SATURN AURA HYBRID 2010 User Guide

Windows
On vehicles with power
windows, the switches are
on the driver door
armrest.
Each passenger door has a switch that controls only
that window.
Press the front of the switch to open the window. Pull
the switch up to close it.
For more information, seePower Windows on
page 3-15.
Seat Adjustment
Manual Seat
1. Lift the bar under the
seat to unlock the seat.
2. Slide the seat to
the desired position
and release the bar.
Try to move the seat to be sure it is locked in place.
SeeManual Seats on page 2-3.
1-7
ProCarManuals.com

Power Seats (If Equipped)
Move the seat forward or rearward by moving the
control forward or rearward.
Raise or lower the front or rear of the seat cushion by
moving the front or rear of the control up or down.
SeePower Seats on page 2-4.
Power Reclining Seatbacks
(If Equipped)
To raise or recline the seatback, tilt the top of the
control forward or rearward.
SeeReclining Seatbacks on page 2-6.
1-8
ProCarManuals.com

Power Lumbar
Press the front (A) or rear (B) of the control to increase
or decrease lumbar support.
SeePower Lumbar on page 2-5.
Heated Seats (If Equipped)
Press the top of the switch to turn the feature on to the
high heat setting. The indicator light (2) will be lit.
Press the top of the switch again to go to the low heat
setting. The indicator light (1) will be lit.
Press the bottom of the switch to turn the feature off.
1-9
ProCarManuals.com

Second Row Seats
Rear Seat
Either side of the seatback can be folded down.
Pull up on the seatback strap while folding the seatback
down to allow access to the trunk.
For more information, seeRear Seats on page 2-9.
Safety Belt
Refer to the following sections for important information
on how to use safety belts properly.
•Safety Belts: They Are for Everyone on page 2-11.
•How to Wear Safety Belts Properly on page 2-16.
•Lap-Shoulder Belt on page 2-24.
•Lower Anchors and Tethers for Children (LATCH)
on page 2-42.
1-10
ProCarManuals.com

Sensing System for Passenger
Airbag
The passenger sensing system will turn off the right
front passenger frontal airbag and seat-mounted
side impact airbag under certain conditions. The driver
airbags and roof-rail airbags are not affected by this.
The passenger airbag status indicator will be visible on
the instrument panel when the vehicle is started.
SeePassenger Sensing System on page 2-66for
important information.
Mirror Adjustment
Exterior Mirrors
Controls for the outside
power mirrors are located
on the inside of the
vehicle near the driver side
mirror.
Use the selector switch to choose either the left or right
outside mirror. Then press the four-way control pad
to move the selected mirror in the desired direction.
SeeOutside Power Mirrors on page 3-35. United States
Canada
1-11
ProCarManuals.com

Interior Mirror
Hold the inside rearview mirror in the center to move it
for a clearer view of behind the vehicle. Adjust the
mirror to reduce the glare of headlamps from behind by
pushing the tab located at the base of the mirror,
forward for daytime use. Pull the tab for nighttime use.
SeeManual Rearview Mirror on page 3-35.
Steering Wheel Adjustment
The lever is located on the left side of the steering
wheel column.
1-12
ProCarManuals.com

To adjust the steering wheel:
1. Pull the lever down.
2. Move the steering wheel up or down or backward
or forward into a comfortable position.
3. Pull the lever up to lock the steering wheel in place.
SeeTilt and Telescopic Steering Wheel on page 4-3.Interior Lighting
Dome Lamp
The dome lamps come on when any door is opened.
They turn off after all the doors are closed.
The dome lamps can also be turned on by turning the
instrument panel brightness knob, located on the
instrument panel to the left of the steering column,
clockwise to the farthest position. In this position, the
dome lamps remain on whether a door is opened
or closed.
1-13
ProCarManuals.com

Reading Lamps
For vehicles with a front overhead console and rear
reading lamps, they come on automatically when
any door is opened. For manual operation while the
doors are closed, press the lens to turn the lamp on
or off.
For more information on interior lighting, see:
•Instrument Panel Brightness on page 4-12.
•Entry/Exit Lighting on page 4-13.
•Parade Dimming on page 4-13.
Exterior Lighting
The lever is located on the left side of the steering
wheel.
2:Turns on the headlamps, parking lamps, and
taillamps.
;:Turns on the parking lamps and taillamps only.
1-14
ProCarManuals.com

AUTO:Automatically turns on the Daytime Running
Lamps during daytime, and the headlamps, parking
lamps, and taillamps at night.
P:Turn the band to this position to turn the Automatic
Headlamp System on or off. In Canada, this position
only works when a vehicle is in the P (Park) position.
For more information, see:
•Headlamps on page 4-10.
•Daytime Running Lamps (DRL) on page 4-11.
•Automatic Headlamp System on page 4-12.
Windshield Wiper/Washer
The windshield wiper lever is on the right side of the
steering column.
9:Turns the wipers off.
&:For intermittent or speed sensitive operation. The
amount of delay time varies between wiping cycles
due to the delay setting selected or the speed of the
vehicle. As vehicle speed is increased or decreased, the
wiper interval also increases or decreases.
1-15
ProCarManuals.com

x:Move the lever to the&position, then turn the
xband up for more frequent wipes or down for
less frequent wipes.
6:Slow wipes.
1:Fast wipes.
8:Single wipe, move the lever down, then release it.
Several wipes, hold the lever down.
Windshield Washer:Press the button at the end of the
lever until the washers begin.
SeeWindshield Wipers on page 4-5andWindshield
Washer on page 4-6.
Climate Controls
The vehicle’s heating, cooling, and ventilation can be
automatically controlled with this system.
A. Fan Control
B. Air Conditioning
C. Air Recirculation
D. Hybrid Air
ConditioningE. Rear Window
Defogger
F. Air Delivery Mode
Control
G. Display
H. Temperature Control
SeeAutomatic Climate Control System on page 4-16.
1-16
