OM600 ENGINE MECHANICAL 1B3-175
OIL PUMP
1 Oil Pump
2 Piston
3 Pressure Spring
4 Guide Pin5 Screw Plug................................................ 50 Nm
6 Combination Bolt...................................... 25 Nm
7 Oil Strainer
8 Bracket
Disassembly Procedure
1. Remove the oil pan.
2. Unscrew the mounting bolt of spracket.

1B3-176 OM600 ENGINE MECHANICAL
Tightening Torque 10 Nm
3. Unscrew the oil strainer bracket bolt.
4. Remove the oil pump.
5. Unscrew the screw plug and remove the relief valve.
6. Installation should follow the removal procedure in the
reverse order.

OM600 ENGINE MECHANICAL 1B3-177
CYLINDER HEAD PRESSURE LEAKAGE TEST
Preceding Work : Removal of the cylinder head
Removal of the exhaust manifold
Removal of the valve
1 Feed Pipe
2 Bolt
3 Return Connection
4 Gasket ................................................................ Replace
5 Coolant Gallery................................................... Sealing
6 Pressure Measuring Plate..................................Completely tight to the cylinder head
7 Cylinder Head.....................................................
Immerse with pressure measuring plate into warm water of approx. 60°C and pressurize with compressed
airof 2 bar.
Notice
If air bubbles are seen, replace the cylinderhead.
Tools Required
115 589 34 63 00 Pressure Measuring Plate
601 589 00 25 00 Suspension Device
UNIT REPAIR

1B3-178 OM600 ENGINE MECHANICAL
Height ‘A’
(cylinder head surface - cylinder head cover surface)
Minimum height after machining
Permissible unevenness of parting surface
Permissible variation of parallelism (longitud. Direction)
Peak-to-valley height
Valve arrears ‘a’
Prechamber protrusion
Service Data
In longitudinal direction
In transverse direction
Intake valve
Exhaust valve142.9 - 143.1mm
142.5mm
0.08mm
0.0mm
Max. 0.1mm
0.0017mm
0.1 - 0.7mm
0.1 - 0.7mm
7.6 - 8.1mm
FACING CYLINDER HEAD MATING SURFACE
Preceding Work : Removal of prechamber
Cylinder head pressure leakage test
1 Valve
2 Cylinder Head
3 Prechamber
A Height of Cylinder HeadB Longitudinal Direction
C Transverse Direction
a Valve Arrears
b Prechamber Protrusion

OM600 ENGINE MECHANICAL 1B3-179
Measurement Procedure
1. Measure height ‘A’.
Limit 142.5 mm
Notice
If the height is less than 142.5mm, replace the cylinder head.
2. Insert the valve (1) and measure valve arrears ‘a’.
Valve Arrears ‘a’ 0.1 - 0.7 mm
Notice
If out of standard, machine the valve seat.
3. Install the prechamber and measure protrusion ‘C’.
Protrusion ‘C’ 7.6 - 8.1mm
4. Assemble the engine and check the valve timing.

1B3-180 OM600 ENGINE MECHANICAL
REPLACEMENT OF CRANKCASE CORE PLUG
Left Right
Core plug.......................................................
f 34mm
OM661LA - 2EA
OM662LA - 3EACore plug.......................................................f 34mm
OM661LA - 2EA
OM662LA - 3EA
Core plug.......................................................
f 17mm
OM661LA - 1EA
OM662LA - 1EACore plug.......................................................f 34mm
OM661LA - 1EA
OM662LA - 1EA Left
Right

OM600 ENGINE MECHANICAL 1B3-181
Tools Required
102 589 00 15 00 Drift
102 589 12 15 00 Drift
Replacement Procedure
1. Completely drain the coolant.
2. Remove any parts which impede access.
(Example : transmission, injection pump)
3. Place the screwdriver to the deepdrawn edge of the core
plug and pull forward and then rotate 90°.
4. Pull out the core plug with pliers.
5. Thoroughly clean the sealing surface and apply Loctite 241.
6. Install the new core plug by using a drift.
Drift 102 589 00 15 00 (F34)
Drift 102 589 12 15 00 (F17)
7. Install the removed parts and fill the coolant.
Notice
The adhesive must be allowed to harden for about 45
minutes before filling of coolant.
8. Warm up the engine and check the coolant for leaks.

1B3-182 OM600 ENGINE MECHANICAL
Service Data
Height ‘Y’
Permissible unevenness of contacting surface
Permissible roughness upper contacting surface
Permissible variation of parallelism of crankcase upper
surface to lower surface in longitudinal direction
Piston protrusion at TDC to crankcase upper surface
In longitudinal direction (B)
In transverse direction (C)Min. 299.62 mm
0.06 mm
0.06 mm
0.0006 - 0.0016 mm
0.05 mm
0.965 mm
0.735 mm
Max.
Min.
FACING CRANKCASE CONTACTING SURFACE
1 Crankcase
2 Crankcase Contacting Surface
Y Height (crankcase upper surface - crankcase
lower surface)B Longitudinal Direction
C Transverse Direction
H Chamfer Height
b Chamfer Angle

OM600 ENGINE MECHANICAL 1B3-183
OIL GALLERY STEEL BALL
Preceding Work : Removal of cooling fan
Removal of the coolant pump housing
Removal of the flywheel and driven plate
1 Steel Ball.................................................f15mm 2Screw Plug...............................Loctite 241,50Nm
Notice
The screw plug (2) has to be installed as a repair solution if the steel ball (1) is leaking.

1B3-184 OM600 ENGINE MECHANICAL
3 Steel Ball.................................................f17mm
4 Seal5 Screw Plug.................................................50Nm
Notice
The seal (4) and screw plug (5) have to be installed as a repair solution if the steel ball (3) is leaking.
Tools Required
601 589 08 15 00 Drift
