wiper SATURN RELAY 2007 User Guide

It is always wise to go slower and be cautious if
rain starts to fall while you are driving. The surface
may get wet suddenly when your reexes are tuned
for driving on dry pavement.
The heavier the rain, the harder it is to see.
Even if your windshield wiper blades are in good
shape, a heavy rain can make it harder to see
road signs and traffic signals, pavement markings,
the edge of the road, and even people walking.
It is wise to keep your windshield wiper and
washer system in good shape and keep your
windshield washer uid reservoir lled with washer
uid. Replace your windshield wiper inserts
when they show signs of streaking or missing
areas on the windshield, or when strips of rubber
start to separate from the inserts.
{CAUTION:
Wet brakes can cause accidents. They
may not work as well in a quick stop and
may cause pulling to one side. You could
lose control of the vehicle.
After driving through a large puddle of
water or a car wash, apply your brake
pedal lightly until your brakes work
normally.
Driving too fast through large water puddles or
even going through some car washes can cause
problems, too. The water may affect your
brakes. Try to avoid puddles. But if you cannot,
try to slow down before you hit them.
377
ProCarManuals.com

Here are some things you can check before a trip:
Windshield Washer Fluid:Is the reservoir
full? Are all windows clean inside and outside?
Wiper Blades:Are they in good shape?
Fuel, Engine Oil, Other Fluids:Have you
checked all levels?
Lamps:Are they all working? Are the lenses
clean?
Tires:They are vitally important to a safe,
trouble-free trip. Is the tread good enough
for long-distance driving? Are the tires
all inated to the recommended pressure?
Weather Forecasts:What is the weather
outlook along your route? Should you
delay your trip a short time to avoid a major
storm system?
Maps:Do you have up-to-date maps?
Highway Hypnosis
Is there actually such a condition as highway
hypnosis? Or is it just plain falling asleep at the
wheel? Call it highway hypnosis, lack of
awareness, or whatever.
There is something about an easy stretch of road
with the same scenery, along with the hum of the
tires on the road, the drone of the engine, and the
rush of the wind against the vehicle that can make
you sleepy. Do not let it happen to you! If it does,
your vehicle can leave the road in less than a
second, and you could crash and be injured.
What can you do about highway hypnosis?
First, be aware that it can happen.
Then here are some tips:
Make sure your vehicle is well ventilated, with
a comfortably cool interior.
Keep your eyes moving. Scan the road ahead
and to the sides. Check your mirrors and your
instruments frequently.
If you get sleepy, pull off the road into a rest,
service, or parking area and take a nap, get
some exercise, or both. For safety, treat
drowsiness on the highway as an emergency.
383
ProCarManuals.com

Service........................................................ 412
Accessories and Modications................... 412
California Proposition 65 Warning.............. 413
Doing Your Own Service Work.................. 413
Adding Equipment to the Outside
of Your Vehicle...................................... 414
Fuel............................................................. 414
Gasoline Octane........................................ 414
Gasoline Specications.............................. 414
California Fuel........................................... 415
Additives................................................... 415
Fuels in Foreign Countries........................ 416
Filling the Tank......................................... 417
Filling a Portable Fuel Container............... 419
Checking Things Under the Hood.............. 420
Hood Release........................................... 421
Engine Compartment Overview.................. 422
Engine Oil................................................. 423
Engine Oil Life System.............................. 426
Engine Air Cleaner/Filter............................ 428
Automatic Transaxle Fluid......................... 430Engine Coolant.......................................... 432
Radiator Pressure Cap.............................. 435
Engine Overheating................................... 435
Overheated Engine Protection
Operating Mode..................................... 437
Cooling System......................................... 438
Power Steering Fluid ................................. 443
Windshield Washer Fluid........................... 444
Brakes...................................................... 445
Battery...................................................... 449
Jump Starting............................................ 450
Bulb Replacement....................................... 455
Halogen Bulbs........................................... 455
Headlamps and Sidemarker Lamps........... 456
Front Turn Signal, Parking and Daytime
Running Lamps (DRL)........................... 457
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps...................................... 458
License Plate Lamp................................... 459
Replacement Bulbs................................... 460
Windshield Wiper Blade Replacement....... 460
Section 5 Service and Appearance Care
409
ProCarManuals.com

Tires............................................................ 462
Tire Sidewall Labeling............................... 463
Tire Terminology and Denitions............... 466
Ination - Tire Pressure............................. 469
High-Speed Operation............................... 471
Tire Inspection and Rotation...................... 472
When It Is Time for New Tires.................. 473
Buying New Tires...................................... 474
Different Size Tires and Wheels................ 476
Uniform Tire Quality Grading..................... 477
Wheel Alignment and Tire Balance............ 478
Wheel Replacement.................................. 478
Tire Chains............................................... 480
Accessory Inator...................................... 480
If a Tire Goes Flat.................................... 483
Changing a Flat Tire................................. 484
Removing the Spare Tire and Tools.......... 485
Removing the Flat Tire and Installing
the Spare Tire....................................... 488
Secondary Latch System........................... 495
Storing a Flat or Spare Tire and Tools...... 497
Compact Spare Tire.................................. 500Appearance Care........................................ 501
Cleaning the Inside of Your Vehicle.......... 501
Fabric/Carpet............................................. 502
Leather...................................................... 503
Instrument Panel, Vinyl, and Other
Plastic Surfaces..................................... 504
Care of Safety Belts.................................. 504
Weatherstrips............................................ 504
Washing Your Vehicle............................... 505
Cleaning Exterior Lamps/Lenses................ 505
Finish Care............................................... 505
Windshield, Backglass, and
Wiper Blades......................................... 506
Aluminum Wheels...................................... 507
Tires......................................................... 507
Sheet Metal Damage................................. 508
Finish Damage.......................................... 508
Underbody Maintenance............................ 508
Chemical Paint Spotting............................ 508
Vehicle Care/Appearance Materials............ 509
Section 5 Service and Appearance Care
410
ProCarManuals.com

Vehicle Identication.................................. 510
Vehicle Identication Number (VIN)........... 510
Service Parts Identication Label............... 510
Electrical System........................................ 511
Add-On Electrical Equipment..................... 511
Headlamp Wiring....................................... 511
Windshield Wiper Fuses............................ 511Power Windows and Other Power
Options.................................................. 511
Fuses and Circuit Breakers....................... 512
Instrument Panel Fuse Block..................... 512
Underhood Fuse Block.............................. 514
Capacities and Specications.................... 518
Section 5 Service and Appearance Care
411
ProCarManuals.com

Replacement Bulbs
Exterior Lamp Bulb Number
Back-up 3057KX
Front Turn Signal, DRL
and Parking3157NAK
High-Beam and Low-Beam
HeadlampsH11
License Plate Lamp 168
Sidemarker 194
Stoplamp, Taillamp and
Turn Signal3057KX
For replacement bulbs not listed here, contact
your retailer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for
wear and cracking. SeeScheduled Maintenance
on page 522for more information.
Replacement blades come in different types and
are removed in different ways. For proper type and
length, seeNormal Maintenance Replacement
Parts on page 532.
460
ProCarManuals.com

To replace the windshield wiper blade assembly
do the following:
1. Lift the wiper arm and turn the blade until it is
facing away from the windshield.
2. Squeeze the tabs (B) on each side of the
wiper blade assembly to remove the wiper
arm (A) from the blade (C).Allowing the wiper blade arm to touch the
windshield when no wiper blade is installed
could damage the windshield. Any damage
that occurs would not be covered by your
warranty. Do not allow the wiper blade arm
to touch the windshield.
3. Push the new wiper blade securely on the
wiper arm until you hear the tabs on each
side of the wiper blade assembly click
into place.
To replace the rear wiper blade, follow the
steps listed above.
461
ProCarManuals.com

Foreign materials such as calcium chloride and
other salts, ice melting agents, road oil and
tar, tree sap, bird droppings, chemicals from
industrial chimneys, etc., can damage your
vehicle’s nish if they remain on painted
surfaces. Wash the vehicle as soon as possible.
If necessary, use non-abrasive cleaners that
are marked safe for painted surfaces to remove
foreign matter.
Exterior painted surfaces are subject to aging,
weather, and chemical fallout that can take their
toll over a period of years. You can help to
keep the paint nish looking new by keeping
your vehicle in a garage or covered whenever
possible.Windshield, Backglass, and Wiper
Blades
If the windshield is not clear after using the
windshield washer, or if the wiper blade chatters
when running, wax, sap or other material may
be on the blade or windshield.
Clean the outside of the windshield with a
full-strength glass cleaning liquid. The windshield
is clean if beads do not form when you rinse it
with water.
Grime from the windshield will stick to the wiper
blades and affect their performance. Clean
the blade by wiping vigorously with a cloth soaked
in full-strength windshield washer solvent. Then
rinse the blade with water.
Check the wiper blades and clean them as
necessary; replace blades that look worn.
506
ProCarManuals.com

Electrical System
Add-On Electrical Equipment
Notice:Do not add anything electrical to your
vehicle unless you check with your retailer
rst. Some electrical equipment can damage
your vehicle and the damage would not
be covered by your warranty. Some add-on
electrical equipment can keep other
components from working as they should.
Your vehicle has an airbag system. Before
attempting to add anything electrical to your
vehicle, seeServicing Your Airbag-Equipped
Vehicle on page 99.
Headlamp Wiring
The headlamp wiring is protected by four internal
fuses in the underhood fuse block. An electrical
overload will cause the lamps to go on and off, or
in some cases to remain off. If this happens,
have your headlamp wiring checked right away.
Windshield Wiper Fuses
The windshield wiper motor is protected by
an internal fuse in the underhood fuse block.
If the motor overheats due to heavy snow, etc.,
the wiper will stop until the motor cools. If the
overload is caused by some electrical problem,
be sure to get it xed.
The rear washer pump is controlled by a relay
located in the engine compartment, behind
the windshield washer uid reservoir. The rear
wiper motor is protected by a fuse located in the
instrument panel fuse block.
Power Windows and Other Power
Options
Circuit breakers in the instrument panel fuse panel
protect the power windows and other power
accessories. When the current load is too heavy,
the circuit breaker opens and closes, protecting
the circuit until the problem is xed.
511
ProCarManuals.com

Fuses Usage
1 Trunk, Door Locks
2 Electronic Level Control
3 Rear Wiper
4 Radio, DVD Player
5 Interior Lamps
6 OnStar
®
7 Keyless Entry Module
8Cluster, Heating, Ventilation,
Air Conditioning
9 Cruise Switch
10 Steering Wheel Illumination
11 Power Mirror
12 Stoplamp, Turn Lamps
13 Heated Seats
14 Blank
15 Electronic Level Control
513
ProCarManuals.com
