SMART FORTWO COUPE 2008 Owners Manual

Seat belts
100
>> Controls. Proper use of seat belts
• Do not twist the seat belt when fastening.
• Adjust the seat belt so that the shoulder
portion is located as close as possible to
the middle of the shoulder (it should not
touch the neck). Never pass the shoulder
portion of the seat belt under your arm.
• Position the lap belt as low as possible on
your hips (over hip joint) and not across the
abdomen.
• Place the seat backrest in a position that is
as upright as possible.
• Never use a seat belt for more than one
person at a time.• Do not fasten a seat belt around a person
and another object at the same time. When
using a seat belt to secure infant or toddler
restraints or children in booster seats,
always follow the child seat manufacturer’s
instructions.
• Check your seat belt during travel to make
sure that it is properly positioned.
• Make sure that the seat belt is always fitted
snugly. Take special care to maintain a snug
fit when wearing loose clothing.
G
Warning!
Do not pass seat belts over sharp edges.
They could tear.
Do not allow the seat belt to get caught in
the door or in the seat adjustment mech

anism. This could damage the seat belt.
Never attempt to make modifications to
seat belts. This could impair the effec

tiveness of the seat belts.
Do not bleach or dye seat belts as this
may severely weaken them. In a crash
the y m ay no t be abl e to p r ovid e a de qu a te
protection.
Damaged seat belts or seat belts that
were highly stressed in an accident must
be replaced. Contact an authorized smart
center.

Lighting>> Controls.
101 Exterior lamp switch
For safety, smart recommends that you drive
with your low beam headlamps on during the
day. In certain countries, local laws dictate
that low beam headlamps are switched on au

tomatically during operation of the vehicle.i
If you drive in countries where vehicles
drive on the other side of the road than the
country in which the vehicle is registered, you
must have the headlamps modified for
symmetrical low beams. Relevant information
can be obtained at any authorized smart cen

ter.Exterior lamp switch Exterior lamp switch (USA only)
M
Lamps off
Daytime running lamp mode
1
1 Canada only.C
Parking lamps
B
Low beam headlamps or high beam
headlamps
M
Lamps off
C
Parking lamps
B
Low beam headlamps or high beam
headlamps
U
Automatic headlamp mode* P54.25
5343
31

Lighting
102
>> Controls. Parking lamps
You can switch on and off the parking lamps
with exterior lamp switch using the manual
headlamp mode.
>Switching on: Turn the exterior lamp switch
to positionC.
The parking lamps come on.
The following lamps also come on:
• Tail lamps
• License plate lamps
• Side marker lamps
Low beam headlamps
You can switch on and off the low beam
headlamps with exterior lamp switch using the
manual headlamp mode.>Switching on: Turn the exterior lamp switch
to positionB.
The low beam headlamps come on.
The low beam headlamp indicator lamp¡
in the instrument cluster comes on.
The following lamps also come on:
• Tail and parking lamps
• License plate lamps
• Side marker lamps
Automatic headlamp mode
1
The following lamps come on and go out auto

matically depending on the brightness of the
ambient light:
• Low beam headlamps
• Tail and parking lamps
•License plate lamps
• Side marker lamps1 Vehicles with rain
light sensor* only.
G
Warning!
If the exterior lamp switch is set to
positionU, the headlamps will not be
automatically switched on under foggy
conditions.
To minimize risk to you and to others,
activate headlamps by turning exterior
lamp switch to positionB when
driving or when traffic and/or ambient
lighting conditions require you to do so.
In low ambient lighting conditions, only
switch from positionU toB with
the vehicle at a standstill in a safe
location. Switching from positionU
toB will briefly switch off the
headlamps. Doing so while driving in low
ambient lighting conditions may result in
an accident.
The automatic headlamp feature is only
an aid to the driver. The driver is
responsible for the operation of the
vehicle’s lights at all times.

Lighting>> Controls.
103
>Turn the exterior lamp switch to
positionU.
With the key in starter switch position1, the
tail and parking lamps, the license plate
lamps, and the side marker lamps will come
on and go out automatically depending on
the brightness of the ambient light.
With the engine running, the low beam
headlamps, the tail and parking lamps, the
license plate lamps and the side marker
lamps will come on and go out automatically
depending on the brightness of the ambient
light.Daytime running lamp mode
1
In Canada the daytime running lamp mode is
mandatory and therefore in a constant mode.
>Turn the exterior lamp switch to
positionM.i
With the daytime running lamp mode acti

vated and the engine running, the low beam
headlamps cannot be switched off manually.
You cannot switch on the high beam head

lamps.
The high beam flasher is available at all times.
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam headlamps.When the engine is running, and you
• turn the exterior lamp switch to
positionC, the low beam headlamps, the
tail and parking lamps, the license plate
lamps and the side marker lamps come on.
• turn the exterior lamp switch to
positionB, the manual headlamp mode
has priority over the daytime running lamp
mode. The corresponding exterior lamps
come on.
1 Canada only.

Lighting
104
>> Controls.
Combination switch (high beam,
high beam flasher, and turn sig

nals)>Make sure that the key in the starter switch
is turned to position1.
Combination switch1
High beam
2
High beam flasherHigh beam headlamps
>Make sure that the low beam headlamps are
switched on (

page 102).
> Switching on: Push the combination switch
in the direction of arrow
1 until it engages.
The high beam headlamps come on.
The high beam headlamp indicator
lampA in the instrument cluster comes
on.
>Switching off: Pull the combination switch in
the direction of arrow
2.
The high beam headlamps go out.
The high beam headlamp indicator
lampA in the instrument cluster goes
out.High beam flasher
>Pull the combination switch briefly in the
direction of arrow
2.
Turn signals
Combination switch
1
Turn signals, right
2
Turn signals, left

Lighting>> Controls.
105
>Switching on: Push the combination switch
in the direction of arrow
1 or
2.
The corresponding turn signals flash.
The corresponding turn signal indicator
lampL orK in the instrument
cluster flashes.
The combination switch resets automati

cally after major steering wheel movement.
i
To signal minor directional changes such
as changing lanes, push the combination
switch only to the point of resistance and
release. The corresponding turn signals will
flash three times.
Coming home functionVehicles without rain
light sensor:
The interior lamps come on and then go out
again after 12 seconds every time when you
lock or unlock the vehicle.
Vehicles with rain
light sensor*:
In addition to the interior lamps, the exterior
lamps come on and then go out again after
12 seconds depending on the brightness of
the ambient light when you lock or unlock the
vehicle.
When leaving the vehicle
>Remove the key from the starter switch.
>Exit the vehicle.
>Press button
ª
on the key.
The vehicle is locked.
The interior and exterior
1 lamps come on
and then go out again after 12 seconds.
When returning to the vehicle
>Press button
©
on the key either once or
twice.The vehicle is either selectively or globally
unlocked.
The interior and exterior
1 lamps come on
and then go out again after 12 seconds.
Front fog lamps
1 Vehicles with rain
light sensor
G
Warning!
Vehicles with rain
light sensor*:
In low ambient lighting or foggy condi

tions, only switch from positionU
toB with the vehicle at a standstill in
a safe location. Switching fromU
toB will briefly switch off the head

lamps. Doing so while driving in low ambi

ent lighting conditions may result in an
accident.

Lighting
106
>> Controls.
i
Fog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
i
Vehicle with rain
light sensor*:
Fog lamps cannot be switched on manually with
the exterior lamp switch in positionU. To
switch on the fog lamps, turn the exterior lamp
switch to positionB first.
1
Switching front fog lamps on/off>Make sure that the parking lamps or the low
beam headlamps are switched on.
> Switching on: Press switch
1.
The front fog lamps come on.
The indicator lamp on the switch comes on.
>Switching off: Press switch1 once more.
The front fog lamps go out.
The indicator lamp on the switch goes out. P54.25
5337
31

Lighting>> Controls.
107 Hazard warning flasher
The hazard warning flasher can be switched
on at all times, even with the key removed from
the starter switch.1
Hazard warning flasher switch
>Switching on: Press hazard warning flasher
switch
1.
All turn signal lamps are flashing.
>Switching off: Press hazard warning flasher
switch1 once more.
Interior lightingThe interior lamp comes on for a period of
time when you open the doors, or lock or
unlock the vehicle with the key.
It goes out
• immediately after switching off the ignition
with all doors closed,
• after 30 seconds if the doors are not
opened,
• after 15 seconds if all doors are closed,
• after 10 minutes if at least one door is open.The rocker switch can be set to three differ

ent positions.
1
Interior lamp
2
Switching on the automatic control
3
Off
4
Continuous operation P54.25
5341
31
P82.20
2954
31

Lighting
108
>> Controls. Automatic control
>Set the rocker switch to position
2.
The interior lamp comes on for a period of
time.
Switching off
>Set the rocker switch to position3.
The interior lamp is permanently switched
off.
Continuous operation
>Set the rocker switch to position4.
The interior lamp is permanently switched
on.
!
When leaving the vehicle, make sure that
• the interior lamp is not set to continuous
operation.
• none of the doors is left open for a long pe

riod of time.
Doing otherwise could result in a discharged
battery.

Windshield wipers
>> Controls.
109 Switching windshield wipers on
and off
Wiper switch0
Windshield wipers off
1
Intermittent wiping
2
Slow continuous wiping
3
Fast continuous wiping
>Make sure that the key in the starter switch
is turned to position1.>Switching on: Turn the wiper switch to
position
2 or
3 depending on the
intensity of the rain.
!
Do not operate the windshield wipers when
the windshield is dry. Dust that accumulates
on a windshield might scratch the glass and/or
damage the wiper blades when wiping occurs
on a dry windshield. If it is necessary to oper

ate the windshield wipers in dry weather con

ditions, always operate the windshield wipers
with windshield washer fluid (

page 110).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immedi

ately.
• For safety reasons, stop the vehicle in a
safe location and remove the key from the
starter switch before attempting to remove
any blockage.
• Remove blockage.
• Turn the windshield wipers on again.
>Switching off: Turn the wiper switch to
position
0.
Intermittent wipingOnly switch on intermittent wiping under wet
weather conditions or in the presence of
precipitation.
Vehicles with rain
light sensor*:
When you select intermittent wiping, the
sensor is activated. The sensor automatically
sets a suitable wiping interval depending on
the wetness of the sensor surface.!
Vehicles with rain
light sensor*:
Do not leave windshield wipers in intermittent
setting when the vehicle is taken to an auto

matic car wash or during windshield cleaning.
Windshield wipers will operate in the pres

ence of water sprayed on the windshield, and
windshield wipers may be damaged as a result. P54.25
5347
31
