SUBARU FORESTER 2005 SG / 2.G Owners Manual

7-24
Starting and operating
y
When driving on badly surfaced roads, gravel
roads, icy roads, or over deep newly fallen
snow, stopping distances may be longer for a
vehicle with the ABS system than one without.
When driving under these conditions, there-
fore, reduce your speed and leave ample dis-
tance from other vehicles. y When you feel the ABS system operating,
you should maintain constant brake pedal pres-
sure. Do not pump the brake pedal since doing
so may defeat the operation of the ABS system.
„ ABS system self-check
You may feel a slight shock in the brake pedal and
hear the operating sound of ABS from the engine com-
partment just after the vehicle is started. This is
caused by an automatic functional test of the ABS sys-
tem being carried out and does not indicate any abnor-
mal condition. „
ABS warning light
The ABS warning light comes on when the ignition
switch is turned to the “ON” position and goes out after
about two seconds.
This is an indication that the ABS system is working
properly.
When driving with an insufficient battery voltage such
as when the engine is jump started, the ABS warning
light may come on. This is due to the low battery volt-
age and does not indicate a malfunction. When the
battery becomes fully charged, the light will go out.
US1115CA

7-25
Starting and operating
– CONTINUED –
If the warning light behaves as follows, the ABS
system may not be working properly.
When the warning light is on, the ABS function
shuts down; however, the conventional brake
system continues to operate normally. yThe warning light does not come on when the
ignition switch is turned to the “ON” position. y The warning light comes on when the ignition
switch is turned to the “ON” position, but it
does not go out even when the vehicle speed
exceeds approximately 8 mph (12 km/h). y The warning light comes on during driving.
If these occur, have the ABS system repaired at
the first available opportunity by your SUBARU
dealer.
NOTE
If the warning light behavior is as described be-
low, the ABS system may be considered normal. y The warning light comes on right after the en-
gine is started but goes out immediately, remain-
ing off. y The warning light remains on after the engine
has been started, but it goes out when the vehicle speed reaches about 8 mph (12 km/h).y
The warning light comes on during driving, but
it goes out immediately and remains off.

7-26
Starting and operating
Electronic Brake Force Distribution
(EBD) system (if equipped)
The EBD system maximizes the effectiveness of the
brakes by allowing the rear brakes to supply a greater
proportion of the braking force. It functions by adjust-
ing the distribution of braking force to the rear wheels
in accordance with the vehicle’s loading condition and
speed.
The EBD system is an integral part of the ABS system
and uses some of the ABS system’s components to
perform its function of optimizing the distribution of
braking force. If any of the ABS components used by
the EBD function fails, the EBD system also stops
working.
When the EBD system is operating, you may hear a
chattering noise or feel a slight vibration in the brake
pedal. This is normal and does not indicate a malfunc- tion.
„
Steps to take if EBD system fails
If a malfunction occurs in the EBD system, the system
stops working and the brake system warning light and
ABS warning light come on simultaneously.
The EBD system may be faulty if the brake system
warning light and ABS warning light illuminate simulta-
neously during driving.
Even if the EBD system fails, the conventional braking
system will still function. However, the rear wheels will
be more prone to locking when the brakes are applied
harder than usual and the vehicle’s motion may there-
fore become somewhat harder to control.
If the brake system warning light and ABS warning
US1115DA

7-27
Starting and operating
– CONTINUED –
light illuminate simultaneously, take the following
steps:
1. Stop the vehicle in the nearest safe, flat place.
2. Shut down the engine, then restart it.
3. Release the parking brake. If both warning lights go
out, the EBD system may be faulty.
Drive carefully to the nearest SUBARU dealer and
have the system inspected.
4. If both warning lights come on again and stay illu-
minated after the engine has been restarted, shut
down the engine again, apply the parking brake, and
check the brake fluid level.
5. If the brake fluid level is not below the “MIN” mark,
the EBD system may be faulty. Drive carefully to the
nearest SUBARU dealer and have the system inspect-
ed.
6. If the brake fluid level is below the “MIN” mark, DO
NOT drive the vehicle. Instead, have the vehicle towed
to the nearest SUBARU dealer for repair.
yDriving with the brake system warning light
on is dangerous. This indicates your brake sys-
tem may not be working properly. If the light re-
mains on, have the brakes inspected by a
SUBARU dealer immediately. y If at all in doubt about whether the brakes are operating properly, do not drive the vehicle.
Have your vehicle towed to the nearest
SUBARU dealer for repair.

7-28
Starting and operating
Vehicle Dynamics Control system (if
equipped)
Always use the utmost care in driving – over-
confidence because you are driving with a Ve-
hicle Dynamics Control system equipped vehi-
cle could easily lead to a serious accident.
y
Even if your vehicle is equipped with Vehicle
Dynamics Control, winter tires or snow chains
should be used when driving on snow-covered
or icy roads; in addition, vehicle speed should
be reduced considerably. Simply having a Vehi-
cle Dynamics Control system does not guaran-
tee that the vehicle will be able to avoid acci-
dents in any situation.y Activation of the Vehicle Dynamics Control
system is an indication that the road being trav-
elled on has a slippery surface; since having
Vehicle Dynamics Control is no guarantee that
full vehicle control will be maintained at all
times and under all conditions, its activation should be seen as a sign that the speed of the
vehicle should be reduced considerably.y
Whenever suspension components, steering
components, or an axle are removed from a ve-
hicle equipped with Vehicle Dynamics Control,
have an authorized SUBARU dealer perform an
inspection of that system. y The following precautions should be ob-
served in order to ensure that the Vehicle Dy-
namics Control system is operating properly: – All four wheels should be fitted with tires of
the same size, type, and brand. Furthermore,
the amount of wear should be the same for all four tires.
– Keep the tire pressure at the proper level as
shown on the placard attached to the vehi-
cle’s door pillar.
– Use only the special temporary spare tire to
replace a flat tire. With a temporary spare tire,
the effectiveness of the Vehicle Dynamics
Control system is reduced and this should be
taken into account when driving the vehicle
in such a condition.
In the event of wheelspin and/or skidding on a slippery
road surface and/or during cornering and/or an eva-
sive maneuver, the Vehicle Dynamics Control system

7-29
Starting and operating
– CONTINUED –
adjusts the engine’s output and the wheels’ respective
braking forces to help maintain traction and directional
control. yTraction Control Function
The traction control function is designed to prevent
spinning of the driving wheels on slippery road surfac-
es, thereby helping to maintain traction and directional
control. Activation of this function is shown by steady
illumination of the Vehicle Dynamics Control operation
indicator light. y Skid Suppression Function
The skid suppression function is designed to help
maintain directional stability by suppressing the
wheels’ tendency to slide sideways during steering op-
erations. Activation of this function is shown by flash-
ing of the Vehicle Dynamics Control operation indica-
tor light.
NOTE y Slight twitching of the brake pedal may be felt
when the Vehicle Dynamics Control system oper-
ates; a small degree of vehicle or steering wheel
shaking may also be noticed in this situation.
These are normal characteristics of Vehicle Dy-
namics Control operation and are no cause for
alarm. y
When driving off immediately after starting the
engine, a short-lived operation noise may be no-
ticed coming from the engine compartment. This
noise is generated as a result of a check being per-
formed on the Vehicle Dynamics Control system
and is normal. y Depending on the timing of activation of the
brakes, certain situations may occur just after
driving off where the brake pedal seems to exhibit
a jolting motion. This too is a consequence of the
Vehicle Dynamics Control operational check and
is normal. y In the circumstances listed below, the vehicle
may be more unstable than it feels to the driver.
The Vehicle Dynamics Control System may there-
fore operate. Such operation does not indicate a system fault. yon gravel-covered or rutted roads
y on unfinished roads
y when the vehicle is towing a trailer
y when the vehicle is fitted with snow tires or
winter tires
y Activation of the Vehicle Dynamics Control sys-
tem will cause operation of the steering wheel to feel slightly different compared to that for normal
conditions.y Even if the vehicle is equipped with a Vehicle

7-30
Starting and operating
Dynamics Control system, it is important that win-
ter tires be used when driving on snow-covered oricy roads. (All four wheels should be fitted with
tires of the same size and brand). Furthermore, if
snow chains are to be used, they should be fitted
on the front wheels. When a vehicle is fitted with
snow chains, however, the effectiveness of the Ve-
hicle Dynamics Control system is reduced and
this should be taken into account when driving the
vehicle in such a condition. y
It is always important to reduce speed when ap-
proaching a corner, even if the vehicle is equipped
with Vehicle Dynamics Control. y All four wheels should be fitted with tires of the
same size, type, and brand; furthermore, the
amount of wear should be the same for all four
tires. If these precautions are not observed and
non-matching tires are used, it is quite possible
that the Vehicle Dynamics Control system will be
unable to operate correctly as intended.y Always turn off the engine before replacing a
tire as failure to do so may render the Vehicle Dy-
namics Control system unable to operate correct-ly. „
Vehicle Dynamics Control system monitor
T Vehicle Dynamics Control operation indicator
light
The indicator light turns on when the ignition key is
turned to the ON position; it turns off approximately
two seconds later. This indicator light flashes during
activation of the skid suppression function and is illu-
minated steadily during activation of the traction con-
trol function.
The following two situations could indicate a malfunc-
tion of the Vehicle Dynamics Control system; if either
US1115EA

7-31
Starting and operating
– CONTINUED –
should occur, have an authorized SUBARU dealer
carry out an inspection of that system at the first avail-
able opportunity. yThe indicator light does not turn on when the ignition
key is turned to the ON position. y The indicator light does not turn off approximately
two seconds after the ignition key has been turned to
the ON position. T Vehicle Dynamics Control warning light/Vehi-
cle Dynamics Control OFF indicator light
This single light has the function of indicating malfunc-
tions in the Vehicle Dynamics Control system and the
function of indicating that the Vehicle Dynamics Con- trol system is not operating. It comes on in the event
of a malfunction in the system and is illuminated when-
ever the system is not operating. V
Vehicle Dynamics Control warning
The warning light comes on when the ignition switch is
turned to the “ON” position and goes off several sec-
onds after engine startup.This lighting pattern indi-
cates that the Vehicle Dynamics Control system is op-
erating normally.
The following situations could indicate a malfunction of
the Vehicle Dynamics Control system; if any should
occur, have an authorized SUBARU dealer carry out
an inspection of the system at the first available oppor-
tunity. y The warning light does not turn on when the ignition
key is turned to the ON position. y The warning light turns on while the vehicle is being
driven. y When a malfunction has occurred in the Vehicle Dy-
namics Control electrical system, only the warning
light will turn on. In such an event, the ABS will still be
operating normally. y The warning light will also turn on when a problem
occurs with the ABS or Vehicle Dynamics Control
electronic control systems.
Because the Vehicle Dynamics Control system con-
US1115FA

7-32
Starting and operating
trols each brake through the ABS, whenever the ABS
stops operating due to a malfunction in that electrical
system, the Vehicle Dynamics Control will also be-
come unable to control all four brakes. Thus Vehicle
Dynamics Control system operation halts and the
warning light turns on. Although both the Vehicle Dy-
namics Control system and the ABS will be inoperable
in this situation, it will still be possible to stop the vehi-
cle using normal braking. The Vehicle Dynamics Con-
trol system and the ABS do not adversely affect oper-
ation of the vehicle in any way when they are inopera-
ble; however should such a situation occur, drive with
care and have an authorized SUBARU dealer carry
out an inspection of those systems at the first available
opportunity.
NOTE
When the warning light turns on and off in the fol-
lowing way, it indicates that the Vehicle Dynamics
Control system is operating normally. y
Although turning on after the engine has been
started, the warning light quickly turns off and
stays off. y The warning light turns on when the vehicle is
being driven; it then turns off and stays off. V Vehicle Dynamics Control OFF indicator light
This light comes on to indicate that the Vehicle Dy- namics Control system is in non-operation mode. This
does not constitute failure of the Vehicle DynamicsControl system.
NOTE y
The indicator light may stay on for a while after
the engine has been started, especially in cold
weather. This occurs because the engine has not
yet warmed up and is completely normal. The light
will turn off when the engine has reached a suit-
able operating temperature. y When an engine problem occurs and the mal-
function indicator lamp turns on, the indicator
light will also come on.
The following two situations could indicate malfunction
of the Vehicle Dynamics Control system; if either
should occur, have an authorized SUBARU dealer
carry out an inspection of that system at the first avail-
able opportunity. y The indicator light does not turn on when the ignition
key is turned to the ON position. y The indicator light fails to turn off after the engine is
started, even when several minutes have passed to al-
low the engine to heat up sufficiently.

7-33
Starting and operating
– CONTINUED –
„Vehicle Dynamics Control OFF switch
Pressing the switch to deactivate the Vehicle Dynam-
ics Control system can facilitate the following opera- tions: y a standing start on a steeply sloping road with a
snowy, gravel-covered, or otherwise slippery surface y extrication of the vehicle when its wheels are stuck
in mud or deep snow
When the switch is pressed during engine operation,
the indicator light illuminates. The Vehicle Dynamics
Control system will be deactivated and the vehicle will
behave like a model not equipped with the Vehicle Dy-
namics Control system. When the switch is pressed
again to reactivate the Vehicle Dynamics Control sys- tem, the indicator light goes off.
With the Vehicle Dynamics Control system deactivat-
ed, traction and stability enhancement offered by Ve- hicle Dynamics Control system is unavailable. There-
fore you should not deactivate the Vehicle Dynamics
Control system except under above-mentioned situa-
tions.
NOTE y
When the switch has been pressed to deactivate
the Vehicle Dynamics Control system, the Vehicle
Dynamics Control system automatically reacti-
vates itself the next time the ignition key is turned
to the OFF position and the engine is restarted. y If the switch is held down for 10 seconds or
longer, the indicator light goes off, the Vehicle Dy-
namics Control system is activated, and the sys-
tem ignores any further pressing of the switch. To
make the switch usable again, turn the ignition key
to the OFF position and restart the engine. y When the switch is pressed to deactivate the Ve-
hicle Dynamics Control system, the vehicle’s run-
ning performance is comparable with that of a ve-
hicle that does not have a Vehicle Dynamics Con-
trol system. Do not deactivate the Vehicle Dynam-
ics Control system except when absolutely neces-
sary.
US7023AA
