SATURN ION 2007 Owners Manual

At times you may notice a decrease in range. This
is normal for any remote keyless entry system.
If the transmitter does not work or if you have to
stand closer to your vehicle for the transmitter
to work, try this:
Check the distance. You may be too far from
your vehicle. You may need to stand closer
during rainy or snowy weather.
Check the location. Other vehicles or objects
may be blocking the signal. Take a few steps
to the left or right, hold the transmitter
higher, and try again.
Check to determine if battery replacement is
necessary. See “Battery Replacement”
underRemote Keyless Entry (RKE) System
Operation on page 91.
If you are still having trouble, see your retailer
or a qualied technician for service.
Remote Keyless Entry (RKE)
System Operation
With this feature, you can lock and unlock the
doors or the trunk from about 26 feet (8 m) away
using the Remote Keyless Entry (RKE)
transmitter supplied with your vehicle.
Q(Lock):Press this
symbol on the RKE
transmitter to lock the
doors. This also
arms the theft-deterrent
system. SeeContent
Theft-Deterrent on
page 103.
Your vehicle can be programmed so that the
parking lamps will ash and/or the horn will sound
when you lock the doors with the RKE transmitter.
See your retailer for more information on
programming this feature.
91
ProCarManuals.com

W(Unlock):Press this symbol on the RKE
transmitter to unlock the driver’s door. This also
disarms the theft-deterrent system. SeeContent
Theft-Deterrent on page 103. Press the button
again to unlock the rest of the doors.
Your vehicle can be programmed so that the
parking lamps will ash and/or the horn will sound
when you unlock the doors with the RKE
transmitter. See your retailer for more information
on programming this feature.
L(Panic Alarm):The RKE transmitter has an
instant panic alarm. Press the horn symbol
when the ignition is turned off. The horn will sound
and the parking lamps and dome lamp will ash
for up to two minutes. To stop the instant
panic alarm, press the symbol again.
V(Trunk):Press and hold this button for
approximately one second to open the trunk. If the
vehicle’s speed is faster than 2 mph (3 km/h),
the trunk will not open when this button is pressed.
The RKE transmitter is used to arm/disarm the
theft-deterrent system. The system will arm when
the lock button on the RKE transmitter pressed.
The system will disarm when the unlock button is
pressed.
Matching Transmitter(s) to
Your Vehicle
Each RKE transmitter is coded to prevent another
transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your retailer. Remember to
bring any remaining transmitters with you
when you go to your retailer. When the retailer
matches the replacement transmitter to your
vehicle, any remaining transmitters must also be
matched. Once your retailer has coded the
new transmitter, the lost transmitter will not unlock
your vehicle. Each vehicle can have a maximum
of four transmitters matched to it.
92
ProCarManuals.com

Battery Replacement
Under normal use, the battery in your RKE
transmitter should last about four years.
You can tell the battery is weak if the transmitter
will not work at the normal range in any location.
If you have to get close to your vehicle before
the transmitter works, it is probably time to change
the battery.
Notice:When replacing the battery, use care
not to touch any of the circuitry. Static
from your body transferred to these surfaces
may damage the transmitter.
1. Use a at thin object to pry open the
transmitter.2. Once the transmitter is separated, use a
toothpick, pen cap, or similar object to remove
the old battery. Do not use a metal object.
3. Insert the new battery as the instructions
under the cover indicate.
4. Snap the transmitter back together tightly so
moisture cannot enter.
5. Check the operation of the transmitter.
93
ProCarManuals.com

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can
easily open the doors and fall out of a
moving vehicle. When a door is
locked, the handle will not open it.
You increase the chance of being
thrown out of the vehicle in a crash if
the doors are not locked. So, wear
safety belts properly and lock the
doors whenever you drive.
CAUTION: (Continued)
CAUTION: (Continued)

Young children who get into unlocked
vehicles may be unable to get out. A
child can be overcome by extreme
heat and can suffer permanent injuries
or even death from heat stroke.
Always lock your vehicle whenever
you leave it.
Outsiders can easily enter through an
unlocked door when you slow down
or stop your vehicle. Locking your
doors can help prevent this from
happening.
There are several ways to lock your vehicle.
To lock a door from the outside, turn the
key toward the front of the vehicle or use the
Remote Keyless Entry (RKE) transmitter, if your
vehicle has one.
94
ProCarManuals.com

From the inside, move
the manual lock knob
above the door
handle or use the power
door lock switch.
Power Door Locks
Press the top of the
switch to unlock the
doors. Press the bottom
of the switch to lock
the doors.
Delayed Locking
This feature will delay the actual locking of the
doors for up to ve seconds when the power door
lock switch or Remote Keyless Entry (RKE)
transmitter is used to lock the vehicle.
If any door is open when locking the vehicle,
three chimes will be heard signaling that
the delayed locking feature is active. Five seconds
after the last door is closed, all of the doors will
lock and the parking lamps will ash. To cancel the
delay and lock the doors immediately, press the
lock button a second time.
If the key is in the ignition this feature will not lock
the doors.
95
ProCarManuals.com

Programmable Automatic
Door Locks
With this feature, the doors will automatically lock
when the vehicle is shifted out of PARK (P) for
vehicles with an automatic transaxle, or the vehicle
speed is greater than 5 mph (8 km/h) for
vehicles with a manual transaxle. The doors will
automatically unlock when the ignition is turned off.
To turn the automatic door locking feature on or
off, do the following:
1. Turn the ignition to RUN with the engine off
and all of the doors closed.
2. Press and hold the power door lock button in
the lock position until the horn chirps twice.
To turn the automatic door unlocking feature on or
off, do the following:
1. Turn the ignition to RUN with the engine off
and all of the doors closed.
2. Press and hold the power door lock button in
the unlock position until the horn chirps twice.
Rear Door Security Locks (Sedan)
Your vehicle has rear door security locks.
These prevent passengers from opening the rear
doors from the inside.
The rear door security
locks are located on the
inside edge of each
rear door. You
must open the rear
doors to access them.
The label depicting
lock and unlock
positions is located
near the lock.
To set the locks, do the following:
1. Insert the key into the security lock slot and
turn it so the slot is in the horizontal position.
2. Close the door.
Security Lock
Label shown
96
ProCarManuals.com

When you want to open a rear door when the
security lock is on, do the following:
1. Unlock the door using the remote keyless
entry transmitter, if the vehicle has one, the
power door lock switch, or by lifting the
rear door manual lock.
2. Open the door from the outside.
To cancel the rear door security lock, do the
following:
1. Unlock the door and open it from the outside.
2. Insert the key into the security lock slot
and turn it so the slot is in the vertical position.
Lockout Protection
If you press the power door lock switch when the
key is in the ignition and any door is open, all
the doors will lock and the driver’s door will unlock.
Be sure to remove the key from the ignition
when locking your vehicle.
The lockout protection can be overridden by
pressing and holding the power door lock in the
lock position for three seconds.
Rear Doors (Coupe)
Your vehicle has a driver’s and passenger’s side
rear access door. To open the rear access
doors, rst you must open the driver’s or
passenger’s door.
Then use the handle located on the front edge of
the rear door to open it.
When closing the doors, the rear door must be
closed and latched before you can close the
driver’s or passenger’s door.
97
ProCarManuals.com

Trunk
To unlock the trunk from the outside, use the
vehicle key or if the vehicle has one, press the
trunk button on the Remote Keyless Entry (RKE)
transmitter, if equipped.
{CAUTION:
It can be dangerous to drive with the trunk
lid open because carbon monoxide (CO)
gas can come into your vehicle. You
cannot see or smell CO. It can cause
unconsciousness and even death.
CAUTION: (Continued)
CAUTION: (Continued)
If you must drive with the trunk lid open
or if electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle. See
Climate Control System.
If you have air outlets on or under
the instrument panel, open them all
the way.
SeeEngine Exhaust on page 120.
98
ProCarManuals.com

Remote Trunk Release
Press the remote trunk
release button, located
on the lower left
side of the instrument
panel, to release
the trunk lid.
The remote trunk release will work when the
ignition is either in LOCK or ACC, the parking
brake is engaged, or the vehicle speed is less than
2 mph (3 km/h).
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it
could damage the handle. The emergency
trunk release handle is only intended to aid a
person trapped in a latched trunk, enabling
them to open the trunk from the inside.
There is a glow-in-the-dark emergency trunk
release handle located on the inside of the trunk
lid. This handle will glow following exposure
to light. Pull the release handle and push the trunk
lid open from the inside to open the trunk.
99
ProCarManuals.com

Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
Manual Windows
If your vehicle has manual windows, use the
window crank to open and close each window.
100
