SUBARU FORESTER 2016 SJ / 4.G Driving Assist Manual

EyeSight malfunction and temporary stop
77
■Temporary stop
The buzzer will sound one short beep, and the
Pre-Collision Braking System OFF indicator
light and Lane Departure Warning OFF
indicator light will illuminate at the same time.
A symbol of “E1”, “E2” or “E3” is displayed on
the meter display, and a pop-up screen is
displayed on the multi function display. (When
the main cruise control is off, they are not
displayed.)
When the cause has been eliminated,
temporary stop will be canceled and the
EyeSight system will automatically restart.
Display Cause Action

It is difficult for the stereo
cameras to detect objects in
front
xThe front windshield is
dirty or fogged up
xPoor weather conditions
xStrong light from the front
xExtremely hot or cold
temperaturesxClean the front windshield.
xIn bad weather or if there is
strong light from the front,
the EyeSight system will
restart once you have
driven your vehicle for a
period of time and the
conditions affecting the
system have improved.
Also, as the “E1” screen
will be displayed after the
“E2” screen, once
operation of the cameras is
stable, the system will
restart. In either case, it
may take some time for the
system to restart.
If the system does not
restart, even after the
conditions have improved
and a period of time has
elapsed, contact your
SUBARU dealer for an
inspection.
S00882
S00861
S00862
EyeSight Disabled
No Camera View

EyeSight malfunction and temporary stop
78
Displayed screen Cause Action

In low or high temperatures The system will restart once
the temperature is within the
operational range of the
EyeSight system.
If the system does not
restart, even when the
temperature inside the
vehicle is normal, contact
your SUBARU dealer for an
inspection.

xWhen the EyeSight
system is starting
xWhen the system has
determined that the
vehicle is extremely
inclined
xWhen the pre-collision
secondary braking has
operated 3 times after the
engine was started
xWhen the engine stops
(except for the stop due to
the start stop function).The system will restart once
the cause has been
eliminated. At this time, it
may take some time for the
system to restart.
If the system does not
restart, even after the
conditions have improved
and a period of time has
elapsed, contact your
SUBARU dealer for an
inspection.
NOTE
When a symbol from “E1” to “E3” (EyeSight temporary stop indicators) is
displayed, no EyeSight functions can be used except for Conventional Cruise
Control.
S00863
S00864
EyeSight Disabled
Temp Range
S00865
S00866
EyeSight Disabled
Check Manual

Customizing functions
79
Customizing functions
■How to customize
The customizing function can be operated when the engine is running, the main cruise
control is off (the or indicator is not displayed on the meter) and the select lever
is in the position.
(1) To turn the customization mode on, press the (following distance setting) switch for
approximately 2 seconds or more.
(2) When the (following distance setting) switch is pressed, the item of customization
and the current setting are displayed on the meter display. Every time the switch is
pressed, the item of customization will be changed.
(3) While pressing the RES/+ or SET/- switch,
the setting is changed. (When the setting
is changed, a beep sounds.)
(4) The setting can be determined when the
RES/+ or SET/- switch is released.
(5) To exit from the customizing mode, perform one of the following operations.
xPlace the ignition switch to the ACC or LOCK (OFF) position.
xTurn the main cruise control on.
xShift the select lever to any other position except for the position.Display Item Setting Default setting
Warning volume Max/Mid/Min Mid
Lead vehicle acquisition alert Activate/Deactivate Activate
Lead Vehicle Start Alert Activate/Deactivate Activate
P
S00829S00867
S00867
Max Mid MinEX.: Warning volume setting
P

Customizing functions
80
●Warning volume setting
The warning volume can be set to
Max/Mid/Min.
When the RES/+ or SET/- switch is pressed,
the setting will change to the next and 3 short
beeps will sound in the volume corresponding
to the setting.
●Lead vehicle acquisition alert setting
The lead vehicle acquisition alert function
setting can be activated or deactivated.
When the RES/+ or SET/- switch is pressed,
the setting will change to the next. When the
setting is changed to be activated, a short
beep will sound. When the setting is changed
to be deactivated, no beeps will sound.
●Lead Vehicle Start Alert setting
The Lead Vehicle Start Alert function setting
can be activated or deactivated.
When the RES/+ or SET/- switch is pressed,
the setting will change to the next. When the
setting is changed to be activated, a two-tone
beep will sound. When the setting is changed
to be deactivated, this function is turned off
and no beeps will sound.
NOTE
Even when the engine is restarted after the ignition switch is placed in the
LOCK (OFF) position, the setting will be restored to the previous status
before the ignition switch is placed in the LOCK (OFF) position.
S00869
Setting
Max
Mid
MinDisplay
S00870
Setting
Activate
Deactivate
Display
S00871
Setting
Activate
Deactivate
Display

List of the pop-up screens on the multi function display
81
List of the pop-up screens on the multi function display
If an EyeSight warning or malfunction is detected, a pop-up screen will be displayed on the
multi function display. Depending on the message, a buzzer will sound at the same time.
If a pop-up screen is displayed, refer to the
pop-up screen list and take the appropriate
action. Display screen 1 and display screen 2
will appear in order. While the mark is
illuminated, pull the (information)/SET
switch to indicate the pop-up screen again.
■Screen list (warning indicator, etc.)
Item Displayed screen mark Action (Reference page)
The “brake more”
warning
For Canada: MFD
For USA: on the meter
display
None
Refer to page 42.
Pre-Collision Braking
System
Refer to page 43.
Pre-Collision Throttle
Management
Refer to page 52.
Lane Departure
Warning
For Canada: MFD
For USA: on the meter
display
None Refer to page 58.
Normal screen Normal screenPop-up screenMark
S00912
EyeSight
Check Manual
8:32FF
MPGMPG
miles
F
MPGMPG
miles
S00873
S00874
Obstacle Detected
S00875
Lane Departure

List of the pop-up screens on the multi function display
82
Item Displayed screen mark Action (Reference page)
Lane Sway Warning
For Canada: MFD
For USA: on the meter
display
None Refer to page 61.
Lead Vehicle Start Alert None
Refer to page 64.
Conventional Cruise
ControlNone
Refer to page 68.
Automatic cancellation
by the systemNone
Refer to page 38.
None
Refer to page 38.
None
Refer to page 38.
S00876
Stay Alert
S00877
Vehicle Ahead Has Moved
S00878
Cruise Control
S00879
OFF
S00880
No Lead VehicleOFF
S00881
Steep GradeOFF

List of the pop-up screens on the multi function display
83
■Screen list (Malfunction, temporary stop, etc.)
*Depending on the location of malfunction, will blink or illuminate.Item Displayed screen mark Action (Reference page)
EyeSight System
Malfunction*Yes
(yellow)
Refer to page 76.
EyeSight system
temporary stopNone
Refer to page 77.
None
Refer to page 78.
None
Refer to page 78.
S00859
EyeSight off
Check Manual
S00862
EyeSight Disabled
No Camera View
S00864
EyeSight Disabled
Temp Range
S00866
EyeSight Disabled
Check Manual

84
Troubleshooting
Cruise control cannot be set.
Did you remember to press the (CRUISE) switch?
If you have not pressed the (CRUISE) switch, the (Adaptive Cruise
Control) indicator will not be shown.
Is EyeSight operation temporarily stopped?
When EyeSight is temporarily stopped, one of the EyeSight temporary stop indi-
cators (“E1”, “E2” or “E3”) will be displayed on the data display.
Set cruise control again after the reason for the temporary stop has been cor-
rected.
Is the [READY] indicator displayed?
When Adaptive Cruise Control is being used Cruise control cannot be set when
the [READY] indicator is not displayed. Set cruise control when the [READY] indi-
cator is displayed.
The [READY] indicator is not displayed.
Have you selected Conventional Cruise Control?
With Conventional Cruise Control, (following distance setting) will not be dis-
played on the meter display.
Are the requirements for setting cruise control met?
In any of the following cases, the [READY] indicator will not be displayed.
xThe brake pedal is depressed.
xThe vehicle speed is over 90 MPH (145 km/h). (When no vehicle in front
has been detected, the speed is between approximately 25 MPH (40 km/h)
and 90 MPH (145 km/h).)
xThe meter display indicates that the shift position indicator is in any posi-
tion other than . (The select lever or paddle shift switches are manually
operated.)
xThe driver’s seatbelt is unfastened.
xAny door of the driver’s, front passenger’s and rear doors is opened.
xThe parking brake is applied (when the brake warning light is illuminated).
xThe vehicle is on a steep grade.
xThe steering wheel is turned significantly in either direction.
xVehicle Dynamics Control is off, or is turned off.
xThe X-mode is turned on. (The X-mode indicator illuminates.)
D

Troubleshooting
85
A vehicle (in front of your vehicle) is not detected, is detected later or detection is
lost quickly.
Is the vehicle in front stopped, moving slowly relative to your vehicle or moving
extremely slowly?
Detection of stopped vehicles, vehicle moving slowly relative to your vehicle, and
vehicles moving extremely slowly may be difficult.
Is the windshield dirty or fogged?
If the windshield is dirty or fogged, it may not be possible to detect object or vehi-
cles. Clean off the dirt or fog from the windshield, and then try using the system
again.
Is the vehicle in front far away?
The maximum detection distance of EyeSight’s stereo cameras is approximately
265 ft (80 m). Detection is not possible if the vehicle is farther away.
Is the vehicle on a curve?
The detection range is limited in the left and right directions to approximately a 25-
degree arc from the vehicle centerline when the cameras are properly aimed.
Is the vehicle on a road with repeated uphill and downhill grades (such as an over-
pass), or on a banked road?
The detection range is limited in the up and down directions.
Did the vehicle detected in front change?
Detection may be delayed after the vehicle in front has changed.
Have water, snow or other substances been kicked up by the vehicle in front as it
drives?
When water or snow have been kicked up, it may not be possible to detect the
vehicle in front.
Control is activated even though no vehicle in front is detected?
Is there a vehicle in the neighboring lane?
Depending on the road conditions, vehicles in neighboring lanes may be detected
as well as a vehicle directly in front.
Are you driving on or near a curve?
When driving on a curve, braking control may be activated in response to guard
rails, the angle of the steering wheel, or roadside structures.
The Lead Vehicle Start Alert activates, even though there is no vehicle in front.
Depending on surrounding objects, traffic environment and weather, the Lead
Vehicle Start Alert may issue a warning in response to objects other than a vehicle
that appear in front of your vehicle.

Troubleshooting
86
EyeSight does not restart after a temporary stop.
Is Vehicle Dynamics Control turned off?
EyeSight cannot be activated when Vehicle Dynamics Control is off.
Is the X-mode turned on?
EyeSight cannot be activated when the X-mode is turned on.
Are you driving in the rain with old wipers or is there an oily film on the windshield?
Replace the wipers with new ones, or clean the oily film off the windshield.
Is your vehicle subject to sunlight from the front (sunset or sunrise, etc.) or to
bright headlights from oncoming vehicles at nighttime?
In these cases, EyeSight may temporarily stop operating.
The timing of the “brake more” warning is sometimes earlier and sometimes later
than what seems to be normal operation.
The “brake more” warning sounds when the system determines that more braking
is necessary, based on conditions such as the distance from the vehicle in front
and the difference in speed. As a result, timing may vary depending on how the
brake of the vehicle in front is applied.
Acceleration is sometimes slower and sometimes faster when the vehicle in front
is no longer detected.
Depending on the timing of when the detection of the vehicle in front is lost,
EyeSight’s ability to react may be slower, causing the start of acceleration to feel
delayed and braking time to feel longer than what seems to be normal operation.
Which SI-DRIVE mode is selected?
The acceleration varies due to the characteristics change of Adaptive Cruise Con-
trol depending on which mode is selected.
Cruise control is canceled automatically.
Did you perform one of the following operations?
xManually depressing the brake pedal
xPressing the CANCEL switch for cruise control
xOperating the paddle shift lever
xShifting the selector lever to the position
xPressing the Vehicle Dynamics Control OFF switch (VDC OFF indicator
illuminates.)
xPressing the X-mode switch (X mode indicator illuminates.)
Has the EyeSight system temporarily stopped?
M
