A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-21.
B. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-15.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-15.
D. Remote Negative (−) Terminal. SeeJump Starting
on page 5-42.
E. Brake/Clutch Cylinder Fluid. SeeBrakes on
page 5-38andHydraulic Clutch on page 5-27.F. Underhood Fuse Block. SeeUnderhood Fuse Block
on page 5-96.
G. Battery. SeeBattery on page 5-41.
H. Remote Positive (+) Terminal. SeeJump Starting
on page 5-42.
I. Engine Coolant Surge Tank. See “Checking Coolant”
underEngine Coolant on page 5-27.
J. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-37.
5-13
ProCarManuals.com

A. Engine Air Cleaner/Filter. SeeEngine
Air Cleaner/Filter on page 5-21.
B. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-15.
C. Engine Oil Fill Cap (Out of View). See “When to
Add Engine Oil” underEngine Oil on page 5-15.
D. Remote Negative (−) Terminal. SeeJump Starting
on page 5-42.
E. Battery. SeeBattery on page 5-41.
F. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 5-96.
G. Remote Positive (+) Terminal (Out of View).
SeeJump Starting on page 5-42.
H. Engine Coolant Surge Tank. See “Checking Coolant”
underEngine Coolant on page 5-27.
I. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-37.Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop for
the 2.2L L4 engine and an orange loop for the
3.5L V6 engine. SeeEngine Compartment Overview
on page 5-12for the location of the engine oil dipstick.
1. Turn off the engine and give the oil several
minutes to drain back into the oil pan. If you do
not do this, the oil dipstick might not show the
actual level.
2. Pull out the dipstick and clean it with a paper towel
or cloth, then push it back in all the way. Remove it
again, keeping the tip down, and check the level.
5-15
ProCarManuals.com

Notice:In cold weather, water can freeze and crack
the engine, radiator, heater core and other parts.
Use the recommended coolant and the proper
coolant mixture.
{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
1. You can remove the coolant surge tank pressure
cap when the cooling system, including the coolant
surge tank pressure cap and upper radiator
hose, is no longer hot. Turn the pressure cap slowly
counterclockwise about one-quarter of a turn.
If you hear a hiss, wait for that to stop. This will
allow any pressure still left to be vented out
the discharge hose.
2. Then keep turning the pressure cap slowly, and
remove it.
5-35
ProCarManuals.com

Notice:If you leave your radio or other accessories
on during the jump starting procedure, they could
be damaged. The repairs would not be covered
by your warranty. Always turn off your radio and
other accessories when jump starting your vehicle.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or the accessory power outlet. Turn off
the radio and all lamps that are not needed. This
will avoid sparks and help save both batteries.
And it could save the radio!
4. Open the hood on the other vehicle and locate the
positive (+) and negative (−) terminal locations on
that vehicle.
Open the hood on your vehicle and nd the remote
positive (+) and remote negative (−) jump starting
terminals.A. Remote Positive
B. Remote Negative
A vehicle that has the 2.2L L4 engine, the remote
positive (+) terminal is located in the engine
compartment on the driver’s side of the vehicle,
on the underhood fuse block. SeeEngine
Compartment Overview on page 5-12for more
information on location.
Access the remote positive (+) terminal by removing
the fuse block cover.
The remote negative (−) terminal is the lift hook,
which is located towards the rear of the engine
on the driver’s side.2.2L L4 Engine
5-43
ProCarManuals.com

10. Now start the vehicle with the good battery and
run the engine for a while.
11. Press the unlock symbol on the remote keyless
entry transmitter to disarm your security system,
if the vehicle has one.
12. Try to start the vehicle that had the dead battery.
If it will not start after a few attempts, it probably
needs service.
Notice:If the jumper cables are connected or
removed in the wrong order, electrical shorting may
occur and damage the vehicle. The repairs would
not be covered by your warranty. Always connect
and remove the jumper cables in the correct
order, making sure that the cables do not touch
each other or other metal.
A. Heavy, Unpainted Metal Engine Part or Remote
Negative (−) Terminal
B. Good Battery or Remote Positive (+) and Remote
Negative (−) Terminals
C. Dead Battery or Remote Positive (+) TerminalJumper Cable Removal
5-46
ProCarManuals.com

To disconnect the jumper cables from both vehicles,
do the following:
1. Disconnect the black negative (−) cable from the
vehicle that had the dead battery.
2. Disconnect the black negative (−) cable from the
vehicle with the good battery.
3. Disconnect the red positive (+) cable from the
vehicle with the good battery.
4. Disconnect the red positive (+) cable from the
other vehicle.
5. Return the underhood fuse block cover to its
original position, if needed.
All-Wheel Drive
If you have an all-wheel-drive vehicle, be sure to
perform the lubricant checks described in this section.
There are two additional systems that need lubrication.
Transfer Case (3.5L V6 Engine)
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it.
SeeScheduled Maintenance on page 6-4.
How to Check Lubricant
A. Fill Plug B. Drain Plug
To get an accurate reading, the vehicle should be on a
level surface.
If the level is below the bottom of the ller plug hole,
located on the transfer case, you’ll need to add some
lubricant. Add enough lubricant to raise the level to the
bottom of the ller plug hole. A uid loss could indicate a
problem; check and have it repaired, if needed.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. SeeRecommended Fluids
and Lubricants on page 6-14.
5-47
ProCarManuals.com

5. Push the locking tab toward the rear of the vehicle
with the tool to lift the headlamp bracket lower arm.
6. Pull back on the front fascia and then pull the
headlamp assembly out from the vehicle. You
may need someone to assist you with this step.
7. Disconnect the electrical connector from the bulb
assembly.
8. Rotate the bulb assembly counterclockwise to
remove it from the housing.
9. Replace the old bulb with a new one.
10. Reverse Steps 1 through 8 to reinstall.
Front Turn Signal and
Parking Lamps
To replace a front turn signal or parking lamp bulb,
do the following:
1. Follow Steps 1 through 6 underHeadlamps on
page 5-49to access the front turn signal or
parking lamp.
2. Rotate the bulb to be replaced counterclockwise
to remove it from the headlamp assembly.
3. Pull the bulb out of the bulb socket assembly.
5-51
ProCarManuals.com

4. Push the new bulb into the bulb socket assembly.
5. Insert the bulb assembly into the headlamp
assembly.
6. Rotate the bulb assembly clockwise until seated.
7. Reverse the steps to reinstall the headlamp
assembly.
Center High-Mounted
Stoplamp (CHMSL)
To replace a CHMSL bulb, do the following:
1. Remove the center high-mounted stoplamp
(CHMSL) fasteners from the outside of the vehicle.
2. Pull the CHMSL out of the liftgate.
3. Disconnect the rear washer hose from the rear
washer nozzle.
4. Disconnect the electrical connector from the CHMSL.
5-52
ProCarManuals.com

5. Turn the bulb socket being replaced
counterclockwise to disconnect it.
6. Pull the bulb out of the bulb socket.
7. Push the new bulb into the bulb socket.
8. Reverse Steps 2 through 4 to reinstall the
taillamp assembly.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up 3156
CHMSL W5W
Front Turn Signal/Parking 3157K
Headlamps
High-beam 9005 or HB3
Low-beam/DRL 9006 or HB4
Rear Turn Signal, Stoplamp
and Taillamp3057
For replacement bulbs not listed here, contact
your retailer.
5-54
ProCarManuals.com

Different Size Tires and Wheels
If you add wheels or tires that are a different size than
your original equipment wheels and tires, this may affect
the way your vehicle performs, including its braking, ride
and handling characteristics, stability, and resistance
to rollover. Additionally, if your vehicle has electronic
systems such as, anti-lock brakes, traction control, and
stability control, the performance of these systems can
be affected.
{CAUTION:
If you add different sized wheels, your
vehicle may not provide an acceptable
level of performance and safety if tires not
recommended for those wheels are selected.
You may increase the chance that you will
crash and suffer serious injury. Only use
Saturn specic wheel and tire systems
developed for your vehicle, and have them
properly installed by a Saturn certied
technician.
SeeBuying New Tires on page 5-65andAccessories
and Modications on page 5-3for additional information.
Uniform Tire Quality Grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
Treadwear 200 Traction AA Temperature A
The following information relates to the system developed
by the United States National Highway Traffic Safety
Administration (NHTSA), which grades tires by
treadwear, traction, and temperature performance. This
applies only to vehicles sold in the United States. The
grades are molded on the sidewalls of most passenger
car tires. The Uniform Tire Quality Grading (UTQG)
system does not apply to deep tread, winter-type snow
tires, space-saver, or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches (25 to 30 cm),
or to some limited-production tires.
While the tires available on General Motors passenger
cars and light trucks may vary with respect to these
grades, they must also conform to federal safety
requirements and additional General Motors Tire
Performance Criteria (TPC) standards.
5-67
