Page 130 of 306
PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
129
PHONE
4
NOTE
OA continuous tone signal is a character string that consists of
numbers and the characters “p” or “w”. (e.g. 056133w0123p#1\
½)
O When the “p” pause tone is used, the tone data up until the
next pause tone will be automatically sent after 2 seconds have
elapsed. When the “w” pause tone is used, the tone data up
until the next pause tone will be automatically sent after a user
operation is performed.
O Release tones can be used when automated operation of a
phone based service such as an answering machine or bank
phone service is desired. A phone number with continuous tone
signals can be registered in the contact list.
O Tone data after a “w” pause tone can be operated on voice
command during a call.
TRANSMIT VOLUME SETTING
1.SelectMic Volume (Mic Volume).
2.Select the desired level for the transmit volume.
3.SelectOK (OK).
NOTE
O
The sound quality of the voice heard from the other party’s
speaker may be negatively impacted.
O To reset the transmit volume, select
Default (Default).
O The volume cannot be adjusted while muted.
INCOMING CALL WAITING
When a call is interrupted by a third party while talking, this
screen is displayed.
1.Select or press the switch on the steering
wheel to start talking with the other party.
To refuse to receive the call: Select or press the switch on the steering wheel. ”Select
or press the switch on the steering
wheel to end the current call and return to the
conversation with the party on hold.
Page 134 of 306
PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
133
PHONE
4
NOTE
OThe text of the message is not displayed while driving.
O Turn the “POWER/VOLUME” knob, or use the volume control
switch on the steering wheel to adjust the message readout
volume.
REPLYING TO A MESSAGE (QUICK REPLY)
15 messages have already been stored.
1. ' L V S O D \ W K H P H V V D J H L Q E R [ V F U H H Q : 3
2.Select the desired message from the list.
3.SelectQuick Message (Quick Message).
4.Select the desired message.
5.SelectSend (Send).
” While the message is being sent, a sending message
screen is displayed.
EDITING QUICK REPLY MESSAGES
This operation cannot be performed while driving.
1.SelectQuick Message (Quick Message).
2.Select corresponding to the desired message to
edit.
3.SelectOK (OK) when editing is completed.
NOTE
O
To reset the editquick reply messages, select Default(Default).
Page 139 of 306
SETUP
138
No.Function
Select to set the desired incoming e-mail tone.
Select or to adjust the incoming e-mail tone
volume.
Select or to adjust the default volume of the
other party’s voice.
Select to reset all setup items.
“Contact/Call History Settings (Contact/Call
History Settings)” SCREEN
The contact can be transferred from a Bluetooth phone
to the system. The contact also can be added, edited and
deleted.
The call history can be deleted and contact and speed dial
can be changed.
1.Display the “Phone/Message Settings (Phone/Message
6 H W W L Q J V
Page 140 of 306
SETUP
139
PHONE
4
No.Function Page
Select to add contacts to the speed dial list. 143
Select to delete contacts from the speed dial
list. 144
Select to set the transferred contact image
display on/off. -
*
Select to clear contacts from the call history. -
*Select to add new contacts to the contact list. 140
*Select to edit contacts in the contact list. 141
*Select to delete contacts from the contact list. 142
Select to reset all setup items. -
*: For PBAP compatible Bluetooth phones, this function is available when
“Automatic Contact/History Transfer (Automatic Contact/History Transfer)”
L V V H W W R R I I : 3
NOTE
OContact data is managed independently for every registered
phone. When one phone is connected, another phone’s
registered data cannot be read.
UPDATE CONTACTS FROM PHONE
Operation methods differ between PBAP compatible and
OPP compatible Bluetooth phones.
If your cellular phone is neither PBAP nor OPP compatible,
the contacts cannot be transferred.
Q FOR PBAP COMPATIBLE Bluetooth PHONES
1.SelectUpdate Contacts from Phone (Update
Contacts from Phone).
” Contacts are transferred automatically.
2. & K H F N W K D W D F R Q
Page 148 of 306
SETUP
147
PHONE
4
3.Select the desired item to be set.
No.Function
Select to change the incoming call display.
Full Screen (Full Screen): When a call is received,
the hands-free screen is displayed and can be operated
on the screen.
Drop-Down (Drop-Down): A message is displayed
on the upper side of the screen.
Select to set display of the contact/history transfer
completion message on/off.
Select to reset all setup items.
Page 158 of 306
APPS
5
ahaTM by HARMAN
157
X
Control screen
No.Function
Select to display a list of preset stations.
A maximum of 35 entries can be displayed in this list.
Select to display a list of stations using the location
information.
A maximum of 10 entries can be displayed in this list.
No.Function
Select to display the audio source selection screen.
Station list
Select to display the station operation screen.
Displays station name.
Select to display the top screen.
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
6 W D W L R Q R S H U D W L R Q V F U H H Q E X W W R Q V : 3
Select to change the station operation screen buttons.
Select to display the content item list.
Displays cover art.
NOTE
OWhen you switch to other modes with the aha application
activated and then turn the system Off/On with the smartphone
device still connected, the aha mode will start instead of
the last mode used. If you do not want to start the aha mode
automatically, turn off the aha application on the smartphone.
Page 159 of 306
ahaTM by HARMAN
158
NOTE
OTop 35 entries in the preset station list on the smartphone are
displayed. When there are more than 35 entries in the preset
station list, change the order of the entries in the list on the
smartphone. You can change the priority of your preset stations
within the aha application (after disconnected from this system)
to modify the station list shown on the screen. Please see your
smartphone aha application “Edit Presets” to modify this list.
O , I W K H U H D U H P X O W L S O H D X G L R
Page 188 of 306
Bluetooth® SETTINGS
187
SETTINGS
7
No.Information
& R P S D W L E L O L W \ S U R ¿ O H R I W K H % O X H W R R W K G H Y L F H
Select to reset all setup items.
NOTE
OIf 2 Bluetooth devices have been registered with the same
device name, the devices can be distinguished referring to the
device’s address.
O Depending on the type of phone, some information may not be
displayed.
CHANGING A DEVICE NAME
1.SelectDevice Name (Device Name).
2.Enter the name and then select OK (OK).
NOTE
O
Even if the device name is changed, the name registered in your
Bluetooth device does not change.
SETTING AUDIO DEVICE CONNECTION METHOD
1.SelectConnect Audio Device from (Connect Audio
Device from).
2.Select the desired connection method.
”
Vehicle (Vehicle): Select to connect the audio
system to the audio device.
”
Device (Device): Select to connect the audio device
to the audio system.
” Depending on the audio device, the “Vehicle
(Vehicle)” or “Device (Device)” connection method
may be best. As such, refer to the manual that comes
with the audio device.
” To reset the connection method, select
Default
(Default).
Page 189 of 306
Bluetooth® SETTINGS
188
“System Settings (System Settings)”
SCREEN
7 K H % O X H W R R W K V H W W L Q J V F D Q E H F R Q ¿ U P H G D Q G F K D Q J H G
1.Display the “Bluetooth Settings (Bluetooth Settings)”
V F U H H Q : 3
2.SelectSystem Settings (System Settings).
3.Select the desired item to be set.
No.
Information Page
Select to set Bluetooth connection on/off. 189
Displays system name. Can be changed to a
desired name. 189
PIN-code used when the Bluetooth device
was registered. Can be changed to a desired
code.189
Device address is unique to the device and
cannot be changed.
-
Select to set the phone connection status
display on/off.-
Select to set the connection status display of
the audio device on/off.-
& R P S D W L E L O L W \ S U R ¿ O H R I W K H V \ V W H P G H Y L F H
-
Select to reset all setup items. -
Page 192 of 306
OTHER SETTINGS
191
SETTINGS
7
No.Function
*1 6 H O H F W W R F K D Q J H W K H Y H K L F O H F O R F N V H W W L Q J V : 3
Select to change the language.
Select to change the unit for measuring distance.
Select to turn the beep sound on/off.
Select to change the button and screen color.
Select to change the keyboard layout.
Select to turn on/off the setting that returns the display
to the split screen automatically after 20 seconds when
a screen other than the split screen is displayed.
Select to turn the animation function on/off.
6 H O H F W W R F X V W R P L ] H W K H V F U H H Q R I I L P D J H : 3
6 H O H F W W R G H O H W H S H U V R Q D O G D W D : 3
Select to set the connected device when using aha.
Select
USB (USB) when using an iPhone, and then
select
Bluetooth (Bluetooth) when using Android
devices.
No. Function
Select to set the connected device when using
Pandora*2. Select USB (USB) when using an iPhone,
and then select
Bluetooth (Bluetooth) when using
Android devices.
Select to update the Gracenote® database. For details,
contact your SUBARU dealer.
Select to display the software information. Notices
related to third party software used in this product are
enlisted. (This includes instructions for obtaining such
software, where applicable.)
Select to set the back camera delay control on/off.
When set to on, the back camera image displays for
approximately 6 seconds after moving the shift lever/
select lever “R” to any position other than “R”.
The display disappears when the shift lever/select lever
is moved to “P”, or when the vehicle speed reaches
approximately 5 mph (8 km/h) or faster.
Select to reset all setup items.
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
