Maintenance and service11-51
–
CONTINUED –
Main fuse
HB8003CB
The main fuses are designed to melt during an overload to prevent dam-
age to the wiring harness and electrical equipment. Check the main
fuses if any electrical component fails to operate (except the starter mo-
tor) and other fuses are good. A melted main fuse must be replaced.
Use only replacements with the same specified rating as the melted
main fuse. If a main fuse blows after it is replaced, have the electrical
system checked by your nearest SUBARU dealer.
Installation of accessories
Always consult your SUBARU dealer before installing fog lights or any other electrical equipment in your vehicle. Such accessories may cause
the electronic system to malfunction if they are incorrectly installed or if
they are not suited for the vehicle.

11-52
Replacing bulbsHBF047CB
Wattage Bulb No.
1 Headlight
Low beam 12V –55W H1
High beam 12V –60W 9005 (HB3)
2 Front turn signal 12V –27W 1156NA (Amber)
3 Map light 12V –8W —
4 Dome light 12V –8W —
5 Door step light 12V –3.4W —
6 Front turn signal light/
parking and front side marker light 12V –27/8W 1157NA (Amber)
7 Front fog light 12V –51W 9006 (HB4)

Maintenance and service11-53
–
CONTINUED –
HBF048CB
HB3019BB
Wattage Bulb No.
8 Licence plate light 12V –5W 168
9 Cargo light 12V –13W 912
Q High mount stop light 12V–13W 912
W Backup light 12V –21W 7440
E Brake rear turn signal/tail light 12V –21/5W 7443
R Tail light 12V –5W 168
T Sports activity lights 12V –55W H3

11-54
Headlight
CAUTION
Halogen headlight bulbs become very hot while in use. If you touch the bulb surface with bare hands or greasy gloves, fingerprints or grease on the bulb surface develop into hot spots, caus-ing the bulb to break. If there are finger prints or grease on thebulb surface, wipe them away with a soft cloth moistened with al-cohol.
NOTE If headlight aiming is required, consult your SUBARU dealer for proper adjustment of the headlight aim.
HBB040BB
HBB039BA
Remove the headlight bulb cover, by turning it counterclockwise.

Maintenance and service11-55
–
CONTINUED –
Low beam light bulbs
HBB042BA
HBB041BB
1. Disconnect the electrical connector for the black cable.
2. Remove the retainer spring.
3. Replace the bulb, then set the retainer spring securely.
4. Reconnect the electrical connector for black cable.
5. Install the headlight bulb cover. High beam light bulbs
HBB044BB
HBB043BA
1. Disconnect the electrical connector from the bulb.
2. Remove the bulb from the headlight assembly by turning it coun-
terclockwise.
3. Replace the bulb with new one.
4. Reconnect the electrical connector. At this time, use care not to
touch the bulb surface.

11-56
5. To install the bulb to the headlight assembly, turn it clockwise until it clicks.
6. Install the headlight bulb cover.
Front fog light
It may be difficult to replace the bulbs. Have your SUBARU dealer
replace the bulbs if necessary. Front turn signal light, parking light and side marker light
The headlight assembly must be removed before the front turn signal
light and parking light bulbs can be replaced. When the headlight as-
sembly has been removed and then reinstalled, it may become neces-
sary to make a headlight aiming adjustment. After a bulb has been re-
placed, it is recommended that the headlight aiming adjustment be
made at a SUBARU dealer.
HBB016BA
1. Remove the headlight assembly mounting screws located at the top
of and the front of the headlight assembly using a phillips screwdriver or
an open-end wrench.
2. Move the headlight assembly forward.

Maintenance and service11-57
–
CONTINUED –
HBB039CBHBB020BA
3. Remove the bulb socket from the headlight assembly by turning it
counterclockwise.
4. Remove the bulb from the socket by pushing it and turning counter-clockwise. Install a new bulb in the socket.
5. Set the bulb socket into the headlight assembly and turn it clockwise
until it locks.
6. Set the headlight assembly into the vehicle body. Tighten the mount-
ing screws. Rear combination lights
Rear combination lights are composed of the rear turn signal/brake/tail
light and back up lights.
Rear turn signal/Brake/Tail and Back up lights
The rear turn signal/brake/tail light is one bulb with two filament types.
If any one of them malfunctions, replace the bulb with a new one.

11-58
HBB084BAHBB083BA
1. Open the tailgate.
2. Pry the cover from the side of the rear combination light.
3. Remove the rear combination light mounting bolts. Then, slide the
rear combination light assembly to the rear and remove it from thevehicle.
HBB085BB
4. Remove the bulb socket from the rear combination light assembly by
turning it counterclockwise.
5. Remove the bulb from the socket by pulling it.
6. Install a new bulb into the socket by pushing it.
7. Set the bulb socket into the rear combination light assembly and turnit clockwise until it stops.
8. Mount the rear combination light assembly into the vehicle body withtwo mounting bolts.

Maintenance and service11-59
–
CONTINUED –
9. Install the cover by inserting the knobs into the places. Tail light (on the tailgate)
HBB087BAHBB086BA
1. Open the tailgate.
2. Remove the tailgate trim by loosening the installation screws.
3. Remove the tail light cover by loosening the installation screws.
HBB048BAHBB088BA
4. Remove the bulb socket from the tail light by turning it counterclock- wise.
5. Remove the bulb from the socket by pulling it.
6. Install a new bulb into the socket by pushing it.
7. Install the bulb socket into the tail light by turning it clockwise until itstops.
8. Install the tail light cover and the tailgate trim.

11-60
License plate light
HBB095BAHB2054BA
1. Remove the upper cover located above the license plate.
2. Push two release buttons and pull the license plate bracket up until itclicks.
3. Remove the two cover installation screws.
4. Push the license plate bracket back to the original position.
HBB092BA
5. Remove the screw from the side of the cover.
6. Remove the cover.
