231 Specifications
Drive belts Manual gearboxEngine variants Outside length
4-cylinder with A/C system, poly-V-belt __ 102.84 in
(2612 mm)
6-cylinder with A/C system, poly-V-belt __ 79.53 in
(2020 mm) Drive belt, 4-cylinder with
A/C system Drive belt, 6-cylinder with
A/C system
IB542
IB543
Type _____________________________ All-synchromesh
5-speed with final
drive and differen-
tial
Oil _______________________________ Saab synthetic
manual gearbox oil
Oil capacity ________________________ 1.9 qts (1.8 litres)
Oil volume (on changing) _____________ 1.6 qts (1.5 litres)
Clutch type ________________________ Hydraulic, single
dry-plate clutch of
diaphragm-spring
type
Speed (mph / km/h) at 1000 rpm in 5th gear:
4-cylinder ________________________ 27–28 / 43–44
ProCarManuals.com

232 SpecificationsAutomatic transmission Suspension
SteeringType ____________________________ Electronically con-
trolled 4-speed,
fully automatic with
hydraulic torque
converter, planetary
gear set and inte-
gral final drive
Lock-up function in
selector positions 3
and 4
Selector-lever positions ______________ P R N D 3 2 1
Transmission-fluid capacity, dry transmis-
sion (incl. torque converter and oil cooler) 7.5 qts (7 litres)
If fluid change required, approximately
3.5 litres can be drained through the drain
plug in the transmission casing
Transmission fluid __________________ Texaco Texamatic
Dexron III (mineral
oil based)
Clutch type _______________________ Hydraulic plate
clutches, brake
bands and one-way
couplings
Speed (mph / km/h) at 1000 rpm in 4th gear:
4- and 6-cylinder _________________ 29 / 46–47Spring type, front and rear ____________ Coil springs
Maximum deflection of springs:
Front ___________________________ 7.09 in (180 mm)
Rear ___________________________ 7.87 in (200 mm)
Dampers, front and rear ______________ Gas-filled dampers
Steering __________________________ Power-assisted
steering of
rack-and-pinion
type; telescopic
steering-column
shaft with universal
joints
Number of turns, lock to lock ___________ 2,9
Power-steering fluid _________________ Power-steering
fluid CHF 11S
ProCarManuals.com

233 Specifications
Brake system Wheels and tiresFootbrake (ABS) ___________________ Hydraulic disc
brakes with vacuum
servo unit. Diago-
nally split circuits;
ventilated discs on
front wheels. EBD
function, see page
146.
Handbrake _______________________ Acts on rear wheels
Brake fluid ________________________ DOT 4
Brake-fluid capacity _________________ 0.925 qts (900 ml)
Disc diameter:
Front __________________________ 11.34 in (288 mm)
Front, 9-5 2.3 Turbo Aero ___________ 12.05 in (306 mm)
Rear ___________________________ 11.26 in (286 mm)
Total friction area of brake pads:
Front __________________________ 36.3 in
2 (234 cm
2)
Rear ___________________________ 15.5 in
2 (100 cm
2)Wheel size ________________________ 6.5 x 16 or 7 x 17
9-5 2.3 Turbo Aero ___________________ Use 6.5 x 16 or
7 x 17 only
Tire size (summer tires):
6.5 x 16 wheels ___________________ 215/55 R16
7 x 17 wheels _____________________ 225/45 R17
Tire size (winter tires):
6 x 15 wheels (not 9-5 2.3 Turbo Aero) __ 195/65 R15 M+S
6.5 x 16 wheels ___________________ 205/55 R16 M+S
Recommended wheels for snow chains _ 6 x 15 (not 9-5 2.3
Turbo Aero) or
6.5 x 16
Compact spare:
Wheel ___________________________ 4 x 16
Tire _____________________________ T115/70 R16
Pressure_________________________ 60 psi (420 kPa)
Maximum life _____________________ 2,200 miles
(3500 km)
Maximum speed __________________ 50 mph (80 km/h)
ProCarManuals.com

234 SpecificationsNOTESnow chains
Snow chains must not be fitted to the rear wheels and must be
used on the following tire/wheel combinations:
Wheel Tire
6 x 15_________ 195/65 R15 M+S (not 9-5 2.3 Turbo Aero) or
205/65 R15 M+S (not 9-5 2.3 Turbo Aero)
6.5 x 16________ 205/55 R16 M+S or
215/55 R16
Max. speed is 30 mph (50 km/h).
Consult your authorized Saab dealer of approved snow chains.NOTEWheels larger than 17” must not be fitted.
The wheel offset must not exceed 49 mm.
Vehicles with 12.05 in (306 mm) front brake discs must not use
15” rims.
Front-wheel alignment: toe-in, measured
between rims:
Front __________________________ 0.0585±0.0195 in
(1.5±0.5 mm)
Rear ___________________________ 0.0866±0.0585 in
(2.2±1.5 mm)
ProCarManuals.com

235 Specifications
Plates and labels When consulting your Saab dealer, it may be
necessary to quote the car’s V.I.N., engine
and gearbox numbers.
1 Modification identity plate.
2 V.I.N. number, inside windshield.
3 Certification label.
4 Gearbox number.
5 Engine number.
6 Tire pressures and color codes
(body & trim), label.
7 Chassis number plate.
8 Chassis number, stamped on body.
9 Vehicle Emission Control Information.
10 Spark ignition system information
(Canada only).
4728473
CANADA US
IB1366
ProCarManuals.com

236 Specifications 1 Region ___________Y = Northern Europe
2 Country __________S = Sweden
3 Manufacturer _____3 = Saab Automobile AB
4 Product line ______E = 9-5
5 Model series ______D = 9-5 with driver’s and
passenger-side airbags
F = 9-5 SE with driver’s and
passenger-side airbags
H = 9-5 Aero with driver’s and
passenger-side airbags
M = 9-5 Griffin with driver’s and
passenger-side airbags
6 Body version _____4 =
5 =4-door
5-door
7 Gearbox __________5 = Manual 5-speed
8 = Automatic 4-speed8 Engine variant _____E =
G =
Z =2.3t
2.3 Turbo
3.0t
9 Check digit ________0-9/X
10 Model year ________Y = 2000
11 Factory ___________3 = Trollhättan
12 Serial number ______000001-999999 position:1234567891011 12
||||||||||| |
V.I.N.:YS3EF4 8E6Y3045842
| | ||||
1 2 3456= identification codes for certain chassis details
IB541
ProCarManuals.com

237 Specifications
Several of the systems in your Saab
car can be adjusted to better fit your
individual needsSome functions are governed by legal
requirements and cannot therefore be
reprogrammed.
Consult an authorized Saab dealer for fur-
ther information.
Car alarm/central locking system:
 The sound level of the siren when locking/
unlocking, HIGH or LOW.
 The number of blinks when locking/
unlocking, 1 to 7.
 Automatic locking of the trunk when the
car is driven, 1 to 8 mph (2-14 km/h), YES
or NO.
 Preclude the unlocking of the trunk while
the car is driven, YES or NO.
 Automatic locking of the trunk after
1 second-4 minutes if it has not been
opened, YES or NO.
 Automatic locking of the trunk when it is
closed, YES or NO.Automatic Climate Control (ACC):
 Indoor temperature can be
increased/decreased relative to the
selected temperature.
 Delayed start of fan after starting the car,
to reduce risk of fogging windshield.
 Temperature at which the defroster mode
is automatically selected.
 Response time for the fan speed when
the selected temperature is changed.
 Temperature at which the air distribution
switches from defroster mode to
defrost/floor mode.
 Last manual selection will be selected the
next time the car is started.Saab Information Display:
 Outdoor temperature display can be
adjusted.
 Days remaining to next service can be
activated/counted or not.
 Delete “Test Brake Light“ message on
SID at start-up.
Miscellaneous:
 Select the on-time for heated rear seat.
 Coolant temperature gauge adjustment
can be increased/decreased.
 Fuel level gauge adjustment can be
increased/decreased.
 Additional sweep of the wipers after wind-
shield washer function (ON or OFF).
 Follow me home on-time can vary from 20
to 50 seconds.
 Night panel illumination deactivation
speed for the speedometer can be
adjusted.
ProCarManuals.com

238 SpecificationsFollowing adjustments can be done
by the driver:Automatic Climate Control (ACC):
To alter the preprogrammed “AUTO“ start
up mode with your own preferences you can
manually select the desired settings for:
 Temperature.
 Fan speed.
Air distribution.
See “Programming I“ on page 73 and “Pro-
gramming II“ on page 74.Saab 9-5 Audio System (see page 93):
 Maximum starting volume (when the
radio is switched on).
 Telephone volume (if the car is equipped
with a phone connected to the audio sys-
tem).
 Speed dependent volume (volume
increases or decreases with vehicle
speed).
 Loudness.Alarm system:
The glass breakage sensor can be tempo-
rarily disabled, see page 39.
Daytime Running Lights:
To disable, turn off the ignition and pull out
fuse 35, see page 194.
ProCarManuals.com

239 Specifications
Afterheater, V6-engine carsThe afterheater enables a comfortable temperature to be main-
tained inside the car even after the engine has been switched off.
The heater can be activated up to 10 minutes after the engine has
stopped, although the coolant temperature must be at least 40°C for
the heater to operate.
To start the heater:
1 The ignition should be OFF.
2 Press and hold the AUTO button on the ACC panel for about a
second, until a chime is sounded and the following appears on
the SID:
”AFTERHEATER
ACTIVATED”.
After five seconds, the SID will indicate how much heat is available
(0 – 100%).
To switch off the heater:
1 Press the OFF button on the ACC panel.
The heater will also be switched off if the ignition is turned ON. The following settings will be in force when the heater is running:
 Air distribution in AUTO mode.
 Recirculation not active but can be selected manually.
 Fan speed is automatic and cannot be changed.
 Only the fan speed is shown on the display. If AUTO is pressed,
the system selections will be indicated.
The following controls do not operate while the afterheater is on:
 Rear-window heating.
 ECON.
 User presets.
Some of the functions can be reprogrammed. For further informa-
tion, please consult your Saab dealer (see page 237).
ProCarManuals.com

240 Specifications
