&Backup light1. Apply a flat-head screwdriver to the
light cover as shown in the illustration, and
pry the light cover off from the rear gate
trim.
2. For left side light, turn the bulb socket
clockwise and remove it.
For right side light, turn the bulb socket
counterclockwise and remove it.3. Pull the bulb out of the bulb socket and
replace it with a new one.4. Install the bulb socket by turning it
clockwise.
5. Install the light cover on the rear gate.
&License plate light1. The license plate lights must be
pushed outwards, and then pulled out to
be removed.
Maintenance and service/Replacing bulbs
11-40

(435,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
2. Turn the bulb socket counterclockwise
and pull out the socket.
3. Pull the bulb out of the socket.
4. Install a new bulb.
5. Reinstall the bulb socket and the
license plate light cover.&Map light
CAUTION
Replacing the bulb could cause
burns since the bulb may be very
hot. Have the bulb replaced by your
SUBARU dealer.
&Vanity mirror light (if
equipped)
CAUTION
Replacing the bulb could cause
burns since the bulb may be very
hot. Have the bulb replaced by your
SUBARU dealer.
&Dome light and cargo area
lightDome lightCargo area light1. Remove the lens by prying the edge of
–CONTINUED–
Maintenance and service/Replacing bulbs
11-41
11

(436,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
the lens with a flat-head screwdriver.
2. Pull the bulb out of the socket.
3. Install a new bulb.
4. Reinstall the lens.&Other bulbsIt may be difficult to replace the bulbs.
Have the bulbs replaced by your
SUBARU dealer if necessary.
Replacing key batteryThe access key fob/transmitter battery
may be discharged under the following
conditions.
.The operation of the keyless access
function is unstable
.The operating distance of the remote
keyless entry system is unstable
.The transmitter does not operate prop-
erly when used within the standard dis-
tance
Replace the battery with a new one.&Safety precautions
CAUTION
.Do not let dust, oil or water get on
or in the access key fob/transmit-
ter when replacing battery.
.Before replacing the battery, re-
move any static electricity.
.Be careful not to touch or damage
the printed circuit board in the
access key fob/transmitter when
replacing the battery.
.Be careful not to allow children to
touch the battery and any re-
moved parts; children couldswallow them.
.There is a danger of an explosion
if the battery is incorrectly re-
placed. Replace only with the
same or equivalent type of the
battery.
.Batteries should not be exposed
to excessive heat such as bright
sunlight, fire or the like.
NOTE.Replace only with the same or
equivalent type of battery recom-
mended by the manufacturer.
.Dispose of used batteries according
to local laws.
.Mount the battery in the correct
orientation to prevent fluid leakage.
Be careful not to bend the terminals. It
may result in a malfunction.
.It is recommended that the battery
be replaced by a SUBARU dealer.
.Use a new battery.
.After replacing the battery, confirm
that the transmitter functions properly.
Maintenance and service/Replacing key battery
11-42

(437,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Replacing battery of access
key fob
CAUTION
When removing or reinstalling the
access key fob cover, make sure that
the plastic part does not come off or
become misaligned.
Battery: Button battery CR20321) Release button
2) Emergency key1. Take out the emergency key.
2. Wrap a flat-head screwdriver with vinyl
tape or a cloth, and insert it in the gap to
remove the cover.3. Take out the battery using a flat-head
screwdriver with vinyl tape or a cloth.
4. Insert a new battery with its positive (+)
side facing upward as shown in the figure.5. Attach the cover to the access key fob
by fitting the projections and recesses
together.
–CONTINUED–
Maintenance and service/Replacing key battery
11-43
11

(438,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Replacing transmitter batteryBattery: Button battery CR1620 or
equivalent1. Wrap a flat-head screwdriver with vinyl
tape or a cloth. Open the key head using a
flat-head screwdriver.
2. Remove the transmitter case from the
key head.3. Open the transmitter case by releasing
the hooks.
1) Negative () side facing up4. Replace the old battery with a new
battery making sure to install the new
battery with the negative () side facing up.
5. Put together the transmitter case by
fitting the hooks on the case.
6. Reinstall the transmitter case in the
key head.
7. Refit the removed half of the key head.
Maintenance and service/Replacing key battery
11-44

(441,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Specifications........................................................12-2
Dimensions...........................................................12-2
Engine..................................................................12-3
Fuel......................................................................12-3
Engine oil.............................................................12-4
Manual transmission, front differential and rear
differential gear oil..............................................12-6
Fluids...................................................................12-7
Engine coolant......................................................12-7
Electrical system..................................................12-8
Tires .....................................................................12-8Temporary spare tires...........................................12-9
Brake disc............................................................12-9
Fuses and circuits..............................................12-10
Fuse panel located in the passenger
compartment...................................................12-10
Fuse panel located in the engine compartment ... 12-12
Bulb chart............................................................12-14
Safety precautions..............................................12-14
Bulb chart..........................................................12-15
Vehicle identification..........................................12-18
Specifications
12

(442,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
SpecificationsThese specifications are subject to change without notice.&Dimensions
in (mm)
Item
Overall length175.8 (4,465)
Overall width71.0 (1,800)
Overall height63.6 (1,615)
Wheel base104.9 (2,665)
Tread
Front 61.0 (1,550)
Rear 61.2 (1,555)
Ground clearance*
1
8.7 (220)
*1: Measured with vehicle empty
Specifications/Specifications
12-2

(443,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&EngineEngine model
FB20
(2.0 L, DOHC, non-turbo)
Engine type Horizontally opposed, liquid cooled 4 cylinder, 4-stroke direct injection gasoline engine
Displacement cu-in (cc) 121.7 (1,995)
Bore6Stroke in (mm) 3.3163.54 (84.0690.0)
Compression ratio12.5 : 1
Firing order1–3–2–4&Fuel
Fuel requirement Fuel tank capacity
Unleaded gasoline with 87 AKI (90 RON) or higher16.6 US gal (63 liters, 13.9 Imp gal)
For more details, refer to“Fuel”F7-3.
–CONTINUED–
Specifications/Specifications
12-3
12

(444,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
&Engine oilFor the checking, adding and replacing procedure or other details, refer to“Engine oil”F11-8.NOTEThe procedure for changing the engine oil and oil filter should be performed by a properly-trained expert. It is recommended
that you have this service performed by your SUBARU dealer.
!Approved engine oil
Always use the SUBARU approved engine oil. For further details, please contact your SUBARU dealer.
If the approved engine oil is unavailable, use the alternative engine oil described on the next page.
Specifications/Specifications
12-4

(445,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
!Alternative engine oil
If the SUBARU approved oil is unavailable, the following alternative oil can be used.NOTEEach quantity indicated here is only a guideline. The necessary quantity for replacement may differ slightly depending on the
temperature and other factors.
Oil gradeSAE viscosity No. and
