SATURN ION 2004 Owners Manual

2. Then go to the front of the vehicle and push the
hood release latch to the side.3. Lift the hood, release
the hood prop from its
retainer and put the
hood prop into the slot
in the hood.
Before closing the hood, be sure all the ller caps are
on properly. Then lift the hood to relieve pressure on the
hood prop. Remove the hood prop from the slot in the
hood and return the prop to its retainer. Then just let the
hood down and close it rmly.
5-11
ProCarManuals.com

Engine Compartment Overview
When you open the hood on 2.2L L4 engine, you’ll see the following:
5-12
ProCarManuals.com

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
B. Engine Oil Fill Location. SeeEngine Oil on
page 5-15.
C. Engine Oil Dipstick Location. SeeEngine Oil on
page 5-15.
D. Brake Master Cylinder. SeeBrakes on page 5-38
andHydraulic Clutch on page 5-25.
E. Remote Positive Terminal Location. SeeJump
Starting on page 5-42.F. Engine Compartment Fuse Block. SeeFuses and
Circuit Breakers on page 5-95.
G. Surge Tank. SeeEngine Coolant on page 5-26.
H. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-37.
Before closing the hood, be sure all ller caps are on
properly.
5-13
ProCarManuals.com

When you open the hood on 2.0L Supercharged engine, you’ll see the following:
5-14
ProCarManuals.com

A. Engine Oil Dipstick Location. SeeEngine Oil on
page 5-15.
B. Electric Cooling Fan. SeeCooling System on
page 5-32.
C. Engine Oil Fill Location. SeeEngine Oil on
page 5-15.
D. Radiator Pressure Cap. SeeEngine Coolant on
page 5-26.
E. Brake Master Cylinder. SeeBrakes on page 5-38
andHydraulic Clutch on page 5-25.
F. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
G. Engine Compartment Fuse Block. SeeFuses and
Circuit Breakers on page 5-95.
H. Remote Positive Terminal Location. SeeJump
Starting on page 5-42.
I. Surge Tank. SeeCoolant Surge Tank Pressure Cap
on page 5-29.
J. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-37.
Before closing the hood, be sure all ller caps are on
properly.Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop. See
Engine Compartment Overview on page 5-12for
the location of the engine oil dipstick.
Turn off the engine and give the oil several minutes to
drain back into the oil pan. If you don’t, the oil
dipstick might not show the actual level.
Pull out the dipstick and clean it with a paper towel or
cloth, then push it back in all the way. Remove it again,
keeping the tip down, and check the level.
5-15
ProCarManuals.com

When to Add Engine Oil
If the oil is at or below the MIN mark, then you will need
to add at least one quart of oil. But you must use the
right kind. This section explains what kind of oil to use.
For engine oil crankcase capacity, seeCapacities
and Specications on page 5-102.
Notice:Do not add too much oil. If your engine has
so much oil that the oil level gets above the upper
mark that shows the proper operating range,
your engine could be damaged.SeeEngine Compartment Overview on page 5-12for
the location of the engine oil ll cap.
Be sure to add enough oil to put the level somewhere in
the proper operating range. Push the dipstick all the
way back in when you are through.
What Kind of Engine Oil to Use
For Vehicles With the 2.2L L4 Engine Only
Look for two things:
GM6094M
Your vehicle’s engine requires oil meeting GM
Standard GM6094M. You should look for and use
only an oil that meets GM Standard GM6094M.
2.2L L4 Engine2.0L Supercharged
Engine
5-16
ProCarManuals.com

SAE 5W-30
As shown in the viscosity chart, SAE 5W-30 is best
for your vehicle. However, if it is going to be 0°F
(–18°C) or above and SAE 5W-30 is not available,
you may use SAE 10W-30.
These numbers on an oil container show its
viscosity, or thickness. Do not use other viscosity
oils such as SAE 20W-50.
Oils meeting these
requirements should also
have the starburst
symbol on the container.
This symbol indicates
that the oil has been
certied by the American
Petroleum Institute (API).
You should look for this information on the oil container,
and useonlythose oils that are identied as meeting
GM Standard GM6094M and have the starburst symbol
on the front of the oil container.
Notice:Use only engine oil identied as meeting
GM Standard GM6094M and showing the American
Petroleum Institute Certied For Gasoline Engines
starburst symbol. Failure to use the recommended oil
can result in engine damage not covered by your
warranty.
5-17
ProCarManuals.com

GM Goodwrench oil meets all the requirements for
your vehicle.
If you are in an area of extreme cold, where the
temperature falls below−20°F (−29°C), it is
recommended that you use either an SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will provide
easier cold starting and better protection for your engine
at extremely low temperatures.
For Vehicles with the 2.0L Supercharged
Engine Only
Look for two things:
GM4718M
Your vehicle’s engine requires a special oil meeting
GM Standard GM4718M. Oils meeting this
standard may be identied as synthetic. However,
not allsyntheticoils will meet this GM standard.
You should look for and use only an oil that meets
GM Standard GM4718M.
Notice:If you use oils that do not have the
GM4718M Standard designation, you can cause
engine damage not covered by your warranty.
5-18
ProCarManuals.com

SAE 5W-30
As shown in the viscosity chart, SAE 5W-30 is
best for your vehicle. However, you can use SAE
10W-30 if it is going to be 0°F (-18°C) or above.
These numbers on an oil container show its
viscosity, or thickness. Do not use other viscosity
oils such as SAE 20W-50.
Oils meeting these
requirements should
also have the starburst
symbol on the container.
This symbol indicates
that the oil has been
certied by the American
Petroleum Institute (API).
You should look for this on the oil container, and use
onlythose oils that are identied as meeting GM
Standard GM4718M and have the starburst symbol on
the front of the oil container.Your vehicle’s engine is lled at the factory with a
Mobil 1®synthetic oil, which meets all requirements for
your vehicle.
Substitute Engine Oil:When adding oil to maintain
engine oil level, oil meeting GM Standard GM4718M
may not be available. You can add substitute oil
designated SAE 5W-30 with the starburst symbol at all
temperatures. If temperatures are above 0°F (-18°C),
you may substitute SAE 10W-30 with the starburst
symbol. Substitute oil not meeting GM Standard
GM4718M should not be used for an oil change.
Engine Oil Additives
Do not add anything to your oil. The recommended oils
with the starburst symbol that meet GM Standard
GM6094M are all you will need for good performance
and engine protection.
5-19
ProCarManuals.com

When to Change Engine Oil
(GM Oil Life System)
Your vehicle has a computer system that lets you know
when to change the engine oil and lter. This is
based on engine revolutions and engine temperature,
and not on mileage. Based on driving conditions,
the mileage at which an oil change will be indicated
can vary considerably. For the oil life system to
work properly, you must reset the system every time
the oil is changed.
When the system has calculated that oil life has been
diminished, it will indicate that an oil change is
necessary. A CHG OIL message will come on.
SeeChange Engine Oil Message on page 3-43for
more information on this message. Change your oil as
soon as possible within the next two times you stop
for fuel. It is possible that, if you are driving under the
best conditions, the oil life system may not indicate
that an oil change is necessary for over a year.However, your engine oil and lter must be changed at
least once a year and at this time the system must
be reset. Your retailer has trained service people who
will perform this work using genuine Saturn parts
and reset the system. It is also important to check your
oil regularly and keep it at the proper level.
If the system is ever reset accidentally, you must
change your oil at 3,000 miles (5 000 km) since your
last oil change. Remember to reset the oil life system
whenever the oil is changed.
How to Reset the Oil Life System
The GM Oil Life System calculates when to change
your engine oil and lter based on vehicle use.
Anytime your oil is changed, reset the system so it can
calculate when the next oil change is required. If a
situation occurs where you change your oil prior to the
CHG OIL message being turned on, reset the system.
5-20
