Maintenance and service11-61
–
CONTINUED –
HBB093BA
7. Remove the bulb socket from the license plate bracket by turning it
counterclockwise.
8. Pull the bulb out of the socket.
9. Install a new bulb in the socket by pushing it.10. Install the bulb socket into the license plate bracket.
11. Install the covers by reversing procedures for removal. Map light, dome light and door step light
HBB068BE

11-62
HSA005BB
HBS037AB
1. Remove the lens by prying the edge of the lens with a regular screw-
driver.
2. Pull the bulb out of the socket. Install a new bulb.
3. Reinstall the lens.

Maintenance and service11-63
–
CONTINUED –
High mount stop and cargo light assembly
HBB089BA
1. Remove the high mount stop light mounting screws.
HBB090BB
2. Remove the bulb socket from the light assembly by turning it counter- clockwise.

11-64
HBB048BA
3. Remove the bulb from the socket by pulling it.
4. Install a new bulb in the socket by pushing it.
5. Set the socket into the light assembly and turn it clockwise until itclicks.
6. Mount the light assembly with the mounting screws. Sport activity lights (if equipped)
HBB082AAHBB081BA
1. Remove front lamp screw and remove the lens and reflector.
2. Disconnect the two wires from the lamp electrical connector.
3. Squeeze the bulb retainer spring to remove.
4. Replace the bulb, then reset the retainer spring securely.
5. Reconnect the bulb wire to the electrical connector.
6. Install the lens and reflector in the housing and secure with the screw.

Maintenance and service11-65
–
CONTINUED –
NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer
replace these bulbs if necessary.

11-66

12
Specifications Specifications12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical system 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities 12-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 12-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel alignment 12-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 12-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located behind the coin tray 12-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse panel located in the engine compartment 12-6 . . . . . . . . . . . . . . . . . . .
Bulb chart 12-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle identification 12-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

12-2
Specifications
These specifications are subject to change without notice. Dimensions
Overall length 199.3 in (4,910 mm)
Overall width 70.1 in (1,780 mm)
Overall height 61.2 in (1,555 mm)
Ground clearance 7.3 in (185 mm)
Front tread 57.9 in (1,470 mm)
Rear tread 57.7 in (1,465 mm)
Wheelbase 104.3 in (2,650 mm)
Engine
Engine model EJ251
Engine type Horizontally opposed, liquid cooled
4 cylinder, 4 stroke gasoline engine
Engine displacement 2,457 cc (150 cu in.)
Bore 3.92 in (99.5 mm)
Stroke 3.11 in (79.0 mm)
Compression ratio 10.0 : 1
Firing order 1 - 3 - 2 - 4
Electrical system
Battery type and capacity
MT: 55D23L
AT: 75D23L
Alternator 12V-90A
Spark plugs type RC10YC4 (Champion) BKR6E-11 (NGK)BKR5E-11 (NGK)
Capacities
Fuel tank 16.9 US gal (64 liters, 14.1 Imp gal)
Engine oil 4.2 US qt (4.0 liters, 3.5 Imp qt)

Specifications12-3
–
CONTINUED –
Transmission oil (MT) 3.7 US qt (3.5 liters, 3.1 Imp qt)
Transmission fluid (AT) 9.8 US qt (9.3 liters, 8.2 Imp qt)
AT differential gear oil 1.3 US qt (1.2 liters, 1.1 Imp qt)
Rear differential gear oil 0.8 US qt (0.8 liters, 0.7 Imp qt)
Power steering gear fluid 0.7 US qt (0.7 liter, 0.6 Imp qt)
Engine coolant MT 7.2 US qt (6.8 liters, 6.0 Imp qt)
AT 7.1 US qt (6.7 liters, 5.9 Imp qt)
Tires
Type Steel belted radial, Tubeless
Size P225/60R16 97H Temporary spare T145/80R16
Pressure
Front Light load 30 psi (210 kPa, 2.1 kg/cm 2
)
Full load 30 psi (210 kpa, 2.1 kg/cm 2
)
Trailer towing 30 psi (210 kPa, 2.1 kg/cm 2
)
Rear Light load 29 psi (200 kPa, 2.0 kg/cm 2
)
Full load 33 psi (230 kpa, 2.3 kg/cm 2
)
Trailer towing 33 psi (230 kPa, 2.3 kg/cm 2
)
Temporary spare 60 psi (420 kPa, 4.2 kg/cm 2
)
Wheel size 16 x 6 1
/2 JJ
Wheel alignment
Toe Front 0 0.12 in (0 3 mm)
Rear 0 0.12 in (0 3 mm)
Camber Front 0 °20’ 30 ’
Rear –0 °10’ 45 ’

12-4
Fuses and circuits Fuse panel located behind the coin tray
HBC001BB
Fuse panelFuse ratingCircuit
115AHeater fan
215AHeater fan
315APower door lock
Keyless entry
420ACigarette lighter
Remote controlled rear view mirrors
510ATail light
Parking light
615ASRS airbag
