SUBARU FORESTER 2001 SF / 1.G Owners Manual

Audio5-35
–
CONTINUED –

To insert a disc
1. Press one of the “Disc select ” buttons 3 (numbered from 1 to 6)
for which the disc indicator light 2 is “OFF”.
The Disc indicator lights are located directly above the corresponding “ Disc select ” buttons.
2. The indicator will begin blinking. The blinking will last for 15 se-conds.
During this period, insert a desired disc, and the disc will begin to
play. (If any disc is not inserted during this period, the “Disc slot ”
1
door will close. Repeat step 1.)
Be sure to hold a disc with the label side (the side where titles areprinted) up.
3. To insert another disc, repeat step 1 and 2 choosing a differentdisc select button. To insert six discs at a time
1. Press and hold the “Disc select ” button number 1 until all disc indi-
cators begin blinking (about 1.5 seconds).
2. The indicators will blink for 15 seconds. During this period, insert
desired six discs.
3. When all discs are loaded, the first disc will begin to play. (If no
disc is inserted within this 15 seconds, the entire disc load sequencewill be canceled.) To remove a disc
1. Press the desired one of the “Disc select ” buttons
3 (numbered
from 1 to 6) for which the disc indicator light is on.
2. Press the “Eject button ”
4 . The selected disc will be ejected and
the indicator light will begin blinking.
3. To remove another disc, repeat step 1 and 2 choosing a different“ Disc select ” button.
(To remove discs when the ignition switch is in the “Lock” position,
press the “Eject” button, and the first disc will be ejected. Press the
“Eject” button again, and the next disc will be ejected and so on. At
this time, the “Disc select ” buttons are disabled.)

5-36
To remove all discs at one time
1. Press and hold the “Eject” button 4 until all “Disc” indicators begin
blinking (about 1.5 seconds), and the first disc will be ejected.
2. When the disc is removed, the next one will be ejected, and so on. To replace a playing disc with another
Simply press the desired one of “Disc select ” buttons
3 (numbered
from 1 to 6) or press the “DISC UP ” or “DISC DOWN ” button on the
radio unit to select the desired disc, and the disc will begin to play. Disc indicators
Lit: when the corresponding storage tray is occupied by a disc. Blinking: Disc player is either in loading, eject or changing mode.OFF: No disc is loaded or the ignition switch is in the “LOCK” position.
Function control
Refer to CD player control operating instructions described in the“ Type P119 and P120 audio sets ” or “Type P121 audio set ” section.

Audio5-37
–
CONTINUED –
Precautions to observe when handling a compact disc (CD)
To remove a disc from the case, press the center of the case and hold
both edges of the disc. If the disc surface is touched directly, contamina-
tion could cause poor tone quality. Do not touch the disc surface. Use a clean disc whenever possible. If there are deposits, wipe the
disc surface from the center outward with a dry, soft cloth. Be sure not to
use a hard cloth, thinner, benzene, alcohol, etc. Never use a badly damaged, deformed or cracked disc. Malfunctions
or problems might result. A disc is vulnerable to heat. Never keep it either in places exposed to
direct sunlight, near heaters or in vehicles parked in the sun or hot days.
OM-4747

6
Interior equipment Sun visors6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirror (if equipped) 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage compartment 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove compartment 6-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead console 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dashboard storage compartment (if equipped) 6-4 . . . . . . . . . . . . . . . . . . . .
Door storage compartment 6-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin tray 6-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 6-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessory power socket 6-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter ( if equipped) 6-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtray 6-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coat hook 6-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light 6-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spotlight 6-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo area light 6-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover (if equipped) 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shopping bag hook 6-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets 6-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Under floor storage tray 6-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-2
Sun visors
HS0089
HS0088
To b loc k out g lare, swing d own the visors. To use t he sun visor at a sid e
wind ow, swing it d own and move it sid eways. Vanity mirror (if equipped)
To use the vanity mirror, swing d own the visor and op en the c over.
Storage compartment
CAUTION
Always keep the storage compartment closed while driving to
reduce the risk of injury in the event of sudden stops or an acci- dent. Do not store spray cans, containers with flammable or corro-
sive liquids or any other dangerous items in the storage compart-ment.

Interior equipment6-3
–
CONTINUED –

Glove compartment
HS0090
Unlock
Lock
To op en the g love c omp artment, p ull the hand le. To c lose it, p ush the lid
firmly up ward .
To loc k the g love c omp artment, insert the master ke y and turn it c loc k-
wise. To unloc k it, insert the masterkey and turn i t c ounterc loc kwise.
Center console
HS0091
To op en the lid , p ull up the loc k release.

6-4

Overhead console
CAUTION
When your vehicle is in the sun or a warm day, the inside of the
overhead console heats up. Avoid storing plastic or other heat-
vulnerable or flammable articles such as a lighter in the overheadconsole.
HS0092
Push
To op en the c onsole, p ush the b utton and the c onsol
e lid will automati-
c ally op en. Dashboard storage compartment (if equipped)
HS0094
Push
To op en the d ashb oard c omp artment, p ush the b utton and p ull up on the

Interior equipment6-5
–
CONTINUED –
lid . Be sure to c lose the c omp artment fully b efore
d riving .
Door storage compartment
HS0095
Push
Eac h d oor is eq uip p ed with a d oor storag e c omp artme nt.
To op en the c omp artment, p ush the b utton and p ull u p on the lid .
Coin tray
HS0096
To op en the c oin tray, p ull the up p er ed g e of the l id .

6-6
Cup holder
CAUTION
When not in use, always keep the holder stored while driving
to reduce the risk of injury in the event of a sudden stop or an accident. Do not pick up a cup from the cup holder or put a cup in the
holder while you are driving, as this may distract you and lead toan accident. Take care to avoid spills. Beverages, if hot, might burn you or
your passengers. Spilled beverages may also damage upholstery,carpets or audio equipment.
In instrument panel
HS6018BA
To use the c up hold er, p ull it out c omp letely.

Interior equipment6-7
–
CONTINUED –

Front passenger ’s cup holder
HS0100
HS0099
A front p asseng er ’s c up hold er is also b uilt in the lid of the c enter c on-
sole. To use the c up hold er, op en the lid b y slid in g it forward and un-
fold the arm. Ad just the op ening area b y slid ing th e lid forward or
rearward to fit the c up . When not in use, fold the arm and c lose the
lid . NOTE On models equipped with a center console arm rest extension, the front passenger ’s cup holder must be eliminated to provide
this feature. Rear passenger ’s cup holder
HS0102
HS0101
The rear p asseng er ’s c up hold er is loc ated at the b ac k of the c enter
