SMART FORTWO COUPE 2008 Owners Manual

Unlocking/locking manually
250
>> Practical hints.
Unlocking the vehicleYou can unlock the driver’s door and the fuel
filler flap by unlocking the driver’s door using
the key. The lock cylinder is fitted with a cap.
>Press button
©
on the key.
The anti
theft warning system* is disarmed.
i
If the transmitter battery in the key is
discharged, the anti
theft warning system*
can no longer be disarmed with button
©
on
the key. For replacing the transmitter battery
(

page 253).
Unlocking the vehicle with the key and opening
a door or the tailgate will trigger the anti

theft warning system* (

page 77).
To cancel the alarm:
>Insert the key in the starter switch.
>Turn starter switch in Position 1
(

page 91).
1
Cap
2
Lock cylinder
>Remove cap
1 from lock cylinder
2.
>Unlock the driver’s door.
The driver’s door and the fuel filler flap are
unlocked.
i
To unlock the vehicle centrally press the
central unlocking switch in the upper center
console (

page 38).
Locking the vehicleIf you can no longer lock the vehicle using the
remote control and you do not have a spare
transmitter battery at hand, please proceed
as follows:
>Open the driver's door.
>Press the central locking switch
(

page 84).
The indicator lamp on central locking
switch
1 comes on, when the starter switch
is in position 1.
The indicator lamp on central locking
switch1 flashes, when the starter switch is
in Position 0.
>Remove the key from the starter switch,
take it with you, and close all doors.
The vehicle is now locked and the anti
theft
warning system* is armed. P72.10
3348
31

Unlocking/locking manually
>> Practical hints.
251 Closing the rear soft top
If the rear soft top does not lock properly
after being closed, proceed as follows:
>Stop the vehicle in a safe location.
>Set the parking brake.
>Make sure that the key in the starter switch
is turned to position1.
>Fold up the rear soft top completely.
The rear soft top stops in the unlocked
position.
>Within one minute, press and hold
symbol± on the retractable soft top
switch for 15 seconds twice.
The rear soft top closes the locking hooks.
>Close the retractable soft top completely.
>Have the rear soft top checked at an autho

rized smart center.

Replacing transmitter battery
252
>> Practical hints.
NotesThe remote control's transmitter battery is
almost spent when the turn signals flash
rapidly nine times in a row when locking the
vehicle.i
If you do not replace the transmitter
battery, after about 100 more times you will no
longer be able to lock or unlock the vehicle
using the remote control.>Replace the transmitter battery.
or
>Have the transmitter battery replaced at an
smart center.
Batteries contain materials that can harm the
environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries for
recycling.
G
Warning!
Batteries contain poisonous and corro

sive substances. Therefore keep the
batteries out of reach of children.
If a battery is swallowed, seek medical
help immediately.

Replacing transmitter battery
>> Practical hints.
253 Replacing transmitter battery
Replacement battery: CR 2016 button cell!
Replace the remote control's transmitter
battery every two years at the latest. Other

wise there is a danger of leakage. The remote
control could be damaged.
1
Key housing top half>Insert a suitable object such as a coin into
the slot at the eyelet of the key housing.
>Carefully turn the coin until key housing top
half
1 is unlatched.
>Open key housing top half
1 to the side.
2
Transmitter battery
>Remove transmitter battery
2 from the
board.
!
Check the polarity when inserting the new
transmitter battery. You could otherwise
damage parts of the electrical system. When
inserting the batteries, make sure they are
clean and free of lint.
>Insert the new transmitter battery.
>Press both halves of the key housing
together again.
>Check the operation of the remote control.
P80.35
2289
31

Replacing bulbs
254
>> Practical hints.
About replacing bulbsSafe vehicle operation depends on proper
exterior lighting and signaling. It is therefore
essential that all bulbs and lamp assemblies
are in good working order at all times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. Contact an autho

rized smart center for headlamp adjustment.
i
If the headlamps or front fog lamps* are
fogged up on the inside as a result of high
humidity, driving the vehicle a distance with
the lights on should clear up the fogging.
G
Warning!
Bulbs and bulb sockets can be very hot.
Allow the lamp to cool down before
changing a bulb. Otherwise you could be
burned if you touch them.
Keep bulbs out of the reach of children.
Halogen lamps contain pressurized gas.
Abulb can explode if you:
• touch or move it when hot
•drop the bulb
• scratch the bulb
Wear eye and hand protection.

Replacing bulbs
>> Practical hints.
255 Overview bulbs
Front lamps Rear lamps
P82.10
4837
31
Lamp
Type
1
Turn signal lamp
PY 21 W
2
Low beam headlamp
H7 (55W)
3
Parking and side

marker lamp
WY 5 W
4
Front fog lamp*
H11
5
High beam headlamp
H7 (55W)
6
Side turn signal lamp
WY 5 W
Lamp
Type
7
High
mounted brake
lamp
W16W
8
Brake, tail, turn
signal, and
sidemarker lamp
12 V 21/5 W
9
Reflector


a
Back
up lamp
12 V 21 W
b
License plate lamp
C5W

Replacing bulbs
256
>> Practical hints. Notes on bulb replacement
• Only use bulbs of the same type and with the
specified watt rating.
• Switch the lights off before replacing a bulb
to prevent short circuits.
• Always use a clean lint
free cloth when
handling bulbs.
• Your hands should be dry and free of oil and
grease.
• Avoid touching the glass of the bulb with
bare fingers.
• If the newly installed bulb does not come on,
contact an authorized smart center.
• Have the bulbs for the front fog lamps*
replaced at an authorized smart center.
Replacing bulbs for front lampsBefore you start to replace a bulb for a front
lamp, do the following first:
>Turn the exterior lamp switch to
positionM (

page 101).
>Switch off the ignition.
>Open the service flap (

page 176)
Left headlamp, (right headlamp in reverse)
1
Bulb socket for parking, and side marker
lamp
2
Bulb socket for turn signal lamp
3
Low beam headlamp cover
4
High beam headlamp coverParking and sidemarker lamp bulb
>Removing:
Driver side: Turn bulb socket
1 toward the
outside.
Passenger side: Turn bulb socket1 toward
the outside.
>Pull bulb socket
1 out of the headlamp
housing.
>Pull the bulb out of bulb socket
1.
> Installing: Insert the new bulb into bulb
socket
1.
>Insert bulb socket
1 into the headlamp
housing.
>Driver side: Turn bulb socket
1 toward the
inside.
Passenger side: Turn bulb socket1 toward
the inside. P82.10
4836
31

Replacing bulbs
>> Practical hints.
257
Low beam headlamp bulb
>Removing: Take off low beam headlamp
cover
3.
>Detach the electrical connector.
>Bend the retainer spring end down and
forward until it unclips. Fold the retainer
spring back.
>Pull the bulb out of the headlamp housing.
>Installing: Insert the new bulb into the
headlamp housing.
>Fold the retainer spring forward.
Bend the retainer spring end forward then
up and back to clip in.
>Attach the electrical connector.
>Reinstall low beam headlamp cover
3.High beam headlamp bulb
>Removing: Take off high beam headlamp
cover
4.
>Detach the electrical connector.
>Tilt the bulb socket down and pull it out.
>Pull the bulb out of the bulb socket.
>Installing: Insert the new bulb into the bulb
socket.
>Fit the bulb so that the retaining lug of the
base plate is pointing up.
>Press the bulb into the bulb socket until it
is fully engaged.
>Attach the electrical connector.
>Reinstall high beam headlamp cover
4.Front turn signal lamp bulb
>Removing: Turn bulb socket
2 counter

clockwise by a quarter of turn and pull it out
of the headlamp housing.
>Press gently onto the bulb and turn it
counterclockwise.
>Pull the bulb out of bulb socket2.
>Installing: Insert the new bulb into bulb
socket
2.
>Press gently onto the bulb and turn it
clockwise.
>Insert bulb socket
2 into the headlamp
housing.
The arrow on bulb socket
2 mu st be in l in e
with the line on the headlamp housing.
>Turn bulb socket
2 clockwise by a quarter
of turn.

Replacing bulbs
258
>> Practical hints. Side turn signal lamp bulb
>Removing: Open the door on the corre

sponding side.
1
Retaining lug
>Press on retaining lug
1 in the direction of
the arrow until the side turn signal lamp
housing disengages.
>Use a suitable tool to loosen the side turn
signal lamp housing from the fender.
>Turn the bulb socket counterclockwise and
pull it out out of the side turn signal lamp
housing.
>Pull the bulb out of the bulb socket.>Installing: Insert the new bulb into the bulb
socket.
>Insert the bulb socket into the side turn
signal lamp housing and turn the bulb
socket clockwise.
>Fit the side turn signal lamp housing onto
the fender.
>Press gently onto the side turn signal lamp
housing.
The side turn signal lamp housing must
audibly engage.
Replacing bulbs for rear lampsBefore you start to replace a bulb for a rear
lamp, do the following first:
>Turn exterior lamp switch to positionM
(

page 101).
>Switch off the ignition.
Tail lamp unit
>Removing:
Coupé:
>Open the upper tailgate.
>Open the lower tailgate.
Cabrio:
>Open the lower tailgate
>Open the rear soft top (

page 89)
>Remove the side cover in the cargo
compartment on the corresponding side.
>Fold the damping material forward, if
necessary.
P82.10
4556
31

Replacing bulbs
>> Practical hints.
259
Left bulb carrier illustrated as example1
Retaining tab
2
Electrical connector
>Press retaining tab
1 in the center of the
bulb carrier upwards.
>Pull the bulb carrier out of the tail lamp
housing.Left bulb carrier with bulb sockets (right bulb
carrier in reverse)
1
Retaining tab
3
Brake, tail, turn signal, and sidemarker
lamp bulb
4
Back
up lamp bulb
>Depending on which bulb needs to be
replaced, press gently onto bulb
3
or
4
and turn it counterclockwise.
>Pull the bulb out of the bulb socket.>Installing: Insert the new bulb into the bulb
socket.
>Press gently onto the bulb and turn it
clockwise until it engages.
>Insert the bulb carrier into the tail lamp
housing.
>Press gently onto the bulb carrier.
Let retaining tab
1 engage.
>Fold the damping material backward, if
necessary.
>Reinstall the side cover in the cargo com

partment.
P82.10
4527
31
