause blindness or severe burns
Flush eyes immediately with water. Get medical help fast
Do not tip battery. Do not open battery
NO SPARKS, FLAMES OR SMOKING
SHIELD EYES
KEEP OUT OF REACH FROM CHILDREN
SEE OWNER’S MANUAL
EXPLOSIVE GASWarning labelsA/C system:Refrigerant at high pressure.
Do not loosen or remove the A/C system fittings before discharging the A/C
system. Improper service methods may cause personal injury.
System to be
serviced by qualified personnel only. For instructions consult dealer man-
ual.
The A/C system complies with SAE J639.
Charge: 680 g R134a.
Compressor oil: 150 cc PAG oil SP-10 alt.
Saab oil 4759106
Maintenance FreeP/N 127 93 95512V 60Ah 580A (EN)
000 A-12102-EP
LEVEL INDICATORDARK OK
CLEAR LOW
CANADA
NETTOYER LE BOUCHON
DE REMPLISSAGE
AVANT DE L’ENLEVER.
UTILISER SEULEMENT
DU LIQUIDE DOT 4 PROV-
ENANT D’UN CONTE-
NANT SCELLÉ.
93_U S _M 07.book Page 8 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 9 of 304
9
Changing wheels:Use only on specified vehicle. Safe working load
2425 lbs. (1100 kg). Use on level firm ground only. Do
not get under a vehicle that is supported only by a jack,
use vehicle support stands. No persons are to remain in
the vehicle.
Contact a Saab dealer if a
xenon headlight requires
replacement.
This label is only found on
cars with xenon headlights.
EVEN WITH ADVANCED AIR BAGS Children can be killed or serious injured by the air bag.
The back seat is the safest place for children.
Never put a rear-facing child seat in the front.
Always use seat belts and child restraints.
Jack Jack is designed only for changing a tire or mounting
tire snow chains.
Vehicle must be level and jack must be placed on firm
and level ground.
Never crawl underneath vehicle when it is jacked up.
JACKING INSTRUCTION
1 Set parking brake and shift transmission to park.
2 Fit top of jack into jacking point next to wheel to be
changed.
3 Crank jack so that vehicle begins to lift.
4 Using socket wrench in tool kit, loosen wheel bolts
one-half turn.
5 Raise vehicle so that tire clears ground. Loosen
wheel bolts completely and remove wheel.
6 Mount spare wheel and tighten bolts enough so
wheel is not loose.
7 Lower vehicle. Tighten wheel bolts in a crisscross
sequence.
93_U S _M 07.book Page 9 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
Page 10 of 304
10
No sparks,
flames or
smokingBuckle up
Refer to
the Owner’s
ManualAirbag
Shield eyesNever place a
rear-facing
child seat in
this seat
Keep out of
reach of
childrenElectric
windows
Battery acid
contains sul-
phuric acidDeactivating
of rear window
switches
Risk of
explosive gasCentral
locking, lock
Central
locking,
unlock
Trunk lid,
opening
HeadlightsWindshield
wipers
Direction
indicatorsWindshield
washers
Parking lights Defroster
Hazard warn-
ing lightsRear window
heating
Front fog
lightsCabin fan
Rear fog light
Coolant tem-
peratureRadiator fan
No charge to
batteryFuel
Foot brake
Coolant level
Engine oil
pressure
ABS brakes
Electronic
Stability
Program
Example of symbols that can be found in your car93_U S _M 07.book Page 10 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com
