1
Owner’s Manual
Saab 9-5, Model Year 2007
Safety 11
Security 43
Instruments and controls 57
Saab 9-5 Audio System3 90
Interior equipment and trunk 113
Starting and driving 139
Car care and technical information 189
Customer Assistance and Information 251
Specifications 257
Index 271
© Saab Automobile AB 2006
Service Readiness, Saab Automobile AB, Trollhättan, Sweden
Printed in Sweden95_U S _M 07.book Page 1 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 2 of 288
2Introduction This manual provides practical guidance on
driving and caring for your Saab.
Although this manual describes the most
important differences between model vari-
ants, it does not include precise specifica-
tions of the different variants. Some differ-
ences also occur to meet special legal
requirements in different countries.
Importation and distribution of Saab auto-
mobiles, spare parts and accessories are
handled exclusively by General Motors of
Canada Limited in Canada and by Saab
Cars USA, Inc. in the U.S.A.We recommend that you read through the
manual before taking the car out for the first
time and that you keep it in the car for future
reference.
To find a specific item, use the overviews
given on pages 3–6. A list of contents is
given at the beginning of each section of the
manual, and there is also a comprehensive
index at the back of the book.
Supplied with the car is a Warranty and Ser-
vice Record booklet and a tire warranty
folder which specifies the regular mainte-
nance to be carried out. The book also con-
tains important warranty conditions.
Since the policy at Saab is one of continual
improvement, we retain the right to incorpo-
rate modifications and to alter specifications
during production without prior notice.
3 Asterisk means: equipment not fitted in all
cars (can depend on model variant, engine
variant, market specification, options or
accessories).
If you have any questions concerning your
car, its equipment, the warranty conditions
or the like, your Saab dealer will be pleased
to help.
Best wishes,
Saab Automobile AB Saab Automobile AB does not accept liability for
any damage caused by the fitting of spare parts,
exchange parts or accessories that are not
approved by Saab Automobile AB.
The specifications, design particulars and illus-
trations included in the manual are not binding.
WARNING
WARNING texts warn against the danger
of injury if the specified instructions are
not followed. NOTICENOTICE texts warn of potential damage
to the car if the recommendations are not
followed.
95_U S _M 07.book Page 2 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 3 of 288
3
Instrument panel
IB3830
Indicator and warning lights ______ 58
Speedometer _________________ 65
Odometer and trip meter ________ 64
Fuel gauge___________________ 65
Temperature gauge ____________ 65
Saab Information Display (SID) ___ 68
Parking lights____________ 73
High/low beam __________ 73
Daytime running lights_____ 73
Instrument illumination ____ 75
Changing bulbs __________ 204
Rear fog light ____________ 74
NIGHT PANEL __________ 72Turn signal and lane change
indicators ______________ 75
High beam flasher ________ 73
Cruise control3_________ 159Front fog lights3_________ 76
NIGHT PANEL __________ 72
Powe r O ut l et3________________ 126
Wipers and washers ______ 77
Rear-window wiper
(SportCombi)3_________ 78
Rain sensing wipers3____ 77
Washers _______________ 203
Wipers and washers ______ 202Saab 9-5 Audio System3_ 90
Steering wheel controls3_ 91Hazard warning lights_____ 76Automatic climate control
(ACC) ________________ 79
Air conditioning (ACC) ____ 243
Heated front seats3___________ 87
Head restraint ________________ 21
Steering wheel controls3_______ 91
Sentronic, manual mode 33____ 15695_U S _M 07.book Page 3 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 4 of 288
4Exterior
IB3831
Driving with a roof rack load______ 179
Fitting the roof carriers3________ 179
Maximum roof load ____________ 258
Rearview mirror _______________ 118
Hood _______________________ 190
Engine compartment: washing ___ 242
Central locking __________ 44
Trunk lid lock, 9-5 Sedan __ 47
Tailgate, 9-5 SportCombi __ 48
Child safety locks ________ 47
Car alarm3____________ 50Headlights _____________ 73
High/low beam __________ 73
Turn signal and lane change
indicators______________ 75
Headlight washers3_____ 77
Changing bulbs _________ 204
Fuel gauge___________________ 65
Refueling ____________________ 146
Economical motoring ___________ 170
Fuel ________________________ 260
b Tires pressure ________________ 267
Wheels and tires ______________ 266
Braking______________________ 160
Driving in cold weather__________ 172
Compact spare tire_____________ 234
Changing a wheel _____________ 236
Trunk _______________________ 129
Folding the rear seat, 9-5 Sedan __ 129
Folding the rear seat,
9-5 SportCombi ______________ 132
Trunk Release Handle __________ 138
Driving with a spare wheel fitted __ 183
Compact spare tire ____________ 234Towing a trailer3________ 174
Towing the car ___________ 183
Rear towing eye _________ 184Headlights ______________ 73
Rear light cluster, 9-5 Sedan 208
Rear lights clusters,
9-5 SportCombi _________ 210
Changing bulbs __________ 204Moonroof3_____________ 123
Washing the car _________ 241
Waxing and polishing _____ 242
Touching up the paint _____ 242
Anti-corrosion treatment ___ 24595_U S _M 07.book Page 4 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 5 of 288
5
Interior
IB3832
Rearview mirrors ______________ 116
Door mirrors __________________ 116
Sun visors ___________________ 125
Safety belts ____________ 12
Airbag_________________ 29
Child safety ____________ 22
Child safety locks ________ 47
Safety belts, maintenance _ 239Glove compartment ______ 126Manual transmission _____ 150
Automatic transmission3_ 151
Electric windows ______________ 115
Ignition switch ________________ 140
Starting the engine ____________ 141
Engine Break-In Period _________ 150
Driving in hot weather __________ 173
Driving in cold weather _________ 172
Parking _____________________ 165
Steering wheel adjustment _ 114
Airbag _________________ 29
Power steering fluid _______ 198
Steering wheel controls3__ 91
Sentronic, manual mode 33 156Seats __________________ 18
Heated front seats3______ 87
Head restraint3_________ 21
Safety belts _____________ 12
Child safety _____________ 22
Folding the rear seat,
9-5 Sedan _____________ 129
Folding the rear seat,
9-5 SportCombi _________ 132
Upholstery and trim _______ 240
Side airbags ____________ 36
Interior lighting ________________ 124
Moonroof3__________________ 123
Dome light, front ______________ 214
95_U S _M 07.book Page 5 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 6 of 288
6Engine compartment
IB3636
Engine ______________________ 194
Checking the oil level ___________ 194
Engine oil, specification _________ 261
Braking______________________ 160
ABS brakes __________________ 161
Brake and clutch fluid ___________ 196
Brake system _________________ 265
Brake pads ___________________ 265
Fuses _________________ 216
Changing a fuse _________ 218
Relays ________________ 220
Table of fuses ___________ 216Temperature gauge ______ 65
Driving in hot weather_____ 173
Driving in cold weather ____ 172
Coolant _______________ 195
Coolant capacity_________ 260
Power steering fluid _______ 198
Steering, technical data ___ 265
Wipers and washers ______ 77
Washers _______________ 203
Washer jets ____________ 203
Jump starting _________________ 186
Battery ______________________ 199
Charging/replacing the battery____ 200
Manual transmission ___________ 150
Automatic transmission3_______ 151
Automatic transmission,
technical data ________________ 264
Manual gearbox, technical data ___ 264
Important considerations for driving 144
Turbo unit ___________________ 191
Engine, technical data __________ 260Ignition switch ___________ 140
Drive belts ______________ 201
Spark plugs _____________ 263
Catalytic converter _______ 145Warning labels __________ 7
V.I.N. number ___________ 268
Engine number __________ 268
Gearbox number _________ 268
Color code______________ 268
Tire and Loading Information
Label _________________ 23195_U S _M 07.book Page 6 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 7 of 288
7
Battery No sparks, flames or smoking.
Shield eyes, explosive gases can cause blindness or injury.
Sulphuric acid can cause blindness or severe burns.
Flush eyes immediately with water. Get medical help fast.
Do not tip battery. Do not open battery.
KEEP OUT OF REACH OF CHILDREN Brake fluid
CLEAN FILLER CAP BEFORE
REMOVING. USE ONLY DOT 4
FLUID FROM SEALED CON-
TAINER. Radiator fan
Radiator fan may start at
any time.
IB336
A/C system
Refrigerant at high pressure.
Do not loosen or remove the A/C system fittings before
discharging the A/C system. Improper service methods
may cause personal injury. System to be serviced by
authorized personnel only. For instructions consult
workshop manual.
The A/C system complies with SAE J639.
Charge: 825 g of R134a.
Compressor oil: PAG oil SP-10 alt.
Saab oil 4759106
Oil amount: See workshop manual.
Warning labels
Maintenance FreeP/N 127 93 95512V 60Ah 580A (EN)
000 A-12102-EP
LEVEL INDICATORDARK OK
CLEAR LOW
AVOID SPARKS AND OPEN FLAMES,
NO SMOKING
WEAR EYE PROTECTION
KEEP OUT OF REACH OF CHILDREN
SEE OWNER’S MANUAL
FLAMMABLE GAS
Coolant:
Never open when engine hot!95_U S _M 07.book Page 7 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 8 of 288
8
IB336
WARNING
EVEN WITH ADVANCED AIR BAGS
Children can be killed or seriously
injured by the air bag.
The back seat is the safest place for
children.
Never put a rear-facing child seat in
the front.
Always use seat belts and child
restraints.Contact a Saab dealer if a
xenon headlight requires
replacement.
This label is only found on
cars with xenon head-
lights.
Jack
Use only on specified vehicles. Safe working load 1100
kg. Use on level firm ground only. Do not get under a
vehicle that is supported only by a jack, use vehicle sup-
port stands.
For more information see your owner´s manual.
95_U S _M 07.book Page 8 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 9 of 288
9
No sparks, fla-
mes or smo-
king.Buckle up
Use protective
gogglesAirbag
Keep out of
reach of
children.Never place a
rear-facing
child seat in
this seat.
Battery acid
contains
sulfuric acid.Electric
windows
Refer to the
Owner’s
Manual.Deactivating
of rear window
switches
Risk of
explosive gas.Central
locking, lock
.Central
locking,
unlock
Tr u n k
lid/tailgate,
opening
HeadlightsWindshield
wipers
Direction
indicatorsWindshield
washers
Parking lights Defroster
Hazard
warning lightsRear window
heating
Front fog
lightsVentilation fan
Rear fog
light
Coolant
temperatureRadiator fan
Battery
chargingFuel
Foot brake
Coolant level
Engine oil
pressure
ABS brakes
Examples of symbols that can be found in your car95_U S _M 07.book Page 9 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
Page 10 of 288
10(This page has been left blank)95_U S _M 07.book Page 10 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
