SKODA OCTAVIA 1997 1.G / (1U) 1.8 92kw Engine Workshop Manual

Downloaded from www.Manualslib.com manuals search engine Lubrication System17
Edition 08.96


Marking range on dipstick:
a - Oil must not be topped up.
b - Oil may be topped up. After topping up, it is possible that the oil level will then be within the range -a-.
c - Oil should be topped up. It is sufficient, after topping up, for the oil level to be within the range -b- (chequered area).
Note:
The oil level must not extend beyond the max.marking of the dipstick.

Downloaded from www.Manualslib.com manuals search engine

Downloaded from www.Manualslib.com manuals search engine







Downloaded from www.Manualslib.com manuals search engine
19Cooling System
Edition 11.96

Coolant mixing ratios ⇒ page 19-3.
Inspecting cooling system for leaks ⇒ page 19-8.
Note:
Always replace seals and gaskets.
1 - Expansion reservoir
2 - Intake manifold 3 - Connection fitting with throttle valve
control unit
4 - Heat exchanger for heating system
5 - ATF cooler ♦ Only on models with automatic gear- box
6 - Radiator ♦ After replacing, fill entire system with fresh coolant
♦ Removing and installing⇒ page 19-9
