SECTION 1D1
M162 ENGINE COOLING
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1D1-1
General Specifications . . . . . . . . . . . . . . . . . 1D1-1
Fastener Tightening Specifications . . . . . . . . 1D1-2
Special Tools . . . . . . . . . . . . . . . . . . . . . . . 1D1-3
Special Tools Table . . . . . . . . . . . . . . . . . . . . 1D1-3
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1D1-4
System Leakage Test . . . . . . . . . . . . . . . . . . 1D1-4
Maintenance and Repair . . . . . . . . . . . . . . 1D1-5
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . 1D1-5Coolant Drain and Fill Up . . . . . . . . . . . . . . . 1D1-5
Coolant Connection Fitting . . . . . . . . . . . . . . 1D1-7
Water Pump . . . . . . . . . . . . . . . . . . . . . . . . . 1D1-8
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . 1D1-10
Oil Cooler Pipe Line . . . . . . . . . . . . . . . . . . 1D1-11
Cooling Fan and Viscous Clutch . . . . . . . . . 1D1-12
Cooling Fan Shroud . . . . . . . . . . . . . . . . . . 1D1-14
Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . 1D1-15
SPECIFICATIONS
GENERAL SPECIFICATIONS
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Description
Water Cooling Forced Circulation
Double Cross Flow
70,000 kcal/h
580 x 482 x 45 mm

f 460, Six Blades
ALUTEC - P78
50 : 50
11.3 L
3.4 L
1.4 bar Application
Cooling Type
Radiator
Dimension(Width´Height´Thickeness)
Cooling Fan
Anti-Freeze Agent
Mixing Ratio of Anti-Freeze Agen with Water (Anti-Freeze Agent : Water)
Coolant Capacity
Reservoir Capacity
Cap Operating Pressure (Reservoir Tank Pressure Cap)
Circulation Type
Radiation Capability

M162 ENGINE COOLING 1D1-5
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
COOLANT DRAIN AND FILL UP
Draning & Filling up Procedure
1. Loosen the cap a little and release pressure and remove
the cap.
Notice
For the risk of scalding, the cap must not be opened unless
the coolant temperature is below 90
oC.
2. Loosen the radiator lower drain cock and drain the coolant.
Notice
Collect coolant by using a proper container.
3. Drain the coolant from the crankcase by inserting a hose
(dia. 14mm) onto the drain bolt on the side of crankcase
(exhaust manifold) and by loosening the plug.
Notice
lJust loosen the drain plug to drain the coolant and do
not remove the plug completely.
lCollect coolant by using proper container.
4. After complete draining of the coolant, remove the hose
connector to drain plug and reinstall the drain plug.
Installation Notice
5. Tighten the radiator lower drain cock.
Tightening Torque 30 Nm

Circulation Type
Radiation
Capability
SECTION 1D2
M161 ENGINE COOLING
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1D2-1
General Specifications . . . . . . . . . . . . . . . . . 1D2-1
Fastener Tightening Specifications . . . . . . . . 1D2-2
Special Tools . . . . . . . . . . . . . . . . . . . . . . . 1D2-3
Special Tools Table . . . . . . . . . . . . . . . . . . . . 1D2-3
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1D2-4
System Leakage Test . . . . . . . . . . . . . . . . . . 1D2-4
Maintenance and Repair . . . . . . . . . . . . . . 1D2-5
On-Vehicle Service . . . . . . . . . . . . . . . . . . . . . 1D2-5Coolant Drain and Fill Up . . . . . . . . . . . . . . . 1D2-5
Cooling Fan and Viscous Clutch . . . . . . . . . . 1D2-7
Coolant Pump . . . . . . . . . . . . . . . . . . . . . . . . 1D2-9
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . 1D2-11
Thermostat Housing Assembly . . . . . . . . . . 1D2-12
Removal and Installation of Cooling
Fan Shroud . . . . . . . . . . . . . . . . . . . . . . . 1D2-14
Removal and Installation of Radiator . . . . . 1D2-15
SPECIFICATIONS
GENERAL SPECIFICATIONS
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
TABLE OF CONTENTS
Description
Water Cooling Forced Circulation
Down Flow
61,500 kcal/h
58,000 kcal/h
680 x 415 x 25 mm
680 x 415 x 28 mm

f 460, 9 Blades
ALUTEC-P78, Dragon Power Coolant A
50 : 50
10.5 L
3.4 L
1.4 bar Application
Cooling Type
Radiator
Dimension(Width´Height´Thickeness)
Cooling Fan
Anti-Freeze Agent
Mixing Ratio of Anti-Freeze Agen with Water (Anti-Freeze Agent : Water)
Coolant Capacity
Reservoir Capacity
Cap Operating Pressure (Reservoir Tank Pressure Cap)

M161 ENGINE COOLING 1D2-5
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE
COOLANT DRAIN AND FILL UP
Draning & Filling up Procedure
1. Loosen the cap a little and release pressure and remove
the cap.
Notice
For the risk of scalding, the cap must not be opened unless
the coolant temperature is below 90oC.
2. Loosen the radiator lower drain cock and drain the coolant.
Notice
Collect coolant by using a proper container.
3. Drain the coolant from the crankcase by inserting a hose
(dia. 14mm) onto the drain bolt on the side of crankcase
(exhaust manifold) and by loosening the plug.
Notice
lJust loosen the drain plug to drain the coolant and do
not remove the plug completely.
lCollect coolant by using proper container.

SECTION 1D3
OM600 ENGINE COOLING
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1D3-1
General Specifications . . . . . . . . . . . . . . . . . 1D3-1
Fastener Tightening Specifications . . . . . . . . 1D3-1
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-2
Cooling Circulation . . . . . . . . . . . . . . . . . . . . 1D3-2
Thermostat Operation . . . . . . . . . . . . . . . . . 1D3-3
Cooling System Leakage Test . . . . . . . . . . . 1D3-4
Maintenance and Repair . . . . . . . . . . . . . . 1D3-5On-Vehicle Service . . . . . . . . . . . . . . . . . . . . 1D3-5
Drain and Filling of Coolant . . . . . . . . . . . . . 1D3-5
Coolant Pump . . . . . . . . . . . . . . . . . . . . . . . . 1D3-6
Coolant Pump Housing . . . . . . . . . . . . . . . . . 1D3-8
Cooling Fan Clutch . . . . . . . . . . . . . . . . . . . 1D3-10
Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-12
Cooling Sub-System . . . . . . . . . . . . . . . . . . 1D3-14
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-16
TABLE OF CONTENTS
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
Application
Coolant
Mixing Ratio (Water : anticorrosion)
CapacityDescription
ALUTEC P- 78
50 : 50
10.5L - 11L
9.5L - 10L
SPECIFICATIONS
GENERAL SPECIFICATIONS
Application
Coolant Pump Bolt
Belt Pulley Bolt
Coolant Pump Housing Return Pipe Bolt
Thermostat Bolt
Cooling Fan Clutch Socket Bolt (Center)
Cooling Fan Clutch Socket Bolt (Side)
Radiator Bolt
Coolant Sub-tank BoltN
· ·· ·
·m
10
10
10
10
45
10
3 - 7
3 - 7
FASTENER TIGHTENING SPECIFICATIONS
662LA
661LA

1D3-4 OM600 ENGINE COOLING
COOLING SYSTEM LEAKAGE TEST
Tools Required
124 589 15 21 00 Tester
Test
1. Loosen the pressure cap by 1 notch and remove the cap
after.
Notice
Do not remove radiator cap when coolant is above 90°C.
2. Add the coolant to the arrow mark of coolant reservoir.
3. Connect the special tool to the injector of reservoir and apply
1.4bar pressure.
Tester 124 589 15 21 00
4. If the pressure on the tester drops, check the hose, pipe
and leakage and, replace or retighten.

OM600 ENGINE COOLING 1D3-5
DRAIN AND FILLING OF COOLANT
Preceding Work : Removal of skid plate
Drain / Filling
1. Loosen the pressure cap of reservoir by 1 notch and remove
pressure and then loosen the cap.
Notice
Do not remove radiator cap when coolant is above 90°C.
2. Open the drain plug and drain the coolant.
Notice
Collect the coolant by using the proper bottle.
3. Remove the drain plug(1) and seal(2) of cylinder block and
drain the coolant.
4. Replace the seal to new one and tighten the drain plug
Installation Notice
Tightening Torque 30 Nm
5. Tighten the drain plug of the lower radiator.
6. Fill the coolant through coolant reservoir-tank.
Notice
lA proportion of 50% by volume of water / anticorrosion
must be ensured
7. After engine is running at idle speed, check the level of
coolant. If necessary, add enough specified coolant.
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE

1D3-14 OM600 ENGINE COOLING
COOLING SUB-SYSTEM
1 Radiator
2 Cooling Fan Shroud
3 Bolt.......................................................... 3-7Nm
4 Cooling Fan Shroud
5 Radiator Deaieration Hose7 Mounting Bracket
8 Make-up Cooling Hose
9 Bolt...........................................................3-7Nm
10 Cooling Reservoir-tank Cap
11 Cooling Reservoir-tank
