If you no longer have the overheat
warning, you can drive. Just to
be safe, drive slower for about
ten minutes. If the warning does
not come back on, you can drive
normally.
If the warning continues and you
have not stopped, pull over, stop,
and park your vehicle right away.
If there is still no sign of steam, idle
the engine for three minutes
while you are parked. If the warning
continues, turn off the engine and
get everyone out of the vehicle until
it cools down.
You may decide not to lift the hood
but to get service help right away.Windshield Washer Fluid
What to Use
When you need windshield or rear
window washer uid, be sure to
read the manufacturer’s instructions
before use. If you will be operating
your vehicle in an area where
the temperature may fall below
freezing, use a uid that has
sufficient protection against freezing.
Adding Windshield Washer
Fluid
Open the cap with the washer
symbol on it. Add washer uid until
the tank is full. SeeEngine
Compartment Overview on
page 5-10for reservoir location.Notice:
When using concentrated
washer uid, follow the
manufacturer’s instructions
for adding water.
Do not mix water with
ready-to-use washer uid.
Water can cause the solution
to freeze and damage your
washer uid tank and other
parts of the washer system.
Also, water does not clean as
well as washer uid.
Fill the washer uid tank only
three-quarters full when it is
very cold. This allows for uid
expansion if freezing occurs,
which could damage the tank if
it is completely full.
Do not use engine coolant
(antifreeze) in your windshield
washer. It can damage the
vehicle’s windshield washer
system and paint.
5-24 Service and Appearance Care
ProCarManuals.com

Windshield Wiper
Blade Replacement
Windshield wiper blades should be
inspected for wear and cracking.
SeeScheduled Maintenance
on page 6-3for more information.
Replacement blades come in
different types and are removed in
different ways. For proper type
and length, seeMaintenance
Replacement Parts on page 6-12.
To replace the windshield wiper
blade:
1. Lift the wiper arm away from the
windshield.2. Push the release lever (B) to
disengage the hook and push the
wiper arm (A) out of the blade (C).
3. Push the new wiper blade
securely on the wiper arm until
you hear the release lever click
into place.
To replace the rear wiper blade, lift
the rear wiper arm from the
window and pull the blade.
Tires
Your new vehicle comes with
high-quality tires made by a
leading tire manufacturer. If you
ever have questions about your
tire warranty and where to obtain
service, see your vehicle
Warranty booklet for details.
For additional information refer
to the tire manufacturer.
{CAUTION
Poorly maintained and
improperly used tires are
dangerous.
Overloading your
vehicle’s tires can cause
overheating as a result
of too much exing. You
could have an air-out and
a serious accident. See
Loading the Vehicle on
page 4-18.
(Continued)
5-38 Service and Appearance Care
ProCarManuals.com

Tire Terminology and
Denitions
Air Pressure:The amount of
air inside the tire pressing
outward on each square inch of
the tire. Air pressure is
expressed in pounds per square
inch (psi) or kilopascal (kPa).
Accessory Weight
:This means
the combined weight of
optional accessories. Some
examples of optional
accessories are, automatic
transmission, power steering,
power brakes, power windows,
power seats, and air
conditioning.
Aspect Ratio
:The relationship
of a tire’s height to its width.
Belt
:A rubber coated layer of
cords that is located between the
plies and the tread. Cords
may be made from steel or other
reinforcing materials.Bead
:The tire bead contains
steel wires wrapped by steel
cords that hold the tire onto
the rim.
Bias Ply Tire
:A pneumatic tire
in which the plies are laid at
alternate angles less than
90 degrees to the centerline of
the tread.
Cold Tire Pressure
:The
amount of air pressure in a tire,
measured in pounds per
square inch (psi) or kilopascals
(kPa) before a tire has built
up heat from driving. See
Inflation - Tire Pressure on
page 5-43.
Curb Weight
:The weight of a
motor vehicle with standard
and optional equipment including
the maximum capacity of fuel,
oil, and coolant, but without
passengers and cargo.DOT Markings
:A code molded
into the sidewall of a tire
signifying that the tire is in
compliance with the U.S.
Department of Transportation
(DOT) motor vehicle safety
standards. The DOT code
includes the Tire Identication
Number (TIN), an alphanumeric
designator which can also
identify the tire manufacturer,
production plant, brand, and date
of production.
GVWR
:Gross Vehicle Weight
Rating. SeeLoading the Vehicle
on page 4-18.
GAWR FRT
:Gross Axle Weight
Rating for the front axle. See
Loading the Vehicle on
page 4-18.
GAWR RR
:Gross Axle Weight
Rating for the rear axle. See
Loading the Vehicle on
page 4-18.
Service and Appearance Care 5-41
ProCarManuals.com

Using the Tire Sealant and
Compressor Kit to
Temporarily Seal and Inate a
Punctured Tire
When using the tire sealant and
compressor kit during cold
temperatures, warm the kit in a
heated environment for 5 minutes.
This will help to inate the tire faster.Always do a safety check rst. See
If a Tire Goes Flat on page 5-58.
1. Remove the tire sealant and
compressor kit from its storage
location. SeeTire Sealant
and Compressor Kit Storage on
page 5-66.
Make sure the on/off button (D)
is in the off (O) position.
2. Unwrap the sealant/air hose (F)
and the power plug (C).
3. Place the kit on the ground.
Make sure the tire valve
stem is positioned close to the
ground so the hose will reach it.
4. Remove the valve stem cap from
the at tire by turning it
counterclockwise.5. Attach the sealant/air hose (F)
onto the tire valve stem. Turn
it clockwise until it is tight.
6. Plug the power plug (C) into the
accessory power outlet in the
vehicle. Unplug all items
from other accessory power
outlets. SeeAccessory Power
Outlet(s) on page 3-16.
If the vehicle has an accessory
power outlet, do not use the
cigarette lighter.
If the vehicle only has a cigarette
lighter, use the cigarette lighter.
Do not pinch the power plug
cord in the door or window.
7. Start the vehicle. The vehicle
must be running while using
the air compressor.
Service and Appearance Care 5-61
ProCarManuals.com

Using the Tire Sealant and
Compressor Kit without
Sealant to Inate a Tire (Not
Punctured)
To use the air compressor to inate
a tire with air only and not sealant:
Always do a safety check rst. See
If a Tire Goes Flat on page 5-58.
1. Remove the tire sealant and
compressor kit from its storage
location. SeeTire Sealant and
Compressor Kit Storage on
page 5-66.2. Unlock the air only hose (F) from
the sealant canister (B) by
pulling up on the lever.
3. Pull the air only hose (F) from
the sealant canister (B).
4. Remove the power plug (C) from
the air compressor (A).
5. Place the kit on the ground.
Make sure the tire valve
stem is positioned close to the
ground so the hose will reach it.
6. Remove the tire valve stem cap
by turning it counterclockwise.
7. Attach the air only hose (F) onto
the tire valve stem and press the
lever down to secure it.
8. Plug the power plug (C) into the
accessory power outlet in the
vehicle. Unplug all items
from other accessory power
outlets. SeeAccessory Power
Outlet(s) on page 3-16.
If the vehicle has an accessory
power outlet, do not use the
cigarette lighter.If the vehicle only has a cigarette
lighter, use the cigarette lighter.
Do not pinch the power plug
cord in the door or window.
9. Start the vehicle. The vehicle
must be running while using
the air compressor.
10. Press the on/off (D) button to
turn the compressor on.
The compressor will inate the
tire with air only.
11. Inate the tire to the
recommended ination pressure
using the pressure gage (E).
The recommended ination
pressure can be found on the
Tire and Loading Information
label. SeeInflation - Tire
Pressure on page 5-43.
The pressure gage (E) may
read higher than the actual tire
pressure while the compressor
is on. Turn the compressor
off to get an accurate reading.
The compressor may be
turned on/off until the correct
pressure is reached.
5-64 Service and Appearance Care
ProCarManuals.com

When cleaning the vehicle’s interior,
only use cleaners specically
designed for the surfaces being
cleaned. Permanent damage may
result from using cleaners on
surfaces for which they were not
intended. Use glass cleaner only on
glass. Remove any accidental
over-spray from other surfaces
immediately. To prevent over-spray,
apply cleaner directly to the
cleaning cloth.
Notice:Using abrasive cleaners
when cleaning glass surfaces on
the vehicle, could scratch the
glass and/or cause damage to the
rear window defogger. When
cleaning the glass on the vehicle,
use only a soft cloth and glass
cleaner.Many cleaners contain solvents that
may become concentrated in the
vehicle’s breathing space. Before
using cleaners, read and adhere to
all safety instructions on the
label. While cleaning the vehicle’s
interior, maintain adequate
ventilation by opening the vehicle’s
doors and windows.
Dust may be removed from small
buttons and knobs using a small
brush with soft bristles.
Products that remove odors from
the vehicle’s upholstery and
clean the vehicle’s glass can be
obtained from your dealer/retailer.
Do not clean the vehicle using:
A knife or any other sharp object
to remove a soil from any interior
surface.
A stiff brush. It can cause
damage to the vehicle’s interior
surfaces.
Heavy pressure or aggressive
rubbing with a cleaning cloth.
Use of heavy pressure can
damage the interior and does not
improve the effectiveness of
soil removal.
Laundry detergents or
dishwashing soaps with
degreasers can leave residue
that streaks and attracts dirt. For
liquid cleaners, about 20 drops
per gallon (3.78 L) of water
is a good guide. Use only mild,
neutral-pH soaps.
Too much cleaner that saturates
the upholstery.
Organic solvents such as naptha,
alcohol, etc. that can damage the
vehicle’s interior.
Service and Appearance Care 5-67
ProCarManuals.com

Add-On Electrical
Equipment
Notice:Do not add anything
electrical to the vehicle unless
you check with your
dealer/retailer rst. Some
electrical equipment can damage
the vehicle and the damage
would not be covered by the
vehicle’s warranty. Some add-on
electrical equipment can keep
other components from working
as they should.
Add-on equipment can drain the
vehicle’s battery, even if the vehicle
is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing Your Airbag-Equipped
Vehicle on page 1-54.
Windshield Wiper Fuses
The windshield wiper motor is
protected by a circuit breaker and a
fuse. If the motor overheats due
to heavy snow or ice, the wiper will
stop until the motor cools. If the
overload is caused by some
electrical problem, have it xed.
Power Windows and
Other Power Options
Circuit breakers in the fuse block
protect the power windows and
other power accessories. When the
current load is too heavy, the
circuit breaker opens and closes,
protecting the circuit until the
problem is xed or goes away.
Fuses and Circuit
Breakers
The wiring circuits in your vehicle
are protected from short circuits by
fuses. This greatly reduces the
chance of circuit overload and re
caused by electrical problems.
There are three fuse blocks - the
main underhood fuse block,
the auxiliary hybrid underhood fuse
block and the instrument panel
fuse block.
To identify and check fuses and
relays, refer to the Fuse Usage
Chart on the inside surface of the
fuse panel door.
Service and Appearance Care 5-75
ProCarManuals.com

Instrument Panel Fuse
Block
The instrument panel fuse block is
located on the passenger side
of the lower console.
Pull the latch of the fuse box cover
straight back to access the
fuses.
FusesUsage
PWR SEAT Power Seat PASS
P/WIN Passenger Side
Power Window
DRIV
P/WIN Driver Side Power
Window
S/ROOF Sunroof Module CIGAR Cigarette LighterFuses Usage
ECM/TCM Engine Control
Module
(ECM)/Transmission
Control Module
(TCM)
FSCM Fuel Storage Control
Module
5-76 Service and Appearance Care
ProCarManuals.com

Door
Automatic Door Lock.......... 2-7
Automatic Door Unlock........ 2-7
Delayed Locking................. 2-6
Locks............................... 2-6
Power Door Locks.............. 2-6
Rear Door Security Locks.... 2-7
Driver
Seat Height Adjuster........... 1-4
Driver Behavior..................... 4-2
Driver Information
Center (DIC)....................3-36
DIC Operation and
Displays.......................3-36
DIC Vehicle
Customization...............3-49
DIC Warnings and
Messages....................3-42
Driver Storage
Compartment...................2-38
Driving
At Night..........................4-12
Before a Long Trip............4-14
Defensive.......................... 4-3
Drunken............................ 4-4Driving (cont.)
Environment...................... 4-2
Highway Hypnosis............4-14
Hill and Mountain Roads....4-14
In Rain and on Wet
Roads.........................4-13
Rocking Your Vehicle to
Get it Out ....................4-17
Winter.............................4-15
Driving for Better Fuel
Economy........................... 4-3
E
EDR ..................................7-14
Electrical System
Add-On Equipment............5-75
Fuses and Circuit
Breakers......................5-75
Instrument Panel Fuse
Block...........................5-76
Power Windows and Other
Power Options..............5-75
Underhood Fuse Block......5-77
Windshield Wiper Fuses....5-75
Electronic Immobilizer
PASS-Key
®III+................2-12Electronic Immobilizer
Operation
PASS-Key
®III+................2-12
Engine
Air Cleaner/Filter...............5-15
Change Engine Oil Light....3-33
Check and Service Engine
Soon Lamp..................3-30
Coolant...........................5-20
Coolant Heater.................2-19
Coolant Temperature
Warning Light...............3-29
Drive Belt Routing.............6-13
Engine Compartment
Overview......................5-10
Exhaust...........................2-26
Oil ..................................5-11
Oil Life System.................5-14
Overheating.....................5-23
Starting...........................2-15
Entry Lighting......................3-14
Event Data Recorders..........7-14
Extender, Safety Belt............1-22
Exterior Lamps....................3-12
i-4 INDEX
ProCarManuals.com

P
Paint, Damage.....................5-73
Park
Shifting Into.....................2-23
Shifting Out of..................2-25
Park Brake..........................2-22
Parking
Over Things That Burn......2-25
Passenger Airbag Status
Indicator..........................3-26
Passenger Sensing System . . . 1-49
Passing..............................4-11
PASS-Key
®III+ Electronic
Immobilizer......................2-12
PASS-Key
®III+ Electronic
Immobilizer Operation........2-12
Perchlorate Materials
Requirements, California...... 5-4
Phone
Bluetooth
®.......................3-72
Power
Door Locks........................ 2-6
Electrical System..............5-75
Retained Accessory...........2-15
Seat................................. 1-4
Windows........................... 2-9Privacy...............................7-14
Event Data Recorders.......7-14
Navigation System............7-15
OnStar............................7-15
Radio Frequency
Identication.................7-15
R
Radio Frequency Identication
(RFID), Privacy.................7-15
Radio(s).............................3-58
Radios
Reception........................3-83
Setting the Clock..............3-56
Theft-Deterrent.................3-82
Rainsense™ II Wipers............ 3-8
Reading Lamps...................3-14
Rear Door Security Locks....... 2-7
Rear Seat Armrest...............2-38
Rear Windshield Washer/
Wiper............................... 3-9
Rearview Mirror, Automatic
Dimming ..........................2-27
Rearview Mirrors..................2-27
Reclining Seatbacks............... 1-5Recommended Fluids and
Lubricants........................6-11
Recreational Vehicle Towing . . . 4-23
Regenerative Braking............2-23
Remote Keyless Entry (RKE)
System............................. 2-3
Remote Keyless Entry (RKE)
System, Operation.............. 2-4
Replacement Bulbs..............5-37
Replacement Parts,
Maintenance....................6-12
Reporting Safety Defects
Canadian Government.......7-12
Saturn.............................7-13
United States
Government..................7-12
Restraint System Check
Checking the Restraint
Systems.......................1-56
Replacing Restraint System
Parts After a Crash........1-57
Retained Accessory Power....2-15
Roadside
Assistance Program............ 7-5
Rocking Your Vehicle to Get
it Out ..............................4-17
i-8 INDEX
ProCarManuals.com
