Adjusting mirrors
To adjust the mirrors by hand, push where indicated by the arrows.
OM-H2737
Remote control mirror switch
The remote control mirrors operate only when the ignition switch is in the “ON” or “ACC” position.
HB4004BB
1. Press either end of the selection switch, “L” for the left, “R” for the
right.
2. Move the direction control switch in the direction you want to move
the mirror.
3. Return the selection switch to the neutral position to prevent
unintentional operation.
The mirrors can also be adjusted manually.

3-32
Outside mirror defogger (if equipped) CAUTION
To prevent the battery from being discharged, do not operate the
defogger continuously for any longer than necessary.
The outside mirror defogger operates only when the ignition switch isin the “ON” or “ACC” position.
HB4004CB
To turn on the outside mirror defogger, push the switch while the en- gine is running.The indicator light located on the switch will come on when the out-
side mirror defogger heater in operation.
To turn it off, push the switch again.
Tilt steering wheel
WARNING
Do not adjust the steering wheel tilt position while driving. This
may cause loss of vehicle control and result in personal injury.

Instruments and controls3-33
–
CONTINUED –
HB4002BA
1. Adjust the seat position. Refer to the “Front seat ” section (chapter 1).
2. Pull the tilt lock lever down.
3. Move the steering wheel to the desired level.
4. Push the lever up to lock the steering wheel in place.
5. Make sure that the steering wheel is securely locked by moving it upand down.
Horn
OM-H0440
To sound the horn, push the horn pad.

3-34

4
Climate control
Ventilator4-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual heating and air conditioning system 4-4 . . . . . . . . . . . . . . . . . . . .
Heater operation 4-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioner operation 4-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips for heater and air conditioner 4-12 . . . . . . . . . . . . . . . . . . .
Air filtration system (if equipped) 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-2
VentilatorCenter and side ventilators
HB5001BB
Adjustable side defroster grille (driver ’s side – if equipped)
HB5003BB
HB5002BB
Normal position
Side defroster grilleFin
Windshield defrost assist position
The driver ’s side defroster grille is adjustable. The normal position as
shown in the diagram directs warm air to the side glass. When more
rapid defrosting of the windshield is desired, the air flow can be
directed temporarily toward the windshield to assist the windshield
defroster. If this is done, the driver ’s side grille should always be
returned to its normal position so that the warm air flow can then be
used to defrost the driver ’s side window.

Climate control4-3
–
CONTINUED –
Air flow selection
HB5006CA
HB5006BA
HB5006EA
HB5006DA
HB5006FA

4-4
Manual heating and air conditioning systemControl panel
HB5004BC
1. Temperature control dial
2. Fan speed control dial
3. Air flow control dial
4. Air conditioner button
5. Air inlet selection button
6. Rear window defogger button (Refer to “Rear window defogger ” in
chapter 3.) n Temperature control dial
This dial regulates the temperature of air flow from the air outlets over
a range from the blue area (cool) to red area (warm). n Fan speed control dial
The fan operates only when the ignition switch is turned to the “ON”
position. The fan speed control dial is used to select four fan speeds. n Air flow control dial
This dial has the following five positions:
: Air flows through the instrument panel outlets.
: Air flows through the instrument panel outlets and the footoutlets.

Climate control4-5
–
CONTINUED –
: Air flows through the foot outlets and some through the wind-
shield defroster outlets.
: Air flows through the windshield defroster outlets and foot outlets.
: Air flows through the windshield defroster outlets.
NOTE When the dial is placed in the “
” or “”position, the air
conditioner compressor operates automatically regardless of the position of the air conditioner button to defog the windshield
quickly. At the same time, the air inlet selection is automaticallyset to “Outside air ” mode.
In this state, you cannot select “recirculation” mode by manually
pressing the air inlet selection button. n Air conditioner button
HB5010BB
The air conditioner operates only when the engine is running.
Push the air conditioner button while the fan is in operation to turn on
the air conditioner. The indicator light will come on.
Push it again to turn off the air conditioner.

4-6
nAir inlet selection button
WARNING
Continued operation in the ON position may fog up the windows.
Switch to the OFF position as soon as the outside dusty condi-tion clears.
HB5008BB
ON position (Recirculation): Interior air is recirculated inside the ve-
hicle. Push the air inlet selection button to the ON position. The indi- cator light will come on.OFF position (Outside Air): Outside air is drawn into the passenger
compartment. Push the air inlet selection button again to the OFF
position. The indicator light will go off.
