refuelling SKODA SUPERB 2009 2.G / (B6/3T) Owner's Manual

Contents 4Side airbags* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head airbags* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deactivating an airbag . . . . . . . . . . . . . . . . . . . . . . . . Transporting children safely
. . . . . . . . . . . . . . . . . .
What you should know about transporting children!
Child seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Attaching a child seat using the “ISOFIX” system .
Attaching child seat using the “Top Tether” system
Driving Tips
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intelligent Technology
. . . . . . . . . . . . . . . . . . . . . . . .
Electronic stability programme (ESP)* . . . . . . . . . .
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antilock brake system (ABS) . . . . . . . . . . . . . . . . . . .
Brake Assist* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uphill-Start off-Assist* . . . . . . . . . . . . . . . . . . . . . . . .
Electromechanical power steering . . . . . . . . . . . . .
Tyre inflation pressure-control system* . . . . . . . . .
Diesel particle filter* (diesel engine) . . . . . . . . . . . .
Driving and the Environment
. . . . . . . . . . . . . . . . .
A new engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
New tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
New brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving in an economical and environmentally
conscious manner . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Environmental compatibility . . . . . . . . . . . . . . . . . . .
Motoring abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Avoiding damage to your vehicle . . . . . . . . . . . . . .
To w i n g a t r a i l e r
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing a trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Maintenance
. . . . . . . . . . . . . . .
Taking care of your vehicle and cleaning the
vehicle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Care of the exterior of vehicle . . . . . . . . . . . . . . . . . .
Care of the interior of vehicle . . . . . . . . . . . . . . . . . .
Fuel
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspecting and replenishing
. . . . . . . . . . . . . . . . . .
Engine compartment . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield washer system . . . . . . . . . . . . . . . . . . . .
Wheels and Tyres
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories, changes and replacement of partsAccessories and replacement parts . . . . . . . . . . . . .
Technical changes . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicles of the group N1 . . . . . . . . . . . . . . . . . . . . . .Breakdown assistance
. . . . . . . . . . . . . .
Breakdown assistance
. . . . . . . . . . . . . . . . . . . . . . . .
First-aid box* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning triangle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fire extinguisher* . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tyre repair kit* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spare wheel* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump-starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tow-starting and towing vehicle . . . . . . . . . . . . . . .
Fuses and light bulbs
. . . . . . . . . . . . . . . . . . . . . . . . . .
Electric fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data
. . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General information . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . .
Performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification details . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel consumption according to the regulations
(99/100/EU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil specifications . . . . . . . . . . . . . . . . . . . . . . .
1.4 ltr./92 kW TSI - EU5 . . . . . . . . . . . . . . . . . . . . . . . .
1.8 ltr./118 kW TSI - EU5 . . . . . . . . . . . . . . . . . . . . . . .
3.6 ltr./191 kW FSI - EU5 . . . . . . . . . . . . . . . . . . . . . . .
1.9 ltr./77 kW TDI PD - EU4 . . . . . . . . . . . . . . . . . . . .
2.0 ltr./103 kW TDI PD - EU4 . . . . . . . . . . . . . . . . . . .
2.0 ltr./125 kW TDI CR - EU5 . . . . . . . . . . . . . . . . . . .
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
181
182
185
185
188
191
192
193
193
193
196
197
197
198
198
198
199
200
201
201
201
201
202
202
206
206
207
208
208211
211
211
211
216
219
219
219
220
222
222
224
226
228
229
234
235
235
241
241
241
241
243
243
243
243
243
244
244
245
245
250
252256
256
261
267
267
267
267
267
267
268
268
269
270
272
274
276
278
280
282
285
s2dk.1.book Page 4 Wednesday, April 8, 2009 12:23 PM

The brief instruction
15
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Refuelling– In order to open the fuel filler flap, press it on the left side in the middle
⇒
fig. 12
.
– Unscrew the fuel filler cap anti-cl
ockwise and place the fuel filler cap
from above on the fuel filler flap
⇒
fig. 13
.
Further information
⇒page 220, “Refuelling”.
Bonnet remote release– Pull the unlocking lever below the
dash panel on the driver's side
⇒
fig. 14
.
Further information
⇒fig. 14
.
Opening the bonnet– Press the locking button
⇒
fig. 15
, the bonnet is then unlocked.
Fig. 12 Right rear side of the vehicle:Open fuel filler flapFig. 13 Fuel filler flap with cap unscrewed
Fig. 14 Bonnet release leverFig. 15 Radiator grille: Lever of the locking button
s2dk.1.book Page 15 Wednesday, April 8, 2009 12:23 PM

Instruments and Indicator/Warning Lights
42
level has dropped below the MIN marking, do not drive any further - risk of accident! Obtain professional assistance.Alternator

The warning light
 comes on after the ignition has been switched on. It should go
out after the engine has started. If the warning light does not go out after the engine has started, or comes on when driving, drive to the nearest specialist garage. The vehicle battery will be discharged in this case so switch off all non-essential electrical components.
Caution
If the warning light
 comes on when driving and in addition the warning light

(cooling system fault) also comes on in display, you must then stop the car imme- diately and switch the engine
off - risk of engine damage!
Engine oil level

Warning light
 lights up
If the warning light
 lights up, the quantity of oil in the engine is probably too low.
Check as soon as possible
the oil level or top up
⇒page 225 with engine oil.
A peep sounds as an additional warning signal.The following text will be displayed in the information display*:
Check oil level!
The warning light will go out if the bonnet
is left open for more than 30 seconds. If
no engine oil has been replenished, th
e warning light will come on again after
driving about 100 km.
Warning light
 flashes
A fault on the engine oil level sensor is indicated additionally by an audible signal and the warning light coming on several times after the ignition has been switched on. In this case have the engine inspected without delay by a specialist garage.The following text will be displayed in the information display*:
Oil sensor Workshop!
Fuel reserve

The warning light
 comes on, if the fuel level is still below 9 litres.
An audible signal sounds as an additional warning signal.The following text will be displayed in the information display*:
Please refuel! Range...kmNote
The Text in the information display* goes out only after refuelling and driving a short distance.
WARNING (continued)
s2dk.1.book Page 42 Wednesday, April 8, 2009 12:23 PM

Lights and Visibility
74
Top up with wash liquid
⇒page 234.
Winter position If the windscreen wipers are in rest posi
tion, they cannot be folded out from the
windscreen. For this reason we recommend
adjusting the windscreen wipers in
winter so that they can be folded out fr
om the windscreen easi
ly. You can set this
rest position as follows:•
Switch on the windscreen wipers.
•
Switch off the ignition. The windscreen wi
pers remain in the position in which
they were when switching off the ignition. You can also use the service po
sition as a winter position.
WARNING
•
Properly maintained windscreen wiper
blades are essential for clear visi-
bility and safe driving
⇒page 74.
•
Do not use the windscreen washer sy
stem at low temperatures, without
heating the windscreen beforehand. Otherwise the window cleaner could freeze on the windscreen and re
strict the view to the front.
•
The rain sensor only operates as a
support. The driver is not released
from the responsibility to set the function of the windscreen wipers manu- ally depending on the visibility conditions.
Caution
In frosty weather, please first of all chec
k whether the windscreen wiper blades are
not frozen to the windscreen before swit
ching them on. Switching on windscreen
wipers when the blades are frozen to the windscreen may result in damage both to the blades and the motor of the windscreen wipers!
Note
•
If the slower or the faster wiper setting is switched on
⇒page 73, fig. 73

and the vehicle speed decreases to below 4
km/h, the lower wiper step is switched
on automatically. At a speed increase of
more than 8 km/h the previous wiper
setting is established again.
•
If there is an obstacle on the windscreen, the wiper will try to push away the
obstacle. If the obstacle continues to bloc
k the wiper, the wiper stops after 5 cycles,
in order to avoid a damage to the wiper.
Remove the obstacle and and switch on
the wiper again.Headlight cleaning system*The headlights are being cleaned after the
windscreen has been sprayed for the first
time and fifth time, the low beam or ma
in beam are switched on and the wind-
screen wiper lever was held in the position
⇒page 73, fig. 73
for about 1
second. The headlight washer nozzles are moved fo
rward out of the bumper by the water
pressure for cleaning the headlights. You should remove stubborn dirt (such
as insect residues) from the headlight
lenses at regular intervals, for example when refuelling. Please refer to the following guidelines. You should remove any snow from the fixtures of the washer nozzles and clear ice in winter with a de-icing spray in order to ensure proper operation of the cleaning system.Replacing wiper blades for the windscreen wipers
A2
A3
A5
Fig. 74 Wiper blade for the windscreen wiper
s2dk.1.book Page 74 Wednesday, April 8, 2009 12:23 PM

Starting-off and Driving
120
You should not switch on any major elec
trical components during the heating
period otherwise the vehicle battery
will be drained unnecessarily.
•
You should start the engine immediately after the glow plug warning light

has gone out.•
The glow plug warning light will come on for about one second if the engine is
at a normal operating temperature or if the outside temperature is above +5°C. This means that you can start the engine
right away
.
•
Interrupt the attempt at starting after 10 seconds if the engine does not start
right awayand wait for about 30 se
conds before repeating the attempt.
•
It is possible that the fuse on the diesel
preglow system is defect if the engine
still does not start. Check the fuse and replace it if necessary
⇒page 256.
•
Contact the nearest specialist garage to obtain professional assistance.
Starting the engine after the fuel tank has run dry It may take longer than normal to start the
engine after refuelling
if the fuel tank has
run completely dry - up to one minute. This is because the fuel system must first of all be filled while the attempting to start the engine.Switching off the engine– The engine can be swit
ched off by turning the ignition key from posi-
tion into
⇒
page 118, fig. 134
.
WARNING
•
Never switch off the engine before the
vehicle is stationary - risk of acci-
dent!•
The brake booster only operates when the engine is running. Greater
physical effort for braking is required
when engine is switched off. Because
if you do not stop as normal, this can cause an accident and severe injuries.
Caution
you should not switch the engine off right
away at the end of your journey after the
engine has been operated for a lengthy peri
od at high loads but should be allowed
it to run at idling speed for about 2 minut
es. This prevents any accumulation of heat
when the engine is switched off.
Note
•
The radiator fan may continue running fo
r a further 10 minutes or so after the
engine and the ignition have
been switched off. The coolant fan may, however, also
switch on again after some time if the coolant temperature rises because of an accumulation of heat in the engine or
if the engine is warm and the engine
compartment is additionally
heated by strong sunlight.
•
This is why particular care is required when carrying out any work in the engine
compartment
⇒page 223, “Working in the engine compartment”.
Shifting (manual gearbox)
A1
Fig. 135 The shift pattern: 5- speed or 6-speed manual gearbox
s2dk.1.book Page 120 Wednesday, April 8, 2009 12:23 PM

Fuel
219
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
FuelPetrolGrades of petrolThere are various grades of petrol. Please read
⇒page 267, “Technical Data” in
order to know which grade of petrol your
vehicle requires. You will also find the
same information affixed to the inside of
the fuel filler flap of your vehicle
⇒ page 220, fig. 199
.
A distinction is made between unleaded an
d leaded petrol. All Škoda vehicles with
petrol engines are equipped with a catalyti
c converter and must therefore be only
driven with
unleaded petrol
. Unleaded petrol
complies with the
standard
DINEN228
.
The individual grades of petr
ol are distinguished by their
octane number
(RON).
Please adopt the following procedure if the grade of petrol which you normally use is not be available in
exceptional circumstances.
•
Engines which need
unleaded premium petrol 95 RON
can also be run on
unleaded regular petrol 91 RON. This does, however, result in a slight loss in performance. If, in an emergency, the only fuel availa
ble is one which has a lower octane number
than that required by the engine then only drive at medium engine speeds and lower engine loadings. You can make unlimited use of fuel whic
h has a higher octane
number than that
required by the engine. There will, howeve
r, be no advantages gained by this in
terms of engine performance and fuel consumption! The handling, performance and
life of your engine are determined to a significant
extent by the quality of the fuel.
Do not use any petrol additives.
Use a fuel
complying with
the standard.
You can find further information on refuelling
⇒page 220, “Refuelling”.
Caution
•
Filling the tank even only once with lead
ed petrol will result in the catalytic
converter being destroyed.•
Operating the engine with petrol of a lo
w octane number can result in engine
damage at high revolutions or severe engine loading.DieselDiesel fuelYour vehicle can be operated with
diesel fuel
, which complies with the standard
DIN EN 590
.
Fuel additives You must not use fuel additives, so-called “flow improvers” (petrol and similar products) in diesel fuel. If the quality of the diesel fuel is poor, it is then necessary to drain the
fuel filter

more often than stated in the Service schedule. You can find information on refuelling
⇒page 220, “Refuelling”.
Caution
•
Use fuel which complies with the standard
DIN EN 590
. Filling the tank even
only once, which does not comply with th
e standard, can result
in damage to the
fuel system.•
Water which has collected in the fuel fi
lter can result in engine problems.
•
Your vehicle is not adapted
for use of biofuel (RME), therefore this fuel must not
be refuelled and driven. Using this fuel (RME) can lead to damage to the engine or the fuel system.
s2dk.1.book Page 219 Wednesday, April 8, 2009 12:23 PM

Fuel
220
Operation in winterWinter-grade diesel fuel A different grade of diesel fuel is available at
filling stations in winter than during the
summer. Using “summer-grade diesel fuel” at
temperatures below 0°C can result in
operational problems because the diesel be
comes viscous as a result of paraffin
separation. It is therefore the case that DIN EN 590 prescribes diesel fuel class for certain periods of the year which can also be pu
rchased at the corresponding time during
the year. “Winter-grade diesel fuel” will still operate properly even at a temperature of -20°C. It is often the case in countries with diff
erent climatic conditions that diesel fuels
available have a different temperature char
acteristic. The authorised Škoda Service
Partners and filling stations in the country
concerned will be able to provide you
with information regarding the diesel fuels available. Prewarming fuel The vehicle is fitted with a fuel filter prewarming system. This secures operation of a vehicle using diesel fuel down to an environmental temperature of -25°C.
Caution
It is not permitted to add the various fuel
additives on the market, including petrol,
to diesel fuel in order to
improve its flow properties.
RefuellingThe filler flap is automatically unlocked or locked with the central locking. Opening the fuel filler cap – Press onto the left side of the fuel filler flap
⇒
fig. 198
.
– Unscrew the fuel filler cap anti-clo
ckwise and place the fuel filler cap
from above on the fuel filler flap
⇒
fig. 199
.Fig. 198 Right rear side of the vehicle: Open fuel filler flapFig. 199 Filler flap with cap unscrewed
s2dk.1.book Page 220 Wednesday, April 8, 2009 12:23 PM

Fuel
221
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Closing fuel filler cap – Screw on the fuel filler cap by turning it to the right until it is heard to
click.
– Close the fuel filler flap until it locks.The correct grade of fuel for your vehicle as
well as the tyre size and inflation pres-
sures are stated on a sticker affixed to the
inside of the fuel filler flap. Further infor-
mation on fuel
⇒page 219.
The fuel tank has a capacity of about 60 litres.
WARNING
Pay attention to any legal requirements if
you do carry a spare canister in the
vehicle. We do not recommend carrying any fuel canisters in your vehicle for safety reasons. The canister can be da
maged in the event of an accident and
fuel may leak out.
Caution
•
Before refuelling it is necessary to switch off the auxiliary heating system (auxil-
iary heating and ventilation) *.•
Remove any fuel which has spilled onto the paintwork of your vehicle immedi-
ately - risk of paint damage!•
Vehicles fitted with catalytic converter sh
ould never be allowed to let the fuel
tank to run completely empty. An irregular
supply of fuel to the engine can result in
misfiring and unburnt fuel may get into the exhaust system, which may result in overheating and damage to the catalytic converter.•
Make sure that the valve is not pressed into the filler tube when inserting the
pump nozzle into the filler tube. Otherwis
e you are unintentionally filling up the
volume, which in case of heat can cause an
expansion of the fuel. This can lead to
an overflow of fuel or damage
to parts of the fuel reservoir.
•
T h e f u e l t a n k i s f u l l j u s t a s s o o n a s t h
e pump nozzle switches off for the first time,
provided the nozzle has been operated properly. Do not continue refuelling - otherwise the expansion volume is filled up.
s2dk.1.book Page 221 Wednesday, April 8, 2009 12:23 PM

Index289
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data Power windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Button in front passenger door and in rear doors
55
Button in the driver's door . . . . . . . . . . . . . . . . . . 54
Central locking system . . . . . . . . . . . . . . . . . . . . . 56
RRadiator fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Rear armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85, 99
Rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Rear window
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Rear window heater . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Rear-view mirror
Exterior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Interior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Recharge battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Synchronisation . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Replacing fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Replacing the wiper blades . . . . . . . . . . . . . . . . . . . . . 74
Roof aerial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212SSafe securing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Safety information
Engine compartment . . . . . . . . . . . . . . . . . . . . . 223
Safety wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . 249Saving electrical energy . . . . . . . . . . . . . . . . . . . . . . . 202
Seat belt height adjuster . . . . . . . . . . . . . . . . . . . . . . 171
Seat belt warning light . . . . . . . . . . . . . . . . . . . . . . . . 170
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168, 172
Belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
fastening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Height adjustment . . . . . . . . . . . . . . . . . . . . . . . . 171
Safety information . . . . . . . . . . . . . . . . . . . . . . . . 169
taking off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Seat heaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Selector lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Selector lever lock
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Selector lever positions . . . . . . . . . . . . . . . . . . . . . . . 132
Selector lever-emergency unlocking (DSG) . . . . . 136
Service Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Service Interval Display . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Shifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Side airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Side lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Stability system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
after fuel tank has run empty . . . . . . . . . . . . . . 120
Diesel engines . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Petrol engines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119Steering
active driver-steering recommendation . . . . 195
Steering force assistance . . . . . . . . . . . . . . . . . . . . . 198
Storage compartment
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Umbrella . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Storage compartments . . . . . . . . . . . . . . . . . . . . . . . . 95
Storage facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Sun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Sun screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Switching lights on and off . . . . . . . . . . . . . . . . . . . . 60
Switching off the engine . . . . . . . . . . . . . . . . . . . . . . 120
TTailgate
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Taking care of your vehicle . . . . . . . . . . . . . . . . . . . 211
TCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141, 151
Temperature
outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The roof luggage rack system . . . . . . . . . . . . . . . . . . 91
Thickness of brake pads
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Tilting roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Tiptronic
automatic gearbox DSG . . . . . . . . . . . . . . . . . . 134
Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
Top Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Towing a trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
s2dk.1.book Page 289 Wednesday, April 8, 2009 12:23 PM
