Page 13 of 306
12
3AUDIO
BASIC OPERATION ............................................. 54
SOME BASICS ......................................................................54 ” TURNING THE SYSTEM ON AND OFF .........................54
” SELECTING AN AUDIO SOURCE ..................................55
” SOUND SETTINGS.........................................................56
” AUDIO SCREEN ADJUSTMENT ....................................58
” VOICE RECOGNITION SYSTEM ...................................59
RADIO OPERATION ............................................. 60
AM/FM RADIO.......................................................................60
” OVERVIEW ...................................................................\
..60
” PRESETTING A STATION ..............................................61
” SELECTING A STATION FROM THE LIST .....................62
” RADIO BROADCAST DATA SYSTEM ............................62
” AVAILABLE HD Radio™ TECHNOLOGY .......................64
” CACHING RADIO PROGRAMS......................................67
SiriusXM
® Satellite Radio ....................................................69
” OVERVIEW ...................................................................\
..69
” HOW TO SUBSCRIBE TO SiriusXM
® Satellite Radio .....70
” DISPLAYING THE RADIO ID ..........................................73
” PRESETTING A CHANNEL ............................................73
” CACHING RADIO PROGRAMS......................................74
” REGISTERING A SMART FAVORITE CHANNEL ...........75
” TuneStart
TM FUNCTION ..................................................75
” TuneScanTM FUNCTION ..................................................76
” SEARCHING BY FEATURED FAVORITES ....................76
” SELECTING A CHANNEL FROM THE LIST ...................76
” PRESERVING A MUSIC INFORMATION .......................77
MEDIA OPERATION ............................................. 78
CD .....................................................................\
.....................78
” OVERVIEW ...................................................................\
..78
USB MEMORY ......................................................................81 ” OVERVIEW ...................................................................\
..81
iPod ...................................................................\
....................84 ” OVERVIEW ...................................................................\
..84
SD CARD (WITH NAVIGATION FUNCTION) .......................87 ” OVERVIEW ...................................................................\
..87
Bluetooth AUDIO ..................................................................91
” OVERVIEW ...................................................................\
..91
” CONNECTING A Bluetooth DEVICE ...............................94
AUX ....................................................................\
...................94 ” OVERVIEW ...................................................................\
..94
AUDIO/VISUAL REMOTE CONTROLS ............... 96
STEERING SWITCHES ........................................................96
SETUP ................................................................... 99
AUDIO SETTINGS ................................................................99
” AUDIO SETTINGS SCREEN ..........................................99
TIPS FOR OPERATING THE AUDIO/VISUAL
SYSTEM .............................................................. 102
OPERATING INFORMATION ..............................................102
” RADIO ..................................................................\
.........102
” CD PLAYER AND DISC ................................................104
” USB MEMORY ..............................................................107
” iPod ...................................................................\
............107
” SD CARD (WITH NAVIGATION FUNCTION) ...............108
” FILE INFORMATION .....................................................108
” TERMS ..................................................................\
........ 112
Page 57 of 306
BASIC OPERATION
56
SOUND SETTINGS
The following sound quality can be adjusted.
BALANCE:
A good balance of the left and right stereo channels and of
the front and rear sound levels is also important.
Keep in mind that when listening to a stereo recording or
broadcast, changing the right/left balance will increase the
volume of 1 group of sounds while decreasing the volume of
another.
EQUALIZER:
Equalizer curves set beforehand to match sound quality can
be selected, and curves can be set to your favorite music by
adjusting them individually over low to high bands.
1.SelectSound (Sound) on the audio control screen.
2.Select the desired screen button.
No.
Function
Select to adjust the sound balance between the front
and rear speakers.
Select to adjust the sound balance between the left and
right speakers.
6 H O H F W W R D G M X V W W K H V R X Q G T X D O L W \ : 3
Select to reset the adjusted sound quality.
Select to change to sound quality appropriate for the
music (POP, ROCK, JAZZ) type.
3.Select .
Page 58 of 306
BASIC OPERATION
57
AUDIO
3
ADJUSTING THE SOUND QUALITY
You can adjust the sound quality from the low band to the
high band.
QADJUSTING THE SOUND QUALITY
1.On the sound settings screen, select Adjust (Adjust)
in “EQ Settings (EQ Settings)”.
2.Select the sound band that you want to adjust.
3.Select or .
” You can also adjust to the desired level by touching
the screen.
” To reset the sound quality, select
FLAT (FLAT).
Q
SAVING THE SOUND QUALITY
You can save the adjusted sound quality settings.
1.Adjust the sound quality.
2.SelectEQ1 (EQ1) or EQ2 (EQ2) for 2 seconds or
more.
” Values cannot be saved for
FLAT (FLAT).
Q USING A PRESET SOUND QUALITY
1.SelectEQ1 (EQ1) or EQ2 (EQ2) to activate the
corresponding preset sound quality.
” To reset the sound quality, select
FLAT (FLAT).
” This function can also be used at the “EQ Settings
(EQ Settings)”.
Q RESETTING THE EQ CURVE
You can return the adjusted value for the currently stored
equalizer to its initial value.
1.Select and hold FLAT (FLAT) for 2 seconds or more.
” The adjusted values for the stored
EQ1 (EQ1) and
EQ2 (EQ2) are returned to their initial values.
Page 62 of 306
RADIO OPERATION
61
AUDIO
3
No.Function
Select to display the audio source selection screen.
Select to display the cache radio operation buttons.
: 3
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
Select to display a list of receivable stations/channels.
Select to scan for receivable stations/channels.
HD Radio only: Select to store information of the audio
F X U U H Q W O \ E H L Q J E U R D G F D V W R Q W K H U D G L R : 3
Select to tune to a preset station/channel.
Select to turn HD Radio mode on/off. When the HD
Radio indicator is off, the station list shows only analog
broadcasts.
Select to display the additional text information.
Analog FM only: Select to display RBDS text messages.
NOTE
OThe radio automatically changes to stereo reception when a
stereo broadcast is received.
O The radio automatically blends to an HD Radio signal in AM or
FM where available.
PRESETTING A STATION
Radio mode has a mix preset function, which can store up
to 36 stations from any of the AM, FM or SiriusXM Satellite
Radio bands.
1.Tune in the desired station.
2.Select(add new) ((add new)).
”
To change the preset station to a different one, select
and hold the preset station.
3.SelectYes < H V R Q W K H F R Q
Page 67 of 306
RADIO OPERATION
66
”FM stations can provide additional digital-only audio
programming on HD2/HD3 Channels.
PRESERVING A MUSIC INFORMATION
Tag information in the music broadcasting is preserved in
the system and transmits to an iPod.
1.SelectTag (Tag) to bookmark the music information.
2. & R Q Q H F W D Q L 3 R G : 3
”
Turn on the power of the iPod if it is not turned on.
” Once an iPod is connected, the music tag moves
from the radio into the iPod.
” When the iPod is connected to iTunes, the “tagged”
information of the songs which were tagged while
listening to the radio can be viewed. Then a user may
decide to purchase the song or CD/Album which had
been listened to on their radio.
” Up to 50 items of tag information can be stored.
NOTE
O The tag information can not be preserved while scanning or
caching the radio station.
O If tagging the music information fails, “Saving the HD Radio
tag was unsuccessful. (Saving the HD Radio tag was
unsuccessful.)” will be displayed on the screen. If this occurs,
tag the information again.
O HD Radio™ stations can be preset.
O An orange
HD) will be displayed on the screen when in digital.
The
HD) Z L O O
Page 71 of 306
RADIO OPERATION
70
No.Information/Function
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
6 H O H F W W R G L V S O D \ D O L V W R I F D W H J R U L H V : 3
Select to search subscribed channels by category.
By turning TuneScan Enable ON with channels
registered in Smart Favorites,
Tune Scan (Tune
6 F D Q L V G L V S O D \ H G : 3
6 H O H F W W R U H F H L Y H W D J L Q I R U P D W L R Q : 3
Select to tune to a preset channel.
is displayed for channels registered in Smart
Favorites.
6 H O H F W W R W X U Q W K H 6 ; 0 ) H D W X U H G R Q R I I : 3
Select to show information such as channel name, song
title, and artist name.
6 H O H F W W R W X U Q W K H 7 X Q H 6 F D Q R Q R I I : 3
Select to display the “Edit Favorites (Edit Favorites)”
V F U H H Q : 3
6 H O H F W W R W X U Q W K H 7 X Q H 6 W D U W R Q R I I : 3
NOTE
O If the ignition switch is turned “OFF” and then set to the “ACC\
”
or “ON” position when listening to an XL channel, broadcasting
from the XL channel will not begin. If so, the SXM001 channel
will be broadcast.
O XL channels may include frequent explicit language or mature
programming.
HOW TO SUBSCRIBE TO SiriusXM® Satellite
Radio
To listen to a satellite radio broadcast in the vehicle, a
subscription to the SiriusXM® Satellite Radio service is
necessary.
A SiriusXM
® Satellite Radio is a tuner designed exclusively
to receive broadcasts provided under a separate
subscription. SiriusXM U.S. satellite and data services
are available only in the 48 contiguous USA and DC.
SiriusXM satellite service is also available in Canada; see
www.siriusxm.ca.
Page 76 of 306
RADIO OPERATION
75
AUDIO
3
No.Function
Fast forwards continuously.
The fast forward speed increased the longer the button
is held down.
Select to access the desired program.
Skips forward through program.
Returns to the live radio broadcast.
Shows the current playback location relative to the
cached broadcast recording time with a bar scale.
NOTE
OThe time displayed on the bar scale may differ from the actual
time.
REGISTERING A SMART FAVORITE
CHANNEL
The TuneStart and TuneScan functions can be used by
registering preset channels as Smart Favorites. Up to 5
channels can be registered in Smart Favorites.
1.SelectSmart Favs Setup (Smart Favs Setup) on the
option screen.
2.Select check boxes for preset channels to be
registered, and then select
OK (OK).
TuneStartTM FUNCTION
TuneStart begins playing the current program from the
beginning when tuning to a channel registered in Smart
Favorites, allowing you to enjoy the complete program.
TuneStart is applicable to channels registered in Smart
) D Y R U L W H V : 3
It is necessary to turn on TuneStart at the option screen to
X V H W K L V I X Q F W L R Q : 3
NOTE
O
Live radio is broadcast immediately after switching from another
mode to SiriusXM mode even if the TuneStart setting is turned
ON. The TuneStart function starts if switching to a channel
registered in Smart Favorites within SiriusXM mode.
O The TuneStart function is not applicable to programs for which
even a little has been listened to from the start.
Page 98 of 306
AUDIO/VISUAL REMOTE CONTROLS
97
AUDIO
3
X“/ ” switch
Mode Operation Function
AM/FM Radio,
SiriusXM
®
Press Preset channel up/down
Press and hold Seek up/down continuously
aha Press
Content up/down
Press and hold Rewind the current content
item for 15 seconds/ Fast
forward the current content
item for 30 seconds
Audio CD, MP3/
WMA/AAC disc,
SD*
1,USB, iPod,
Bluetooth audio Press
6 H O H F W D W U D F N ¿ O H
Press and hold Fast forward/rewind
Pandora*
2Press Track up (“”only)
Press and hold Thumbs up/down
List screen Press Cursor left/right
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
X Mute/enter switch
Mode Operation Function
Except list
screen Press
Mute/unmute
List screen Press Select cursor entry
XBack switch
Mode Operation Function
All Press
Return to the previous screen
when
is displayed on
the screen.
Press and hold Return to the “HOME
(HOME)” screen
X
List switch
Mode Operation Function
Audio screen,
Navigation*
screen Press
Show list screen
*: With navigation function
Page 100 of 306
SETUP
99
AUDIO
3
SETUP
AUDIO SETTINGS
Detailed audio settings can be programmed.
1.Select.
2.SelectSETTINGS (SETTINGS).
3.SelectAudio (Audio).
4.Select the items to be set.
AUDIO SETTINGS SCREEN
No.
Function Page
Select to specify the sound settings. 56
Select to change the number of preset radio
stations/channels displayed on the screen.100
Page 101 of 306
SETUP
100
No.Function Page
Select to specify the iPod/SD*/USB auto play
settings on/off. -
Select to specify the iPod sound signal input
settings.101
Unsupported.
-
Select to specify cover art settings on/off. -
Select to specify automatic sound levelizer
settings.101
Select to enable cache radio.
-
Select to reset all setup items. -
*: With navigation function
DISPLAYING THE “Audio Settings (Audio
Settings)” SCREEN IN A DIFFERENT WAY
XUSB video/SD video*
*: With navigation function
1.Select on the audio control screen.
2.SelectSettings (Settings).
SETTING THE NUMBER OF RADIO PRESETS
1.Display the “Audio Settings (Audio Settings)” screen.
: 3
2.SelectNumber of Radio Presets (Number of Radio
Presets).
3.Select the button with the desired number to be
displayed.
