cooling SATURN VUE HYBRID 2007 User Guide

Cooling System
When you decide it is safe to lift the hood, here is
what you will see:
A. Electric Engine Fan
B. Coolant Surge Tank with Pressure Cap{CAUTION:
An electric engine cooling fan under the
hood can start up even when the engine
is not running and can injure you. Keep
hands, clothing, and tools away from any
underhood electric fan.
If the coolant inside the coolant surge tank is
boiling, do not do anything else until it cools
down. The vehicle should be parked on a
level surface.
311
ProCarManuals.com

The coolant level should be at the COLD FILL
line. If it is not, you may have a leak at the radiator
hoses, heater hoses, radiator, water pump, or
somewhere else in the cooling system.
{CAUTION:
Heater and radiator hoses, and other
engine parts, can be very hot. Do not
touch them. If you do, you can be burned.
Do not run the engine if there is a leak.
If you run the engine, it could lose all
coolant. That could cause an engine re,
and you could be burned. Get any leak
xed before you drive the vehicle.If there seems to be no leak, with the engine on,
check to see if the electric engine cooling fan
is running. If the engine is overheating, the
fan should be running. If it is not, your vehicle
needs service. Turn off the engine.
Notice:Engine damage from running your
engine without coolant is not covered by
your warranty.
Notice:Using coolant other than DEX-COOL®
may cause premature engine, heater core,
or radiator corrosion. In addition, the engine
coolant could require changing sooner, at
30,000 miles (50 000 km) or 24 months,
whichever occurs rst. Any repairs would not
be covered by your warranty. Always use
DEX-COOL
®(silicate-free) coolant in your
vehicle.
312
ProCarManuals.com

How to Add Coolant to the Coolant
Surge Tank
Notice:This vehicle has a specic coolant ll
procedure. Failure to follow this procedure
could cause your engine to overheat and
be severely damaged.
If you have not found a problem yet, check to see
if coolant is visible in the surge tank. If coolant
is visible but the coolant level is not at the COLD
FILL line, add a 50/50 mixture of clean, drinkable
water and DEX-COOL
®coolant at the coolant
surge tank, but be sure the cooling system,
including the coolant surge tank pressure cap,
is cool before you do it. SeeEngine Coolant
on page 306for more information.
{CAUTION:
Steam and scalding liquids from a hot
cooling system can blow out and burn
you badly. They are under pressure, and if
you turn the coolant surge tank pressure
cap — even a little — they can come out at
high speed. Never turn the cap when the
cooling system, including the coolant
surge tank pressure cap, is hot. Wait for
the cooling system and coolant surge
tank pressure cap to cool if you ever have
to turn the pressure cap.
313
ProCarManuals.com

{CAUTION:
Adding only plain water to your cooling
system can be dangerous. Plain water, or
some other liquid such as alcohol, can
boil before the proper coolant mixture will.
Your vehicle’s coolant warning system is
set for the proper coolant mixture. With
plain water or the wrong mixture, your
engine could get too hot but you would
not get the overheat warning. Your engine
could catch re and you or others could
be burned. Use a 50/50 mixture of clean,
drinkable water and DEX-COOL
®coolant.Notice:In cold weather, water can freeze and
crack the engine, radiator, heater core and
other parts. Use the recommended coolant and
the proper coolant mixture.
{CAUTION:
You can be burned if you spill coolant on
hot engine parts. Coolant contains
ethylene glycol and it will burn if the
engine parts are hot enough. Do not spill
coolant on a hot engine.
314
ProCarManuals.com

1. You can remove the coolant surge tank
pressure cap when the cooling system,
including the coolant surge tank pressure cap
and upper radiator hose, is no longer hot.
Turn the pressure cap slowly counterclockwise
about one-quarter of a turn.
If you hear a hiss, wait for that to stop.
This will allow any pressure still left to be
vented out the discharge hose.
2. Then keep turning the pressure cap slowly,
and remove it.3. Fill the coolant surge tank with the proper
DEX-COOL®coolant mixture, to the COLD
FILL line.
315
ProCarManuals.com

4. With the coolant surge tank pressure cap off,
start the engine and let it run until you can
feel the upper radiator hose getting hot.
Watch out for the engine cooling fan.By this time, the coolant level inside the
coolant surge tank may be lower. If the level
is lower, add more of the proper DEX-COOL
®
coolant mixture to the coolant surge tank
until the level reaches the COLD FILL line.
5. Then replace the pressure cap. Be sure the
pressure cap is hand-tight.
Check the level in the surge tank when the cooling
system has cooled down. If the coolant is not at
the proper level, repeat Steps 1 through 3 and
reinstall the pressure cap. If the coolant still is not
at the proper level when the system cools down
again, see your retailer.
316
ProCarManuals.com

Each new wheel should have the same
load-carrying capacity, diameter, width, offset and
be mounted the same way as the one it replaces.
{CAUTION:
Using the wrong replacement wheels,
wheel bolts, or wheel nuts on your vehicle
can be dangerous. It could affect the
braking and handling of your vehicle,
make your tires lose air and make you
lose control. You could have a collision in
which you or others could be injured.
Always use the correct wheel, wheel bolts,
and wheel nuts for replacement.
If you need to replace any of your wheels, wheel
bolts, or wheel nuts, replace them only with
new Saturn original equipment parts. This way,
you will be sure to have the right wheel, wheel
bolts, and wheel nuts for your vehicle.Notice:The wrong wheel can also cause
problems with bearing life, brake cooling,
speedometer or odometer calibration,
headlamp aim, bumper height, vehicle ground
clearance, and tire clearance to the body
and chassis.{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after a time. The wheel could
come off and cause a crash. When you
change a wheel, remove any rust or dirt
from places where the wheel attaches to
the vehicle. In an emergency, you can use a
cloth or a paper towel to do this; but be
sure to use a scraper or wire brush later, if
you need to, to get all the rust or dirt off.
354
ProCarManuals.com

Fuses Usage
REAR DEFOG Rear Defogger
COOL HI Cooling Fan High
LH HDLP Driver’s Side Headlamp
RR WIPER Rear Wiper
ABS Anti-lock Brake System Module
IGN/INJEngine Ignition Module,
Fuel Injectors
PWR WDW Power Window Relay and Sunroof
CIGAR LITER Cigarette Lighter
HVAC
BLOWERClimate Control System
Blower Motor
RH HDLP Passenger’s Side Headlamp
FRT WIPER Front Wiper
ETC Electronic Throttle Control
SUNROOF Sunroof Module
BRAKE StoplampsFuses Usage
PWR TRAINEngine Control Module, Transaxle
Control Module, Powertrain Control
Module
BACKUPLow Coolant Switch, Back-up
Lamps, Vehicle Speed Sensor
(Manual), Transaxle Range Switch
HTD SEATS Heated Seats
IGN Ignition Switch
COOL LO Cooling Fan Low
A/C CLUTCH Air Conditioning Clutch
FUEL PUMP Fuel Pump
AUX OUTLETS Auxiliary Power Outlets
ESCM/CANV Electric Storage Control Module
ABS Anti-lock Brake System Ignition
PWR SEAT Power Seats
384
ProCarManuals.com

Relays Usage
DRL Daytime Running Lamps Relay
HORN Horn Relay
COOL FAN HI Cooling Fan High Relay
ENG MAINEngine Control Module/CAM,
Emissions, Injectors, Electronic
Throttle Control Relay
REAR DEFOG Rear Defog System Relay
WIPER
SYSTEMWiper System Relay
PWR WDWPower Window Switch, Sunroof
Module Relay
FRT WIPER Front Wiper System Relay
COOL FAN
LOWCooling Fan Low RelayRelays Usage
A/C CLUTCH Air Conditioning Clutch Relay
FUEL PUMP Fuel Pump System Relay
RR WIPER Rear Wiper System Relay
Misc. Usage
FUSE PULLER Fuse Puller
A/C DIODE Air Conditioning Diode
385
ProCarManuals.com

Capacities and Specications
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134aFor the air conditioning system refrigerant
charge amount, see the refrigerant caution label
located under the hood. See your retailer for
more information.
Cooling System 9.3 qt 8.8 L
Engine Oil with Filter 5.0 qt 4.7 L
Fuel Tank 16.6 gal 62.8 L
Transaxle (Bottom Pan Removal) 7.0 qt 6.6 L
Wheel Nut Torque 100 ft lb
140Y
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
Engine Specications
Engine VIN Code Transaxle Spark Plug Gap
2.4L L4 5 Automatic 0.040 inches (1.01 mm)
387
